Roberts Blutube 50 User manual

Please read this manual before use
ROBERTS
DAB / DAB+ / FM Bluetooth stereo digital radio
Enjoy Listening

Controls ........................................................................... 2-3
Using the radio for the first time...........................................4
Operating your radio............................................................5
Selecting a station - DAB.....................................................6
Secondary services - DAB...................................................7
Display options - DAB...................................................... 7-8
Finding new stations - DAB .................................................9
Manual tuning - DAB .........................................................10
Dynamic Range Control (DRC) - DAB...............................11
Prune stations - DAB.........................................................12
Operating your radio - FM auto-tune .................................13
Manual tuning - FM............................................................14
Display options - FM..........................................................15
Scan sensitivity setting - FM..............................................16
Stereo / Mono setting - FM................................................17
Presetting stations.............................................................18
Recalling a preset station ..................................................19
Bluetooth mode ........................................................... 20-23
Connecting Bluetooth devices...........................................21
Playing audio files in Bluetooth mode................................22
Disconnecting a Bluetooth device .....................................23
Setting the alarm times................................................ 24-26
Contents
When the alarm sounds.....................................................27
Cancelling alarms..............................................................27
Snooze function.................................................................27
Disable alarms...................................................................28
To view the alarm settings .................................................28
Sleep function....................................................................29
Setting the clock format.....................................................30
Setting the clock manually........................................... 31-32
Automatically updating the clock .......................................33
Clock display .....................................................................34
Display backlight dimmer...................................................34
Software version................................................................35
Language function.............................................................36
System reset......................................................................37
Headphone socket.............................................................38
Auxiliary input socket.........................................................39
USB socket for iPhone or smart phone charging ..............40
Software upgrades ............................................................40
Cautions ............................................................................41
Specifications ....................................................................42
Circuit features ..................................................................42
Guarantee.............................................................Back page
1

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 2
Controls (Top)
1. Tuning / Select / Info control
2. Loudspeakers x 2
3. LCD display
4. Menu button
5. Snooze button
1
7
6 35
14
6. Volume control
7. Mode button
8. Previous button
9. On/Off / Sleep button
10. Play / Pause button
Button operation
Long press
8
9
4
13
12
10 11
2
11. Alarm button
12. Dimmer button
13. Next button
14. Preset button

3
Controls (rear)
15. DAB / FM wire aerial
16. USB socket (for software upgrades only)
17. Charging socket
18. DC input socket
19. Headphone socket
20. Auxiliary input socket
21. Bass speaker
15 16 17 18 19 20
21

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 4
Using the radio for the first time
1. Place your radio on a flat surface.
2. Fully extend the wire aerial located on the rear of your radio. Place
the wire antenna so that it is as straight as possible extending either
above or below the radio.
3. Insert the adaptor plug into the DC socket located on the rear of your
radio. Plug the adaptor into a standard 13 amp mains socket outlet.
The display will show 'WELCOME' for a few seconds. During this time
the radio is scanning to find a DAB radio signal. After a short time the
current time and day will appear on the display.
4. If no signal is found, '0:00' will be displayed. It may be necessary to
relocate your radio to a position giving better reception. You should
then carry out a scan to find stations as described on page 9.
IMPORTANT: The mains adaptor is used as the means of connecting
the radio to the mains supply. The mains socket used for the radio must
remain accessible during normal use. In order to disconnect the radio
from the mains completely, the mains adaptor should be removed from
the mains socket outlet completely.
Characters appearing on the LCD display indicate that the radio is connected
to and powered from the mains supply.

5
Operating your radio
1. Press and release the On/Off button to switch on your radio.
When first switched on, the radio will be in DAB mode. After each use
the radio will remember the mode used and then switch on in that
mode the next time that it is used.
2. If the radio has been used before, the last used station will be selected.
3. If this is the first time that the radio has been used a scan of the Band
III DAB channels will be carried out (depending on whether scanning
was already completed in standby mode). During the scanning process
the display will show the progress of the station search. The number
on the right of the display is the number of stations that have been
found.
4. When the scan is completed the first station (in numeric-alpha order
0...9, A...Z will be selected. The first station in the list of stations found
during scanning will be played. The display will show the station name.
5. If no signals are found then it may be necessary to relocate your radio
to a position giving better reception. You should then carry out a scan
to find stations as described on page 9.
• Your radio has an indicator on the display to indicate the strength
of the DAB radio signal being received.
Note: When first switched on, the radio will set the volume to a moderately
high level, in case the broadcast is very quiet. After you have set the
volume control, the radio will remember the setting that you have applied
for the next time that it is used.
1

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 6
Selecting a station - DAB
1. Press and release the On/Off button to switch on your radio.
2. Press and release the Mode button until the DAB mode is selected.
The display will show the name of the radio station currently selected.
3. Rotate the Tuning control to step through the list of available stations.
4. When the desired station name appears on the display, press and
release the Tuning control to select the station. The radio will select
the new station.
5. Adjust the Volume control to the required setting.
Note: If after selecting a station the station does not connect it may be
necessary to relocate your radio to a position giving better reception.
3,4
1
2
5

7
Secondary services - DAB
1. Certain radio stations have one or more secondary services associated
with them. If a station has a secondary service associated with it then
the secondary service will then appear immediately after the primary
service as you rotate the Tuning control.
2. To tune to the secondary service, press and release the Tuning
control. Most secondary services do not broadcast continually and
if the selected service is not available, the radio will re-tune to the
associated primary service.
Display options - DAB
Your radio has a range of display options when in DAB mode:-
1. Press and release the Tuning / Info control to cycle through the
various options. All display options except the text display will revert
to the clock display after about 10 seconds.
a. Time and day Displays the current time
and day of the week.
b. Date Displays the current date.
c. Station name Displays the DAB station name being
listened to.
a
b
c
1,2
1

If you need any further advice, please call our Technical Helpline on :-
020 8758 0338 (Mon-Fri) 8
i
d
h
Display options DAB - cont
d. Scrolling text Displays scrolling text messages such
as artist/track name, phone in number,
etc.
e. Programme type Displays the type of station being
listened to e.g. Pop, Classic, News, etc.
f. Multiplex Name Displays the name of the DAB multiplex
to which the current station belongs.
g. Frequency Displays the frequency for the
currently tuned DAB station.
h. Bit rate Displays the digital audio bit rate for the
currently tuned DAB station.
i. Signal strength Displays the signal strength for the station
being listened to.The minimum signal
marker shows the minimum required signal
strength for clear DAB reception.
e
f
g

9
Finding new stations - DAB
From time to time, new DAB radio stations may become available. Or you
may have moved to a different part of the country. In this case you may
need to cause your radio to scan for new stations.
1. Press and release the On/Off button to switch on your radio.
2. If needed, press and release the Mode button until the DAB mode is
selected.
3. Press and release the Menu button. The DAB menu will show on the
display.
4. Rotate the Tuning control until the display shows 'SCAN'.
5. Press and release the Tuning control. Your radio will perform a scan
of the Band III DAB channels. As new stations are found, the station
counter on the right-hand side of the display will increase and stations
will be added to the list.
4,5
1
2
3
