RSC608 / RESC608
8A SmartCharge with Battery Analyser
Up to 3.5L
RSC612 / RESC612
12A SmartCharge with Battery Analyser
Up to 5.0L
Instructions
SmartCharge
Retain these instructions for future reference
www.ringautomotive.co.uk
Ensure area is well ventilated
P01
P11
P21
P31
P41
P51
P61
P71
P81
P91
P101
P111
P121
P131
P141
P151
P161
Contents
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 1 27/10/2014 14:36
130.ua — all for cars!
130.ua

2
SmartCharge
1Safety
RISK OF EXPLOSION
Only connect the battery leads when the mains supply is disconnected.
Explosive gases may escape from the battery during the charging process.
Prevent flames and sparks and provide adequate ventilation during charging.
Indoor use only.
Unplug the charger from the mains before breaking or making the connection to
the battery.
Not suitable for use with non-rechargeable batteries.
In addition to the battery types and capacity detailed in the specifications, the
charger is suitable for the following only:
• Charging only a single battery at any one time
• Charging rechargeable lead acid, Gel, EFB, AGM or calcium batteries
with 6 cells
The Ring SmartCharger automatically adjusts the charge rate applied as the
battery charges. With the battery fully charged the charging process stops, as
the battery naturally discharges further charge is applied until the battery is
again fully charged. This is an ongoing process to ensure a safe connection for an
indefinite period.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
The charger contains no serviceable replaceable parts.
Not for commercial use.
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 2 27/10/2014 14:36
130.ua — all for cars!
130.ua

3
2Contents
3
RSC608 / RESC608
• AC Plug
• Battery clips
• Instructions
RSC612 / RESC612
• AC Plug
• Battery clips
• Instructions
Features
1LCD Display
2Navigation Keys
3AutoCharge /Memory Saver
4Standard lead acid vehicle setting (14.4v)
5Start Stop (AGM) vehicle setting (14.6v)
6Fault / Incorrect Polarity
1
2
3
4
5
6
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 3 27/10/2014 14:36
130.ua — all for cars!
130.ua

4
4
SmartCharge
The Ring RSC608/RESC608/RSC612/RESC612 are all 7 stage chargers
1 2 3 4 5 6 7
1. Desulphation - The automatic desulphation stage pulse charges the battery to breakdown the build up of lead
sulphate crystals. These crystals occur when a battery has been discharged or left unused for a period of time.
2. Soft Start - A slow steady build up of the charging process that limits the charging current applied until the
battery voltage is above 12v.
3. Bulk Charge - The main part of the charging process where 80% of the required charge is applied
4. Absorption - Charged up to full capacity with a steady decline in charging current to allow the battery to absorb
more power.
5. Battery Test - The SmartCharge conducts an automatic discharge test. If further charging is required the battery
recondition function is automatically selected. If fully charged the battery goes into the float stage.
6. Recondition - An additional automatic charging stage to recover deeply discharged batteries.
7. Float - The float stage maintains the battery at 100% charge without overcharging or damaging the battery,
allowing the charger to be left connected to the battery for an indefinite period. Ideal for batteries used only
intermittently, such as seasonally used batteries including motorcycles, caravans, boats and classic cars.
Amps (A) Volts (V)
3Features
OK Check Low / Bad
Reverse Polarity Fault
Performance/
completion
Charging Modes Testing Modes
R(E)SC612
only
R(E)SC612 only
Maintenance charge
Charging &
maintenance modes
Charging stages
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 4 27/10/2014 14:36
130.ua — all for cars!
130.ua

