Rosco Mor-Vision STSK1030 Instruction Manual

STSK6630
STSK1030
STSK5530
MOR-VISION MIRROR MONITOR
BACKUP CAMERA SYSTEM
INSTALLATION/USER MANUAL

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
1 2
GENERAL
1. This system is intended for use in automotive applications. Power source
should be an automobile storage battery (12V/24V).
2. Make sure all cables are connected properly. Improper cable connections
may damage the monitor. Remove the cable connection when you do not
intend to use the unit for a long period of time
3. Please install this system according to the instructions in this manual.
4. Connect the system to an ignition switched power source. Connection to
an unswitched battery source will reduce battery life.
WARNING
1. High voltages exist within the monitor. Opening of monitor case is unsafe, and
never necessary for operating purposes.
2. In case of any failure, please turn off the display at once, and notify our
company or the corresponding dealer. The monitor is made up of many
precise electronic components. Any disassembly or modification may lead
to damage and voiding of warranty.
WARNING
1. To prevent electrical shock, DO NOT OPEN THE MONITOR CASE.
There are dangerous voltages inside the monitor. There are no user
serviceable parts inside.
2. Avoid exposing monitor to water, rain, moisture etc. It is NOT waterproof.
Any moisture inside the monitor could cause extensive damage.
3. Do not disassemble the camera or the monitor. This voids the
warranty. Disassembling the camera will compromise the waterproof seal.
STORAGE
1. Do not expose the monitor to excessive heat or cold. The storage
temperature of this device is -5ºF~+158º F, and operating temperature is
+5ºF~+149ºF.
2. Do not store or operate in humid environments.

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
3 4
INSTALLATION INSTRUCTIONS
IMPORTANT
For typical rear-view installation, the rear camera MUST be connected
to the power harness at the connector marked “REVERSE”
NOTE : THE FOLLOWING INSTRUCTIONS ARE FOR TYPICAL REAR-VIEW
APPLICATION.
STSC109B CAMERA
1. Find location for camera close to rear marker lights, centered on vehicle.
Attachment point must be sturdy enough to support camera and bracket.
(Fig. 1)
2. Camera is designed for installation near the top of the vehicle in order to capture
images of the rear bumper and danger zones immediately behind the vehicle.
It is not recommended to be installed near the bumper. This reduces the view of
critical areas and increases the chance of physical damage to the camera.
3. Remove camera cover by removing the screws located at the ends of the camera.
Remove camera by twisting retaining ring counterclockwise until camera is
released. (Fig. 2)
4. Drill one ¾” (16mm) hole where the camera cable will go through the body of
the vehicle. Make sure there are no obstructions behind your hole. (Using the
camera base as a template, drill two 1/8”(3.5mm) holes for attachment screws.
(Fig. 3)
5. Attach camera housing to vehicle with screws provided.
6. Insert camera back into housing and adjust lens angle to desired setting. Note that
the light sensor is the bottom of the camera. Once the angle is set, tighten retaining
ring onto camera. Tighten set screws on the sides of the camera. (Fig. 4)
7. Return top cover and secure with original screws. (Fig. 5)
STSM217 MONITOR
1. Attach mirror/monitor inside vehicle in an existing interior mirror location
(e.g. center of dash, or overhead).
3. Fasten mirror monitor to bracket and adjust mounting angle to allow optimum
driver viewing comfort.
STSH341 CAMERA EXTENSION CABLE
1. Be sure to position the cable properly. The male end attaches to the camera.
The female end attaches to the power/video/audio distribution harness, typically
located under the dashboard.
2. Do not run the cable over sharp edges or corners. Do not kink the cable.
Keep the cable away from hot and rotating parts.
3. Fasten all cable runs, and secure all excess cable. (Fig. 6)
COLOR BACKUP CAMERA SYSTEM, COLOR MIRROR MONITOR
Please read this manual thoroughly. This manual contains instructions to make
the installation of the camera and monitor easier. The mirror/monitor backup
camera system is an upgrade to standard rearview mirror systems, and will provide
additional rearview vision when installed and maintained properly. It is not intended
in any way to be a substitute for careful and cautious driving. All applicable traffic
laws and motor vehicle safety regulations must still be obeyed.
FEATURES
STSC109B CAMERA
• 40,000 pixel image sensor
• 0.5 Lux sensitivity (6 IR-LED)
• Auto white balance (AWB)
• Field of view 150° diagonal
• Automatic electronic iris provides a clearer,
more consistent image in low and bright light
• Compact and lightweight design installs
easily into most vehicles
• Rain/snow proof
CONTENTS OF COMPLETE SYSTEM
STSM217 HIGH BRIGHTNESS
LCD COLOR 7” MONITOR
• Menu button for picture,
system and options
• 2 video channels
• Power/stand-by switch
• Built-in speaker
• Auto-dimming
PART LIST STSK1030
Power Harness STSK5465/PHAR
Backup Camera STSC109B
Extension Harness STSH341
Fuse Holder HAR6028 (x2)
Interior
Mirror/Monitor
STSM1030A (includes
Monitor STSM217)
PART LIST STSK6630
Power Harness STSK5465/PHAR
Backup camera STSK109B
Extension Harness STSH341
Fuse Holder HAR6028 (x2)
Interior
Mirror/Monitor
STSM630A (includes
Monitor STSM217)
PART LIST STSK5530
Power Harness STSK5465/PHAR
Backup Camera STSK109B
Extension Harness STSH341
Fuse Holder HAR6028 (x2)
Interior
Mirror/Monitor
STSM530A (includes
Monitor STSM217)

