Rinnai RHFE-556FTD Operating instructions

How to use your
Space Heater
. EnergysaverRHFE-SGFDT
Rinnai
Guarantee
Layout of appliance
Features
Safety Points
Operation
Adjusting Temperature
Humidifier
Installer
<
<
<
<
<
<
.
<
<
I
SERVICE CoNi’ACrs
NZ [phone]
0800 RINNAI

FIXED TIME PERIOD OPERAlTION.
The Energysaver RHFE-556FDT includes an option so that operation
of the appliance automatically stops after a fixed time period.
It is possible to choose any one of seven time periods. The periods
are: 1, 2, 3, 6, 8, 10 or 12 hours.
This option must be activated by a qualified person or trained Rinnai
service person.
Fixed time period operation is ideally suited to classroom situations,
clubs, meeting halls, and other areas where a limit is required on the
length of time the appliance operates.
The feature can provide substantial energy savings in cases where
users are likely to forget to turn the appliance off when they leave the
room after meetings or lessons.
If a power failure occurs at any time during operation, the appliance
will remain OFF once the power is re-instated. The ON/OFF button
must be pressed to re-ignite the appliance.
I, r’
, .. I*
Contact Rinnai on one of the telephone numbers
cover of this booklet for further advice. listed on the back
-l--l-

IMPORTANT
This appliance shall be installed in accordance
with:
l Manufacturer’s Instructions
l Local Authority Building Codes
l NZS 5261 Installation Code for Gas Burning
Equipment
l Any other relevant Statutory Regulation
This appliance must be installed, serviced and
removed by an authorised person.
AGA APPROVAL NO 5209. -
DEAR CUSTOMER
THANK YOU FOR PURCHASING THIS RINNAI APPLIANCE. WE ARE PLEASED TO ADVISE THAT
RINNAI PRODUCTS ARE NOW COVERED BY A 2 YEAR. GUARANTEE: FREE PARTS AND
LABOUR FOR THE FIRST YEAR AND PARTS ONLY FOR THE SECOND YEAR.
-THIS GUARANTEE IS IN ADDITION TO ANY GUARANTEES WHICH
CONSUMERS MAY HAVE UNDER THE CONSUMER GUARANTEES ACT -
SHOULD YOU HAVE ANY QUERIES REGARDING THIS GUARANTEE PLEASE CONTACT YOUR
LOCAL RINNAI AGENT.
4 /
. , 2
Please recordbelow the followinginformationfor your own records.
Your Retailer:
Address: Phone:
Date of Purchase:
Your Installer: Installer’sLicence No.
Address: Phone:
Date of Installation:
-2-

GETTINGTO KNOWYOURNEW RHFE4556FDT
Built into the warm
air discharge duct.
Power ON/combustion
GAS4ZONNECTION .’ LJI
lNDlCATOR DISPLAY
iel with
- switch, room
temperature selection.
Temperature and
appliance error codes
are shown here.
interior of the
appliance and fan from
dust particles.
. EXHAUST OUTLET
Exhausts flue products
to the outside of the
building.
-3-

CONTROL PANEL,LAYOUT *
,d
,
ON/OFF Button
Selected Room
Temperature Display *
v
” I A
Temperatyre Control II
JJ
IT emoerature Adiustment Buttons
* Flashing LED is room temperature.
Steady LED is selected temperature.
Power ON/Combustion
Indicator
-@ Filtter
\ J
1Filter Indicator
-4-

FEATURES
r .
FILTER INDICATOR
When the fan filter becomes covered with
dust and the temperature inside the
appliance rises, the filter indicator will
flash. The filter should be vacuumed at
regular intervals to avoid unnecessary
strain on the appliance.
(See page 10)10)
r \
HUMIDIFIER TRAY
The integral humidifier tray can be filled
with water as required to raise the humidity
level in the room.
Humdifier Tray
W’
, , ) / (See page 11)
MEMORY
VERTICAL LOUVRE ADJUSTMENT
The louvre can be adjusted to alter the
direction of the air flow by using a screw
driving or similar tool by gently bending the
vertical louvre(s) to the left or right.
(See page 11)
J
f I
RXED TIME OPERATION
This feature will automatically stop the ap-
pliance after a fixed time period.
It is possible to choose any one of seven
time periods. The periods are: 1, 2, 3, 6, 8,
10 or 12 hours.
This feature can provide substantial energy
savings in cases where users are likely to
forget to turn the appliance off when they
leave the room after meetings or lessons.
The micro-computer records selected pre-
set temperature, to maintain comfort levels,
so your preferred temperature always
remains in place.
-6--6-

