Robustel EG9012 User manual

EG9012
KONE Connection 210 (North America)
For 3G/4G Networks
User Guide

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 2/22
Confidential
About This Document
This document provides hardware and software information of the Robustel EG9012 Gateway, including
introduction, installation, configuration and operation.
Copyright©2017 Guangzhou Robustel Technologies Co., Limited.
All rights reserved.
Trademarks and Permissions
, are trademarks of Guangzhou Robustel Technologies Co., Limited. All other
trademarks and trade names mentioned in this document are the property of their respective owners.
Disclaimer
No part of this document may be reproduced in any form without the written permission of the copyright owner.
The contents of this document are subject to change without notice due to continued progress in methodology,
design and manufacturing. Robustel shall have no liability for any error or damage of any kind resulting from the use
of this document.
Technical Support
Tel: [phone]
Fax: [phone]
Email: suppor[email protected]m
Web: www.robustel.com

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 3/22
Confidential
Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data
may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare
when wireless devices such as the gateway is used in a normal manner with a well-constructed network, the
gateway should not be used in situations where failure to transmit or receive data could result in damage of any kind
to the user or any other party, including but not limited to personal injury, death, or loss of property. Robustel
accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received
using the gateway, or for failure of the gateway to transmit or receive such data.
Safety Precautions
General
The gateway generates radio frequency (RF) power. When using the gateway, care must be taken on safety
issues related to RF interference as well as regulations of RF equipment.
Do not use your gateway in aircraft, hospitals, petrol stations or in places where using cellular products is
prohibited.
Be sure that the gateway will not be interfering with nearby equipment. For example: pacemakers or medical
equipment. The antenna of the gateway should be away from computers, office equipment, home appliance,
etc.
An external antenna must be connected to the gateway for proper operation. Only uses approved antenna with
the gateway. Please contact authorized distributor on finding an approved antenna.
Always keep the antenna with minimum safety distance of 20 cm or more from human body. Do not put the
antenna inside metallic box, containers, etc.
RF exposure statements
1. For mobile devices without co-location (the transmitting antenna is installed or located more than 20cm
away from the body of user and nearby person)
FCC RF Radiation Exposure Statement
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and human body.
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open.
Gateway may be used at this time.
Using the Gateway in Vehicle
Check for any regulation or law authorizing the use of cellular devices in vehicle in your country before installing
the gateway.
The driver or operator of any vehicle should not operate the gateway while driving.
Install the gateway by qualified personnel. Consult your vehicle distributor for any possible interference of
electronic parts by the gateway.
The gateway should be connected to the vehicle’s supply system by using a fuse-protected terminal in the
vehicle’s fuse box.
Be careful when the gateway is powered by the vehicle’s main battery. The battery may be drained after
extended period.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 4/22
Confidential
Protecting Your Gateway
To ensure error-free usage, please install and operate your gateway with care. Do remember the following:
Do not expose the gateway to extreme conditions such as high humidity / rain, high temperature, direct sunlight,
caustic / harsh chemicals, dust, or water.
Do not try to disassemble or modify the gateway. There is no user serviceable part inside and the warranty
would be void.
Do not drop, hit or shake the gateway. Do not use the gateway under extreme vibrating conditions.
Do not pull the antenna or power supply cable. Attach/detach by holding the connector.
Connect the gateway only according to the instruction manual. Failure to do it will void the warranty.
In case of problem, please contact authorized distributor.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 5/22
Confidential
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 6/22
Confidential
Industry Canada statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
1) this device may not cause interference, and
2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes:
1) l'appareil ne doit pas produire de brouillage, et
2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
This device and its antenna(s) must not be co-located or operating in conjunction with any other
antenna or transmitter, except tested built-in radios.
Cet appareil et son antenne ne doivent pas être situés ou fonctionner en conjonction avec une autre
antenne ou un autre émetteur, exception faites des radios intégrées qui ont été testées.
The County Code Selection feature is disabled for products marketed in the US/ Canada.
La fonction de sélection de l'indicatif du pays est désactivée pour les produits commercialisés aux
États-Unis et au Canada.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your
body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 7/22
Confidential
Regulatory and Type Approval Information
Table 1: Directives
2011/65/EC Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011
on the restriction of the use of certain hazardous substances in electrical and
electronic equipment (RoHS)
2012/19/EU Directive 2012/19/EU the European Parliament and of the Council
of 4 July 2012 on waste electrical and electronic equipment (WEEE)
Table 2: Standards of the Ministry of Information Industry of the People’s Republic of China
SJ/T
11363-2006
“Requirements for Concentration Limits for Certain Hazardous Substances in Electronic
Information Products” (2006-06).
SJ/T
11364-2006
“Marking for Control of Pollution Caused by Electronic Information Products”
(2006-06).
According to the “Chinese Administration on the Control of Pollution caused
by Electronic Information Products” (ACPEIP) the EPUP, i.e., Environmental
Protection Use Period, of this product is 20 years as per the symbol shown here, unless otherwise
marked. The EPUP is valid only as long as the product is operated within the operating limits
described in the Hardware Interface Description.
Please see Table 3 for an overview of toxic or hazardous substances or elements that might be
contained in product parts in concentrations above the limits defined by SJ/T 11363-2006.
Table 3: Toxic or Hazardous Substances or Elements with Defined Concentration Limits
Name of the Part
Hazardous Substances
(Pb)
(Hg)
(Cd)
(Cr (VI) )
(PBB)
(PBDE)
Metal parts o o o o o o
Circuit modules
x
o
o
o
o
o
Cables and cable assemblies
o
o
o
o
o
o
Plastic and polymeric parts o o o o o o
o:
Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is
below the limit requirement in SJ/T11363-2006.
x:
Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials for this
part might exceed the limit requirement in SJ/T11363-2006.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 8/22
Confidential
Document History
Updates between document versions are cumulative. Therefore, the latest document version contains all updates
made to previous versions.
Date Firmware Version Doc Version Change Description
25 April, 2017 0.10.2 v.1.0.0 Initial release
2 June, 2017
0.11.2
v.1.1.0
Updated:
1. Product picture
2. Input Voltage
3. Power Consumption
4. Packing list
5. Operating temperature
6. LED Indicator
7. 4.1 Generate diagnose file about APN
8. 4.3.1 ISP APN, dial up number

