RIGHT ANGLE NewHeights 4 FD Series User manual

www.raproducts.com
Page1 OF 6
Read all the instructions before beginning.
Instruction # 53205
K&A Manufacturing
Hardware Pack # 53023
Version Dated: 7/11/16
6703 Zinser Street
Schofield, WI 54476
Phone: [phone]
Fax: [phone]
NewHeights™ Series 4 FD Fixed Height
Workstation Assembly Instructions

Page 2 OF 6
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Hardware Pack # 53023 Drawn Actual Size
53638 51708
52236
B
C
3
5
Tools Required for Assembly:
Power Driver W/Adjustable Torque
#2 Phillips Head Driver Bit
#2 Square Head Driver Bit
3/16" Hex Head Driver Bit or
Allen Wrench
Tape Measure
Level
Warranty Information: NewHeights™ products are warranted to be free of defects due
to manufacturing or materials as follows: Five years on the support brackets, aluminum
columns, and feet. We will replace any defective part after inspection by an authorized
agent. Costs incurred due to product replacement such as installation labor or transpor-
tation are not covered under this warranty.
Instruction # 53205
D
Note: This hardware pack is used
on a variety of workstations. You
will have some hardware left over
that is not used on this particular
workstation. 53678
800934

Page 3 OF 6
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Instruction # 53205
ITEM # PART # DESCRIPTION QTY.
1 Varies NH Type 1 Worksurface 1
2 Varies NH S4 Fixed Leg Assembly 2
3 51 08 M5 x 18mm ( /8") Sq/Ph/Wshr Head Wood Screw 34
4 Varies NH S4 Cross Support 1
5 800934 Cross Support End Cap 2
6 Varies LT U-Channel 1
53638 5/16-18 x 3/8 Button Head Socket Screw 4
Step 1: Lay the worksurface 1on a protected surface
with the pilot holes facing up. Align the holes in the
worksurface supports on the leg assemblies 2with
the pilot holes in the worksurface. The leg assemblies
are interchangeable.
Step 2: Attach the worksurface supports to the work-
surface with (1) wood screw 3in each outside corner.
Leave the screws loose by about 1/8" so you can
adjust the legs when attaching the cross support 4
later.
1
2
3
Worksurface
Support
Steps 1 & 2

Page 4 OF 6
Instruction # 53026
Step 3: With the help of an assistant align the
cross support 4with the stickers on both leg
assemblies. See below. Insert (4) socket
screws 7through the holes in the ends of the
cross support and thread them into the weld
nuts that are held in place by the stickers. Do not
fully tighten. Check that the cross support is level
and parallel to the worksurface. Fully tighten the
socket screws.
Step 4; Insert (2) end caps 5into the ends of
the cross support.
Both legs.
Step 3
4
5
Step 4

Page 5 OF 6
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Instruction # 53205
Step 5: Fully tighten the (8) wood screws 3at the
corners of the worksurface supports. Do not over-
tighten the screws. Use a low torque setting on the
power driver. Add (8) more wood screws in the
remaining holes in the worksurface supports. .
Step 6: Align the holes in the u-channel 6with the
pilot holes in the worksurface 1. Attach the u-channel
with (8-10) wood screws 3.
Step 7: With the help of an assistant. set the workstation upright in its final location.
Level the workstation if required by turning the leveling glides clockwise (from the top)
on the low corners of the unit. If your workstation has casters, level it by turning the
bolts at the top of the casters.
1
6
3
3
Leveling Glide
Steps 5 & 6

ITEM # PART # DESCRIPTION QTY.
A Varies Track Assembly 1
B 52336 3/16" Aluminum Rivet Washer .198 x .510 x .06 2
C 526 8 8-18X1/2 Phillips Pan Self Drill Screw 2
D 51 08 M5 x 18mm ( /8") Sq/Ph/Wshr Head Wood Screw 2
E Varies LT U-channel 1
Page 6 OF 6
K&A Manufacturing
6703 Zinser Street Schofield, WI 54476
Phone: [phone]
Fax: [phone]
www.raproducts.com
Instructions To Install a Track on a Series 4 FD
Workstation:
Step 1: Place the front of the track Aagainst the
bottom of the worksurface and the back of the track
on the angled part of the u-channel.
Instruction # 53205
Step 2: Align the holes in the track Awith one set of pilot holes in the u-channel E
keeping the front of the track 1/8"-5/8" from the front of the worksurface. Place (2) washers
Bon (2) self drilling screws C. Drive them through the track and into the u-channel.
Step 3: Attach the front of the track Ato the worksurface using (2) wood screws D. Do
not over-tighten the wood screws. Use a low torque setting on the power driver.
Step 4: Complete the installation using the instructions that came with the product you
are installing.
A
B
C
D
E
Your worksurface may
be different than the
one shown here.
Side View
(Track wil be at
an angle when
installation is finished.)
