Rosen Aviation 7004 Series User manual

Document Number 106211
Rev B
ELECTRONIC REVISION
CONTROLLED

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 2 of 31
Technical Manual, 7” Widescreen Display
© 2013, 2014 by Rosen Aviation, LLC
All Rights Reserved
The information contained herein is proprietary to Rosen Aviation, LLC. No part of this publication
may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any
language in any form by any means without the written authorization from Rosen Aviation, LLC,
except as allowed under copyright laws.
Disclaimer of Liability
The information contained in this document is subject to change without notice. Because we are
continuously improving and adding features to our products, Rosen Aviation, LLC reserves the right
to change specifications without prior notice. Rosen Aviation, LLC shall not be liable for technical or
editorial errors or omissions contained herein.
Rosen Aviation, LLC
1020 Owen Loop South
Eugene, OR 97402
541.342.3802
888.668.4955
Fax: [phone]
www.rosenaviation.com

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 3 of 31
Contents
1. INTRODUCTION.................................................................................................................5
1.1. Base Compatibility........................................................................................................5
2. SYSTEM OVERVIEW .........................................................................................................6
2.1. High-definition Systems................................................................................................7
3. INSTALLATION GUIDELINES...........................................................................................7
3.1. Installing/Removing SlimLine Arm Assemblies.............................................................8
3.2. Stowing a Locking Arm Display ....................................................................................8
3.3. CVBS Pogo Connection Displays.................................................................................9
3.4. CVBS Micro-D Connection Displays...........................................................................10
3.5. SDI Pogo Connection Displays...................................................................................11
3.6. Base Installations........................................................................................................12
3.6.1. CVBS Pogo Base Receptacles....................................................................................... 12
3.6.2. SDI Pogo Base Receptacles........................................................................................... 12
3.6.3. CVBS Micro-D Base Receptacles................................................................................... 13
3.7. Electrical Requirements..............................................................................................13
3.8. Pinout Connections.....................................................................................................13
3.8.1. RS-232 Control............................................................................................................... 13
4. INITIAL POWER UP .........................................................................................................14
5. DISPLAY TOUCH CONTROLS........................................................................................14
5.1. Source Select .............................................................................................................14
6. OSD MENU OPTIONS......................................................................................................15
6.1. Exit..............................................................................................................................15
6.2. User Menu..................................................................................................................16
6.2.1. Backlight......................................................................................................................... 16
6.2.2. Aspect Ratio................................................................................................................... 16
6.2.3. Scheme.......................................................................................................................... 17
6.3. Image Adjust Menu.....................................................................................................17
6.3.1. Scheme.......................................................................................................................... 17
6.3.2. Picture-quality Controls................................................................................................... 18
6.3.3. Reset Scheme................................................................................................................ 18
6.3.4. Image Adjust Advanced (Submenu) ............................................................................... 18
6.4. Info..............................................................................................................................20
7. TECHNICIAN MENU.........................................................................................................21
7.1. Technician Advanced Submenu.................................................................................22
7.1.1. Factory Reset................................................................................................................. 22
7.1.2. 3D Comb Filter ............................................................................................................... 22
7.1.3. Composite Sig (Signal)................................................................................................... 22
7.1.4. AGC (Automatic Gain Control)........................................................................................ 23

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 4 of 31
7.2. Technician Mode Menu...............................................................................................23
7.2.1. Power Mode ................................................................................................................... 23
7.2.2. Operation Mode.............................................................................................................. 24
7.2.3. SDI Overscan................................................................................................................. 24
7.2.4. SDI Overscan %............................................................................................................. 24
7.3. OSD Timeout..............................................................................................................24
7.4. Front Panel LED.........................................................................................................25
7.5. Source Select Menu ...................................................................................................25
8. MAINTENANCE: TENSION ADJUSTMENTS..................................................................26
9. TECHNICAL REFERENCES AND SUPPORT.................................................................26
9.1. Troubleshooting..........................................................................................................27
9.2. Cleaning the Display...................................................................................................27
9.3. RTCA DO-160F Qualifications for Displays................................................................28
9.4. Supported Video Resolutions .....................................................................................30
9.4.1. CVBS/Composite Resolutions ........................................................................................ 30
9.4.2. SDI Resolutions.............................................................................................................. 30
10. DEFINITIONS..................................................................................................................30
11. REVISION HISTORY ......................................................................................................31

