Ropox Hudson 40-25023 User manual

Hudson, shower bed
User Manual
Mounting instruction
Keep this folder with the product at all times

Page 2
Content
Content .................................................................................................................................................. 2
Product information ............................................................................................................................................... 3
Part Numbers ......................................................................................................................................................... 3
Technical data ........................................................................................................................................................ 4
Daily use ................................................................................................................................................................. 4
The slat ................................................................................................................................................................... 4
After use................................................................................................................................................................. 5
Recommendations in use ....................................................................................................................................... 6
Important info before mountin ............................................................................................................................ 7
Placement of the Main 230 V socket, the hot and cold Water and the Drain: ......................................................... 7
Mountin Instructions ............................................................................................................................................ 8
Receivin the Hudson Shower Bed: ........................................................................................................................ 8
1. Prepare the mountin / dismount the top cover plate ....................................................................................... 9
2. Prepare the mountin / dismount the front plate .............................................................................................10
3. Mountin to the wall .........................................................................................................................................11
4. Remount the front plate ....................................................................................................................................13
5. Mount the shelves on the Liftin unit. ...............................................................................................................14
6. Mount the Shower tray on the Liftin unit. .......................................................................................................15
Wire dia ram ........................................................................................................................................................19
Connectin cables..................................................................................................................................................20
Disconnectin cables .............................................................................................................................................20
Placement of the handcontrol. ..............................................................................................................................20
Labelling .............................................................................................................................................. 21
Label......................................................................................................................................................................21
Symbol view: .........................................................................................................................................................21
Support ................................................................................................................................................ 22
Fault findin ..........................................................................................................................................................22
Waste handlin .....................................................................................................................................................22
Factors affectin the operation .............................................................................................................................22
Factors affectin stora e and transport .................................................................................................................22
Spareparts ........................................................................................................................................... 23
Accessories .......................................................................................................................................... 24
Bed uard ..............................................................................................................................................................24
Maintenance ....................................................................................................................................... 25
Cleanin ................................................................................................................................................................25
CE- erklæring ....................................................................................................................................... 26
EU – Declaration of Conformity .............................................................................................................................26
Co plaints........................................................................................................................................... 27

Page 3
General information
Product information
Product : Hudson Shower bed, height adjustable
Producer : Ropox, DK-47 Naestved, Phone [phone]
Usability – The height adjustable shower bed can be used to nurse children and
adults (up to 15 Kg). The shower bed can be used at home, in day care center or
institutions to obtain good and correct working conditions for the carer.
When not in use, the shower tray can be folded up against the wall to save space.
By using the up and down button on the handheld control switch, the height
adjustment of the shower bed can be performed.
Part Numbers
Length of
shower bed Part No.
146cm 4 -25 23
178cm 4 -25 26
21 cm 4 -25 29
It is important to read this manual before mounting and daily
use.

Page 4
General information
Technical data
Electrical connection: 23 V, 5 Hz, max 2. A
Standby consumption: 7W
Duty cycle: Max 1 %, 2 min/18 min
Height: Work surface 3 – 1 cm
Unit, B=6 cm, H=116cm, D=13cm
Material – Frame: Welded steel tubes St.37, Stainless and aluminum
Shower tray: ABS
Surface treatment: Powder coating, white RAL 9 1 matt, Chromate
Maximum load: 15 kg
This product has CE-marking according to ”Medical equipment, Low
Voltage and EMC directives. Has been tested according to the European
standards DS/EN ISO 12182 and DS/EN ISO 6 6 1-1. This product is in risk
group 1.
Daily use
Before start using this product, be sure that “main power” has been connected as
described in electrical connections.
By using the up ▲ down ▼ bottom on the handheld control switch, the height
adjustment of the shower bed can be performed. The control switch has a spiral
cord, which can be pulled out to a length of 2 cm.
The slat
The slats have two sides with
different hardness and can be turned
around in the Shower tray.
The soft side is used, when the
person on the Shower bed needs to
be washed.
The hard side is used, when the
person on the Shower bed needs to
be changed.
Maximum load onto the Hudson Shower bed 150 kg.

Page 5
General information
After use
When not using the shower bed, the shower tray can be folded up against the Lifting
unit. This way it will only take up the space of approx. 30cm from the wall.
Inside the lifting unit, a gas damper is mounted, to reduce the power needed, when
folding the tray up and down.

Page 6
General information
Recommendations in use
The height ad ustable shower bed helps the caretaker to obtain the most optimal
working height.
Height ad ustment allows you to customize the working height to the individual
carer, and can also save unnecessary lifting, when transferring from e.g. wheelchair.
To ensure optimum utilization of the shower bed features
and avoid accidents, it is important to observe some
basics safety procedures
•NEVER leave a person on the shower bed unattended - not even for a very short
period.
•The shower bed must be operated only by adults.
•Pay particular attention to other people in the room, when using the shower
bed. Make sure that no children are playing under or with the shower bed.
•Keep the hand control out of the reach of children. Make sure that they cannot
operate the shower bed unattended. A bracket for wall mounting is included with
delivery.
•Make sure that there is free space above and below the shower bed to allow
height ad ustment. The shower bed is upfoldable, but please be aware of
obstacles above, below and around the shower bed to prevent risk of trapping.
•If the control switch has been damaged or stopped working, it has to be replaced
immediately. The up and down buttons are “push and hold”. The motor stops
when the button is being released. This is a very important safety element.
•If two shower beds are mounted next to each other, we recommend to mount a
side cover between, to avoid the risk of trapping.
•Constantly be aware of ob ects under the shower bed.

Page 7
Mounting Instructions
Important info before mounting
Make sure that you allow free space on all sides of the Hudson unit as shown below.
Placement of the Main 230 V socket the hot and cold Water and
the Drain:
The main 23 V socket, the drain and the hot and cold water, must be placed in the
free area beside the lifting unit and according to the national requirements for such
installations.

Page 8
Mounting Instructions
Receiving the Hudson Shower Bed:
The Hudson Shower Bed will come in two packages. One for the “Lifting unit” and
one for the “Shower tray unit”.
It is important to follow the mounting instructions to assemble the unit in the right
way and to obtain a safe product.
Lifting unit
Shower tray

Page 9
Mounting Instructions
1. Prepare the mounting / dismount the top cover plate
Pull up the cover plate on the top of the lifting unit to get access to the nut, which
holds the front plate. Loosen this nut.

Page 10
Mounting Instructions
2. Prepare the mounting / dismount the front plate
Slide the front plate out of the Lifting unit to get access to the wall mounting holes
in the unit.
!! Be aware not to bend or scratch the front plate in the process !!
