USE AND CARE GUIDE
WALL MOUNTED HOOD

Fig.1
Fig.2 Fig.3
Fig.4 Fig.5

A B
Fig.6 Fig.7
Fig.8 Fig.9
Fig.10 Fig.11
Fig.14

Fig.15
GENERAL
Carefully read the following important information regarding installation
safety and maintenance. Keep this information booklet accessible for further
consultations. The appliance has been designed for use in the ducting
version (air exhaust to the outside – Fig.1B), filtering version (air circulation
on the inside – Fig.1A) or with external motor (Fig.1C).
SAFETY PRECAUTION
1. Please take note that when the cooker hood is operating simultaneously
with an open fireplace or burner that depend on the air in the environment,
the cooker hood may removes the air from the environment which a burner
or fireplace need for combustion. The negative pressure in the environment
must not exceed 4Pa (4x10-5 bar). Provide adequate ventilation in the
environment for a safe operation of the cooker hood. Follow the local laws
applicable for external air evacuation.
Before connecting the model to the electricity network:
- control the data plate (positioned inside the appliance) to ascertain that the
voltage and power correspond to the network and the socket is suitable. If in
doubt please ask qualified electrician for help.

2. WARNING!
In certain circumstances electrical appliances may be a danger hazard.
A) Do not check the status of the filters while the cooker hood is operating
B) Do not touch bulbs or adjacent areas, after prolonged use of the lighting
installation.
C) Flambe cooking is prohibited underneath the cooker hood
D) Avoid free flame, as it is damaging the filters and can cause fire hazard
E) Constantly check food frying, the overheated oil may become a fire
hazard
F) Disconnect the electrical plug prior to any maintenance.
G) There shall be adequate ventilation in the room when the range hood is
operating
H) There is a risk of fire if cleaning is not carried out in accordance with the
instructions
I) If the supply cord is damaged, it must be replaced by the manufacturer or
its service agent or a similarly qualified person
J) This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
K) Children should be supervised to ensure that they do not play with the
appliance.
L) The air must not be discharged into a flue that is used for exhausting
fumes from appliances burning gas or other fuels
M) The minimum distance between the supporting surface for the cooking
vessels on the hob and the lowest part of the range hood shall be at least
65cm. The instructions for installation of the gas hob specify a greater
distance has to be taken into account if requirement stated
O) Regulation concerning the discharge of air has to be fulfilled.
INSTALLATION INSTRUCTIONS
Assembly and electrical connections must be carried out by specialized
personnel.

• Electric Connection
The appliance has been manufactured as class I, therefore earth cable is
necessary.
The connection to the mains is carried out as follows:
If the plug is not provided, connect the electrical load as indicated on the
description label. When a plug is provided, the cooker hood must be
installed in order that the plug is easy to access.
An omnipolar switch with a minimum aperture of 3mm between contacts; in
line with the electrical load and local standards, must be placed between the
appliance and the network in the case of direct connection to the electrical
network.
• The minimum distance between the support surfaces of the cooking pots on
the cooker top and the lowest part of the cooker hood must be at least 65 cm.
If a connection tube composed of two parts is used, the upper part must be
placed outside the lower part.
Do not connect the cooker hood exhaust to the same conductor used to
circulate hot air or for evacuating fumes from other appliances generated by
other than an electrical source.
Before proceeding with the assembly operations, remove the anti-grease
filter(s) (Fig.5) so that the unit is easier to handle.
In the case of assembly the appliance, in the suction version prepare the hole
for evacuation of the air.
• FIXING TO THE WALL
Drill the holes A respecting to the distances indicated (Fig.2).
Fix the appliance to the wall and align it in horizontal position to the wall
units. When the appliance has been adjusted, fix the hood using the screws
A.
For the various installations use screws and screw anchors suited to the type
of wall (e.g. reinforced concrete, plasterboard, etc.). If the screws and screw
anchors are provided with the product, kindly check the screws are suitable
for the type of wall in which the hood is to be fixed.
IEC227 North America
L=live Brown Black
N=neutral Blue White
E=earth Green/Yellow Green

