Ricoh Aficio SP C420DN-KP
Color HotSpot Printer
The Freedom to Print From Anywhere.

Ricoh Aficio SP C420DN-KP Color HotSpot Printer
ASecure Mobile Printing Solution That Allows
Anyone to Print From Anywhere At Anytime.
Give every user the freedom to easily print documents,
e-mails and Web content in full-color from Internet-
enabled laptops, cell phones and handheld devices
without downloading drivers or installing additional
software. Ricoh HotSpot technology ensures reliable
access to driverless laser printing in a totally embedded,
secure mobile printing system. The RICOH®Aficio®
SP C420DN-KP Color HotSpot Printer delivers powerful
31-ppm full-color and monochrome laser printing with
superior image quality on every page. Increase printing
productivity and offer unique capabilities with a
brandable, turn-key solution. Ricoh HotSpot
printing technology makes it
easy to print anywhere.

High-yield toner bottles deliver low cost-per-page
factors and install quickly for maximum uptime
and ease of use.
AComplete Plug-and-Play Solution
Ricoh has partnered with PrinterOn®Corporation,
aleading provider of mobile printing technology, to
deliver the industry’s first and only fully integrated,
full-color mobile printing solution.
•Simple installation — This turn-key system is self-configuring and ready to
Print Simply Anywhere®in minutes. Access to the Internet is all that’s needed.
Plus, every Ricoh Aficio SP C420DN-KP includes a one-year subscription to
PrinterOn's mobile printing service.
•Totally embedded — All printer hardware enhancements are preconfigured;
all software is pre-loaded, no additional support is required. That means no
external appliances and no way for users to accidentally change system settings
or access other jobs.
• A real One-for-All solution — Use the compact Ricoh Aficio SP C420DN-KP
for daily network color printing tasks in addition to supporting mobile users
with HotSpot. Designed to fit in the tightest workspaces, this universal printer
enables every user to print in full-color with greater control while minimizing
compatibility and supportissues.
Total Data Security
Every environment with existing high-speed Internet
access — wired or wireless — can reduce their support
burden with Ricoh’s versatile HotSpot Printer technology.
•Mobile handheld device printing — Simply forwardany e-mail from PDAs or
Internet-enabled cell phones – with or without attachments – to the HotSpot
Printer’s e-mail address. No drivers required!
•Driverless Web-based printing — Surf to the HotSpot Printer Web address
using any browser,and upload a file or enter the Web page URL to be printed.
After submitting each print request, the service automatically replies to the
sender’s e-mail address with a secure release code that is entered at the
keypad attached to the printer.
•Ironclad data encryption — All print jobs are encrypted and transferred using
128-bit secureSSL communications.
•Secure mobile printing — After printing, every job is automatically erased
from printer memory. No worries about unauthorized reprinting.
Simple Branded Web Interface Options
Ricoh HotSpot Printer technology adds value by
enabling organizations to take greater ownership
of this solution as an exclusive, branded interface to
build customer loyalty or as a revenue generating
service for cost recovery.
•Flexibility — Set up the Ricoh Aficio SP C420DN-KP mobile printing solution
as a free convenience to attract new customers or as a chargeable printing
service to increase revenues.
•Customizable interface — Incorporate company logos and colors on the
PrintSpots™Web page to reflect your business identity and present HotSpot
printing as a value-added service exclusive to your establishment.
•Add links and custom messages — Customize the main user interface to add
links to other websites, add new printers or insertnew screens for additional
services, print job options and job confirmation/approval steps.
•Support for third party billing systems — Ricoh is partnering with PrinterOn
and WebPay Services Aps (WPS) to enable hosted billing solutions so that the
system can count the number of pages, calculate the job cost, and initiate a
credit card billing sequence. When sending a job from a PC the service is called
WebPay. When sending from a handheld device it is called MobilePay.
SuperiorRobustConnectedProductive
Driverless full-color printing to any Ricoh HotSpot
Printer on your network makes mobile professionals
and field-based service and sales agents more
productive.
The Total
Green Office
Solution
Ricoh continues its long-
standing commitment to
developing office solutions
with environmentally friendly
and superior energy- and
supply-saving features,
without compromising
productivity.

