Rosco STSK453X Series Instruction Manual

90-21 144th Place
Jamaica, NY 11435
1.800.227.2095
www.roscovision.com
Smart-VisionTM 4.3" Rearview
Mirror/Monitor Combo
Backup Camera System
INSTALLATION/USER'S MANUAL
STSK453X Series

STSK4530 Component List
Qty P/N Qty.
1
STSC130W (White)
STSC130R (Chrome)
STSC130B (Black)
*system comes with 1 camera
with a choice of 3 colors:
BACK UP CAMERA, INCLUDES:
P/N STSC100X HIGH MOUNT, LOOK DOWN
CAMERA WITH HARDWARE
P/N STSH333 CAMERA POWER & SPLITTER
HARNESS
1 STSM230
BACK UP CAMERA MIRROR/MONITOR
INCLUDES:
P/N STSM1000 4.3" COLOR MIRROR MONITOR
P/N STSW1000 WINDSHIELD MOUNT #1 FOR
MIRROR MONITOR
P/N STSH4530 MONITOR POWER HARNESS
1 STSH330 BACK UP CAMERA EXTENSION HARNESS,
25FT, ROSCO, P/N STSH330
Notes:
• Please read this manual carefully before using the product.
• This system is intended as an aid to safe reverse operation. Drivers must always use extreme
caution when operating a vehicle.
• Specications subject to change without prior notice.
Warning:
• To prevent electrical shock, DO NOT OPEN MONITOR CASE.
• Avoid exposing monitor to water, rain, moisture etc.
• Do not disassemble the camera. This voids the warranty. Disassembling the camera will
compromise the waterproof seal.
1www.roscovision.com
STSM230
STSW1000
STSM1000
STSH4530
STSH330
STSC1001 STSC1002 STSC1000
STSH333
STSC130W STSC130R STSC130B

STSK4531 Component List
Qty P/N Qty.
1
STSC130W (White)
STSC130R (Chrome)
STSC130B (Black)
*system comes with 1 camera
with a choice of 3 colors:
BACK UP CAMERA, INCLUDES:
P/N STSC100X HIGH MOUNT, LOOK DOWN
CAMERA WITH HARDWARE
P/N STSH333 CAMERA POWER & SPLITTER
HARNESS
1 STSM231
BACK UP CAMERA MIRROR/MONITOR
INCLUDES:
P/N STSM1001 4.3" CLIP ON COLOR
MIRROR MONITOR
P/N STSH4530 MONITOR POWER HARNESS
1 STSH330 BACK UP CAMERA EXTENSION HARNESS,
25FT, ROSCO, P/N STSH330
Notes:
• Please read this manual carefully before using the product.
• This system is intended as an aid to safe reverse operation. Drivers must always use extreme
caution when operating a vehicle.
• Specications subject to change without prior notice.
Warning:
• To prevent electrical shock, DO NOT OPEN MONITOR CASE.
• Avoid exposing monitor to water, rain, moisture etc.
• Do not disassemble the camera. This voids the warranty. Disassembling the camera will
compromise the waterproof seal.
2www.roscovision.com
STSH330
STSC1001 STSC1002 STSC1000
STSH333
STSM231
STSH4530
STSC130W STSC130R STSC130B
STSM1001

Smart-VisionTM 4.3" Rearview Mirror/Monitor
Combo Backup Camera System
Rosco Vision Systems introduces a revolutionary new
backup camera system for small to medium vehicles.
Smart-VisionTM utilizes an interior rearview mirror to
display a 4.3" LCD monitor when the vehicle shifts into
reverse. This monitor allows the driver to see behind
the vehicle for added convenience and safety.
The camera has an advanced CMOS lens sensor
able to process excellent images under dark and light
conditions. The camera has a 170° diagonal eld of
vision giving superb coverage behind the vehicle and
complies with the latest NHTSA 49 CFR Parts 571 and
585 (RIN 2127-AK43), when installed properly.
General Technical Specications:
Power Supply: 12VDC
Power Consumption: ~3 Watt
Current Draw: ~250 mA
Video Input: 1 Vp-p@75 impedance
Monitor Dimensions: 11"W x 3"H x 1.5"D
Installation Tools:
C O N T E N T S
How To Operate
Display.............. 4
Color Camera ... 7
Wiring
Diagram ......... 5-6
Rearview Mirror
Installation....... 8
Camera
Installation....... 9
Testing &
Maintenance .. 10
3
A Century of Automotive Safety
1. Wire Tester 4. Wire Stripper 7. Drill
2. Phillips Screwdriver 5. Pencil 8. Tape
3. Tape Measure 6. Drill Bits 9. Wire Ties
(Not Shown)
1.
2.
3.
4.
5.
7.
8.
6.

4www.roscovision.com
How To Operate Display:
1. V1/V2 - Not Applicable.
2. "Up" - Menu selection control.
3. Menu - Switches to setup menu.
4. "Down" - Menu selection control.
5. Power - Switches monitor off.
Typically not used
How To Set Your Monitor:
On-screen menu commands may be
selected pressing the MENU button
while the mirror/monitor is on:
Brightness
Contrast
Saturation
Hue
Sharpness
4:3/16:9
Reset
How To Operate Display
Monitor Technical Specications:
Screen: 4.3" TFT Color LCD
Brightness: 350cd/m2
Contrast ratio: 300:1
Resolution: 480 x 272
Current Draw: Max 120mA
Video format: NTSC/PAL
Display format: 4 : 3 or 16 : 9
Nomenclature: 12V
Working Temp.
°F(°C): -5° to 158°
(-20° to 70°)
IMPORTANT: The Rearview Mirror/
Monitor is not intended to be used for
prolonged periods of time. Therefore
the monitor stays off until triggered by
reverse circuit.
1.
2.
3.
4.
5.

