Robogo Rapid User manual
USER MANUAL
MODEL: RAPID
ANYWHERE
EVERYWHERE
TABLE OF CONTENTS
Warnings & General information ……………………………………......…....….3-4
Package Content...................................................................................................... 5
Main Parts .................................................................................................................... 6
Technical Parameters ............................................................................................... 7
Opening & Installing .................................................................................................. 8
Operating............................................................................................................... 9-11
Battery & Charging ................................................................................................. 12
Riding ................................................................................................................... 13-14
WARNINGS & GENERAL INFORMATION
3
The responsibility for your ROBOGO e-scooter maintenance is
yours, and will help reduce risks of injuries.
Therefore, read this manual and follow it's instructions, they will help
you avoid these risks.
WARNING!
READ THIS MANUAL!
IMPORTANT INFORMATION
WHY IS IT NECESSARY TO READ THIS USER MANUAL?
This Manual was written to help you to use and maintain your ROBOGO
electric scooter properly.
For your safely and enjoyment from your first ride, it is important for you
to understand your new ROBOGO; its features and performance.
The ROBOGO requires a simple installment before your first ride, please
see instructions.
Before Riding: Ensure that the Folding Lever is firmly locked in place.
WARNINGS & GENERAL INFORMATION
4
DISCLAIMER
GENERAL WARNING
Ensure that the Folding Lever of the folding mechanism is firmly
locking the folding mechanism.
ROBOGO PTY LTD is not liable for any accidental damages related to
the use of this product.
GENERAL WARNING
Always wear a helmet when riding ROBOGO.
Always follow the local laws and regulations.
Never ride your scooter in poor visibility.
Do not do stunts, wheelies or jumps. They will increase your
chances of injury and damage your ROBOGO.
Do not carry passengers.
PACKAGE CONTENT
5
PLEASE CONTACT ROBOGO OFFICE IF THERE ARE ANY MISSING PARTS
In this box you will find:
Scooter Frame
Handle bar Kit
Charger
Installation tool and screw
User manual
MAIN PARTS
6
TECHNICAL PARAMETERS
7
model RAPID
Frame material Aluminum-alloy
Battery range 25-30Km
Charging time (2A) 5-6 Hours
Front wheel (size, tire type) 10" Inflate
Rear wheel(size, tire type) 10.5" Vacuum
Max speed 25-30Km/h
Expanded size 1070x430x1170mm
Folded size 1070x430 x 393mm
Battery 36V/7.8Ah Lithium-ion
Weight 13Kg
Display Battery/Speed gear/ speed/
Distance/Light Control
Motor power (W) 350W
Front brake No
Rear brake E-brake + Disk
Load (Kg) 100Kg
Charging voltage 42V
Front Lights Yes
Rear light Yes
Waterproof IP54
ASSEMBLY INSTRUCTIONS
Check the package contents
carefully and make sure all parts are
in good condition, then take the
scooter out of the box in folding
status.
Screw the brake level with the Allen
Wrench.
Rotate the left handle in a
clockwise direction and the left
hand in an anticlockwise direction
until it is fixed (Note: the right handle
has a reverse screw!)
Tire pressure
(2.5bar / 250 KPA /36PSI)
Note: Maintaining proper tire
pressure allows you a safer,
smoother and faster ride. It will save
battery cycle, and extend tire life.
OPENING / INSTALLING
8
FOLDING & UNFOLDING INSTRUCTIONS
Unfolding:
Step 1: Unclasp the locking clasp from the hook.
Step 2: Turn the steering column to a certain angle to avoid hitting the
protective cover when lifting the steering column up, then push the
column slightly to lock the folding lever into final position.
OPERATING
9
OPERATING
Folding
Step 1: Turn the steering column at a certain degree until the
folding OHYHU is completely away from the protective cover, then
press down the folding OHYHU.
Step 2: Fold down the steering column, align the locking clasp with
the side of the locking hook, then buckle into the locking hook in
parallel.
OPERATING
INTEGRATED INTELLIGENT DASHBOARD
0
4 bars battery status display
Double click the left button to switch
speed mode
Total mileage (km) displayed in non-
riding state. Current speed (km/h)
displayed in riding state.
Short press on left button to turn
on
Long press on left
button to turn off
(in non-riding state)
Long press right button to turn on
and turn off the front light
11
BATTERY & CHARGING
Battery specification
Charging safety & tips
Charging must be conducted in a dry, well ventilated
area, make certain power receptacle is dry, do not
touch power receptacle with wet hands
Use charger provided by the scooter vendor only
First time charging requires 5-7 hours
Connect the charging cable to charging port, then connect the
chargers electric cable to an electrical outlet.
Charging light red - battery is charging, charging Light
turned green - charging is complete.
To maximize battery life, please charge the battery at
least every other month or two days after the last riding
Batteries must be charged in a timely manager.
Neglect to do so can cause the battery over-
discharge which can lead to severe damage to the
batteries
Over Discharge protection
ROBOGO scooter has the internal over-discharge protection,
when the scooter is shut down state /battery is low, the control
system will power off to protect the battery bank, in order to
bypass over-discharge protection, The scooter need to be
charged to wake up, lf the scooter does not wake up 30
minutes charging, contact ROBOGO authorized dealers or
ROBOGO service department.
Specification Details Note
Battery type Lithium-ion battery
Battery operating temp
cannot exceed temp
specified by this table
Charge time varies by
environment and
battery capacity
changes
Charging time 5-7 hours( 36v 7.8Ah)
Rated output voltage 42V
Operating temp Charge: 0~45°C
Operating temp
Storage temp Charge: 0~45°C
Discharge: -20~60°C
Long press on right button to turn on
and turn off the front light.
12
RIDING THE SCOOTER
1. Hold the handle bar
with your hands and
Put your foot on the
accelerator pedal.
Then slide your other
foot to engine the
scooter
2. The harder you press
down on the foot
accelerator, the faster
the speed, conversely,
the slower the speed
3. To slow down the
scooter, disengage
the foot accelerator
and squeeze the
brake handle to
engage the brake
system
Checking list before riding
The ROBOGO scooter involves a few mechanical and electric
setting. Before riding, inspect each component of the scooter
to ensure normal operation.
Below are the points to pay much more attention to:
Be sure the folding lever is locked in place
Check and make sure the handle bar are not in loosen
Check and make sure the tire is properly inflated
Check and make sure the battery is fully charged
Be sure to read the user manual before riding at your first time
How to ride the scooter
13
RIDING THE SCOOTER
Avoid obstacles on
the road
Avoid wading depth
deeper than 10 cm
Do not exceed 150
incline while riding
Do not carry
passengers
Do not ride up
and down stairs
Do not ride by
only one hand
RIDING WARNINGS
14