s
Ricoh Aficio SP C420DN-KP
Specifications
System Specifications
SP C420DN-KP Part #406624
Configuration Desktop Color Laser Printer
Imaging Process Laser beam scanning, electro-
photographic printing,
Dual component toner, 4 tandem
drum method
Print Speed 31-ppm (Letter) in Full-Color and B&W
First Print Speed Color: 15 seconds; B&W: 10 seconds
Warm-Up Time <30 seconds
Print Resolutions 600 x 600 dpi, 1200 x 600 dpi,
1200 x 1200 dpi
CPU 800MHz
Memory 512 MB RAM (Standard/Maximum)
60 GB HardDisk Drive Type 420
(Standard)
Printer Languages* PCL5c, PCL6, Adobe®PostScript®3™
+PDF Direct, Ricoh Refined Print
Command Stream (RPCS)
*Page Description Languages areaccessible for standard network printing only.
Fonts 136 PostScript 3 fonts, 45 Intellifonts,
13 International fonts
StandardInterfaces 10Base-T/100Base-TX Ethernet, USB 2.0,
USB Host Interface for Keypad,
VM Cardfor JAVA-based SDK option
Optional Interfaces IEEE 802.11a/b/g Wireless LAN,
Bluetooth Wireless, Gigabit Ethernet,
IEEE 1284 Parallel
Network Protocols Simultaneous auto-sensing/auto-
switching
TCP/IP, Novell IPX/SPX, AppleTalk
Operating Systems Windows 2000/XP/Server 2003/Vista
NetWare v 3.12, 3.2, 4.1, 4.11, 5.0,
5.1, 6, 6.5
Macintosh OS 8.6 – 9.2x, OS X 10.1
or later
UNIX (using Ricoh UNIX filter)
SAP R/3 3.x or later
Maximum Paper 2,300 sheets
Capacity
Standard Tray 550 sheets
Bypass Tray 100 sheets
Optional Paper Tray 550 sheets (1, 2, or 3 may be added)
Duplex Standard Automatic Duplexing
(Approx. 100% of simplex speed)
Acceptable Paper Std. & Opt. Trays: 3.9" x 5.8" to
Sizes* 8.5" x 14"
Bypass Tray: Width: 2.8" - 8.5";
Length: 5.5" - 35.4"
*HotSpot print jobs default to either Letter or Legal size. Other paper sizes
areonly available when the device is used as a standard network printer.
Acceptable Paper All Sources: 14 lb. - 57 lb. Bond/
Weights 120 lb. Index
When Duplexing: 14 lb. - 43 lb. Bond/
90 lb. Index
Output Capacity 500 sheets, face down
Keypad Ricoh USB Keypad
Dimensions (WxDxH)17.6" x 23.2" x 19.2"
(Add 1" height when keypad is installed)
Weight 110 lb.
Power Source 120V,60Hz
Maximum Power 990W or less
Consumption
Energy Saver Mode 6W or less
Options & Supplies
IEEE 802.11a/b/g Part #403000
Wireless LAN Type L
Bluetooth Wireless Part #412866
Type 3245
Gigabit Ethernet Part #402547
Type A
IEEE 1284 Parallel Part#411699
Paper Feed Unit Part #420165
Type 4000*
*Optional Paper Feed Units can only be accessed when the printer is used
as a standard network printer.
Ricoh BB-HPL10A-R Part#100123FNG
Ethernet Adaptor
PrinterOn Two-Year Part #003357MIU
Service Extension
HY Black Toner
Cartridge Part #888308 Yield: 15,000 pages*
HY Yellow Toner
Cartridge Part#888309 Yield: 15,000 pages*
HY Magenta Toner
Cartridge Part#888310 Yield: 15,000 pages*
HY Cyan Toner
Cartridge Part #888311 Yield: 15,000 pages*
Black Toner Cartridge Part #888276 Yield: 5,000 pages*
Yellow Toner Cartridge Part#888277 Yield: 5,000 pages*
Magenta Toner Part #888278 Yield: 5,000 pages*
Cartridge
Cyan Toner Cartridge Part #888279 Yield: 5,000 pages*
Photoconductor Unit Part #402319 Yield: 50,000 pages
Black
Photoconductor Unit Part #402320 Yield: 50,000 pages
Color
Waste Toner Bottle Part#402324 Yield: 50,000 pages
Intermediate Transfer
Unit Part #402323 Yield: 100,000 pages
Paper Feed Roller Part #403066 Yield: 100,000 pages
for 3rd PFU
Maintenance Kit Part # 402593 Yield: 100,000 pages
(Type C411)
Includes Fusing Unit, Transfer Roller, Paper Feed Roller.
*@ 5% coverage.
The Ricoh SP C420DN-KP ships with a one-year subscription to the
PrinterOn Service which must be registered in order to be active.
The Ricoh SP C420DN-KP ships with starter toner cartridges
that yield 3,000 pages; all other consumables ship at full yield.
For maximum performance and yield, we recommend using
genuine Ricoh parts and supplies.
Bundled Solution
The Ricoh Aficio SP C420DN-KP HotSpot Printer arrives with
these components already installed for true plug-and-play
mobile printing:
•Aficio SP C420DN-KP with 550-Sheet Paper Tray &
100-Sheet Bypass Tray
•512 MB RAM
•60 GB Hard Disk Drive
•USB Host Interface
•Ricoh USB Keypad
•JAVA VM Card
•PrinterOn’s JAVA-based mobile printing software
•One-Year PrinterOn Subscription included
Warranty
The Ricoh Aficio SP C420DN-KP is under warranty against
defects for a period of one year from the date of purchase.
Consumables are under warranty for a period of 90 days from
the date of purchase or until depleted, which ever comes first.
Please refer to warranty document shipped with the product
for more details.
The HotSpot Workflow:
Printing from your PDA, Laptop or Phone is as easy as 1, 2, 3.
1. Documents and Web pages to be printed are sent
from a wired or wireless laptop, cell phone or
handheld device to the PrintSpots™server using
128-bit SSL encryption.
1. The printer’s unique Web page or e-mail address
is noted on a label affixed to the printer.
1. Each job is assigned a private release code
automatically.
2. The receiving server generates a compressed
printable data file and transmits it securely
to the destination printer, once again using
128-bit SSL encryption for complete file
integrity and protection.
3. The job resides safely in the printer's hard
disk drive until the user arrives at the
printer and enters a confidential 4 – 10
digit release code using the attached keypad.
3. The file is decompressed, printed and is
then automatically erased from memory
for total security. It’s that easy!
1. 2. 3.
Bringing Ricoh Value to Your Organization
Ricoh technology offers a diverse portfolio of solutions to help your organization stay
competitive and move ahead. Let Ricoh show you how to empower your business to
improve critical processes, keep information secure, ensure compliance and promote
environmental sustainability while reducing the total cost of ownership.