\ 7
/
SAFE-FYPOINTS
>
Do not restrict the warm air discharge This appliance must not be used for any
by placing articles in front of the heater. purpose other than heating.
Do not spray aerosols whilst the heater is
operating. Most aerosols contain butane
gas, and can be a fire hazard if ar
this heater when it is in use.
Fh.re guard is recommended where
children may be able to touch the flue
terminal.
Do not allow curtains or other
flammable or combustible materials to
come intocontact tiiih the heater.
Do not allow anyone to sit on or lean
against the appliance.
I
Combustible materials must not be placed
where the heater could ignite them.
-7-

SAFETY PQCMTS .I
Keep flammable materials, trees,
shrubs, etc, away from the flue
terminal.
Do not allow anyone to post articles
through the louvres.
Filter should be cleaned at regular
intervals. See Page IO. Young children should be supervised at
all times. Hand or body contact with the
louvres should be avoided.
clean with vacuum deanef, weekly.
Do not place articles containing liquids
on top of the heater, Liquids spilt on
the controls may ‘cause extensive
Do not allow young children or the infirm to
sleep directly in front of the heater.
-a-

\9
/
OPERATING YOUR NEW RHFE-556FDT
n TO OPEN THE CONTROL PANEL
Using a finger, pull door lightly forward from the
centre catch point on the left hand side of the
control panel cover. The control panel cover
will open forward to an angle.
n TURNING ON
Press the ON/OFF button to operate the
heater. The ON indicator will glow green.
After approximately 20 seconds the spark
generator will be heard before the burner
ignites and the ON indicator glows red,
indicating that the burner is alight. Warm air
can be felt coming from the louvres
approximately 15 seconds later.
Power ON/Combustion
indicator
1Filter Indicator
If the heater does not ignite on initial use, this may be due to air remaining in the gas supply
line, and the temperature display will flash. The spark generator will only continue for 15 seconds.
After this it will be necessary to press the ON/OFF button, then ON again.
n TURNING OFF
Power ON/Combustion
Indicator
Simply press the ON/OFF button to switch off
the h-t%er. The 0,Windicator will go out. The
convection fan will continue to operate for
several minutes after the burner has gone out
in order to cool the appliance. Do not unplug
the appliance while the convection fan is
running.
Filter Indicator
f
DO NOT turn heater off by unplugging at the power point.
The convection fan will continue to run until the appliance cools. 7
-9-

1 n ROOM TEMPERATURE ADJUSTMENT
I he room temperature and pre-set temperatures can only be displayed and adjusted when
the heater is running.
ON/OFF Button
n
1’1
Press the “A” button to increase the temperature
setting or “V” button to decrease the temperature
setting.
The Temperatures can be preset to:
a) [ L ] low (about 1O’C)
b) [16”C] to [26’C] in 2’ C steps
c) [ H ] (continuously high)
Selected Room
Temperature Display l
Temperature Adjustment Buttons
* Flashing LED is room temperature.
Steady LED is selected temperature.
.
If the heater does not ignite then the pre-set temperature may not be set to, a setting which is
higher than the room temperature. The ON indicator will change colour from red to green
when the heater reaches the pre-set temperature and stops running. The heater will operate at
eight minute intervals to maintain warmth in a room.
n FAN FILTER
To protect the room air fan from dust particles or
lint, a filter is situated at the rear of the appliance.
When this filter becomes blocked, the filter
indicator will flash to indicate that it should be
cleaned. Clean the filter weekly during the heating
season to avoid unnecessary strain on the
appliance.
Do not remove filter when appliance is
operating. When the filter requires cleaning,
clean filter before using the appliance, or whilst
the appliance is not operating.
If you do not clean the filter at regular intervals
and the filier indicator is allowed to remain
flashing, then the appliance will stop and [201 will
flash on the Digital Display signifying that the
inbuilt safety device has functioned. You must
clean the filter before operating the heater again.
-lO-