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 9/22
Confidential
Contents
Chapter 1 Product Concept ........................................................................................................................... 10
1.1 Key Features............................................................................................................................................. 10
1.2 Package Contents .....................................................................................................................................11
1.3 Specifications ...........................................................................................................................................11
1.4 Ordering Information ...............................................................................................................................12
1.5 Dimensions...............................................................................................................................................13
Chapter 2 Hardware Installation.................................................................................................................... 14
2.1 LED Indicators...........................................................................................................................................14
2.2 PIN Assignment ........................................................................................................................................15
2.3 Ethernet Ports ..........................................................................................................................................16
2.4 Insert or Remove SIM Card ......................................................................................................................17
2.5 Attach External Antenna (SMA Type).......................................................................................................18
2.6 Mount the Gateway .................................................................................................................................19
2.7 Ground the Gateway ................................................................................................................................20
2.8 Connect the Gateway to a Computer.......................................................................................................20
2.9 Power Supply............................................................................................................................................21

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 10/22
Confidential
Chapter 1 Product Concept
1.1 Key Features
Robustel EG9012 is an industrial gateway designed for monitoring and provides fast, reliable and stable Internet
connectivity.
EG9012 is a powerful gateway developed from RobustOS, a Robustel self-developed and Linux-based operating
system which designed to be used in Robustel hardware gateways. The RobustOS includes basic networking features
and protocols providing users with a custom experience. Meanwhile, Robustel offers a Software Development Kit
(SDK) to partners and customers to allow additional customization by using C or Python or Java, also provides rich
APPs to satisfy fragmented IoT market.
Supports 3G/4G cellular network
Various interfaces: RS232/RS485/Console/USB/Ethernet/FXS
Emergency call and respond via voice interface
Modbus gateway serial protocol Support
RS485 interface supports BACnet protocol
Event output via Email, SMS
Auto reboot via SMS/Incoming Call/Timing
RobustOS + SDK + App
IPsec/OpenVPN/GRE/PPTP/L2TP/DMVPN Support
Support IBM IoT (Bluemix Internet of Things) devices management platform
Support KMC (KONE Monitoring Centre) monitoring platform
Management and upgrading via SMS/Web/CLI/SNMP/RobustLink Cloud
Robust industrial design (9 to 26V DC, desktop or DIN rail mounting)

