Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small
parts which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below.
NO. Picture Description Dimension Q'TY
1
Flat Washer 5/16"*22*2mm 8 pcs
Spring Washer
Bolt
8 pcs
4 pcs
5/16"*12*2mm
5/16"*18*89mm
Hardware pack locations
727 / 728 - 12 SIDE CHAIR, SKU# 42407278 / 42407280
ASSEMBLY INSTRUCTION
JSFC SKU 42407278 / 42407280
727 / 728-12 SIDE CHAIR
2
Flat Washer 1/4"*19*2mm 2 pcs
Spring Washer
Bolt
2 pcs
2 pcs
1/4"*12*2mm
1/4"*20*32mm
3
4
5
6
7
8
Flat Washer 5/16"*22*2mm 4 pcs
Spring Washer 4 pcs
5/16"*12*2mm
Allen Key 4mm 1 pc
Nut 5/16"*12mm 4 pcs
1 pc
4 pcs
Screw #4 x 45mm
Wrench 12*88mm
COMPONENT LIST
NO.
A
B
C
E
Description Sketch Q`TY
1pc
1pc
2pcs
1pc
Back Rest
Seat Cushion
Front Leg - L
Stretcher
This product is manufactured by JSFC for
Tool Required(not provided)
9
HARDWARE LIST
D 1pc
Front Leg - R
C

ASSEMBLY INSTRUCTION
JSFC
This product is manufactured by JSFC for
A
B
3
2
3
1
STEP 1: Attach the Seat Cushion (B) to Back Rest （A), secure with Flat Washers, Spring Washers and
Bolts (2) by using Allen Key (3).
Step 1
Step 2
STEP 2: Attach the Seat Cushion (B) to Back Rest （A) , secure with Flat Washers, Spring Washers and
Bolts (1) by using Allen Key (3).
Notes: Please make sure all bolts & screws
have been completely tightened before using.
6
5
4
7
C
B
A
E
8
Step 4
not provided
Step 3
9
STEP 3: Attach The Front Leg L (C) and Front Leg R (D) to Seat Cushion (B), secure with Flat Washers
(4), Spring Washers (5) and Nuts (6) by using Wrench (7).
STEP 4: Attach The Stretcher (E) to Front Leg L/R (C/D) and Back Rest (A), Secure with Screws (8), by
using Philips Head Screw Driver (9) (not provided).
C
D
SKU 42407278 / 42407280
727 / 728-12 SIDE CHAIR
