Roban Apache AH-64D User manual



ApacheAH‐64D
including
SM2.0 mechanics 
Manual



CCPMSCALERCHELICOPTER

Copyright@2015 - Roban Limited – All rights reserved

SuperScale700Manual–AH‐64D
Release2.0‐Jan2015

RobanLimited
ZhengyacunIndustrialZone,VentureCrossRd.
Jiaolian,WanjiangCityDistrictofDongguan,
523046DongguanCounty(GD)‐PRC




SPECIFICATIONS
Bodylength:  1692mm
Width:620mm
Height:435mm
Mainrotordiameter:  1560mm
Mainbladelength:  700mm
Tailrotordiameter:  280mm
Tailbladelength:  105mm
Mainshaftdiameter:  12mm
Tailshaftdiameter:  5mm
Spindlediameter:  8mm
Batterycompartment:  120x60x180mm
Motor:*1x750MX450KVbrushlessoutrunner,12Scapable
Speedcontroller:* 1x120Abrushless,12Scapable
Servo:*3xmetalgearcyclic,1xmetalgeartailservo
Battery:* 44.4V5000mAh35C+
Flighttime:   5minutes
Takeoffweight:  8500g
FlightStabilization:* 3axisflybarlessgyro
RadioControl:*  min.6channelwithpitchandthrottlecurves

*)Optionallyavailableequipment


TheCompactorisahighperformanceradiocontrolledscalehelicopter.
Ourgoalwastocreateasimple,highperformancehelicopter,withaminimumofmechanicalcomponentsandsimplemaintenance.
Pleasereadthisusermanualcarefully,itcontainsinstructionsforthecorrectassemblyofthemodel.
Pleaserefertothewebsitewww.robanmodel.comforupdatesandotherimportantinformation.
Thankyouforyourpurchase,andhaveagreattimewithyourCompactor!
RobanLimited



Copyright@2015 - Roban Limited – All rights reserved
IMPORTANTNOTES

*Thisradiocontrolledhelicopterisnotatoy.
*Thisradiocontrolledhelicoptercanbeverydangerous.
*Thisradiocontrolledhelicopterisatechnicallycomplexdevicewhichhastobebuiltandhandledverycarefully.
*Thisradiocontrolledhelicoptermustbebuiltfollowingtheseinstructions.Thismanualprovidesthenecessaryinformation
tocorrectlyassemblethemodel.Itisnecessarytocarefullyfollowalltheinstructions.
*Inexperiencedpilotsmustbemonitoredbyexpertpilots.
*Alloperatorsmustwearsafetyglassesandtakeappropriatesafetyprecautions.
*Aradiocontrolledhelicoptermustonlybeusedinopenspaceswithoutobstacles,andfarenoughfrompeopletominimize
thepossibilityofaccidentsorofinjurytopropertyorpersons.
*Aradiocontrolledhelicoptercanbehaveinanunexpectedmanner,causinglossofcontrolofthemodel,andmakeitavery
dangerousflyingobject.
*Lackofcarewithassemblyormaintenancecanresultinanunreliableanddangerousmodel.

*NeitherRobanLimitednoritsagentshaveanycontrolovertheassembly,maintenanceanduseofthisproduct.Therefore,no
responsibilitycanbetracedbacktothemanufacturer.YouherebyagreetoreleaseRobanLimitedfromanyresponsibilityor
liabilityarisingfromtheuseofthisproduct.

SAFETYGUIDELINES

*Flyonlyinareasdedicatedtotheuseofmodelhelicopters.
*Followallcontrolproceduresfortheradiofrequencysystem.
*Itisnecessarythatyouknowyourradiosystemwell.Checkallfunctionsofthetransmitterbeforeeveryflight.
*Thebladesofthemodelrotateataveryhighspeed;beawareofthedangertheyposeandthedamagetheymaycause.
*Neverflyinthevicinityofotherpeople.



NOTESFORASSEMBLY
Pleaserefertothismanualforassemblyinstructionsforthismodel.
Followtheorderofassemblyindicated.Theinstructionsaredividedintochapters,whicharestructuredinawaythat
eachstepisbasedontheworkdoneinthepreviousstep.Changingtheorderofassemblymayresultinadditionalor
unnecessarysteps.
Usethreadlockersandretainingcompoundsasindicated.Ingeneral,eachboltorscrewthatengageswithametalpart
requiresthreadlock.
Factorypre‐assembledcomponentshavebeenassembledwithalltherequiredthreadlockandlubricants,
andhavepassedqualitycontrol.Itisnotnecessarytodisassembleandre‐assemblethem.
Wedonotrecommendtheuseofthincyanoacrylateglueforsurfacemountofpaintedparts.Thefumesofthecuringglueleave
whitestainsontheclearcoat,whicharehardtoremove.


