Technical Bulletin PAGE: 1/5
Reissued: 09-Jan-14
Model: Aries-P1.5
Date: 04-Oct-10
No.: RM077001h
RTB Reissue
The items in bold italics have been added.
Subject: Firmware Release Note: Engine
Prepared by: T. Miyamoto
From: 1st PP Tech Service Sect., PP Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware)
Tier 2
This RTB has been issued to announce the firmware release information for the Engine.
Version
Program No.
Effective Date
Availability of RFU
1.009:16
M0775253B
January 2014 production
Not available
1.008:16
M0775253A
January 2013 production
Not available
1.007:16
M0775253
June 2012 production
Not available
1.006:16
M0775252E
July 2011 production
Not available
1.005:16
M0775252D
May 2011 production
Not available
1.004:16
M0775252C
April 2011 production
Not available
1.003:16
M0775252B
February 2011 production
Not available
1.000A:16
M0775252A
1st Mass production
Not available
Note: Definition of Availability of RFU via @Remote
“Available” The firmware can be updated via RFU or SD card.
“Not available”: The firmware can only be updated via SD card.
Version
Modified Points or Symptom Corrected
1.009 :16
Specification changes:
1. To meet the Energy Star Ver2.0 standards, ITB alignment control
values are no longer stored on the NVRAM during monochrome
printing.
2. Higher reliability against SC39x (drum-lock); machine warm-up
following a forced termination is performed after activating the
development motor.
3. Higher reliability against Jam 170 when alternately running A3/DLT
and A4/LT staple jobs.
NOTE
When applying this firmware, make sure to upgrade the firmware for
SR5020 to Ver.3.19 (P/N:D4345620N) or newer.

Technical Bulletin PAGE: 2/5
Reissued: 09-Jan-14
Model: Aries-P1.5
Date: 04-Oct-10
No.: RM077001h
Version
Modified Points or Symptom Corrected
1.008 :16
Modified Points
Support for both ProC901 and ProC901 PLUS
Following Firmware need to be updated together.
Part number
Version
Web Support
M0776083A
1.04
Engine
M0775253A
1.008:16
System
M0776081A
2.00
1.007:16
Modified Points
1. Improvement for shockjitter
2. Improvement for removing JAM037
3. Countermeasure against SC621
4. Countermeasure against SC453
5. Improvement for mis-display of SR5020 JAM
6. Countermeasure against displaying "Now printing" while adjusting the
fusing temperature
7. Countermeasure against jam in SR5020 soon after recovering from pause
during stapling, and irregular paper stock.
When the flywheel is added to the machine for a countermeasure against the
shockjitter, following SP need to be changed together.
SP2-992-001: 0.0 -> 0.5
SP2-993-001: 0 -> 1
Following Firmware need to be updated together
Part number
Version
Web Support
M0776083
1.03.1
Engine
M0775253
1.007:16
System/Copy
M0776081
1.07
1.006:16
Modified Points
- JAM for following situation has been fixed
decurler setting is changed for every sheet, and paper is feed from
different tray every sheet.
Eg. 1st sheet from tray 1 go through upper pass of decurler
2nd sheet from tray 3 go through lower pass of decurler
3rd sheet from tray 1 go through upper pass of deculer again <-- JAM
- Order of signal from SR5020 has been modified to prevent the lost of
SR5020 setting
- PM counter for thermistor can be cleared
Following firmware need to be upgraded together
Part number
version
Engine
M0775252E
1.006:16
System/Copy
M0776091E
1.04
Websys
M0776093C
1.02

