Robustel R1500 User manual

RT046_UG_R1500_v.1.0.3 May 28, 2021 1/97
gateway
User Guide
R1500
Industrial Cellular Iot Gateway
User Guide
Guangzhou Robustel LTD
www.robustel.com

RT046_UG_R1500_v.1.0.3 May 28, 2021 2/97
About This Document
This document provides hardware and software information of the Robustel R1500, including introduction,
installation, configuration and operation.
Copyright© 2021 Guangzhou Robustel LTD
All rights reserved.
Trademarks and Permissions
、are trademarks of Guangzhou Robustel LTD. All other trademarks and trade
names mentioned in this document are the property of their respective owners.
Disclaimer
No part of this document may be reproduced in any form without the written permission of the copyright owner. It
is the customer's responsibility to review the advice provided in this document and its suitability for the system.
Robustel makes no representations about the specific knowledge of the customer's system or the specific
performance of the system. The contents of this document are subject to change without notice due to continued
progress in methodology, design and manufacturing. Robustel shall have no liability for any error or damage of any
kind resulting from the inappropriate use of this document.
Technical Support
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.robustel.com

RT046_UG_R1500_v.1.0.3 May 28, 2021 3/97
Important Notice
Due to the nature of wireless communications, transmission and reception of data can never be guaranteed. Data
may be delayed, corrupted (i.e., have errors) or be totally lost. Although significant delays or losses of data are rare
when wireless devices such as the gateway is used in a normal manner with a well-constructed network, the
gateway should not be used in situations where failure to transmit or receive data could result in damage of any kind
to the user or any other party, including but not limited to personal injury, death, or loss of property. Robustel
accepts no responsibility for damages of any kind resulting from delays or errors in data transmitted or received
using the gateway, or for failure of the gateway to transmit or receive such data.
Safety Precautions
General
The gateway generates radio frequency (RF) power. When using the gateway, care must be taken on safety
issues related to RF interference as well as regulations of RF equipment.
Do not use your gateway in aircraft, hospitals, petrol stations or in places where using cellular products is
prohibited.
Be sure that the gateway will not be interfering with nearby equipment. For example: pacemakers or medical
equipment. The antenna of the gateway should be away from computers, office equipment, home appliance,
etc.
An external antenna must be connected to the gateway for proper operation. Only uses approved antenna with
the gateway. Please contact authorized distributor on finding an approved antenna.
Always keep the antenna with minimum safety distance of 20 cm or more from human body. Do not put the
antenna inside metallic box, containers, etc.
RF exposure statements
1. For mobile devices without co-location (the transmitting antenna is installed or located more than 20cm
away from the body of user and nearby person)
FCC RF Radiation Exposure Statement
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20 centimeters between the
radiator and human body.
Note: Some airlines may permit the use of cellular phones while the aircraft is on the ground and the door is open.
Gateway may be used at this time.
Using the gateway in Vehicle
Check for any regulation or law authorizing the use of cellular devices in vehicle in local country before installing
the gateway.
The driver or operator of any vehicle should not operate the gateway while driving.
Install the gateway by qualified personnel. Consult your vehicle distributor for any possible interference of
electronic parts by the gateway.
The gateway should be connected to the vehicle’s supply system by using a fuse-protected terminal in the
vehicle’s fuse box.
Be careful when the gateway is powered by the vehicle’s main battery. The battery may be drained after
extended period.

RT046_UG_R1500_v.1.0.3 May 28, 2021 4/97
Protecting Your Gateway
To ensure error-free usage, please install and operate your gateway with care. Do remember the following:
Do not expose the gateway to extreme conditions such as high humidity / rain, high temperature, direct sunlight,
caustic / harsh chemicals, dust, or water.
Do not try to disassemble or modify the gateway. There is no user serviceable part inside and the warranty
would be void.
Do not drop, hit or shake the gateway. Do not use the gateway under extreme vibrating conditions.
Do not pull the antenna or power supply cable. Attach/detach by holding the connector.
Connect the gateway only according to the instruction manual. Failure to do it will void the warranty.
In case of problem, please contact authorized distributor.

