Linear 1000 burn media installation: 13569-C | 1
Experience has shown that the majority of performance problems are caused by burn media being
installed incorrectly. Please take the time to read and follow these instructions as malfunctioning
due to incorrect burn media placement is not covered by warranty.
• The Linear MUST NEVER be used with other burn media or burn media that is damaged.
• The Linear burn media sets are di󰀨erent and cannot be interchanged, ensure you have ordered
the correct set before installation.
Correct placement
It is important to place the burn media in the correct position. Incorrect placement can create
carbon build-up and a󰀨ect performance.
Single-sided/double-sided
When installing the burn media you will ALWAYS be working on the side where the pilot assembly
is, to the back of the rebox.
Linear 1000
Burn media installation
R2902 Linear driftwood log set kit contents
Part number Description Quantity
13044 Vermiculite 1 bag (approx. 0.75 L)
13476 Wire wool (glowing ash) 1 bag (approx. 3 g)
13480 Log set A and stone set14 logs and 9 stones
13482 Log set C 1 log
1Log set A and stone set come packaged in the same box
R2904 Linear 1000 crushed glass kit contents
Part number Description Quantity
13473 Crushed black glass 3 bags (approx. 2.5 kg)
13476 Wire wool (glowing ash) 1 bag (approx. 3 g)
Ensure the gaps between the
burners are kept clear of any
vermiculite or crushed glass.
This is important as these gaps
provide secondary air to the
unit.
A tip to stop any burn media
going into the gaps is to place
the installation guide in the
burner gap while placing the
vermiculite or crushed glass
over the burner.
Important

2 | Linear 1000 burn media installation: 13569-C
A1
log C
A3
A4
We recommend identifying the log sections before installation—lay them on the oor in a
conguration resembling the above. This will ensure you’re not forcing incorrect log pieces onto the
burner supports and scratching the paint.
1 7 8 12 13
Linear log set C
Linear log set A
(includes log set AND
stone set)
A1
A2 A3 A4
2 5 9 13
Stone set (numbers are stamped on the back)
Grey stones
Vermiculite
Wire wool
Brown stones
Driftwood log set (charred side face down)

Linear 1000 burn media installation: 13569-C | 3
A2
1. Fold up the laser cut burner surrounds and tabs
The burners have laser cut sections and tabs that need to be folded up (refer images below) to
locate the di󰀨erent log sections.
2. Spread vermiculite
Using the image above as reference, spread (DO NOT POUR) approximately three quarters of the
bag of vermiculite across the burner section in a singe layer. Start the re and check for complete
burner ignition.
Important:
• Avoid blocking the pilot and ame rod ports
• Ensure clearance around the left and right hand log locators
• Ensure the gaps between the burners are kept clear
3. Add the wire wool
Remove sections of the wire wool and place where the ames will be. These provide a glow e󰀨ect
and will enhance the ame picture. Keep away from the pilot assembly as this can cause the ame
rods to earth out.

4 | Linear 1000 burn media installation: 13569-C
4. Install log C (for all log pieces—charred side faces down)
For clarity the following log images are shown without the vermiculite.
Position log C against the ‘L’ tab on the RH end and the straight tab on the LH end.
‘L’ tab on RH end Straight tab on LH end
5. Install A1 (from log set A)
Install A1 against the ‘L’ tab at the RH end and the straight tab at the mid log position.
‘L’ tab on RH end
Straight tab at mid log
Note position of the left hand section
relative to the front burner surround

Linear 1000 burn media installation: 13569-C | 5
6. Install logs A2, A3, and A4 as shown
A3 A2 A4
7. Install the stone set
Place decorative stones around the burner as desired—just make sure they are not blocking any
burner ports. You can use the image on p.2-3 as reference for placement.
8. Position left over vermiculite
Place the remaining vermiculite around the burners and use to cover the metal log locator
brackets, if they are showing, and any other gaps.
9. Test operation
Check for cross-lighting and complete ame across all burners, and check impingement on the
logs. Adjust logs as required. Some ames may lean back in the re until the glass has been
installed. Check again with the glass installed, using the below image as reference for the correct
ame pattern.

6 | Linear 1000 burn media installation: 13569-C
Crushed glass and wire wool
1. Evenly spread the complete bag of crushed glass over the surface of the burner BETWEEN
the fold lines of the back and front burner. Ensure the gaps between the burners are kept
clear of glass pieces. This is important as these gaps provide secondary air to the unit, refer
guide on how to keep clear on the front page.
2. Remove sections of the wire wool and place evenly across the burner where the ames will be,
these provide a glow e󰀨ect and will enhance the ame picture.
Important: Make sure the area around the pilot assembly is kept clear.
3. Test operation by checking for cross-lighting and complete ame across all the burners. Some
ames may lean back in the re until the glass has been installed.

Linear 1000 burn media installation: 13569-C | 7
Note the clear area around the pilot assembly
Line indicates the front burner fold line
Keep gap between burner clear
Keep gap between burner clear

Linear 1000 burn media installation 13569-C