Technical Bulletin PAGE: 3/5
Reissued: 09-Jan-14
Model: Aries-P1.5
Date: 04-Oct-10
No.: RM077001h
Version
Modified Points or Symptom Corrected
Ope Panel CHN
M0776387
1.05
Ope Panel NA
M0776385C
1.05
Ope Panel EU
M0776386C
1.05
Language
M0776390B
1.04
Network Support
M0776692C
7.12
1.005:16
Modified Points
- Early web cleaning indication has been fixed
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
- Countermeasure for 2 output checks, waste toner could clog and disable
the function of the toner collection coil, which could result in breakage of
the gear rotating the waste toner transport coil, and toner leakage.
- Following adjustable range has been changed in Web Image Monitor
Erase Margin Adj Leading Edge
Erase Margin Adj Trailing Edge
Minimum setting 0.0 --> -6.0
Following firmware need to be upgraded together
Part number
Version
Engine
M0775252D
1.005:16
System/Copy
M0776091D
1.03
Websys
M0776093B
1.01
Ope Panel NA
M0776385B
1.04
Ope Panel EU
M0776386B
1.04
Language
M0776390A
1.03
1.004:16
Modified Points
Bugs in menu items in Custom Paper Setting Advanced Setting are fixed.
Item Menu No. 03 "Pickup Assist Setting"
Item Menu No. 15 "Paper Transfer Feed Speed Adjustment"
Bug which has been fixed
Even the No. 03 "Pickup Assist Setting"was set as OFF, inside the machie,
"Pickup Assist Setting" was set to auto setting; therefore, depending on Paper
weight and Paper Size, "Pickup Assist Setting"
was activated.
Even the No 15 "Paper Transfer Feed Spped Adjustment" was set as
0.0, PTR was not moving at the correct speed
Apply Condition for Creo Controller
Please use Creo Controller Ver 1.003:16 or older.

Technical Bulletin PAGE: 4/5
Reissued: 09-Jan-14
Model: Aries-P1.5
Date: 04-Oct-10
No.: RM077001h
Version
Modified Points or Symptom Corrected
1.003:16
Modified Points
＜Specification Changes＞
1. Creo controller is supported.
2. New function has been added to avoid decrease in productivity which
occurs when frequently activating/deactivating the units involving image
creation.
SP2-908-001 Deactivating image creation｜Extend deactivation time ON/OFF
SP2-908-002 Deactivating image creation｜Time extended
This function is not available on System Firmware 1.01 or older.
It will become available when the System Firmware is upgraded.
(Firmware Version: TBA)
3. Saddle-stitching is available with custom paper sizes on the Plockmatic.
(Available when connected to the Creo controller)
4. Potential control has been modified to avoid the problem of ID exceeding
the upper limit when powering on the machine.
＜Fixes＞
1. Problem of decrease in print speed when saddle-stitching SRA3 on the
Booklet Finisher (SR5020) has been fixed.
2. Problem of the printer halting and disabled to resume from an error when
saddle-stitching in duplex on the Plockmatic has been fixed.
3. Problem of the printer disabled to warm-up and recover from a jam or
open-door status has been fixed.
4. Problem of indicating incorrect jam locations in the downstream peripherals
when the configuration consists of both Booklet Trimmer (TR5020) and
Stacker (SK5010) has been fixed.
Apply condition:
Firmwares below to be applied together as a set.
Program Name
Program No.
Version
System
M0776091B
1.01
Network Support (NCS)
M0776092B
7.11
Engine
M0775252B
1.003:16
* Update to the following versions is required for all peripherals listed below.
Program No.
Version
SR5000
B8305102S
V02.030:62
SR5020
D4345620K
V03.160:08
TR5020
D4555510D
V15.280:16
Note
- Make sure to update the peripherals in order of proximity to the main
frame.
- Do not update consecutively by selecting several peripherals
1.000A:16
1st Mass production

Technical Bulletin PAGE: 1/2
Reissued: 12-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077002b
RTB Reissue
The items in bold italics have been corrected.
Subject: Firmware Release Note: Language Install Prepared by: H. Kawamura
From: PPBG Service Planning Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware) Tier 2
This RTB has been issued to announce the firmware release information for the
Language Install.
Version Program No. Effective Date
1.04 M0776390B July 2011 Production
1.03 M0776390A May 2011 production
1.01 M0776390 1st Mass production
Version Modified Points or Symptom Corrected
1.04 Modified Points
- In the Paper Library, Advanced setting for paper created from "*Not
Programmed" can be adjusted.
- When replacing GW-Controller, data saved to paper library can be
restored.
- On the operation panel, Paper Library screen, some words have
been changed.
・ Recall Paper Library
→ Paper Library
・ Program/Change/Delete Custom Paper
→ Custom Paper
Following firmware need to be upgraded together
Part number version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12