Option #3: Power Provided From Front and
Back of Vehicle (Least Common)
Option #2: Power Provided From Front of Vehicle
Option #1: Power Provided From Back of Vehicle
(Most Common)
Option #3: Power Provided From Front and
Back of Vehicle (Least Common)
Option #2: Power Provided From Front of Vehicle
Option #1: Power Provided From Back of Vehicle
(Most Common)
AV1 (DO NOT USE)AV1 (DO NOT USE)AV1 (DO NOT USE)
PN: STSH4530 PN: STSH4530 PN: STSH4530
P/N: STSH330 P/N: STSH330 P/N: STSH330
P/N: STSH331
Note: Additional
wire or adjustment
to harness may be
required.
P/N: STSH331
Note: Adjustment
to harness may be
required.
P/N: STSH331
P/N: STSH332 P/N: STSH332 P/N: STSH332
P/N: STSM100X P/N: STSM100X P/N: STSM100X
P/N: STSC100X P/N: STSC100X P/N: STSC100X
AV2 AV2 AV2
(Red) (Red)
DO NOT USE
7" 7" 7"
68" 68" 68"
7" 7" 7"
7" 7" 7"
Trigger (Green) Trigger (Green) Trigger (Green)
(Red) 12V (Red) 12V (Red)
Chassis Ground Chassis Ground Chassis Ground
Tie all 3 together
Tie both together
To Positive Reverse
Light Wire At The
Rear Of The Vehicle.
To reverse light circuit
at front fuse box.
To reverse light circuit
at front fuse box.
To Chassis
Ground To Chassis
Ground
To Chassis
Ground
5 6
Wiring DiagramWiring Diagram
Red Power
Wire Red Power
Wire
12" 12" 12"
11" 11" 11"
11"
3A 250V
11" 11"
26' 26' 26'
2" 2" 2"
10" 10"
10" 10"
2" 2" 2"
8" 8" 8"
3' 3' 3'
76" 76"
76"
To Positive Reverse
Light Wire At The
Rear Of The Vehicle.
3A 250V 3A 250V
(Red)

7
Color Camera
A Century of Automotive Safety
Camera Technical Specications:
Signal System: NTSC
Sync System: Internal
Horizontal Resolution: 420TVL
Minimum Illumination: 0.2Lux
Diagonal Angle: 170°
Video Output: RCA, 1.0Vp-p,
75ohm
Waterproof Grade: IP67
Current Draw: Max. 90mA
Nominal Voltage: DC12V
Working Temp. °F(°C): -22° to 158°
(-30° to 70°)
Features and Benets:
• Superb Night Vision
• 170° Diagonal eld of vision
• Easy installation
*STSC130 Color Camera is also available in chrome (Not Shown)

Rearview Mirror Installation
Figure. 2
Figure. 1
For standard mirror monitor
1. Attach windshield mounting bracket
to the back of STSM230 mirror/
monitor. Be certain that the monitor
is in the upright position when
attaching the mounting bracket.
(Figure 1)
2. Remove old rearview mirror from
factory mirror-mount tab.
3. Mount rearview mirror/monitor
securely to mounting tab by
tightening screw. (Figure 2)
4. Route the 8-pin connector end of
the power harness to the location
of mirror/monitor (preferably
through the headliner and the
vehicles A or B pillars).
5. Connect the power harness with
the mating 8-pin receptacle end
coming out of the mirror/monitor.
IMPORTANT: Please be certain to
match both guiding lines on each
connector for a proper connection.
For clip on mirror monitor
1. Expand STSM231 mirror monitor
clamps and place over existing rear
view mirror
www.roscovision.com
Tightning Screw
8

9
Camera Installation
A Century of Automotive Safety
1. Select a high and centered location
at the rear of the vehicle to mount
the STSC130 camera.
IMPORTANT: When selecting this
location it is highly recommended
that the image transmitted by the
camera show the rear bumper and
area behind the vehicle.
2. We do not recommend mounting
the camera near the lower area of
the vehicle (ex. bumper). This
reduces the view of the camera and
increases the chance of physical
damage to the camera.
3. Once the location for the camera
is chosen, drill the mounting hole
to the inside of the vehicle using a
5/16 drill bit. Be sure to clear any
obstacles before drilling hole.
4. Attach the provided 3M double
sided tape to the back of the
camera.
5. Insert camera wire through newly
drilled hole and mount securely in
place.
6. To nalize the camera installation,
hand tighten the provided 5/16 nut
to the back of the camera on the
inside of the vehicle.
Figure. 1
Figure. 2
Figure. 3
Camera mount in
suggested location
Mount camera assembly high. (Centered)
Typical monitor image of view from properly
installed camera
Obstructions behind truck
Diamond Plate
Position of camera

10 A Century of Automotive Safety
Testing
How to Test:
1. Apply the parking brakes.
2. Turn Ignition on. (DO NOT TURN ON VEHICLE)
3. Shift into reverse gear.
4. Image should appear on the monitor.
Trouble Shooting:
Problem Solution
No power to monitor while reversing. Check power and reverse trigger
connections.
"No Signal" appears while reversing.
1. Press AV1/AV2 button to change
video inputs.
2. Check video input connections.
3. Check camera power connections.
Video image is not sharp. Check camera lens for debris.
Maintenance:
Always keep camera clear from dirt, snow, and mud. Clean camera with a soft
moist cloth.

A Century of
Automotive Safety
90-21 144th Place
Jamaica, NY 11435
www.roscovision.com
Ph. 1.800.227.2095 Fx. 1.718.297.0323
Printed in China
Lit. P/N: 04242012