• FIXING THE DECORATIVE TELESCOPIC FLUE
Arrange the electrical power supply within the dimensions of the decorative
flue. If your appliance is to be installed in the ducting version or in the
version with external motor, prepare the air exhaust opening. Adjust the
width of the support bracket of the upper flue (Fig.3). Then fix it to the
ceiling using the screws A (Fig.2) make sure that it is in line with your hood
and respecting the distance from the ceiling indicated in Fig.2. Connect the
flange C to the air exhaust hole using a connection pipe (Fig.4).
To transform the hood from a ducting version into a filtering version, ask
your dealer for the charcoal filters and please follow the installation
instructions.
• FILTERING VERSION
Install the hood and the two flues as described in the paragraph for
installation of the hood in ducting version. To assemble the filtering flue
refers to the instructions contained in the kit. If the kit is not provided, please
order it from your dealer. The charcoal filters must be fitted in the ducting
unit located inside the hood.
USE AND MAINTENANCE
• It is recommended to operate the appliance prior to cooking.
It is recommended to leave the appliance in operation for
15 minutes after cooking is terminated in order to completely eliminate
cooking vapors and odours.
The proper function of the cooker hood is conditioned by the regularity of
the maintenance operations, in particular, the active carbon filter.
• The anti-grease filters capture the grease particles suspended in the air, and
are therefore subject to clogging according to the frequency of the use of the
appliance.
In order to prevent fire hazard, it is recommendable to clean the filter at a
maximum of 2 months by carrying out the following instructions:
- Remove the filters from the cooker hood and wash them in a solution of
water and neutral liquid detergent, leaving to soak.
- Rinse thoroughly with warm water and leave to dry.
- The filters may also be washed in the dishwasher.
Please take note that the aluminum panels may alter in color after several
washes.

• The active carbon filters purify the air that is replaced in the environment.
The filters are not washable or reuseable and must be replaced at maximum
every four months. The saturation of the active carbon filter depends on the
frequency of use of the appliance, also by the type of cooking and the
regularity of cleaning on the anti-grease filters. (Fig 6) To remove the
charcoal filters place our hand on one filter at a time and turn it toward the
front part. The charcoal filter can now be removed. Always ensure to replace
both filters at the same time.
• Clean the fan and other surfaces of the cooker hood regularly using a cloth
moistened with denatured alcohol or non abrasive liquid detergent.
• The illumination installation is designed for use during cooking and not for
prolonged general illumination of the environment. Prolonged use of the
illumination installation notably reduces the duration of the bulb.
Use a one-edged screwdriver or any other appropriate tool to lift and remove
the overhead light fixture. Replace the damaged lamp. Use only halogen
lamps as the original specification, avoiding contact with hands. Return the
light fixture to its position (snap fastening). (Fig. 7)
• How to replace the charcoal filters：
(1) Push the right middle corner on the glass of the decoration door (Fig.A),
the decoration door will open (Fig.B).
(2) Take out the aluminum filter (Fig.C);
(3) Push the clips on the charcoal filters and then pull back, then the charcoal
filters can be taken down (Fig.D).
Fig.A Fig.B

Fig.C Fig.D
• FUNCTION KEYS: (Fig.8)
A = OFF
B = SPEED I / OFF
C = SPEED II / OFF
D = SPEED III / OFF
E = LIGHT
• If your appliance does not have the INTENSIVE speed function, press key
A for two seconds and it will be activated for 15 minutes after which it will
return to the previously set speed. If the function program of the unit is
active the LED will flash.
By pressing any key except the key for the light, the hood will return
immediately to its normal functioning.
The “automatic stop timer” mode delays stopping operation of the hood,
the mode will continue functioning for 15 minutes at the operating speed
set at the time this function is activated.
FUNCTION KEYS: (Fig.10)
A == OFF
B == SPEED 1/“－”Control
C == SPEED 2/“＋”Control
D == SPEED 4
E == LIGHT
By pressing key B、C or D individually, the speed for each key will be the
same as above table. At the same time indicated light will flash on the each
function key button. To stop the speed function press key A.
If Speed 3 is required，press key C adjust“＋”. At Speed 3 program both key
B and key C indication light will flash on each function key button.
To on the light press key E. To off the light press key E again.
•
FUNCTION KEYS
:
(Fig.9)
A= TIMER – 15 MINUTES
B= SPEED I
C= SPEED II
D= SPEED III
E =LIGHT