\11
/
n HUMIDIFIER TRAY
F F
So that you can humidify the air, your Rinnai RHFE-556FDT is fitted with an enamelled tray at
the bottom of the heater. If you choose to make use of the humidifier tray, it will need filling
about once a day during the heating season. Do not fill the humidifier tray while the heater
is running.
L /
LJ
1 To fill the humidifier tray:
Remove the bottom trim panel, below the louvres,
by pulling on both sides. Simply pull the tray
forward to allow it to be filled with water. The
warm air will be humidified as it passes over the
I I
water in the tray. Refit the bottom trim panel after
filling the tray. The RHFE-556FDT is a very high ..
\
efficiency appliance, during operation a small
amount of condensation is produced in the flue
system, this drains into the enamelled humidifier
tray.
he humidifier has the benefit (when filled with water) of raising the humidity in the air. With increased
humidity, the heater can actually be run at a lower temperature while still maintaining the same level
H VERTICAL LOUVRE ADJUSTMENT
The warm air flow direction may be altered by
inserting a screwdriver or similar tool and gently
bending the vertical louvre(s) either to the left or the
right.
Note: these louvres are not designed to be
adjust&f more than’6 times.
-ll-

CARING F IEMf’RfiFlX556FDT
This appliance is controlled by a micro computer. If there is something wrong with the
appliance then it will stop, as it is protected by the following safety devices.
Ignition Safety Device Power Failure Safety Device
Burner Safety Device Power Surge Safety Device
Overheat Safety Device Fan Delay Safety Device
Your RHFE-556FDT requires very little maintenance,
simply clean the rear fan filter once a week and
wipe the outer case and louvre section with a
damp cloth. 4
DO NOT USE SOLVENTS.
Solvents may melt or distort plastic parts.
a
Problem .E 5
5 0 ‘< 0-J 0
U-J1
5 ;g5 2 tjQ ‘E s S?‘E
2 $ 8 czoa
‘S Q 20)
‘- u
.-.z sg Remedy
5 g 32 20 5 CT, 82
2 g f,F z $ & Cause z” 82 6 ‘2 22
Not Plugged In 0 0 Plug In
Power Cut 0 0 0 Re-ignite manually after
power is restored
(Initial Installation) 0 Purge air
Air in gas pipe (Installer)
Gas Filter Blocked 0 0 0 Service Call
Miss Ignition 0 0 Service Call
Flue’tet‘hinal ,’ .’ 0 0 0
obstructed Clear obstruction
Flue manifold not 0
connected Service Call
Louvre obstructed 0 0 Clear obstruction
Air filter blocked 0 0 Clean filter (weekly)
Gas Escape 0 Service Call
Gas turned off at meter 0 0 Turn gas on
-12-

PRISERVICE CHECK :
Before asking for a service call please check the following points.
These points are part of the normal operation of the unit.
n At Ignition:
Heater does not operate. -+ Is the heater plugged in?
Have the fuses or breaker blown at the switch board?
Is there a power failure?
Is the air filter blocked?
Is anything blocking the outlet for the hot air?
Is the flue blocked?
Is the central timer turned off? (where fited)
Warm air does not flow when the burner lights. +
Smoke or strange smells are produced on the
first trial light up after installation.
Sharp clicking noises at ignition, or when the
unit cuts down on the thermostat, or goes out.
n During combustion:
Clunking noise when the thermostat operates.
The fan is started automatically after a short delay.
This is to allow the heat exchanger to warm up,
helping to avoid cold draughts.
This is caused bygrease oroiland dustonthe heat exchanger
andwillstopaftera shorttime.
+ This is simply expansion noise from the heat exchanger. I
+ This is the sound of the solenoid gas valves opening and
closing.
Unit is not heating room. Isthe set temperaturehighenough?
--) 1 ::z~~~i~~~~~k~.a,,,? 1
Are the doorsand windowsofthe roomclosed?
Air filter is blocked or the louvres are blocked
or obstructed.
Heater will not reignite after overheating.
--) 1 Allowheaterto cool,clean air fifter,operate again. 1
n
When the unjt is turned off:
1 Convectionfancontinuesto runafterturningOFF.1 --)
H Other Points:
Steam isdischargedfromthe flueterminal. +
Evenafter unithas cooleddownthe heater does not ignite
again. Repairis necessary.
Contactyourlocalagentor Rinnaifora
service call. ,
Thii isto removethe residualheat fromthe heat exchanger, the
fanwillstopwhen the heatercoolsdown.
L
Highefficiencyappliancestendto dischargewater vapouron
co& days,this is normal.
Unitcutsoffwithoutapparentreason.
Power Failure. + Switch OFF,’ then ON againwhen poweris restoredto
reset controls.
-13-

