WIPER CONTROL | W10, 12, 25, 38 & 50
Installation Instructions
Before installation please read these instructions.
www.rocaindustry.com
Item no. Voltage Wipers
532202 12/24 V Up to 2
532203 12/24 V Up to 3
Limited warranty
»Roca warrants the wiper control to be free from
defective material and workmanship for a period
of 3 years from the date of purchase.
»This warranty does not apply to failure or damage
caused by improper installation, misuse, lightning
strike or damage from a power surge.
»If failure occurs during this period, return it
to your dealer for repair or replacement.
Fits wiper motors: W10, W12, W25, W38 and W50
■Up to 2 or 3 motors
■Synchronized sweep
■Interval
■Slow speed
■Fast speed
■Washer output
58
178
192
108
40
4,5

2
87
36
5
For 24V system use
resistor (600 Ω) for LED.
LED
24V 12V
600 Ω
(On) Momentary
On
Off
5 2
3
6
Brown
Grey
Black
Ground
12/24VDC
Washer
Fuse
W3 W2 W1
G F S P
P (Park)
Sw (Switch)
G (Ground)
(Fast) F
(Slow) S
G F S P
Switch circiut
Off - 2&3 - (2&3,5&6)
Function for switch
-One push to the on position will start all motors in synchronized interval.
-One more push to momentary will run all motors in slow speed synchronized.
-One more push will run all motors in fast speed synchronized.
-One more push starts from interval and so on.
-One long push from off to momentary will start one motor in interval (W1).
-One more push will run one motor in slow speed.
-One more push will run one motor in fast speed.
-One more push starts one motor from interval and so on.
Washer:
When running, push switch to momentary more than one second and
washer will start.
Motor protection:
If motor runs too slow or stops, it will shut off if not reaching park position
within 5 sec. Push switch to off and then to on, and motor will start again.
Installation
(Keep the battery main switch off during installation).
1. Place the control unit to desired position.
2. Insert the screws into holes and tighten.
3. Connect the cable from switch.
4. Connect the remaining cables
according to diagram.
5. Turn on main switch and test all functions.
Switch 466223
Actuator 466026
W12 System W25, 38 or 50 System

2
87
36
5
For 24V system use
resistor (600 Ω) for LED.
LED
24V 12V
600 Ω
(On) Momentary
On
Off
5 2
3
6
Brown
Grey
Black
Ground
12/24VDC
Washer
Fuse
W3 W2 W1
G F S P
P (Park)
Sw (Switch)
G (Ground)
(Fast) F
(Slow) S
G F S P
Switch circiut
Off - 2&3 - (2&3,5&6)
Function for switch
-One push to the on position will start all motors in synchronized interval.
-One more push to momentary will run all motors in slow speed synchronized.
-One more push will run all motors in fast speed synchronized.
-One more push starts from interval and so on.
-One long push from off to momentary will start one motor in interval (W1).
-One more push will run one motor in slow speed.
-One more push will run one motor in fast speed.
-One more push starts one motor from interval and so on.
Washer:
When running, push switch to momentary more than one second and
washer will start.
Motor protection:
If motor runs too slow or stops, it will shut off if not reaching park position
within 5 sec. Push switch to off and then to on, and motor will start again.
Installation
(Keep the battery main switch off during installation).
1. Place the control unit to desired position.
2. Insert the screws into holes and tighten.
3. Connect the cable from switch.
4. Connect the remaining cables
according to diagram.
5. Turn on main switch and test all functions.
Switch 466223
Actuator 466026
W12 System W25, 38 or 50 System