RT046_UG_R1500_v.1.0.3 May 28, 2021 5/97
Regulatory and Type Approval Information
Table 1: Directives
2011/65/EU
The European RoHS2.0 2011/65/EU Directive was issued by the European parliament
and the European Council on 1 July 2011 on the restriction of the use of certain
Hazardous substances in electrical and electronic equipment.
2012/19/EU
The European WEEE 2012/19/EU Directive was issued by the European parliament
and the European Council on 24 July 2012 on waste electrical and electronic equipment.
2013/56/EU
The European 2013/56/EU Directive is a battery Directive which published in the EU official gazette
on 10 December 2013. The button battery used in this product conforms to the standard of
2013/56/EU directive.
Table 2: Standards of the electronic industry of the People’s Republic of China
SJ/T
11363-2006
The electronic industry standard of the People's Republic of China SJ/T 11363-2006 “Requirements
for Concentration Limits for Certain Toxic and Hazardous Substances in Electronic Information
Products” issued by the ministry of information industry of the People's Republic of China on
November 6, 2006, stipulates the maximum allowable concentration of toxic and hazardous
substances in electronic information products.
Please see Table 3 for an overview of toxic or hazardous substances or elements that might be
contained in product parts in concentrations above the limits defined by SJ/T 11363-2006.
SJ/T
11364-2014
The electronic industry standard of the People's Republic of China SJ/T 11364-2014 “Labeling
Requirements for Restricted Use of Hazardous Substances in Electronic and Electrical Products”
issued by the ministry of Industry and information technology of the People's Republic of China on
July 9, 2014, stipulates the Labeling requirements of hazardous substances in electronic and
electrical products, environmental protection use time limit and whether it can be recycled.
This standard is applicable to electronic and electrical products sold within the territory of the
People's Republic of China, and can also be used for reference in the logistics process of electronic
and electrical products.
The orange logo below is used for Robustel products:
Indicates its warning attribute, that is, some hazardous substances are contained in the product.
The "10" in the middle of the legend refers to the environment-friendly Use Period (EFUP) * of
electronic information product, which is 10 years. It can be used safely during the
environment-friendly Use Period. After the environmental protection period of use, it should enter
the recycling system.
*The term of environmental protection use of electronic information products refers to the term
during which the toxic and hazardous substances or elements contained in electronic information
products will not be leaked or mutated and cause serious pollution to the environment or serious
damage to people and property under normal conditions of use.

RT046_UG_R1500_v.1.0.3 May 28, 2021 6/97
Table 3: Toxic or Hazardous Substances or Elements with Defined Concentration Limits
Name of
the Part
Hazardous Substances
(Pb)
(Hg)
(Cd)
(Cr(VI))
(PBB)
(PBDE)
(DEHP)
(BBP)
(DBP)
(DIBP)
Metal
parts
o
o
o
o
o
o
o
o
o
o
Circuit
modules
o
o
o
o
o
o
o
o
o
o
Cables
and cable
assemblie
s
o
o
o
o
o
o
o
o
o
o
Plastic
and
polymeric
parts
o
o
o
o
o
o
o
o
o
o
o:
Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is
below the limit requirement in RoHS2.0.
X:
Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials for this
part might exceed the limit requirement in RoHS2.0.

RT046_UG_R1500_v.1.0.3 May 28, 2021 7/97
Document History
Updates between document versions are cumulative. Therefore, the latest document version contains all updates
made to previous versions.
Date
Firmware Version
Document Version
Change Description
Apr 29, 2019
1.0.0
v.1.0.0
Initial release
Jun 10, 2019
1.0.0
v.1.0.1
1. Revise the status of UER in chapter 2.2 LED
Indicators.
2. Revise the screenshot of RobustOS main
interface about the device version number in
chapter 3.4 and 4.1.1.
3. Revise the Screenshot of the Cellular frequency
in chapter 4.2.4.
4. Revise the screenshot of firewall function and
added the Enable VPN NAT Traversal function and
related description in chapter 4.3.2.
5. Revise the screenshot of IPsec_General and
add Optimize DH Exponent Size function and
related description in chapter 4.4.1.
6. Revise the description of input power in
chapter 1.1.1.
7. Revise the description of Power consumption
in chapter 1.1.3.
8. Revise the Product name.
Sep 12, 2019
1.0.0
v.1.0.2
1. Revise the Front panel interface.
2. Revise the Regulatory and Type Approval
Information.
May 28, 2021
1.0.2
v.1.0.3
1. Revise RS232 serial port pin definition.
2. Revise the description of LED indicators.
3. Revise the description of cellular.