Technical Bulletin PAGE: 2/2
Reissued: 12-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077002b
Version Modified Points or Symptom Corrected
1.03 Modified point
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
Following firmware need to be upgraded together
Part number Version
Engine M0775252D 1.005:16
System/Copy M0776091D 1.03
Websys M0776093B 1.01
Ope Panel NA M0776385B 1.04
Ope Panel EU M0776386B 1.04
Language M0776390A 1.03
1.01 1st Mass production

Technical Bulletin PAGE: 1/3
Reissued: 11-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077003b
RTB Reissue
The items in bold italics have been corrected.
Subject: Firmware Release Note: OpePanel.EXP Prepared by: H. Kawamura
From: PPBG Service Planning Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware) Tier 2
This RTB has been issued to announce the firmware release information for the
OpePanel.EXP.
For US Models
Version Program No. Effective Date
1.05 M0776385C July 2011 production
1.04 M0776385B May 2011 production
1.01 M0776385A 1st Mass production
For EU Models
Version Program No. Effective Date
1.05 M0776386C July 2011 Production
1.04 M0776386B May 2011 production
1.01 M0776386A 1st Mass production
For CHN Models
Version Program No. Effective Date
1.05 M0776387 1st Mass production

Technical Bulletin PAGE: 2/3
Reissued: 11-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077003b
For US Models
Version Modified Points or Symptom Corrected
1.05 Modified Points
- In the Paper Library, Advanced setting for paper created from "*Not
Programmed" can be adjusted.
- When replacing GW-Controller, data saved to paper library can be
restored.
- On the operation panel, Paper Library screen, some words have
been changed.
- Recall Paper Library -> Paper Library
- Program/Change/Delete Custom Paper -> Custom Paper
Following firmware need to be upgraded together
Part number Version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12
1.04 Modified point
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
Following firmware need to be upgraded together
Part number Version
Engine M0775252D 1.005:16
System/Copy M0776091D 1.03
Websys M0776093B 1.01
Ope Panel NA M0776385B 1.04
Ope Panel EU M0776386B 1.04
Language M0776390A 1.03
1.01 1st Mass production

Technical Bulletin PAGE: 3/3
Reissued: 11-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077003b
For EU Models
Version Modified Points or Symptom Corrected
1.05 Modified Points
- In the Paper Library, Advanced setting for paper created from "*Not
Programmed" can be adjusted.
- When replacing GW-Controller, data saved to paper library can be
restored.
- On the operation panel, Paper Library screen, some words have
been changed.
- Recall Paper Library -> Paper Library
- Program/Change/Delete Custom Paper -> Custom Paper
Following firmware need to be upgraded together
Part number Version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12
1.04 Modified point
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
Following firmware need to be upgraded together
Part number Version
Engine M0775252D 1.005:16
System/Copy M0776091D 1.03
Websys M0776093B 1.01
Ope Panel NA M0776385B 1.04
Ope Panel EU M0776386B 1.04
Language M0776390A 1.03
1.01 1st Mass production
For CHN Models
Version Modified Points or Symptom Corrected
1.05 1st Mass production