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 11/22
Confidential
1.2 Package Contents
Before installing your EG9012 Gateway, verify the kit contents as following.
Note: The following pictures are for illustration purposes only, not based on their actual sizes.
1 x Robustel EG9012 KONE Connection 210 (North America)
35 mm DIN rail mounting kit
Note: If any of the above items is missing or damaged, please contact your Robustel sales representative.
1.3 Specifications
Cellular Interface
Standards: W-CDMA/FDD-LTE/TDD-LTE
W-CDMA: max. 14.4Mbps/5.76Mbps (DL/UL)
FDD-LTE: max. 100/50 Mbps (DL/UL)
TDD-LTE: max. 100/50 Mbps (DL/UL)
SIM: 1 (3V & 1.8V)
Antenna interface: SMA female (ANT1+ANT2)
Ethernet Interface
Number of ports: 2 x 10/100 Mbps (LAN1+LAN2)
Magnet isolation protection: 1.5KV
Serial Interfaces
Number of ports: 2 x RS-232, 1 x RS-485
Baud rate: 300bps to 57600bps
RS-232: Tx, Rx, GND
RS-485: A (Data+), B (Data-)

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 12/22
Confidential
Interface: 3.81mm connector
Audio Interface
Physical Connector: 3.81mm 3-PIN terminal block
Interface type: FXS
Interface Standard: ITU Q.512 (SLIC), ITU K.20 (overcurrent and overvoltage protection)
Subscriber line interface circuit (SLIC)
Ring voltage: 40~90 Vpk configurable
Ring frequency: 20~25 Hz
Ring waveform: sinusoidal
Maximum ringer load: 5 ringer equivalence numbers (RENs)
On-hook/off-hook characteristics:
On-hook voltage (tip/ring): -46~-56V;
Off-hook current: 18~20 mA
Terminating impedance: configurable
System
LED indicators: PWR, DEV1, DEV2, NET, RSSI, KMC, ERR
Built-in RTC, Watchdog, Timer
Expansion: 1 x USB 2.0 host up to 480 Mbps
Software
Ne two rk p ro to co ls: PP P, TCP, U DP, D HCP, I CMP, N AT,
DMZ, DDNS, VRRP, HTTP, HTTPs, DNS, ARP, SNTP, Telnet, SNMP etc.
Firewall: SPI, anti-DoS, Filter, Access Control
Serial port: TCP client/server, UDP, Modbus RTU/ASCII to Modbus TCP, Virtual COM (COM port redirector), BACnet
Power Supply and Consumption
Power supply interface: 2-PIN 3.81mm terminal block
Input voltage: 9 to 26 VDC (Overvoltage Protection)
Power consumption: 900mA(MAX)@9V, 600mA(MAX)@12V, 400mA(MAX)@26V
Physical Characteristics
Housing & weight: Metal, 300g
Dimension: (L x W x H): 134mm x 98mm x 32mm
Installation: 35mm DIN rail
Normal Operating Temperature: -30~+70°C,
Extended Operating Temperature: -40~-30°C, +70~+85°C
Humidity: 5~95%RH
1.4 Ordering Information
Model No.
Description
Frequency
Operating Environment
EG9012-4LB Gateway, 4G
module
4G:B2/4/5/13/17
3G:B2/5
Normal Operating
Temperature: -30~+70°C

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 13/22
Confidential
Extended Operating
Temperature: -40~-30°C,
+70~+85°C
Humidity: 5~95%RH
1.5 Dimensions