RT046_UG_R1500_v.1.0.3 May 28, 2021 8/97
Contents
Chapter 1 Product Overview ......................................................................................................................... 10
1.1 Key Features.............................................................................................................................................10
1.2 Package Contents .....................................................................................................................................12
1.3 Specifications ...........................................................................................................................................13
1.4 Dimensions...............................................................................................................................................15
1.5 Ordering Information ...............................................................................................................................15
Chapter 2 Hardware Installation.................................................................................................................... 17
2.1 Front panel interface................................................................................................................................17
2.2 LED Indicators...........................................................................................................................................18
2.3 Insert or Remove SIM Card ......................................................................................................................18
2.4 Attach External Antenna (SMA Type).......................................................................................................20
2.5 Mount the Gateway .................................................................................................................................20
2.6 Connect the Gateway to a Computer.......................................................................................................21
2.7 Power Supply............................................................................................................................................21
Chapter 3 Initial Configuration ...................................................................................................................... 22
3.1 Configure the PC.......................................................................................................................................22
3.2 Factory Default Settings ...........................................................................................................................25
3.3 Login the Gateway....................................................................................................................................25
3.4 Control Panel............................................................................................................................................25
Chapter 4 Gateway Configuration....................................................................................................................... 28
4.1 System......................................................................................................................................................28
4.1.1 System Information...........................................................................................................................28
4.1.2 Cellular Status...................................................................................................................................28
4.1.3 Internet Status..................................................................................................................................29
4.2 Interface ...................................................................................................................................................29
4.2.1 Link Manager ....................................................................................................................................29
4.2.2 LAN ...................................................................................................................................................35
4.2.3 Ethernet............................................................................................................................................39
4.2.4 Cellular..............................................................................................................................................39
4.2.5 Serial Port .........................................................................................................................................44
4.3 The internet..............................................................................................................................................49
4.3.1 Routing..............................................................................................................................................49
4.3.2 Firewall .............................................................................................................................................50
4.3.3 IP Passthrough ..................................................................................................................................56
4.4 Virtual private network ............................................................................................................................56
4.4.1 IPsec..................................................................................................................................................56
4.4.2 OpenVPN ..........................................................................................................................................64
4.4.3 GRE ...................................................................................................................................................72
4.5 Service......................................................................................................................................................74
4.5.1 Syslog................................................................................................................................................74
4.5.2 Event.................................................................................................................................................75
4.5.3 NTP ...................................................................................................................................................78
4.5.4 SMS...................................................................................................................................................79
4.5.5 Email .................................................................................................................................................80

RT046_UG_R1500_v.1.0.3 May 28, 2021 9/97
4.5.6 DDNS.................................................................................................................................................81
4.5.7 SSH....................................................................................................................................................82
4.5.8 Web Server .......................................................................................................................................83
4.5.9 Advanced..........................................................................................................................................84
4.6 System......................................................................................................................................................85
4.6.1 Debug................................................................................................................................................85
4.6.2 Update ..............................................................................................................................................86
4.6.3 App Center........................................................................................................................................86
4.6.4 Tools..................................................................................................................................................87
4.6.5 Profile................................................................................................................................................90
4.6.6 User Management............................................................................................................................91
Glossary............................................................................................................................................................. 93