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
5 6
1. Monitor: Connect the red wire to an ignition switched accessory (ex: radio)
power source, and connect the black wire to chassis ground. See wiring diagram for
connections (See Fig. 6.)
2. The monitor terminates in a 13-pin connector, which should be connected to the
mating 13-pin receptacle end of the power/video/audio distribution harness. When
connecting the cables check to make sure to match the directions of the arrows on the
13-pin connectors (male to female.)
3. For typical rearview installation, connect the camera extension cable from the rear
view camera to the harness connector marked C1.
4. For multi-camera installations, be sure to mark each extension cable properly and
connect to the appropriate harness connector marked C1 or C2. Bundle excess cable
together using a cable tie or electrical tape.
5. The green wire is the REVERSE trigger wire. In typical rearview installations,
connecting this wire to the vehicle’s backup light circuit will activate the rearview
image whenever the vehicle shifts into reverse.
6. Camera: Drill a ¾” (16mm) diameter hole into vehicle body near the camera and
bracket. Insert camera cable into vehicle (be careful not to kink cable) and fit grommet
into hole. Apply sealant around grommet to increase resistance to water penetration.
Connect camera to the camera extension cable which runs inside the vehicle.
7. Feed as much cable as possible into vehicle and clamp securely. This reduces the
possibility of it being hooked or snagged.
8. Keep all cables away from HOT, ROTATING, and ELECTRICALLY NOISE components.
9. FUEL TANKERS & OTHER SPECIALTY VEHICLES: All electrical equipment fitted
to petroleum vehicles must be connected via battery master switch and must be
isolated from the battery while the vehicle is loading and unloading. For other
specialty vehicles, please check applicable code and regulations prior to installation.
10. Always consult your dealer when fitting an electrical or electronic equipment to a
vehicle fitted with a CAN-bus or multiplex system.
IMPORTANT
For installations requiring multiple cameras, or for installations not requiring
typical rearview images, please refer to the wiring diagram (Fig.6) and the
particular vehicle’s electrical schematic for selection of proper power and
trigger connection points.
WIRING CAMERA AND MONITOR
FUNCTIONS AND OPERATIONS
MONITOR
1. POWER
When the ignition is switched on, the monitor will be in standby mode, waiting for
trigger signal. (When a trigger wire is energized by 12v power, the image captured
by the selected camera will appear on the monitor.) Pressing the power switch will
change the monitor status from standby to steady-on. Steady-on mode status will
show camera view depending on user selection.
2. LIGHT SENSOR
When auto dimming is active, monitor will automatically change screen brightness
according to ambient light around the monitor.
3/5. VOLUME +/-
Adjust Speaker Volume. These buttons are also used to adjust the values
within selected setting of menu option.
4. ‘MENU’ Button (See p.7)
Press MENU to active screen options.
Press Menu to cycle through choices and +/- to change settings.
6. C1/C2
Switches from Camera 1 to Camera 2 and vice-versa.