:
The Energysaver 556 has the ability to check its own operation continuously. if a fault occurs, an
Error Message will flash on the control panel Display. This assists with diagnosing the fault, and
may enable you to overcome a problem without a service call. Please quote the code displayed
when enquiring about service.
Flashing LED FAULT I REMEDY .
16 Ignition failure Check gas is turned ON.
Service call if repeated.
Flame failure Check gas is turned ON.
Service call if repeated.
Overheat Clean filter
Service call if repeated.
Room overheat Lower room temperature
to less than 40%.
22*24
24*26 Room Temperature
Sensor faulty Service call
Overheat temperature
Sensor faulty Service call
LOd6*18 Sparker failure Service call
16d8*20 Combustion fan failure Service call
18e20 Faulty ON/OFF switch Service call
L&l6 ,
I’ , Faulty solenoids Service call
Faultly Flame Rod Service call
Communication Error Turn heater OFF,
then ON again.
1 LO-HI 1 Power failure Turn heater OFF,
then ON again.
/In all cases, you may be able to clear the Error message simply by turning the heater OFF, then ON ’
again. If the Error Message still remains or returns on the next operation, contact Rinnai or your
nearest service agent and arrange for a service call.
-14-

INSTALLATION INSTRUCTtONS
I
SPECIFICATION
input: 23 MJ/h Burner: Stainless Bunsen Type
Ignition: Continuous Spark Gas Inlet: ~11215 BSP Connection
Flue: Forced Flue (Components are supplied with appliance).
Gas Control: Rinnai Electronic Modulating Controls.
Electrical Supply: 23OV, 50 Hz. This appliance is fitted with a supply lead and 3 pin plug.
Replace only with Rinnai part number 3010.
W Remove parts from carton and check that all parts shown below are included in the
installation kit.
Flue Manifold. ...... ..... . ... .l Spare rubber seal
........................
1
(‘A’ Flue units only)
.‘....
:.*.
::.:
..
0
-:
0 .
:.
.. ..
‘.‘...
..
(For weatherboard installations) I
(M4)
For Back Spacer Set Flue Securing Screws
Cl== 2 (M4.8 X 32)
Wood Screws 22
For Air Intake Clip Wall Bracket Screws
Check the unit supplied is correct for the gas type in your area.
Refer to local gas authority for confirmation of gas type if in doubt.
Refer to data plate located inside the front panel.
Check for damage, if the unit is damaged contact your supplier or Rinnai.
Do not install a damaged unit before checking with your supplier.
Refer to an approved pipe sizing chart if in doubt about size of gas line.
-15--15-

When positioning the heater the main points
governing the location are: This heater is not designed to be built in.
1. FlUElNG
2. WARM AIR DISTRIBUTION
This heater must not be installed where curtains
or other combustible materials could come into
contact with it.
In some cases curtains may need restraining.
See diagram for other recommended
clearances.
300 mm
0
c3 50 mm
:
, c
Flue fittings must be kept clear of flammable
materials.
I I
The flue is not designed to be positioned under
floors, or below the level of the heater.
I I
The flue terminal should be positioned away
from flammable materials.
Flue Tetmmal
-16-

