Rocket Fish RF-TVMLPT03 User manual

M8 x 16mm M8 x 40mm M8 x 60mm
M8 bag
A
PQ
O
Tools you will need:
• Stud nder
• Awl
• Pencil
• Level
• Tape measure
Thank you for choosing the
Rocketsh RF-TVMLPT03.
The RF-TVMLPT03 TV mount
is designed to support
a TV weighing up to
130 lbs. (59 kg)
• Phillips screw driver
• Hammer (Concrete Only)
• ½ in. socket wrench
• 3/16 in. wood drill bit
• 3/8 in. masonry drill bit (Concrete Only)
• Power drill
QUICK SETUP GUIDE
RF-TVMLPT03 1 Attach the TV brackets
Option 1: Attaching to a at
mounting surface
Attach the left and right TV brackets
(B and C) to the back of the TV using:
The M4/M5 washers (F) and
the M4 x 12 mm (D)
or M5 x 12 mm (H) screws.
Or
The M6/M8 washers (M) and
the M6 x 12 mm (J) screws
or M6 x 20 mm (K) screws
or the M8 x 16 mm (O) screws.
2 Install the wall plate
Option 1: Installing to a wood stud wall
Caution: Avoid potential injuries or property damage! DO NOT over-tighten the lag bolts.
Note: Any material covering the wall must not exceed 5/8 in. (16 mm).
a. Locate the studs. Verify the center of the stud with an awl or thin nail or use an
edge-to-edge stud nder.
b. Level the wall plate (A) and mark hole locations.
c. Drill pilot holes as illustrated.
d. Align the wall plate (A) with the pilot holes, then place the washers (T) over the holes.
Insert the lag bolts (U) through the washers, then tighten the lag bolts with a socket wrench
only until the washers are pulled rmly against the wall plate.
DO NOT over-tighten the lag bolts.
Package contents
A Wall plate (1)
B Left TV bracket (1)
C Right TV bracket (1)
M4 bag
D M4 x 12 mm screws (4)
E M4 x 30 mm screws (4)
F M4/M5 washers (8)
G M4/M5 spacers (4)
M5 bag
H M5 x 12 mm screws (4)
I M5 x 30 mm screws (4)
M6 bag
J M6 x 12 mm screws (4)
K M6 x 20 mm screws (4)
L M6 x 35 mm screws (4)
M M6/M8 washers (4)
N M6/M8 spacers (4)
M8 bag
O M8 x 16 mm screws (4)
P M8 x 40 mm screws (4)
Q M8 x 60 mm screws (4)
Hex key bag
R 3⁄16 in. Hex Key (1)
Lag bolt bag
S Concrete anchors (4)
T Lag bolt washers (4)
U 5⁄16 in. x 23⁄4 in. lag bolts (4)
M4 x 12mm
M5 x 12mm
M6 x 12mm
M4 x 30mm
M5 x 30mm
M6 x 20mm
in. x 2 in.
M6 x 35mm
M4 bag
Hex key bag
M5 bag
M6 bag
Lag bolt bag
D
H
R
G
I
J
E
KL
F
MN
Option 2: Attaching to a curved or
irregular mounting surface
Attach the left and right TV brackets (B and C) to the
back of the TV using:
The M4/M5 spacers (G), M4/M5 washers (F), and
the M4 x 30 mm screws (E) or M5 x 30 mm screws (I).
Or
The M6/M8 spacers (N), M6/M8 washers (M),
and the M6 x 35 mm screws (L)
or the M8 x 40 mm (P) or M8 x 60 mm screws(Q).
Note: Use the M4 washers (F) between
the spacers and the bracket with the M4
or M5 screws only.
BC
U
ST
H
K
O
D
J
B
C
F M
16 - 24 in.
406mm - 610mm
< 16 mm
(5⁄8 in.)
T
A
U
B
C
B
C
a.
b.
c.
d.
or or
75mm
3 in.
M4/M5 M4/M5
M6/M8 M6/M8
3/16 in.
or
I
P
Q
E
L
F
M
NG
B
C
For

6907-002015<00> 10-0363
Option 2: Installing to a solid concrete or concrete block wall
Caution: Avoid potential injuries or property damage! DO NOT over-tighten the lag bolts.
Note:Any material covering the wall must not exceed 5/8 in. (16 mm).
< 16 mm
(5⁄8in.)
75mm
3 in.
A
T
U
S
10° 5°
R
4 Adjust the tilt angle
(if necessary)
You can adjust the tilt angle
of the screen 10° forward or
5° backward.
If necessary, the tilt tension can be
adjusted by tightening or
loosening the tension knob with
either the hex key (R) or by hand.
IMPORTANT SAFETY INSTRUCTIONS • SAVE THESE INSTRUCTIONS
Caution: Do not use this product for any purpose not explicitly specied by Rocketsh. Improper installation
may cause property damage or personal injury. If you do not understand these directions, or have doubts
about the safety of the installation, contact Customer Service or call a qualied contractor. Rocketsh is not
responsible for damage or injury caused by incorrect installation or use. The weight of your TV must not
exceed 130 lbs. (59 kg). The wall must be capable of supporting ve times the weight of the TV and wall
mount combined.
This product contains small items that could be a choking hazard if swallowed. Keep these items away from
young children!
5-year limited warranty
Visit www.rocketshproducts.com for details.
We’re here for you
www.rocketshproducts.com
For customer service, call:
800-620-2790 (U.S./Canada markets)
01 800-926-3010 (Mexico market)
© 2010 BBY Solutions, Inc., All Rights Reserved.
Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richeld, MN USA 55423-3645
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo Piso, Colonia Cruz Manca, Programa Parcial de Desarrollo
Santa Fe, Delegación Cuajimalpa, Distrito Federal, México 05349
ROCKETFISH is a trademark of BBY Solutions, Inc. Registered in some countries. All other products and brand names are
trademarks of their respective owners.
3 Mount the TV to the wall
Holding the TV with the top of the screen tilted toward the wall, slide the upper notches of the TV bracket
over the upper ange of the wall plate. Then, gently lower the TV until the lock engages the
lower ange of the wall plate. There will be an audible click when the TV is securely latched into place.
Remove the TV from the wall
Slide the latch to the unlatched position, then lift the TV up and off the wall bracket.
Unlatched
[Latched]
HEAVY! You will need assistance