5
5Connection
1. Ensure AC mains plug is not connected to the AC mains supply
2.
For batteries inside the vehicle:
• Attach the red (+) battery clip to the red (+) terminal on the battery
• Attach the black (-) battery clip to a bolt or bracket on the engine block, away from the battery and fuel lines
For batteries outside the vehicle:
• Attach the red (+) battery clip to the red (+) terminal on the battery
• Attach the black (-) battery clip to the black (-) terminal on the battery
3. The polarity check LED illuminates if the charger is connected to the battery incorrectly. i.e. the red (+) clip connected to
the black (-) battery terminal. Ensure connection is correct and the ‘Polarity Check’ LED is not illuminated
4. Connect mains plug to the AC mains supply and switch on.
5.
After charging, disconnect the battery charger from the supply mains. Then remove the chassis connection and
then the battery connection.
6
Select the charging mode required
* Default charging modes
Normal Battery Maintainance Winter Battery Start/Stop Standard
Charging Charging Charging Recondition Vehicles Vehicles
RSC608/RESC608 * (Up to 8A) (0.8A) *
RSC612/RESC612 * (Up to 12A) (0.8A) *
2. Press the navigation arrows to select the battery charging icon and press SET.
3. Press the navigation arrows to select the required charging mode and press SET.
Pressing EXIT at any stage takes you to the first stage of the menu process.
Maintenance charge
Charging &
maintenance modes
Winter chargeRepair
SET
Battery Charging
Operation - Battery Charging
1. Select the battery / vehicle type you are charging:
Standard vehicle – using traditional lead acid battery types (14.4v applied)
Start / Stop vehicle – using modern AGM battery types (14.6v applied)
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 5 27/10/2014 14:36
130.ua — all for cars!
130.ua

7
6
SmartCharge
6
4 Pressing the Auto Charge function will automatically apply the fastest charge rate the battery connected can safely take.
With this mode selected ‘AUTO’ is displayed on the LCD display
5. Charging is complete when 100% is displayed on the LCD screen
Battery Voltage Battery Start Power Alternator Output Battery Capacity
RSC608/RESC608 *   -
RSC612/RESC612 *   
Operation - Battery Charging
Operation - Battery Analysing
* Default charging modes
Battery analysing modes operate with and without AC mains supply. Connecting the battery clips to the battery
automatically activates the charger
1. Press the navigation arrows to select the battery charging icon and press SET.
2. Press the navigation arrows to select the required charging mode and press SET.
Pressing EXIT at any stage takes you to the first stage of the menu process.
Battery Capacity is RSC612/RESC612 only.
Battery Analysing
TEST SET
Winter Mode
Used for charging batteries at low temperatures (-20°C to +5°C). Increases the battery voltage to 14.6v
(standard vehicle) or 14.8v (Start/Stop vehicle).
Battery Charging Mode
For standard battery charging at temperatures over 5°C
Increases the battery voltage to 14.4v (standard vehicle) or 14.6v (Start/Stop vehicle).
Maintenance Mode
Applies to low 0.8A charging rate, ideal for long term seasonal connection
Recondition Mode
Applies a controlled increased charging voltage to allow recovery of deeply discharged batteries
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 6 27/10/2014 14:36
130.ua — all for cars!
130.ua

7
7Operation - Battery Analysing
Battery Voltage Mode
Displays the battery voltage as a % of its capacity:
Press the navigation arrows to select the battery % icon and press SET.
12.7v – 100%
12.5v – 90%
12.4v – 80%
12.3v – 70%
12.2v – 60%
12.1v – 50%
11.9v – 40%
11.8v – 30%
11.6v – 20%
11.3v – 10%
1. +
Battery Start Power
Assesses battery cranking power and recovery. Measures the voltage drop during engine starting to identify potential
starting problems due to battery failure.
1. +
2. A1 + With A1 displayed press SET - measures static battery voltage
3. A2 + With A2 displayed start the vehicle engine.
4. Min battery voltage recorded during cranking displayed and good, check or bad status displayed
Good >8v, check 7-8v and bad <7v
Alternator Output
Assesses battery cranking power and recovery. Measures the voltage drop during engine starting to identify potential
starting problems due to battery failure.
1. + = A1 displayed
2. (Rev engine to 3000rpm*) + Maintain revs during 10 second countdown
3. A2 displayed (Rev engine to 2000rpm**) + Maintain revs during 10 second countdown
4. Battery voltages then displayed for both 3000rpm and 2000rpm tests
Good or bad status displayed
* 3000rpm with no battery loading. i.e. no lights AC, etc
** 2000rpm with battery loading. i.e. lights AC, etc
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 7 27/10/2014 14:36
130.ua — all for cars!
130.ua