Copyright@2015 - Roban Limited – All rights reserved
1 – Elevated tail gearbox 2 – Short tail tube

3 – Short torque tube

4 – Ball links x4

5 – Tail boom clamp

6 – Main Frame

7 – Motor pulley

8 – Short tail pushrod

9 – Tail rotor assy

10 – Main rotor assy

11 – Tail servo holder x2

12 – Tube Bearings x2


13 – Tail servo holder

14 – Pushrod supports x3

15 – Main rotor blades x4

16 – Long torque tube

17 – Long tail boom

18 – Long tail pushrod

19 – Tail boom supports

20 – Tail rotor blades x4

21 – Transparent washer 22 – Screw M3x20 x2 23 – Screw M4x10 x4 
24 – Washer M4 x4

25 – Washer M3 x8 

26 – Motor shaft support

27 – Support holders x3

28 – Washer M6 x3


29 – Panhead screw M3x10
x3


30 – L brackets x4

31 – Screw M3x10 x6

32 – M3 Nyloc Nut x4

33 – Ball links x4
 
34 – Nut M2 x4

35 – Screw A3x16 x4

36 – Screw A1.7x7 x6

CONTENTS:

Copyright@2015 - Roban Limited – All rights reserved
37 – Wooden washers x6

38 – Screw M3x10 x3

39 – Washer M3 x8



40 – Screw M3x22 x2
41 – Screw M3x35 x2

42 – Nyloc Nut M3 x3

43 – Sleeve 3x4x11 x2

44 – Sleeve 3x4x6.5 x2

45 – Screw M3x12

46 – Screw M3x14

47 – Screw M3x16

48 – Hinge

49 – Stub wing set

50 – Weapon holder set

51 – Rocket station set

52 – Rocket pod set

53 – Tail wing

54 – Scale part

55 – Scale part


56 – Scale part

57 – Scale part

58 – Scale part

59 – Scale part

60 – Scale part

61 – Scale part

62 – Scale part

63 – Scale part

64 – Scale part

65 – Scale part

66 – Scale part

67 – Scale part

68 – Scale part

69 – Scale part

70 – Scale part

71 – Cockpit Lever

72 – Scale part


Copyright@2015 - Roban Limited – All rights reserved
73 – Scale part

74 – Scale part

75 – Scale part

76 – Scale part

77 – Scale part

78 – Scale part

79 – Scale part

80 – Scale part

81 – Scale part

82 – Scale part

83 – Scale part

84 – Wooden holders x2
  
85 – Wooden holders x2

86 – Wooden holders x2

87 – Wooden holders x2

88 – Wooden holders x1
89 – Scale part 90 – Scale part 91 – Scale part 92 – Scale part
93 – Scale part 94 – Scale part 95 – Scale part

96 – Scale part
97 – Scale part 98 – Scale part

99 – Scale part 2x42x13 100 – Scale part 2x24x22
101 – Scale part 2x22x28 102 – Scale part 2x33x23 103 – Scale part 2x29x29 104 – Scale part 2x25x24
105 – Scale part 1.5x29x17 106 – Front landing gear 107 – Aft landing gear 108 – Scale part

Copyright@2015 - Roban Limited – All rights reserved
109 – Scale part 110 – EVA tail rubber 111 – LED controller 112 – LED light green
113 – LED light red 114 – prolonging wire 115 – Decal set



ADDITIONALCOMPONENTSREQUIRED
*ElectricMotor:
12S–450KV750MX,orsimilar
pinionshaftdiameter6mm
*Speedcontroller:
minimum120Atobesafe
*Batteries:10‐12S4000‐5000mAh
*1flybarless3axiscontrolunit,suitableforscaleflying
*Radiopowersystem
*3cyclicservos
*1tailrotorservo
*6channelradiocontrolsystemon2.4GHz

TOOLS,LUBRICANTS,ADHESIVES
*Genericpliers
*Hexagonaldriver,size1.5,2,2.5,3,4mm
*4mmT‐Wrench
*5.5mmSocketwrench(forM3nuts)
*8mmHexforkwrench(forM5nuts)
*Mediumthreadlocker(eg.Loctite243)
*Strongretainingcompound(eg.Loctite648)
*Spraylubricant(eg.Try‐FlowOil)
*Syntheticgrease(eg.Tri‐FlowSyntheticGrease)
*Cyanoacrylateadhesive
*PitchGauge(forset‐up)
*Solderingequipment(formotorwiring)
Inside the main box there are:
Insidethemainbox:
Bag1:Manual
Box2:Fuselage
Box3:TailWings
Box4:Scaleparts,Accessories
Box5:Boom,Blades,Tailblades,Rods
Box6:Mechanics











Copyright@2015 - Roban Limited – All rights reserved




AssemblyScaleFuselage
Priortoinstallingthemechanicsintothefuselage,pleasepreparethefuselageaccordingtothefollowingsteps.Installationintothe
fuselagemostofthehelicoptermechanicbecomeinaccessible.Thelandinggearhastobeinstalledfirst.Asyouwillhavetoturnthe
mechanicsover,pleasemakesurethatyouarenotscratchingthepaintbyusingaoldblanketorarigwhileworkingonit.

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved





Copyright@2015 - Roban Limited – All rights reserved
Explodedviewofthemachinegun:


Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved

Copyright@2015 - Roban Limited – All rights reserved
