Room & Board FLOAT SHELF User manual

FLOAT SHELF & FLOAT BOX SHELF
Keep these instructions for future use
ASSEMBLY INSTRUCTIONS
RECOMMENDED TOOLS AND MATERIALS:
Level
3/16” Drill bit
#2 Phillips screwdriver
Power drill
Pencil
THIS PRODUCT INCLUDES:
A.
B.
C.
D.
E.
A. - Float shelf
B. - Mounting bracket
C. - Mounting screws
D. - Wall anchors
E. - Set screws
The maximum recommended load for this product is 20 pounds. If you are mounting this shelf to a surface
other than drywall, or if you are uncertain about assembly, please contact a professional for help with
installation.
SPECIAL CONSIDERATIONS:
(hardware not to scale)

4600 Olson Memorial Highway | Minneapolis, Minnesota 55422 I www.roomandboard.com I 800.486.6554
10/2416
1
2
3
4
Place the mounting bracket against your wall at the desired location. Use a level to ensure accurate
placement. Ensure the mounting bracket is oriented in correspondence with the “up” arrow. Use a pencil to
mark the location of each of the mounting holes. It is recommended that at least one of the holes be
centered over a stud.
Remove the mounting bracket from the wall and use a #2 Phillips screwdriver to install the wall anchors.
Ensure that the wall anchors are flush to the wall after installation.
Note: It is not necessary to use a wall anchor for mounting holes positioned over studs. Instead, use a drill
to pre-drill a 3/16” pilot hole and continue to step 3.
Reposition the mounting bracket and align the mounting holes with the anchors. Use the mounting screws
to fasten the mounting bracket to the wall.
Slide the shelf over the protruding arms of the mounting bracket with the predrilled holes facing UP, then
use the set screws to fasten the shelf in place.
Note: Pre-drilled holes face up