8
8
SmartCharge
7Operation - Battery Analysing
Battery Capacity
Measures the cranking performance of the battery to determine engine starting ability and battery performance.
1. +
2. + CCA or EN + Set the battery standard CCA or EN***
3. + CCA/EN value + Input the battery CCA or EN value ***
*** markings on a battery will state the battery standard and value
If CCA or EN values not stated, select CCA and use the following table
CCA
1000-1299cc 300 CCA
1300-1599cc 400 CCA
1600-1999cc 500 CCA
2000-2999cc 700 CCA
3000-3500cc 800 CCA
4. Actual battery value is displayed plus capacity %
Good, check or bad status displayed
Good >74 %, check 50-74% and bad <50%
This function will not operate if the battery voltage is less than 8v
Operation - Memory Saver
Memory Saver
The memory saver function allows the vehicle electrical and audio settings to be retained when the battery is removed.
1. Connect the SmartCharge battery clips to positive (+) and negative (-) cables on the vehicle that attached to
the battery terminals
2. With the AC mains power connected press the Auto Charge button for 5 seconds. Memory Saver mode is
activated when MEM is displayed on the LCD display
3. Remove the vehicle battery
4. Ensure the vehicle battery is connected correctly before disengaging the SmartCharger to ensure no loss of
vehicle / audio settings
5 Seconds
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 8 27/10/2014 14:36
130.ua — all for cars!
130.ua

10 Specifications
9Operation - Fault Codes
9
Code Detail Reason Action
F01 Battery voltage below 12v Battery is defective Replace the battery
after charging for 300mins or Load maybe connected to the battery Disconnect load from the battery
F01 If after 20 hours (five times in Recondition Battery is sulphated Replace the battery
mode) due to a faulty battery, the beyond reconditioning
battery does not enter the float stage
F02 Battery voltage too high Battery rated above 12v Check the battery rating
F03 Actual charging rate Charger error Disconnect the charger and the AC supply, then
exceeds the charge rate set reconnect, if error happens again charger faulty
or Interference from another device Turn off / disconnect other devices
that may cause interference.
F04 Charger temperature too high High ambient temperature Select a lower charging current to charge
Allow the charger to cool for 30mins
or Poor ventilation Ensure enough space for adequate
ventilation (10cm clearance)
F05 Does not enter float stage within 24hrs Charge current too low Disconnect battery and AC supply.
Reconnect and select a higher charging rate
or Load maybe connected to a battery Disconnect load from battery
or Battery is defective Replace the battery
F06 Reverse polarity Battery clips connected incorrectly Re-connect the battery clips correctly
F07 Measured charging voltage is too Poor functioning regulator Check regulator
high during the alternator test
F08 Measured charging voltage is too Belt maybe loose Check belt and alternator
low during the alternator test or Poor functioning alternator
12v, 8A 12v, 12A
Part Number RSC608/RESC608 RSC612/RESC612
Input Voltage AC 220-240VAC, 50Hz 220-240VAC, 50Hz
Charging Voltage 14.4v (winter 14.6v) – Standard vehicle 14.4v (winter 14.6v) – Standard vehicle
14.6v (winter 14.8v) – START/STOP (AGM) 14.6v (winter 14.8v) – START/STOP (AGM)
Charging Current Up to 8A Max Up to 12A Max
Types of Battery Lead acid, Gel, Calcium, AGM, EFB Lead acid, Gel, Calcium, AGM, EFB
14-220Ah (Charging) 25-300Ah (Charging)
Dimensions 195 x 138 x 78 195 x 138 x 78
Weight 1.51Kg 1.51Kg
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 9 27/10/2014 14:36
130.ua — all for cars!
130.ua

11 Warranty
10
SmartCharge
The RSC608/RESC608/RSC612/RESC612 SmartChargers come with a standard 12 months guarantee.
Register your purchase either on the form attached or via the Ring website:
www.ringautomotive.co.uk/uk/contact/register-your-product
and you will receive an additional 4 years protection – free (as long as, within 4 weeks from date of
purchase, an online registration is made, or we receive the completed registration form).
In the event of a warranty claim in the first instance contact our Technical Helpline: [phone]
• 8272 RING SmartCharge RSC608 RESC608 Instructions Book.indb 10 27/10/2014 14:36
130.ua — all for cars!
130.ua
