Roban Airwolf Compactor User manual


C
o
om

A
i
mp
CCPMS
C
i
r
w
pa
C
ALERC
H
w
ol
f
ac
H
ELICOP
T
f
ct
T
ER
t
o
r
Ma
r

nual





Copyright@2013 - Roban Limited – All rights reserved

Compactor700Manual–Airwolf
Release1.0‐December2013

RobanLimited
DryriverIndustrialZone,VentureCrossRd.
Jiaolian,WanjiangCityDistrictofDongguan,
523046DongguanCounty(GD)‐PRC


SPECIFICATIONS
Bodylength:  1790mm
Width:   580mm
Height:   510mm
Mainrotordiameter:  15mm
Mainbladelength:  750mm
Tailrotordiameter:  280mm
Tailbladelength:  105mm
Mainshaftdiameter:  12mm
Tailshaftdiameter:  5mm
Spindlediameter:  8mm
Batterycompartment:  120x60x180mm
Motor:*   1x750MX530KVbrushlessoutrunner,12Scapable
Speedcontroller:* 1x120Abrushless,12Scapable
Servo:*   3xmetalgearcyclic,1xmetalgeartailservo
Battery:* 44.4V5000mAh35C+
Flighttime:   5minutes
Takeoffweight:  8500g
FlightStabilization:* 3axisflybarlessgyro
RadioControl:*  min.6channelwithpitchandthrottlecurves

*)Optionallyavailableequipment


TheCompactorisahighperformanceradiocontrolledscalehelicopter.
Ourgoalwastocreateasimple,highperformancehelicopter,withaminimumofmechanicalcomponentsandsimplemaintenance.
Pleasereadthisusermanualcarefully,itcontainsinstructionsforthecorrectassemblyofthemodel.
Pleaserefertothewebsitewww.robanmodel.comforupdatesandotherimportantinformation.
Thankyouforyourpurchase,andhaveagreattimewithyourCompactor!
RobanLimited



Copyright@2013 - Roban Limited – All rights reserved
IMPORTANTNOTES

*Thisradiocontrolledhelicopterisnotatoy.
*Thisradiocontrolledhelicoptercanbeverydangerous.
*Thisradiocontrolledhelicopterisatechnicallycomplexdevicewhichhastobebuiltandhandledverycarefully.
*Thisradiocontrolledhelicoptermustbebuiltfollowingtheseinstructions.Thismanualprovidesthenecessaryinformation
tocorrectlyassemblethemodel.Itisnecessarytocarefullyfollowalltheinstructions.
*Inexperiencedpilotsmustbemonitoredbyexpertpilots.
*Alloperatorsmustwearsafetyglassesandtakeappropriatesafetyprecautions.
*Aradiocontrolledhelicoptermustonlybeusedinopenspaceswithoutobstacles,andfarenoughfrompeopletominimize
thepossibilityofaccidentsorofinjurytopropertyorpersons.
*Aradiocontrolledhelicoptercanbehaveinanunexpectedmanner,causinglossofcontrolofthemodel,makingitvery
dangerous.
*Lackofcarewithassemblyormaintenancecanresultinanunreliableanddangerousmodel.

*NeitherRobanLimitednoritsagentshaveanycontrolovertheassembly,maintenanceanduseofthisproduct.Therefore,no
responsibilitycanbetracedbacktothemanufacturer.YouherebyagreetoreleaseRobanLimitedfromanyresponsibilityor
liabilityarisingfromtheuseofthisproduct.

SAFETYGUIDELINES

*Flyonlyinareasdedicatedtotheuseofmodelhelicopters.
*Followallcontrolproceduresfortheradiofrequencysystem.
*Itisnecessarythatyouknowyourradiosystemwell.Checkallfunctionsofthetransmitterbeforeeveryflight.
*Thebladesofthemodelrotateataveryhighspeed;beawareofthedangertheyposeandthedamagetheymaycause.
*Neverflyinthevicinityofotherpeople.



NOTESFORASSEMBLY
Pleaserefertothismanualforassemblyinstructionsforthismodel.
Followtheorderofassemblyindicated.Theinstructionsaredividedintochapters,whicharestructuredinawaythat
eachstepisbasedontheworkdoneinthepreviousstep.Changingtheorderofassemblymayresultinadditionalor
unnecessarysteps.
Usethreadlockersandretainingcompoundsasindicated.Ingeneral,eachboltorscrewthatengageswithametalpart
requiresthreadlock.
Factorypre‐assembledcomponentshavebeenassembledwithalltherequiredthreadlockandlubricants,
andhavepassedqualitycontrol.Itisnotnecessarytodisassembleandre‐assemblethem.
Wedonotrecommendtheuseofthincyanoacrylateglueforsurfacemountofpaintedparts.Thefumesofthecuringglueleave
whitestainsontheclearcoat,whicharehardtoremove.