Technical Bulletin PAGE: 1/2
Reissued: 12-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077004b
RTB Reissue
The items in bold italics have been corrected.
Subject: Firmware Release Note: Network Support Prepared by: H.Kawamura
From: PPBG Service Planning Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware) Tier 2
This RTB has been issued to announce the firmware release information for the Network
Support.
Version Program No. Effective Date
7.12 M0776092C July 2011 production
7.11 M0776092B February 2011 production
7.10 M0776092A 1st Mass production
Version Modified Points or Symptom Corrected
7.12 Modified Points
- If SSDP = Active (Web ImageMonitor > Configuration > Network
Security), a high load on the CPU might result in Web ImageMonitor
locking up.
- LP with an external controller will lose network connectivity. This
only occurred if the network settings were changed repeatedly and
the LP's "NetWare" setting was already "Active" (before the network
settings were changed).
- The LP icon might not be shown in the Windows "Network" dialogue
if SSDP is enabled. This affected Windows Vista, 2008/R2, and 7.
- The device might lose network connectivity if SSDP is enabled.
Network connectivity could be temporarily restored after a power
cycle.
Following firmware need to be upgraded together
Part number version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12

Technical Bulletin PAGE: 2/2
Reissued: 12-Jul-11
Model: Aries-P1.5 Date: 04-Oct-10 No.: RM077004b
Version Modified Points or Symptom Corrected
7.11 Symptom corrected:
1. Scan to SMB fails if the file submitted to the DFS folder in the destination
and the file of the same name exist in the DFS folder.
2. If Windows Authentication is enabled, printing a large number of copies of
a job might take longer than might typically be expected
3. Chunk Transfer Encoding over an IPP port might results in print jobs
being reset.
7.10 1st Mass production

T echnical B ulletin PAGE: 1/2
Reissued: 22-Feb-13
Model: Aries-P1.5 Date: 04-Oct-10 No .: RM077005d
RTB Reissue
The items in bold italics have been corrected.
Subject: Firmware Release Note: Web Support Prepared by: T. Miyamoto
From: 1st PP Tech Service Sect., PP Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware) Tier 2
This RTB has been issued to announce the firmware release information for the Web
Support.
Version Program No. Effective Date Availability of RFU
1.04 M0776083A January 2013 production Not Available
1.03.1 M0776083 May 2012 production Not Available
1.02 M0776093C June 2011 production Not Available
1.01 M0776093B May 2011 production Not Available
1.00 M0776093A 1st Mass production Not Available
Note: Definition of Availability of RFU via @Remote
“Available”: The firmware can be updated via RFU or SD card.
”Not available”: The firmware can only be updated via SD card.
Version Modified Points or Symptom Corrected
1.04 Modified Points
Support for both ProC901 and ProC901 PLUS
Following Firmware need to be updated together.
Part number Version
Web Support M0776083A 1.04
Engine M0775253A 1.008:16
System M0776081A 2.00
1.03.1 Modified Points
1. Improvement for shockjitter
2. Improvement for removing JAM037
3. Countermeasure against SC621
4. Countermeasure against SC453
5. Improvement for mis-display of SR5020 JAM
6. Countermeasure against displaying "Now printing" while adjusting the
fusing temperature
7. Countermeasure against jam in SR5020 soon after recovering from pause
during stapling, and irregular paper stock.
When the flywheel is added to the machine for a countermeasure against the
shockjitter, following SP need to be changed together.

T echnical B ulletin PAGE: 2/2
Reissued: 22-Feb-13
Model: Aries-P1.5 Date: 04-Oct-10 No .: RM077005d
Version Modified Points or Symptom Corrected
SP2-992-001: 0.0 -> 0.5
SP2-993-001: 0 -> 1
Following Firmware need to be updated together
Part number Version
Web Support M0776083 1.03.1
Engine M0775253 1.007:16
System/Copy M0776081 1.07
1.02 Modified Point
In the Paper Library, Advanced setting for paper created from "*Not
Programmed" can be adjusted.
Following firmware need to be upgraded together
Part number Version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12
1.01 Modified Points
- Early web cleaning indication has been fixed
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
- Countermeasure for 2 output checks, waste toner could clog and disable
the function of the toner collection coil, which could result in breakage of
the gear rotating the waste toner transport coil, and toner leakage.
- Following adjustable range has been changed in Web Image Monitor
Erase Margin Adj Leading Edge
Erase Margin Adj Trailing Edge
Minimum setting 0.0 --> -6.0
Following firmware need to be upgraded together
Part number Version
Engine M0775252D 1.005:16
System/Copy M0776091D 1.03
Websys M0776093B 1.01
Ope Panel NA M0776385B 1.04
Ope Panel EU M0776386B 1.04
Language M0776390A 1.03
1.00 1st Mass production

