PRODUCT MANUAL
34ST (V.2.0)
34ST FS (V.2.0.F)
RON-WPM-710229-34ST/34STFS-Rev.3

EXPLODED VIEW
ITEM. 3
MODEL ST - PART No. 537551
ITEM. 3
MODEL ST FS - PART No. 537511
ITEM. 5 - PART No. 729021
ITEM. 11
MODEL STE - PART No. 534210
p2
34ST (V.2.0)
34ST FS (V.2.0.F)

PARTS LIST
ITEM NO. QTY. DESCRIPTION PART NO.
1 3 Screw 543311
2 1 Self-tailing arm 596751
3 1 Self-tailing top complete
Model ST 537551
3 1 Self-tailing top complete
Model ST FS 537511
3.1 1 Circlip 726400U
3.2 1 Top ring 782100
3.3 6 Screw 781811
3.4 1Disc
Model ST (537551 only) 726310
4 1 Drum complete 729110
5 1 Drive shaft complete 729021
5.1 1 Drive shaft 729011
5.2 4 Arm spring 713300
5.3 4 Pawl 713200
6 1 Shaft ring 729750
7 1 Roller bearing complete 727400
8 2 Bushing (not removable) 716501
9 1 Ratchet gear all models 711701
10 1 Gear Wheel complete 711710
11 1 Ratchet gear
Model ST 536100
11.1 4 Bushing RD100492
11.2 1 Ratchet gear
Wheel STE/STE AD BD 534200
12 1 Bushing 729501
13 1 Cover 729503
14 1 Circlip 729502U
15 1 Base 731850
1 Service kit 18 (not included) 710018
p3
34ST (V.2.0)
34ST FS (V.2.0.F)

MOUNTING INSTRUCTIONS
PAWL SPRING MOUNTING
Installing the winch is easy, if you follow these instructions. The numbers in ( ) refer to the
position numbers in the parts list.
Tools required for the installation:
• Allenkey(4mm)
• Allenkey(5mm)
• Ø6.5mm(1/4”)drill
• Beddingcompound
1. Remove screws (1).
2. Remove self-tailing arm (2) and drum (4).
3. Marklocationofboltholesusingthetemplate.
IMPORTANT: On the 34ST the self-tailing arm (2) is fixed in one position.
 Ensurecorrectpositioningoftheself-tailingarm,beforemarkingtheboltholes.
 DrillboltholesØ6.5mm(1/4”).Besurethatnodustcomesintocontactwiththewinch
while drilling.
5. Apply a light coat of bedding compound, ensuring that each bolthole is bedded.
Keep drain grooves clear.
6. Fastenbase(15)intoplaceusing5pieces.M6(1/4”)countersunkheadscrews.
Uselargewashersorabackingplate.
7. Assemble in reverse order.
8. Checkthatthewinchisfunctioningcorrectly:
-Thedrumshouldoperatesmoothly,byturningthedrumclockwisebyhand.
-Thedrummustnotturnwhentryingtoturnthedrumanticlockwise.
-Whileturningthewinchhandleclockwisethedrumshouldturn.
-Whileturningthewinchhandleanticlockwisethedrumshouldnotturn.
Note the curved
spring“arm”
• 5xM6(1/4”)countersunkheadscrewsandcorresponding
nuts(lengthdependingondeckthickness)
• 5xlargewashersorbackingplate
• Ringspannertomatchnuts
p4
34ST (V.2.0)
34ST FS (V.2.0.F)

SERVICE INSTRUCTIONS
Tools required for service:
• Allenkey(4mm)
• Screwdriver(small)
1. Remove screws (1).
2. Remove self-tailing arm (2) and drum (4).
3. Insert a winch handle. Pull up the drive shaft (5) gently, while turning gear wheel (10)
and ratchet gear (9) carefully. Remove drive shaft (5).
4. Remove plugs (5.4), pawls (5.3) and arm springs (5.2).
5. Remove ratchet gear (9).
6. Remove shaft ring (6). It can be dicult to get the shaft over the top of the base (15).
By turning and tilting the shaft, it will come o. DO NOT use violence.
7. Remove gear wheel (10).
8. To release the roller bearing (7), gently insert a small screwdriver between roller bearing,
and base (15). Remove roller bearing.
9. The ratchet gear (11) should be cleaned without being removed from the base (15).
10.Cleanallpartsinbenzine.Remembertocleanthegearteethandrollerbearingtrack
inside the drum (4).
11. Assemble in reverse order. During assemble, by the use of a small soft brush lightly grease
all gear teeth, drive shaft, roller bearing, shafts, pawls, springs and bushings. Pawls should
only be lubricated with a very thin film of ANDERSEN WINCH GREASE. It is very important
that pawls can move freely.
IMPORTANT: Whenassemblingthewinch,checkthefunctioningofeachpawlbypushing
the pawl against the spring. The pawls should move smoothly and automatically return to
their normal position, where the pawls engage with the teeth. If the pawls do not function
correctly,cleanandlubricatethepawlsandgears.Checkthefunctionofthepawlsagainto
makesurethatitworkscorrectly.Ifthepawlsdonotworkcorrectlyreplacethespringsand
recheckthefunctioning.
Malfunctioning pawls may lead to unexpected release of the winch force resulting in fatal
injuries to the user and others.
ServiceKitNo:18(part.no.710018)containssparepartsforthiswinch.
Maintenance instructions for PVD coated stainless steel surfaces.
PVD-coated surfaces should be rinsed regularly in fresh water to remove any salt residue, dirt
orothercontaminantsanddriedgentlywithasoftcloth.Toremovegreaseorothermarks,
a mild abrasive free cleaning agent such as spray-on glass cleaning solution may be used.
No caustic detergents or other aggressive or abrasive cleaning agents
should ever be used, as they may damage the surface.
• Winchhandle
• ANDERSENwinchgrease
p5
34ST (V.2.0)
34ST FS (V.2.0.F)