Do not flue into natural draught flues or fireplaces,
this unit can only be used with one of the six
types of Rinnai flue kits.
Do not flue unit into other rooms.
Flue terminal must be outside.
I
Flue may be positioned directly under opening
windows, with a minimum clearance of 150 mm.
FLUE SIZES:
6 Flue lengths are available.
AA flue suits wall 75 - 115 mm
A flue suits wall 115 - 240 mm
B flue suits wall 240 - 400 mm
C flue suits wall 400 - 600 mm
D flue suits wall 600 - 800 mm
E flue suits wall 800 - 1000 mm
Co-ax flue also available.
SNOW AREAS
4 .d
, ,I
In areas subject to heavy snowfall, keep snow
clear of flue terminal at all times.
STANDARD INSTALLATION OF FLUE MANIFOLD.
Diagram below shows minimum clearances and
distances from obstructions. Also check local
regulations.
Flammable
m I 130Omm
Side Clearances
500 mm
I I -l
FIT BACK COVERS (SIDES ONLY)
Fit back covers (sides only) as shown below.
GAS CONNECTI
with
Fit suitable copper flare elbow to appliance inlet.
-17 -

LOCATION
Do not install the heater in an unusually dusty
area.
X
Use a flue guard if the terminal is easily
accessible to children.
Check local regulations.
Guards are available as an optional extra.
Guard
Floor must be level.
Do not use electrical extension cords to connect
unit to power supply.
Keep the power cord away from the flue.
FLUE MANIFOLD POSITION.
FOR WEATHERBOARD WALLS DRILL
THROUGH CENTRE OF WEATHER BOARD
FROM OUTSIDE, THEN DRILL FROM INSIDE
THROUGH PLASTERBOARD.
Flue Hole
Cavity Openmg
i 280/ /
Before drilling the flue hole, check for water and
gas pipes as well as electric cables.
Use an 80 mm (8 cm) drill for hole through wall.
WALL MOUNTING BRACKETS
Place top back spacer in position. Mark the position
of the top edge of the top spacer on the wall. Move
the heater away from the wall. Mark centre lines
80 mm down from the top edge mark, and 40 mm in
front the left and right hand sides of the top spacer.
Attach wall brackets at the marked position.
Remove right hand back cover.
Centre of hole for flue manifold can be drilled
anywhere within the shaded area. (To avoid
studs etc.)
-18-

SLEEVE AND MANCFOLDINSTALLATI‘ON
Skive Ternhal
METHOD FOR STANDARD WALLS
1. Dis-assemble Manifold from Sleeve.
The flue consists of 3 parts, sleeve,
inside connectors and tube, outside
terminal; (dis-assemble by pulling hard on
outside terminal and inner connections,
then pull sleeve off outer terminal).
2. Adjustment of Sleeve Length.
Measure wall thickness through Extensionjoint
previously drilled 80 mm hole. undo plastic Extension
End of sleeve should protrude 5-10 mm
from outside wall. Adjust sleeve length to (“A”and‘AA’fluesonly)
wall thickness plus 5 -10 mm. (Sleeve is w.
threaded for adjustment).
3. For A and AA flues only
Depending on flue set and wall thickness
extension piece “C” may need to be
removed.
Cut plastic, remove extension, then follow
instruction 2.
This applies to “A” and “AA” flues only.
There is no extension on other flues, they
can be fully adjusted by turning the
threaded section. :
Removeextansionat this
pointifneoxsary.
4. Fixing Sleeve.
Fix to the wall, using the 3 screws
provided.
NOTE:
The flange is marked ‘TOP”, sleeve
must be fitted with this mark UP.
Check sleeve protrudes 5-10 mm on
the outside.
Don’tremovegroanplasticcoveringfromsbevs.
-19-

SLEEVE AND NIFOLDINSTALLATION
METHOD FOR STANDARD WALLS
Terminalsad
5. Check rubber seal is in place on terminal. (AddVteattw board’
l For weather board walls, add spare
rubber seal provided to compensate for
weatherboard angle.
6. Installation of Terminal _‘, ‘.
From outside, insert terminal into sleeve
with the “A” mark at the top. Left hand
side fixing tie is marked “LEFT” (from
inside).
7. Attaching Ties
Pull hard on left and right hand side ties,
clip ties over lugs inside sleeve. You
should be able to pull ties 2 or 3 slots
past the starting point. Cut the ties,
leaving about 20 mm past the lugs. Bend
ties so they are parallel with the wall. erminal
8. Insert Inner Connection Assembly. Push
assembly into the terminal tube, make
sure “TOP” mark is uppermost. Fix with 3
screws provided.
-,’ /
. .’ ,I
9. Manifold can still be turned after
attaching.
-2o-
