Riester ri-sonic PCP-USB Instruction Manual

1
Instruction of use
Electronic Stethoscope
ri-sonic PCP-USB
ri-sonic PCP-1

02
Table of Content
1. Introduction
1.1 Important Information read prior to Start-up
1.2 Safety Symbols / Information
1.3 Packaging Symbols
1.4 Intended Use
1.4.1 Indication
1.4.2 Contraindication
1.4.3 Intended patient population
1.4.4 Intended operators / users
1.4.5 Required skills / training of operators
1.4.6 Environmental conditions / Intended Environment
1.5 Warnings / Attention
2. First application
2.1 Scope of Supply
2.2 Device Function
3. Operation and Function
3.1 Introduction
3.2 Commissioning
3.2.1 Installation ri-sonic PCP-USB
3.2.2 Installation ri-sonic PCP-1
3.23 Auscultation Sessions (Examination of the patient)
4. Care instructions
4.1 General Information
4.2 Cleaning and Disinfection
5. Technical Data
6. Accessories
7. Maintenance / Accuracy check / Calibration
8. Disposal
9. Trouble Shooting
10. Electromagnetic Compatibility
11. Warranty

03
1. Introduction
1.1 Important Information read prior to Start-up
You have purchased a high quality Riester Stethoscope, which has been manu-
factured according to the Directive 93/42 EEC and is subject to the strictest qua-
lity controls at all times. Read these instructions for use carefully before putting
the unit into operation and keep them in a safe place. If you should have any
questions, we are available to answer queries at all times. Our address can be
found in these instructions for use. The address of our sales partner will be given
upon request. Please note that all instruments described in these instructions
for use are only to be used by suitably trained personnel. The perfect and safe
functioning of this device is only guaranteed when original parts and accessories
from Riester are used.
1.2 Safety Symbols / Information
Symbol Note on symbol
Follow the instructions in the operation manual.
Protection class II
IP22
Warning!
The general warning sign indicates a potentially hazardous
situation which could result in serious injury.
Warning!
The general warning sign indicates a potentially hazardous
situation which could result in serious injury.
Attention!
Important note in this instruction use.
The attention symbol indicates a potentially hazardous situation
which may result in minor or moderate injury. It may also be used
to alert against unsafe practices

04
Manufacturing date
YYYY-MM-DD / (Year-Month-Day)
Manufacturer
Lot number
Relative Luftfeuchtigkeit für Transport- und Lagerbedingungen
Air pressure for transport and storage
Air pressure for Ambient Operating
0124 CE-Kennzeichnung
Symbol for the marking of electrical and electronics devices
according to Directive 2002/96/EC.
Direct current
Non-ionizing radiation
USB- Plug

05
Symbol Note on symbol
Fragile. Show transport package contents fragile, so handling
should be handled with care.
Beware the package from getting wet.
Upward. It shows the correct position to transport the package.
Keep away from sunlight
"Green Dot" (country-specific)
1.3 Packaging Symbols
1.4 Intended Use
Electronic stethoscope sensor to convert internal bodysounds, such as heart and
lung sounds to electronic Signals and deliver to suitable PC or mobile device.
1.4.1Indication
The instruments serve the trained doctor or specialist as an aid in the detec-
tion, diagnosis, monitoring and treatment, the alleviation of illnesses, injuries
or disabilities.
1.4.2 Contraindication
There are no contraindications.
1.4.3 Intended patient population
The device is intended for all patients. The electronic stethoscope is in physical
contact with the patient‘s body (upper body).
