RiverRidge X-FRAME 06-001/16-018 User manual

ASSEMBLY INSTRUCTIONS
RiverRidge® X-FRAME 4 SHELF TOWER
ITEM# 06-001
/16-018 WHITE
ITEM# 06-002/16-019 ESPRESSO
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be
taken in unpacking and assembling this item to keep small parts away from children.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over.
Don’t use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

Send requests for missing or damaged parts replacements by email to:
[e-mail] or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 100 POUNDS.
DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS. IF LOADED WITH MORE THAN 25
POUNDS PER SHELF AS THIS MAY CAUSE DAMAGE TO THE SHELF AND MAY CAUSE SERIOUS
INJURY OR DEATH.

PARTS LIST
NO PARTS QTY DESCRIPTION
1 1PC TOP BOARD
2 2PCS SIDE FRAME
3 3PCS SHELF
4 1PC BACK CROSS BAR
5 1PC FRONT CROSS BAR
A 16PCS LONG WOOD SCREW 5x45mm
B 4PCS WOOD SCREW 4x35mm
C 16PCS PLASTIC CAP
D
2PCS WOOD SCREW 4x40mm
E 2PCS PLASTIC ANCHOR
F 1PC ALLEN WRENCH
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOTINCLUDED)
THE USE OF POWER SCREWDRIVER IS NOTRECOMMENDED

STEP 1
STEP 1
1. Place top board (1) upside down on soft padded surface.
2. Attach back cross bar (4) to top board (1) by inserting 2 wood screws (B) through holes on back
cross bar (4) and tighten to top board (1).
3. Repeat above step to assemble front cross bar(5).
STEP 2
STEP 2
1. Attach top board (1) to side frame (2) by inserting 2 long wood screws (A) through holes on side
frame (2) and tighten to back cross bar (4) and front cross bar (5) by using Allen wrench (F).
When tightening, slightly push screw in to catch inner thread.
2. Attach 1 shelf (3) to side frame (2) by inserting 2 long wood screws (A) through holes on side
frame (2) and tighten to the shelf (3) using Allen wrench (F). When tightening, slightly push
screw in to catch inner thread.
3. Repeat above step to assemble other 2 shelves(3).

STEP 3
STEP 3
1. Attach other side frame (2) to top board (1) by inserting 2 long wood screws (A) through holes on
side frame (2) and tighten to front and back cross bars (4 &5). When tightening, slightly push
screw in to catch inner thread.
2. Insert 6 long wood screws (A) through holes on side frame (2) and tighten long wood screws (A)
into each shelf (3). When tightening, slightly push screw in to catch inner thread.
STEP 4
STEP 4
1. Press 8 plastic caps (C) into wood screw holes on 1 side frame (2). If added pressure is needed
to keep plastic cap in place – cover cap with a piece of paper and tap lightly with hammer to
secure cap.
2. Press another 8 plastic caps (C) into wood screw holes on other side frame(2).

STEP 5
STEP 5
1. Use template drawing (included) to drill 2 holes on and insert 2 plastic anchors (E) into holes on
wall.
2. Insert 2 wood screws (D) through holes on back cross bar (4) and tighten to plastic anchors (E).

ENJOY YOUR NEW RiverRidge® CABINET NOW!
Attention Adults: Cabinet should be checked periodically for damage or loose screws/parts. Take
appropriate action necessary to correct hazards such as tightening of screws and taking any
damaged parts away from children.
Warning Please make sure your item is secured to the wall, per
assembly instructions.
Thank you for purchasing this RiverRidge® Home Products item. We hope you enjoy it and
consider purchasing other RiverRidge®items.
Send requests for missing or damaged parts replacements by email to:
[e-mail] or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI54016.
