Rosco myMIX CONNECT User manual

USER MANUAL - myMIX®CONNECT 1
myMIX®CONNECT
WHAT IS myMIX CONNECT?
The Rosco myMIX Connect dongle works in conjunction with the
myMIX app, providing the opportunity to preview, save, recall, and
send specified colors and white presets via RDM. Choose from a
database of True Rosco Color™gel matches or build your own color
through the myMIX App Color and White Modes.
• RJ45 Connector
• Self-Powered via Miro Cube®2
• Secure access via unique pairing code
• 68mm (2.69”) long x 21mm (.81”)
• 3-year limited warranty
Compatible Rosco Products:
Miro Cube®2 WNC
Miro Cube®2 4C
Miro Cube®2 4CA
Miro Cube®2 UV365
myMIX®Connect
DESIGNED BY THE BLACK TANK

USER MANUAL - myMIX®CONNECT 2
myMIX®CONNECT
Download the myMIX app.

Press SCAN.
Click on myMIX Connect.

Note: myMIX Connect will not be visible if another device is
connected to it. The current user can disconnect by pressing
the 3 dots and choosing "Disconnect", or by pressing and
holding the product name.
1
2
4
5
6
IOS ANDROID
SETTING UP YOUR myMIX CONNECT
Sign into your app and press "No Light Connected" to get started.
3
Enter pairing code (found on a label in packaging material).
Note: for security purposes, each myMIX Connect comes with a unique pairing

with this pairing code can control the dongle via the myMIX App. Simply enter the
7
Select the down arrow to enter live mode.
8
pairing code when prompted in the myMIX
App. The pairing code will remain connected
-

Please contact [e-mail] to
retrieve misplaced pairing codes.

USER MANUAL - myMIX®CONNECT 3
myMIX®CONNECT
MIXING COLORS
Gel ModeWhite Mode Color Mode


•White Mode

•Gel Mode gives you access to up to 54 True Rosco Color™gel matches.
•Color Mode

USER MANUAL - myMIX®CONNECT 4
myMIX®CONNECT
SAVING COLORS
To save a color, press the "save"

on the control window.
Name your color, and select or
create the folder you want to
have it saved in.


USER MANUAL - myMIX®CONNECT 5
myMIX®CONNECT
You can share a color or a folder via email, text message, or

an Android device. "Share this preset" will be displayed on an
iOS device.
SAVING COLORS SHARING COLORS
Clicking on the 3 dots next to the color will open its color card.

USER MANUAL - myMIX®CONNECT 6
myMIX®CONNECT
RDM VIA myMIX CONNECT



screen to adjust the DMX address or

or parameter you would like to toggle
from the menu.


Note: Some features may not be avai-



Connect".

USER MANUAL - myMIX®CONNECT 7
myMIX®CONNECT
MULTIPLE FIXTURES







RJ45 PIN LAYOUT
Pin 1 = D1 + (Data from dongle)
Pin 2 = D1- (Data from dongle)
Pin 3 = D2+ (Power for dongle)


Pin 6 = D2- (Power for dongle)
Pin 7 = Ground
Pin 8 = Ground

USER MANUAL - myMIX®CONNECT 8
myMIX®CONNECT
DISCLAIMERS CERTIFICATIONS
General precautions
• Rosco products are made to be used by trained professionals only.
• Rosco products are not for household use.
• Rosco myMIX Connect is designed for operation within the range of -4° to 113°F
(-20° to +40°C).
• Ensure Rosco myMIX Connect Dongle is stored within the range of -4° to 140°F
(-20° to +60°C).
Risk of electric shock and fire
• Do not open the product. There are no user serviceable parts inside.
• Must only be serviced by a qualified technician.
• Do not operate the product if the ambient temperature exceeds 113ºF (40° C).
• Let the product cool down completely before you handle it.
Warnings
• Not for residential use.
• Not for household use.
Certifications

ETSI EN 300 328 V2.1(2016-11)
Draft ETSI EN 301 489-1 V2.2.0 (2017-03)
Draft ETSI EN 301 489-17 V3.2.0 (2017-03)
EN 62479 : 2010
FCC :
This device complies with Part 15 of the FCC Rules.
ROHS :
          


USER MANUAL - myMIX®CONNECT 9
myMIX®CONNECT
3-YEAR LIMITED WARRANTY
Rosco Laboratories warrants to the first retail purchaser that this Product will be free from defects in workmanship and material for a period of 36 months from the date of original
purchase.
For warranty service you must be able to provide proof of purchase. Should this Product prove defective during the warranty period, please contact your local Rosco office for
Return Authorization. No warranty service will be performed without Return Authorization.
At Rosco’s sole discretion, covered Products will be repaired or replaced with new or refurbished equipment or a model of like kind and quality. Exchanged or replaced parts and
Products assume the remaining warranty period of the original product covered by this limited warranty. You are responsible for securely packaging the defective. Product and
returning it to Rosco as per the instructions of the Return Authorization. Within North America, Rosco will ship the repaired or replaced Product to you freight prepaid. Shipments
to other locations will be made freight collect.
This warranty is non-transferable and does not extend beyond the first retail purchase of the Product.
This warranty does not cover damage to the Rosco Product caused by parts not manufactured, distributed or certified by Rosco.
Rosco is not obligated to provide warranty service should the Product fail to be properly maintained or fail to function properly as a result of misuse, abuse, improper installation,
neglect, improper shipping, damage caused by disasters such as flood, fire and lightning, improper electrical current or unauthorized service repairs other than those by a Rosco
Authorized Servicer.
If a claimed defect cannot be identified or reproduced, you will be held responsible for the costs incurred. Unless otherwise stipulated by state law, all warranties expressed or
implied are limited to the 36 month period of this warranty.
THE WARRANTYAND REMEDY PROVIDED ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS OR IMPLIED WARRANT IES INCLUDING BUTNOTLIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED IN THIS WRITTEN WARRANTY
AND UNLESS EXCLUSIONS ARE SPECIFICALLY FORBIDDEN BY STATE LAW, NEITHER ROSCO NOR ITS AFFILIATES WILL BE LIABLE FOR ANY LOSS, INCONVENIENCE, OR
DAMAGE, INCLUDING DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING INJURY TO PERSONS OR PROPERTY, RESULTING FROM THE USE OR
INABILITY TO USE THE ROSCO PRODUCT, WHETHER RESULTING FROM BREACH OF WARRANTY OR ANY OTHER LEGAL THEORY.