GENERAL INFORMATION
Due to the best choice of materials and high precision in manufacturing, we recommend, for
normal use, only to dismantle, clean and lubricate the winch once every second year. Under
extensive use, such as racing, charter or blue water sailing, we recommend to lubricate the
winch once every year.
We strongly recommend always to use ANDERSEN WINCH GREASE, when lubricating your
winch. ANDERSEN WINCH GREASE is a high quality silicone/Teflon grease product.
Mostothertypesofgrease,including“marinegrease”arenotsuitableforlubricationof
winches. Non-suitable grease products can cause malfunction, which could result in fatal
injuries for the user and others.
Pawl arm springs should be replaced every second year. Spare arm springs and other parts
that may be required are included in the ANDERSEN Service Kit. Please refer to the service
instruction for the Service Kit suitable for the specific winch.
When the winch handle is not in use but the winch is under load, we recommend, from a
safety point of view, to remove the winch handle from the winch.
To ensure correct function of the self-tailing unit, only use recommended line sizes. When
using the winch with mooring lines DO NOT use the self-tailing function and be sure that the
mooring line is not in contact with the self-tailing arm.
To ensure the best possible functioning of the winch, we recommend that
the winch is placed in accordance with the line entry (shown below).
Be also aware that the self-tailing arm is positioned correctly. We recommend to have the
self-tailing arm positioned within the shaded area (shown above). On this model the self-
tailingarmisxed,makingitveryimportanttoestablishtheproperlocationoftheholes
priortodrillingtheseinthedeck.
To identify the Output Drive Gear, insert a winch handle into the winch
androtateinbothdirections,thedrivegearwillonlyrotateclockwise
in a fast and slow speed.
Ideal
rope
entry
Output
drive
gear
p6
34ST (V.2.0)
34ST FS (V.2.0.F)

SAFETY NOTICES
ALL WINCHES
DO NOT DISCARD
Failure to observe these precautions
could result in serious injury or death.
Read All Safety Notices and Product Manuals
Do not install or operate this winch before reading and fully understanding the contents of
this Product Manual.
Stay Alert When Operating
Andersen winches are very powerful and have the potential to cause significant damage
and/or serious injury if used improperly or without due caution and vigilance.
Operators Must be Trained
Help prevent significant damage and/or serious injury by ensuring any person operating a
winch has a thorough understanding of its proper operation and is aware of the potential
hazards involved. As a minimum, all winch operators must read and understand this Safety
Notice Sheet and the Product Manual.
Particularattentionisdrawntothefollowingpoints:
• Childrenandothersnotqualiedtooperateanelectricwinchmustbekeptatasafe
distance from the winch and any rigging or fittings that are under load.
• Longhairand/orlooseclothingmustbetiedbacktoavoidbeingcaughtinthewinch.
• In the event of a rope override or other fault, stop the winch and turn o power before
attempting to resolve the problem.
Avoid Accidental Operation
Remove winch handles and turn o power to the winch when not in use to help avoid
unsupervised or unintentional operation. Failure to do so could result in significant
damage and/or serious injury.
Maintenance
Turnopowertothewinchbeforeperforminganymaintenanceorservicetasks.Failure
to do so could result in significant damage and/or serious injury.
Lifting Operations
Thewinchmustnotbeoperatedwiththeropeintheselftailerwhenusedinanykindof
lifting operation.
Any lifting operations should be conducted by two persons in order to maintain constant
visual contact with the object being lifted.
Furthermore the self tailer must not be used as a cleat for a rope used to lift or suspend
any object. The rope must be secured properly by tying o, or leading to a suitable fitting
such as a cleat or bollard.
p7
34ST (V.2.0)
34ST FS (V.2.0.F)

Visit www.andersenwinches.com
Visit www.ronstan.com/warranty
Manufactured by Ronstan Denmark ApS.
Jægervænget36-7100Vejle-Denmark
o[email protected]-www.andersenwinches.com
WORLDWIDE DISTRIBUTION & SERVICE
WARRANTY
34ST (V.2.0) |34ST FS (V.2.0.F)