RT046_UG_R1500_v.1.0.3 May 28, 2021 10/97
Chapter 1 Product Overview
1.1 Key Features
The Robustel Industrial Cellular lot gateway R1500 supports GSM/GPRS/EDGE 2G networks, 3G networks such as
WCDMA, HSPA+ 3.5G and LTE 4G networks, providing high-speed wireless network bandwidth for devices over
wireless connections, and it has dual SIM backups to ensure a stable connection to the wireless network.
The R1500 uses Robustel self-developed operating system RobustOS. RobustOS is developed on Linux-based systems
and is suitable for most of router devices of Robustel. In addition to basic network functions and protocols, the
system gives customers a more customized, more convenient and more practical customization experience. At the
same time, Robustel will provide SDKs for partners and customers, allowing users to develop their own functions of
using C, Python or Java software languages. In addition, we will provide a wealth of App applications running on
RobustOS to meet the needs of fragmented IoT applications.
Robustel is one of the world’s leading manufacturers of industrial quality solutions for the IoT and M2M market.
Robustel’s portfolio of award-winning solutions are comprised of: Wireless Modems, Routers, Gateways, EDGE
Computing, Cloud Software and End-to-End IoT solutions.
Founded in 2010 in Guangzhou, China –Robustel has been concentrating on producing the highest quality IoT
products possible. As a supplier of wireless IoT hardware Robustel works with over 50 distribution partners servicing
more than 120 countries and maintains a dedicated local presence in: Germany, Australia, Japan, UK, US, the
Netherlands and Hong Kong. Robustel can respond quickly to users' needs, provide fast, professional services and
more targeted R&D and technical support to meet the needs of user customization and individualization. Up to now,
Robustel’s products and services have been radiated to more than 100 countries and regions around the world.
Products are widely used in smart cities, power, oil and gas, finance, environmental protection, security, industrial
automation, medical and other fields. The company's business continues to be healthy, stable and rapid growth.
After years of continuous efforts, Robustel has become a pioneer in the Internet of Things industry.
RobustOS + SDK + App
Supports multiple VPNs such as IPsec/OpenVPN/GRE/L2TP/PPTP/DMVPN
Supports dual card link backup and ICMP detection
Supports SMS, Email, SNMP Trap and RobustLink
Event alarm
Supports Modbus RTU to TCP、Modbus Master
Supports TCP client/server, UDP, virtual serial port

RT046_UG_R1500_v.1.0.3 May 28, 2021 11/97
Supports DHCP server
Supports IP Pass-through
Supports RobustVPN cloud platform, providing simple and secure remote access for industrial equipment such as
PLC
Supports RobustLink M2M centralized management platform to monitor device network status and statistics
device traffic in real time
Supports for firmware upgrades for Web, CLI, USB, SMS and RobustLink
Robust industrial design (9-36V DC input voltage for horizontal desktop placement, Din rail mounting)

RT046_UG_R1500_v.1.0.3 May 28, 2021 12/97
1.2 Package Contents
Before installing your R1500, verify the kit contents as following.
Note: The following pictures are for illustration purposes only, not based on their actual sizes.
1 x Robustel Cellular lot gateway R1500
Terminal block (3.5mm, for power connector)
1 x Quick Start Guide with download link of other documents or tools
Note: If any of the above items is missing or damaged, please contact your Robustel sales representative.
Optional Accessories (sold separately)
3G/4G SMA cellular antenna (stubby/magnet optional)
Stubby antenna 1 Magnet antenna 2

RT046_UG_R1500_v.1.0.3 May 28, 2021 13/97
35 mm DIN rail mounting kit
1x serial cable
Cable
AC/DC power adapter (12V DC, 1.5 A; EU/US/UK/AU plug optional)
1.3 Specifications
Cellular Interface
Number of antennas: 2 ( MAIN + AUX )
Connector: SMA, female
SIM slot: 2 (3.0 V & 1.8 V)
Standards: GSM/WCDMA/FDD LTE/TDD LTE
Ethernet Interface
Number of ports: 1 x 10/100 ports
Serial Interface
Number of ports: 2 x RS232

RT046_UG_R1500_v.1.0.3 May 28, 2021 14/97
Connector: DB9
Signal: TxD、RxD、GND、CTS、RTS、DSR、DTR
Baud rate: 300 bps to 115200 bps
Others
LED indicators: 1 x RUN, 1 x MDM, 1 x USR, 3 x RSSI
Built-in: RTC, Watchdog, Timer
Software (Basic features of RobustOS)
Network protocols: ：PPP、PPPoE、TCP、UDP、DHCP、ICMP、NAT、HTTP、HTTPs、DNS、ARP、NTP、SMTP、
Telnet、SSH2、DDNS, etc.
VPN tunnel: IPsec, OpenVPN, GRE
Management: Web, CLI, SMS
Serial port: Transparent, TCP Client/Server, UDP, Modbus RTU Gateway
App Center (Available Apps for RobustOS)
Apps*: Language, RobustLink
*Request on demand. For more Apps please visit www.robustel.com.
Power Supply and Consumption
Connector: 2-pin 3.5 mm female socket
Input voltage: 9 to 36V DC
Power consumption: Idle: 80 mA@12 V
Data link: 450 mA (peak) @12 V
Physical Characteristics
Ingress protection: IP30
Housing & Weight: Plastic
Dimensions: 118mm x 97.5mm x 28.5mm
Installations: Desktop, and 35 mm DIN rail mounting
(DIN rail mounting requires additional installation accessories)
Approvals
Environmental: RoHS2.0, WEEE