T echnical B ulletin PAGE: 1/3
Reissued: 22-Feb-13
Model: Aries-P1.5 Date: 04-Oct-10 No .: RM077006g
RTB Reissue
The items in bold italics have been added.
Subject: Firmware Release Note: System Prepared by: T. Miyamoto
From: 1st PP Tech Service Sect., PP Tech Service Dept.
Classification:
Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other (Firmware) Tier 2
This RTB has been issued to announce the firmware release information for the System.
Version Program No. Effective Date Availability of RFU
2.00 M0776081A January 2013 production Not available
1.07 M0776081 May 2012 production Not available
1.06 M0776091G April 2012 Production Not available
1.05 M0776091F September 2011 Production Not available
1.04 M0776091E July 2011 Production Not available
1.03 M0776091D May 2011 Production Not available
1.02 M0776091C May 2011 Production Not available
1.01 M0776091B February 2011 production Not available
1.00 M0776091A 1st Mass production Not available
Note: Definition of Availability of RFU via @Remote
“Available” The firmware can be updated via RFU or SD card.
“Not available”: The firmware can only be updated via SD card.
Version Modified Points or Symptom Corrected
2.00 Modified Points
Support for both ProC901 and ProC901 PLUS
Following Firmware need to be updated together.
Part number Version
Web Support M0776083A 1.04
Engine M0775253A 1.008:16
System M0776081A 2.00
1.07 Modified Points
1. Improvement for shockjitter
2. Improvement for removing JAM037
3. Countermeasure against SC621
4. Countermeasure against SC453
5. Improvement for mis-display of SR5020 JAM
6. Countermeasure against displaying "Now printing" while adjusting the
fusing temperature

T echnical B ulletin PAGE: 2/3
Reissued: 22-Feb-13
Model: Aries-P1.5 Date: 04-Oct-10 No .: RM077006g
Version Modified Points or Symptom Corrected
7. Countermeasure against jam in SR5020 soon after recovering from pause
during stapling, and irregular paper stock.
When the flywheel is added to the machine for a countermeasure against the
shockjitter, following SP need to be changed together.
SP2-992-001: 0.0 -> 0.5
SP2-993-001: 0 -> 1
Following Firmware need to be updated together
Part number Version
Web Support M0776083 1.03.1
Engine M0775253 1.007:16
System/Copy M0776081 1.07
1.06 Modified Points
Able to saddle stitch custom size paper using Plockmatic/COLUMBIA
EFI version need to upgrade together with following patch when applying this
firmware
1-1B0MG8
1.05 Modified Points
- Add the function to confirm the paper catalog version
1.04 Modified Points
- In the Paper Library, Advanced setting for paper created from "*Not
Programmed" can be adjusted.
- When replacing GW-Controller, data saved to paper library can be
restored.
- On the operation panel, Paper Library screen, some words have been
changed.
- Recall Paper Library -> Paper Library
- Program/Change/Delete Custom Paper -> Custom Paper
- Version of Paper library can be checked
Following firmware need to be upgraded together
Part number version
Engine M0775252E 1.006:16
System/Copy M0776091E 1.04
Websys M0776093C 1.02
Ope Panel CHN M0776387 1.05
Ope Panel NA M0776385C 1.05
Ope Panel EU M0776386C 1.05
Language M0776390B 1.04
Network Support M0776692C 7.12