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 14/22
Confidential
Chapter 2 Hardware Installation
2.1 LED Indicators
Name
Color
Status
Description
PWR Green On Gateway is powered on
DEV1 Green On Connected to controller1
DEV2 Green On Connected to controller2
NET Green Always On Connected to 4G network
Blinking every 100ms Connected to 3G network
RSSI Green Blinking every 1s Signal level: 0-9 (Low Signal)
Blinking every 100ms
Signal level: 10-19 (Medium Signal)
Always on
Signal level: 20-31 (High Signal)
Off
No signal
KMC Green
Blinking
Registering the KMC Platform
On Connected to the KMC Platform
Off Disconnected to the KMC Platform
ERR Green On Gateway in fault

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 15/22
Confidential
2.2 PIN Assignment
There are terminal block PIN relationship tables on the front view of the EG9012, as the following figure showed.
Top View
Front View
Bottom View
XPW (Power supply interface)
PIN Function Direction
1 V+ AdapterEG9012
2 V- EG9012Adapter
XIT (FXS)
PIN Function Direction
1 RING DeviceEG9012
2 --
3 TIP EG9012Device
XRS1/XRS2 (RS232 serial port)
PIN Function Direction
1 RX DeviceEG9012
2 TX EG9012Device
3 GND --
XRS3 (RS485 serial port)
PIN Function Direction
1 GND --
2 A --
3 B --
XRS4 (Debug)
PIN Function Direction
1 RX DeviceEG9012
2 TX EG9012Device
3 GND --

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 16/22
Confidential
2.3 Ethernet Ports
Bottom View
Each Ethernet port has two LED indicators (please check the picture above). The yellow one is Speed indicator and
the green one is Link indicator. There are three status of each indicator. For details please refer to the form below.
Indicator Status Description
Speed Indicator Off 10 Mbps mode.
On 100 Mbps mode.
Link Indicator
Off Connection is down.
On Connection is up.
Blink Data is being transmitted
Ethernet Ports

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 17/22
Confidential
2.4 Insert or Remove SIM Card
Be sure to insert a SIM card before you use the gateway.
Insert or remove the SIM as shown in the following steps.
Inserting SIM Card
1. Power off the gateway.
2. Use a pointed stick to press the Push Button, and then take out the SIM Card Tray.
3. Place the SIM card on the tray, and insert them to the slot until you hear “a cracking sound”.
Removing SIM card
1. Power off the gateway.
2. Press the Push Button, and the tray with SIM card will pop up to be pulled out.
Note:
1. Don’t touch the metal surface of the SIM card in case information in the card is lost or destroyed.
2. Don’t bend or scratch your SIM card. Keep the card away from electricity and magnetism.
3. Make sure to disconnect the power source from your gateway before inserting and removing your SIM card.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 18/22
Confidential
2.5 Attach External Antenna (SMA Type)
Attach an external SMA antenna to the gateway’s connector and twist tightly. Make sure the antenna is within the
correct frequency range provided by the ISP and with 50 Ohm impedance.
Note: Recommended torque for tightening is 0.35 N.m.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 19/22
Confidential
2.6 Mount the Gateway
The gateway can be mounted a 35 mm DIN rail.
DIN rail size (measured in mm)
Use 3 pcs of M3*6 flat head Phillips screws to fix the DIN rail to the gateway, and then hang the DIN rail on the
mounting bracket. It is necessary to choose a standard bracket.
Note: Recommended torque for mounting is 1.0 N.m, and the maximum allowed is 1.2 N.m.

Robustel EG9012 User Guide
RT_UG_EG9012_v.1.0.12 June, 2017 20/22
Confidential
2.7 Ground the Gateway
Gateway grounding helps prevent the noise effect due to electromagnetic interference (EMI). Connect the gateway to
the site ground wire by the ground screw before powering on.
Note: This product is appropriate to be mounted on a sound grounded device surface, such as a metal panel.
Bottom View
2.8 Connect the Gateway to a Computer
Connect an Ethernet cable to LAN1 or LAN2 at the bottom of the EG9012, and connect the other end of the cable to
your computer.
Ground Screw
