RiverRidge LADDER SPACESAVER 06-098 User manual

ITEM#: 06-098 White
ITEM#: 06-099 Gray
ASSEMBLY INSTRUCTIONS
ADULT ASSEMBLY REQUIRED
WARNING
SEE FULL WARNING ON PAGE 2
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
Young children can be seriously injured or killed if furniture tips over.
Don’t use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.
RiverRidge®Ladder Spacesaver

THIS SHELF UNIT WILL HOLD UP TO 20 POUNDS PER SHELF OR A TOTAL OF 60 POUNDS.
DO NOT LOAD EACH SHELF WITH MORE THAN 20 POUNDS OR 60 POUNDS TOTAL WEIGHT.
IF OVERLOADED WITH MORE THAN 20 POUNDS PER SHELF OR 60 POUNDS TOTAL
WEIGHT, SHELF MAY TIP FROM WALL AND CAUSE SERIOUS INJURY OR DEATH.

PARTS LIST
NO QTY DESCRIPTION
1 1PC
2 1PC
3 1PC
4 1PC
5 1PC
6 1PC
7 1PC
8 1PC
9
11
1PC
1PC
Top Shelf Left Rail Board
Top Shelf Right Rail Board
Middle Shelf Left Rail Board
Middle Shelf Right Rail Board
Bottom Shelf Left Rail Board
Bottom Shelf Right Rail Board
Top Shelf
Middle Shelf
Bottom Shelf
10 3PCS Rear Rail Board
Bottom Rear Cross Bar
Upper Right Side Frame
Upper Left Side Frame
12 1PC
13 1PC
Bottom Right Side Frame
14 1PC
Bottom Left Side Frame
15 1PC

TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
A16PCS Wood Dowel
B8PCS Screw (4x45mm)
C12PCS
D
1PC
E
F
Adjustable Anchor Bracket
G1PC
H
27PCS
1PC
Screw (3.5x25mm)
Machine Screw (6x20mm)
Plastic Anchor
1PC Screw (4x8mm)
Screw (4x30mm)
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
PARTS LIST
NO PARTS QTY DESCRIPTION

STEP 1
STEP 2
1. Insert 1 screw (D) through hole on top shelf left rail board (1) and tighten to rear rail board (10).
2. Repeat above step to assemble top shelf right rail board (2) to rear rail board (10).
1. Insert 1 screw (D) through hole on middle shelf left rail board (3) and tighten to rear rail
board (10).
2. Repeat above step to assemble middle shelf right rail board (4) to rear rail board (10).

STEP 3
STEP 4
1. Insert 1 screw (D) through hole on bottom shelf left rail board (5) and tighten to rear rail
board (10).
2. Repeat above step to assemble bottom shelf right rail board (6) to rear rail board (10).
1. Insert 4 wood dowels (A) into wood dowel holes on top shelf (7).
2. Attach top shelf (7) to pre-assembled rail boards (1, 2, 10) by inserting wood dowels (A) into
wood dowel holes on rail boards (1, 2, 10).
3. Insert 7 screws (D) through holes on top shelf (7) and tighten to rail boards (1, 2, 10).
4. Attach adjustable anchor bracket (H) to top shelf (7) by inserting 1 screw (F) through hole on
adjustable anchor bracket (H), then tighten to top shelf (7).

STEP 5
STEP 6
1. Insert 4 wood dowels (A) into wood dowel holes on middle shelf (8).
2. Attach middle shelf (8) to pre-assembled middle shelf rail boards (3, 4, 10) by inserting wood
dowels (A) into wood dowel holes on middle shelf rail boards (3, 4, 10).
3. Insert 7 screws (D) through holes on middle shelf (8) and tighten to middle shelf rail
boards (3, 4, 10).
1. Insert 4 wood dowels (A) into wood dowel holes on bottom shelf (9).
2. Attach bottom shelf (9) to pre-assembled bottom shelf rail boards (5, 6, 10) by inserting wood
dowels (A) into wood dowel holes on bottom shelf rail boards (5, 6, 10).
3. Insert 7 screws (D) through holes on bottom shelf (9) and tighten to bottom shelf rail boards
(5, 6, 10).

STEP 7
1. Insert 2 wood dowels (A) into wood dowel holes on upper left side frame (13).
2. Attach upper left side frame (13) to bottom left side frame (15) by inserting wood dowels (A)
into wood dowel holes on bottom left side frame (15).
3. Insert 2 screws (B) through holes on bottom left side frame (15) and tighten to upper left
side frame (13).
4. Repeat above steps to assemble upper right side frame (12) to bottom right side frame (14).
1. Attach pre-assembled top shelf (7) and rail boards to upper right side frame (12) by inserting
2 machine screws (C) through holes on top shelf right rail board (2) and tighten to upper right
side frame (12).
2. Repeat above step to assemble middle shelf (8) and bottom shelf (9) to upper right side
frame (12).
3. Attach bottom rear cross bar (11) to bottom right side frame (14) by inserting 2 screws (B)
through holes on bottom right side frame (14) and tighten to bottom rear cross bar (11).
STEP 8

STEP 9
STEP 10
1. Attach pre-assembled shelves and rail boards to upper left side frame (13) by inserting
2 machine screws (C) through holes on each left rail board (1, 3, 5) and tighten to upper left
side frame (13).
2. Attach bottom rear cross bar (11) to bottom left side frame (15) by inserting 2 screws (B)
through holes on bottom left side frame (15) and tighten to bottom rear cross bar (11).
Option #1: Securing to Drywall
1. Position spacesaver against wall in desired location. Using a pencil, make small mark on wall through
hole on bracket (H). Move spacesaver away from wall and screw 1 plastic anchor (G) into wall on
pencil mark.
2. Place spacesaver against wall, insert 1 screw (E) through hole on bracket (H), then tighten to plastic
anchor (G).
Option #2: Securing to Drywall and Wood Stud
1. Position spacesaver against wall in desired location. Insert 1 screw (E) through hole on bracket (H),
then tighten through drywall and into wood stud.
*Tip: Anchor bracket (H) can be adjusted to correct distance from wall to cabinet as needed. Once adjusted,
be sure to re-tighten bracket inside cabinet for stability.
11

ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure youritem is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

Enjoy your new RiverRidge®Spacesaver!
To order replacement parts at no cost to you,email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016
Thank you for purchasing this RiverRidge®Home item. We hope you
enjoy it and consider purchasing other RiverRidge®items.