T echnical B ulletin PAGE: 3/3
Reissued: 22-Feb-13
Model: Aries-P1.5 Date: 04-Oct-10 No .: RM077006g
Version Modified Points or Symptom Corrected
1.03 Modified Points
- Early web cleaning indication has been fixed
- fuser unit PM counter is corresponding to several fusing unit to prevent
fusing belt from wearing away
Following firmware need to be upgraded together
Part number Version
Engine M0775252D 1.005:16
System/Copy M0776091D 1.03
Websys M0776093B 1.01
Ope Panel NA M0776385B 1.04
Ope Panel EU M0776386B 1.04
Language M0776390A 1.03
1.02 Modified Point
Counting method for Printer has been changed
1.01 <Fixes>
1. Problem of "key mark" for indicating Apply Auto Paper Select: NO,
disappear when the paper was set to the tray has been fixed.
2. JAM clearance animation was fixed.
3. Problem of indicating incorrect jam locations in the downstream
peripherals when the configuration consists of both Ring Binder RB 5000
and Stacker (SK5010) has been fixed.
Apply condition:
Firmwares below to be applied together as a set.
Program Name Program No. Version
System M0776091B 1.01
Network Support (NCS) M0776092B 7.11
Engine M0775252 1.003:16
* Update to the following versions is required for all peripherals listed below.
Program No. Version
SR5000 B8305102S V02.030:62
SR5020 D4345620K V03.160:08
TR5020 D4555510D V15.280:16
Note
Make sure to update the peripherals in order of proximity to the main frame.
Do not update consecutively by selecting several peripherals
1.00 1st Mass production

Technical Bulletin PAGE: 1/2
Model: Aries-P1.5/C1.5 Date: 25-Oct-10 No.: RM077007
Subject: Latest firmware version List Prepared by: N.Iida
From: PPBG Service Planning Dept.
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other ( ) Tier 2
This RTB has been issued to announce the firmware versions applied to the 1st mass
production of the Aries-P1.5/C1.5. Firmwares are available from the Download Center.
Please refer to the table ‘Peripheral Devices’ described on the following page for
peripheral devices installed with the Aries-P1.5/C1.5.
Aries-P1.5
Program Name Firmware No. Version Note
System M0776091A Ver.1.00
Engine M0775252A Ver.1.000A:16
Websys M0776093A Ver.1.00
OpePanel(NA) M0776385A Ver.1.01
OpePanel(EU) M0776386A Ver.1.01
Language M0776390 Ver.1.01
NCS M0776092A Ver.7.10
Aries-C1.5
Program Name Firmware No. Version Note
System/Copy D0956091A Ver.1.00.1
Engine D0955252A Ver.1.000A:16
Scanner D0956097A Ver.01.10
Websys D0956093A Ver.1.00.1
WebUapl D0956095A Ver.1.00.19
OpePanel(NA) M0776395A Ver.1.01
OpePanel(EU) M0776396A Ver.1.01
Language M0776391 Ver.1.01
NCS D0956092A Ver.7.10
NFA D0956096A Ver.1.00
Color controller E41
Soft ware System version Parts number Note
System soft ware V1.0 M3916740
User soft ware V1.0 M3916730
Color controller E81
Soft ware System version Parts number Note
System soft ware V1.0 M3926740
User soft ware V1.0 M3926730

Technical Bulletin PAGE: 2/2
Model: Aries-P1.5/C1.5 Date: 25-Oct-10 No.: RM077007
The firmware versions in the following table are required for proper operation of the unit.
Please prepare the firmware in advance to perform the update upon site installation.
Note
 Peripheral devices must be updated from the units installed closest to the mainframe.
Power cycle the mainframe after updating each peripheral.
 Make sure to check the notes described in the release note before updating the
peripheral devices.
Peripheral Devices
Devices Firmware No. Version Note
Finisher SR5020 D4345620J Ver.03.140:08
Finisher SR5000 B8305102R Ver.02.000:61
High Capacity Stacker SK5000
1st D4475104H_up Ver.02.270:09
High Capacity Stacker SK5000
2nd D4475104H_down Ver.02.270:09
Cover Interposer Tray CI5010 B8355510H Ver.03.010:46
Z-Folding Unit ZF4000 B6605552 Ver 2.14 ROM replacement required
for update.
ROM p/n B6605552
Perfect Binder GB5000
P-Binder_B1
P-Binder_B2
P-Binder_B3
P-Binder_B4
P-Binder_B5
D3915020E
D3915070D
D3915730A
D3915120C
D3915170C
Ver.0.320:11
Ver.0.220:00
Ver.1.19
Ver.0.160:00
Ver.0.28:00
Ring Binder RB5000
Ring Binder_B1
Ring Binder_B2
D3925510G
D3925520C
Ver 01.310:04
Ver 01.060:01
Trimmer Unit TR5020 D4555510C Ver15.270：15
Buffer Pass Unit Type 5000 M3791702C Ver.02.030:05