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
7 8
SPECIFICATIONS
STSC109B CAMERA
Pickup Device 1/4” CMOS Sensor
TV System NTSC
Pixels 720(H) x 480(V) NTSC
Sensing Area 5.6mm x 5.6mm
Horizontal Resoulution 420 TV Lines
Signal to Noise Ratio Minimum 45dB
Power Supply 12VDC
Max Power Consumption 1.8W at 12VDC
Current MAX. 75MmA
Lens Angle 150o(D)
Operation Temperature -5oF to +140ºF (-20oC to 60oC)
Storage Temperature -5oF to +167ºF (-20oC to 75oC)
Weight 0.23lbs (0.1kg)
Dimensions W x H x D (83.5 x 57.8 x 44.2 mm)
( 83.5 x 57.8 x 44.2 mm )
STSM217 MONITOR
Screen 7.0 inch Color TFT-LCD High Brightness
Voltage Input Range 12 to 24 VDC
Power MAX. 75MmA
Max Current Consumption 850 mA at 12VDC
TV System NTSC
Video Input/Output Composite Video Single (1vp-p 750OHM)
Resolution 800(H) x 480(V)
LCD Brightness 1800cd/m2
Operating Temperature -5oF to +149oF (-15oC to 65oC)
Storage Temperature 5oF to 158oF (-20oC to 70oC)
DISCLAIMER
The use of Rosco’s Vehicle CCTV system should not in any way be used as a substitute for careful and cautious
driving. Always obey traffic laws and motor safety regulations must always be adhered to. Specifications subject to
change without any notice.
NOTE: On-screen menu commands should only be selected when monitor is in
steady-on mode. Never change settings while operating vehicle.
Press the MENU button once to set desired brightness.
Press +/- to increase/reduce the brightness.
Wait 3 seconds to exit setup mode.
Press the MENU button twice to set desired contrast.
Press +/- to increase/reduce the contrast.
Wait 3 seconds to exit setup mode.
Press the MENU button three times to set desired color.
Press +/- to increase/reduce the color.
Wait 3 seconds to exit setup mode.
Continue to press the MENU button to change desired settings.
Tint: Press +/- to increase/reduce the tint
Language: Press +/- to select English/ French/ Spanish.
Reset: Press +/- to restore factory defaults.
CAM1: Press +/- to select Normal/Mirror mode.
CAM2: Press +/- to select Normal/Mirror mode.
Vertical: Press +/- to flip image vertically.
Dimming: Press +/- to select Auto/ Day/ Night.
Scale: Press +/- to select On/Off for backup grid to appear when in triggered mode.
Scale Adjustment: Press - to change selected line on backup grid.
Press + to adjust position of line on backup grid.
Wait 3 seconds to exit setup mode.
MENU CONFIGURATION

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
FIG. 1
9
FIG. 2
CAMERA HOUSING
CAMERA MOUNTING HOLE PATTERN
FIG. 3
10

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
FIG. 4
FIG. 5
11
FIG. 6
12
Note: For typical single camera installation, this trigger wire should be
connected to the vehicle’s “back up lights” circuit, and the rearview camera
should be attached to the connector marked “REVERSE”

Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual Mor-Vision™Mirror/Monitor Backup Camera System, Installation User Manual
NOTES
13
NOTES
14

90-21 144th Place, Jamaica, New York 11435
TEL [phone] • FAX [phone]
[email protected]
www.roscomirrors.com www.roscovision.com
A CENTURY OF AUTOMOTIVE VISION SAFETY
M6212018