RT046_UG_R1500_v.1.0.3 May 28, 2021 15/97
1.4 Dimensions
Front view side view
Rear view Top & Bottom view
1.5 Ordering Information
Model
R1500-4L
Router Type
LTE Gataway
Air Interface
GSM/WCDMA/FDD LTE/TDD LTE
Frequency Bands
LTE
4G*
3G
WCDMA/HSPA/DC-HSPA+
2G
GPRS/EDGE
Operating
Environment
-40 to +75 °C
5 to 95% RH

RT046_UG_R1500_v.1.0.3 May 28, 2021 16/97
*For more information about frequency bands in different countries, please contact your Robustel sales
representative.

RT046_UG_R1500_v.1.0.3 May 28, 2021 17/97
Chapter 2 Hardware Installation
2.1 Front panel interface
Name
Mark
Function
Power
interfa
ce
V+
Power input
positive,
9-36VDC
Power
interfa
ce
V-
Power input
negative
Notes：Pin definitions for COM1 and COM2 are the same.
Label
Name
Mark
Function
Direction
1
--
--
2
TXD
Transmit Data, Signal output
R1500 →Device
3
RXD
Receive Data, Signal input
R1500 ←Device
4
DTR
Data Terminal Ready, Signal
input
R1500 ←Device
4
GND
System Ground
--
6
DSR
Data Set Ready, Signal output
R1500 →Device
7
RTS
Request to Send, Signal input
R1500 ←Device
8
CTS
Clear to Send, Signal output
R1500 →Device
9
--
--
--
--
5 4 3 2 1
9 8 7 6

RT046_UG_R1500_v.1.0.3 May 28, 2021 18/97
2.2 LED Indicators
Name
Color
Status
Description
RUN
Green
On, solid
Power on
Green
Fast blinking (2Hz)
System initializing
Green
On, blinking (1Hz)
Initialization completed, device operating
normally
MDM
Green
On, solid
Link connection is working
Green
On, blinking
Link connection is communicating
Green
Off
Link connection is not working
USR
Green
On, blinking
Backup card is being used
Green
On, solid
Main card is being used
None
All off (three lights)
No signal
Green
On, solid(one light)
Received Signal Strength Indication -111 to
-93dBm (Weak signal)
Green
On, solid(two light)
Wireless module : Received Signal Strength
Indication -91 to -73 dBm (Moderate signal)
Green
On, solid(three light)
Received Signal Strength Indication greater than
-73 dBm (Strong signal)
2.3 Insert or Remove SIM Card

RT046_UG_R1500_v.1.0.3 May 28, 2021 19/97
Please confirm before inserting the SIM card. When the SIM card is turned on and the device is configured without
the correct PIN, the SIM card is unavailable.
Insert SIM card
1. Make sure gateway is powered off.
2. To insert SIM card, press the card with finger until you hear a click
Remove SIM card
1. Make sure gateway is powered off.
2. To remove SIM card, press the card with finger until it pops out and then take out the card.
Note:
1. Recommended torque for inserting is 0.5 N.m, and the maximum allowed is 0.7 N.m.
2. Use the specific M2M SIM card when the device is working in extreme temperature, because the regular card for
long-time working in harsh environment will be disconnected frequently.
3. Do not touch the metal of the card surface in case information in the card will lose or be destroyed.
4. Do not bend or scratch the card.
5. Keep the card away from electricity and magnetism.
6. Make sure gateway is powered off before inserting or removing the card.

RT046_UG_R1500_v.1.0.3 May 28, 2021 20/97
2.4 Attach External Antenna (SMA Type)
Attach an external SMA antenna to the gateway’s antenna connector and twist tightly. Make sure the antenna is
within the correct frequency range provided by the ISP and with 50 Ohm impedance.
Note: Recommended torque for tightening is 0.35 N.m.
2.5 Mount the Gateway
The gateway can be placed on a desktop or mounted to a 35 mm DIN rail.
Installation method
DIN rail mounting (measured in mm)
Main antenna, SMA
antenna with a male
connector for cellular
connection
Slave antenna, SMA
antenna with a male
connector for cellular
connection