Technical Bulletin PAGE: 1/3
Reissued:27-Apr-11
Model: Aries-P1.5/C1.5 Date: 25-Oct-10 No.: RM077008c
RTB Reissue
The items in bold italics were corrected or added.
This RTB has been issued to announce the release of the data files (xxx.mqp) and the
Media List used for the Paper Library on the Aries-P1.5/C1.5.
MQP files and Media Lists are confidential information.
About the Media List
Media have been evaluated under 4 categories, “Image Quality”, “Image Performance”,
“Feed Performance” and “Others”, which are ranked in 4 levels (A+, A, B, and C). The
lowest rank from among the 4 categories becomes the overall evaluation rank for each
media.
About the MQP file
The MQP file only contains data for media ranked either ‘A+’ or ‘A’. Installing the MQP file
into the Aries–P1.5/C1.5 will enable application of the media from the Paper Library.
Rank Description
A+ Good results, no remarks. (Better than the product spec) (Only Image Quality)
A Good results, no remarks. (Product Spec)
B Note the remarks. Customers must be aware of the remarks.
C Not recommended.
Example of media evaluation results:
Subject: Paper Libraly Data for AriesP1.5/C1.5 Prepared by: H. Kawamura
From: 1st PP Service Planning Sec., PP Service Planning
Classification: Troubleshooting
Mechanical
Paper path
Part information
Electrical
Transmit/receive
Action required
Service manual revision
Retrofit information
Product Safety Other ( ) Tier 2
Overall Image Quality Image
Permanence Feed Performance Others
A A A A A
B B A B A
C C A A A

Technical Bulletin PAGE: 2/3
Reissued:27-Apr-11
Model: Aries-P1.5/C1.5 Date: 25-Oct-10 No.: RM077008c
Media List & MQP file
The Media List and MQP file have been uploaded onto the GKM support site Tier2 under
the title “Pro C901and 901S Media List/Paper Library Data” in the ‘Summary’ column.
Download the latest version from the GKM, and install the MQP file when setting up the
machine.
[NA] Release Date : 27th Apr 2011
Summary : Pro C901and 901S Media List/Paper Library Data for North America
Media List : ProC901_C901S Media List for NA(Rev.6).xls
MQP file : ProC901_Printer_NA_Rev6.mqp
ProC901S_Copier_NA_Rev6.mqp
[EU] Release Date : 27th Apr 2011
Summary : Pro C901and 901S Media List/Paper Library Data for EU
Media List : ProC901_C901S Media List for EU(Rev.7).xls
MQP file : ProC901_Printer_EU_Rev7.mqp
ProC901S_Copier_EU_Rev7.mqp
[AP] Release Date : 27th Apr 2011
Summary : Pro C901and 901S Media List/Paper Library Data for AP
Media List : ProC901_C901S Media List for AP(Rev.7).xls
MQP file : ProC901_Printer_AP_Rev7.mqp
ProC901S_Copier_AP_Rev7.mqp
NOTE
 The Printer model and the Copier model use different MQP files; no interchangeability.
Install the correct MQP file for the machine. The software is designed to reject the
installation if the MQP file is not for the correct machine.
 The MQP file does not incorporate regional restrictions. Reinstall the file if you
installed a file for an incorrect region.
 The MQP file name must be renamed upon installation. Refer to ‘Installation
Procedure: Paper Library’ described on the following page.