FUNCTION KEYS: (Fig.11)
A == Automatic Stop Timer —15 minutes
B == Speed 1/“－”Control
C == Speed 2/“＋”Control
D == Speed 4
E == Light
By pressing key B、C or D individually, the speed for each key will be the
same as above table. At the same time indicated light will flash on the each
function key buttons. To stop the speed function press key A.
If Speed 3 is required，press key C adjust“＋”. At Speed 3 program both key
B and key C indication light will flash on each function key button.
To on the light press key E. To off the light press key E again.
When the appliance and light are ON together or separately, press key A the
Automatic Stop Timer will start the 15 minutes count down. Indication light
on the key A button will flash for the duration. To stop the Automatic Stop
Timer Function before 15 minutes time frame, press key A again.
• FUNCTION KEYS :( Fig.14)
A= Filtering system / Set clock
B= Delay Timer
C= Speed S1/ “-” adjust / off
D= Digital display
E= Speed S1/ “+” adjust / off
F= Alarm
G= Light
When the Key A is flashing, at the same time “ ”is flashing on the
digital display, it reminds the user to clean the filters. After the filter has
been cleaned assemble back. Press key A till the light is off and the unit is
back to setting function again.
When pressing key A for 3 seconds, the clock “ ”on the digital
display will flash, press key A to switch the mode function to set hours
and minutes, and then press key C or E to set the correct time. The
Clock’s system is 24 hours.
When the motor is on, press key B the light will on. At the same time
“ ” will flash on the digital display，and to press key B to
switch the function mode to set hours and minutes. To set the time to
automatically shut off, key C or E has to be pressed. Press key B for 3

seconds to stop the delay timer.
Press key C or E, to start the first speed, and it shows “ ” on the digital
display，and to press key C once again to turn off. To run the 2
nd
, 3
rd
and “Turbo” speed, press Key E. If the “Turbo”speed is on, press key
E once again to turn off; and by pressing key C the speed can be
adjusted down from 3
rd
, 2
nd
and 1
st
.
Press key F light will flash, and it shows“ ” flashing on the
digital display，to press key F again to switch to set hours and minutes
mode. To set the alarm press key C or E. To stop the alarm, press the key
F. And to cancel the alarm set, press the key F for 3 seconds.
Press key G light will on, and symbol “ ” display on the digital screen,
and press key G again to turn off the light.
•FUNCTION KEYS: (Fig.15)
A= Timer (automatic shut off)
B= Speed 1 / adjust / switch off
C= digital display screen (showing timer and speed)
D= Speed 3 / adjust / switch off
E= Light
When key A is being pressed, digital display screen will show "15 minutes"
for timer whereas the minutes can be adjusted by pressing "+" or "-" on key
B and D. When the first speed is on, pressing key A once to switch off, the
digital display will shows "00" on the screen
When key B is being pressed, it shows "F1" on the digital display screen at
the same time first speed is on. By pressing key B again to switch off,
the digital display will show "00" on the screen.
When key D is being pressed, it shows "F3" on the digital display screen at
the same time the third speed is on. By pressing key D again to switch off,
the digital display will show "00" on the screen.
The second speed F2 and Turbo speed F4 can be adjusted by pressing key B
or D. When key E is being pressed, the light will on, by pressing key E again
is to switch off the light.
If the motor and light are operating together or only the motor is working,
pressing key A, automatic switch off timer mode will get on. In other word
the unit will delay 15 minutes to turn off the motor and the light. To press
key B or key D is to adjust the time, whereas to press key A again is to stop
the timer.
Troubleshooting

Problem Possible reason Solution
Hood doesn’t work Electric supply Check whether the plug is connected
Check whether the main switch is
turned on
Poor airflow Aluminum grease filters
clogged
Clean the filters, assembly back
when dry
Charcoal filters clogged Replace the charcoal filters
Motor running
without air flow
Butterfly valve jammed Contact technician
After running for a
while, motor stop
working
High temperature safety
device activated
The kitchen is not sufficiently
ventilated
The hood is being
installed too near to the
cooking stove
The hood must be least 65cm of
distance from the stove
Strong cooking
smell
Charcoal filters do not
install
In re-circulating mode, charcoal
filters must be installed
Oil dripping onto
stove
Oil cup missing or not
installed
Replace aluminum filter and replace
oil cup
Aluminum grease filter
saturated
Wash the aluminum grease filters
Whirring sound Fan blade problem Contact with technician
THE MANUFACTURORY DECLINES ALL RESPONSIBILITY FOR
EVENTUAL DAMAGES CAUSED BY BREACHING THE ABOVE
WARNINGS.

Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm to
the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
Warranty Information
The manufacturer provides warranty in accordance with the legislation
of the customer's own country of residence, with a minimum of 1 year
(Germany: 2 years), starting from the date on which the appliance is
sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized
service centre. When making a claim under the warranty, the original
bill of purchase (with purchase date) must be submitted.
The warranty will not apply in cases of:
- Normal wear and tear
- Incorrect use, e.g. overloading of the appliance, use of non-approved
accessories
- Use of force, damage caused by external influences
- Damage caused by non-observance of the user manual, e.g. connection
to an unsuitable mains supply or non-compliance with the installation
instructions
- Partially or completely dismantled appliances