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 5 of 31
1. INTRODUCTION
Rosen’s new 7004 series of personal displays allow for direct upgrades for high-definition and
Composite units with a variety of existing bases on your aircraft. In addition to the sleek, tablet-
style display, the touch-sense front panel enables source select capability directly from the front
panel on select models depending on the base. The 7004 models differ depending on the plug-in
arm configuration and input signal. All SDI models (7004-3xx) support 3G HD-SDI up to 1080p,
and are compatible with the Rockwell Collins Venue™ system using RS-232.
This manual describes the compatibility of bases and display models, and it provides general
instructions about how to install the new arm-mounted displays onto your aircraft and confirm that
they are functioning correctly.
Note: Only trained and qualified personnel should perform installation and service.
Technical drawings and the Technical Manual are available on the Rosen Aviation website at
www.rosenaviation.com. From the home page, select the Products tab and browse by product
category. Please contact Technical Support at 541.342.3802 if you need assistance locating
product information.
1.1. Base Compatibility
The tables below show which bases are compatible with the new 7004 displays. For a
comparison of base-mounting diagrams, see Base Installations, beginning on page 12, to
compare. Bases are sold separately.
Table 1 Composite (CVBS) display and base compatibility
Display
Model
Description
Base
Type
Base Model &
Aircraft Connections
7004-013
7" Center mount, Non-locking arm
Micro-D
0100-002
0100-004
DB9 with
source select
7004-060
7" Left mount, Non-locking arm
0100-005
Molex/BNC
without source
select
7004-061
7" Right mount, Non-locking arm
7004-015
7" Center mount, Non-locking arm
CVBS
Pogo
0100-041
0100-042
DB9 with
source select
7004-037
7" Center mount, Locking arm
0100-040
Molex/BNC
without source
select

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 6 of 31
Table 2 SDI display and base compatibility
Display
Model
Description
Base
Type
Base Model &
Aircraft Connections
7004-362
7”, SDI, Left mount, Non-locking SlimLine
SDI arm
SDI
Pogo
0100-344
RS-232
with source
select
7004-363
7”, SDI, Right mount, Non-locking SlimLine
SDI arm
7004-315
7”, SDI, Center mount, Non-locking
SlimLine SDI arm
0100-342
RS-232
without source
select
7004-337
7”, SDI, Center mount, Locking
SlimLine SDI arm
2. SYSTEM OVERVIEW
The typical installation of personal displays consists of multiple arm-mounted displays connected
to a video source. The following figures show how to configure analog (standard definition) and
HD displays to create a complete cabin entertainment system or integrate a display into an
existing system.
Figure 1 Connecting analog displays
These displays are typically connected to a video distribution unit, which provides a single
Composite video signal (NTSC, PAL, or SECAM) to each display. The video distribution box
performs the source selection.
Composite
Composite
Personal Displays
DVD Player

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 7 of 31
2.1. High-definition Systems
SDI units display either standard definition (SD) or high-definition (HD) video using serial digital
video input. In this configuration, the video is sourced by a digital video distribution switch or
source and de-serialized into an SDI format.
High-definition displays are typically installed in a system where the SDI video is distributed from
a cabin management system and/or HD video distribution to each display.
Figure 2 Connecting HD displays
3. INSTALLATION GUIDELINES
The 7” arm-mount displays plug in to round bases depending on the connector type and input
signal. Ensure the correct orientation when plugging the arm into the base receptacle, as shown
below, so that the alignment pin in the base follows the arm’s keyed slot connection and is not
forced.
Figure 3 Arm and base interface
Blu-ray Player
Blu-ray Player
Personal
Display
HD Distribution
Cabin
Management
System
SDI
SDI
Personal
Display
DVI/HDMI
DVI/HDMI
Slot
Alignment
pin

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 8 of 31
3.1. Installing/Removing SlimLine Arm Assemblies
To install a SlimLine arm assembly, press the arm button all the way in and push straight down
on the arm into the plug body until it is secure in the base.
Figure 4 SlimLine locking arm features
To remove a SlimLine arm assembly, press the arm button in all the way and lift up on the
display/arm assembly.
3.2. Stowing a Locking Arm Display
SlimLine locking arm displays have two locking points at 0º and 180º to secure displays in a
stowed position, without disconnecting power, during taxiing, takeoff, and landing (TTL).
To stow a SlimLine locking arm display, rotate the arm to either 0º or 180 º until it locks. To
deploy a SlimLine locking arm display, press the arm button halfway and rotate the arm away
from the locked position.
Figure 5 Stowing positions for SlimLine locking arm displays
Arm button
Plug body
Arm button
Plug body
Arm rotation
locks at 0º
and 180º
Composite arm
SDI arm

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 9 of 31
To stow a SlimLine SDI locking arm, rotate the arm until it locks into either stowed position. To
deploy, press the arm button and rotate the arm away from the locked position.
Figure 6 Arm button on SlimLine SDI locking arms
Touching the LCD with excessive force may leave pressure spots
that show in video display. Handle with care.
3.3. CVBS Pogo Connection Displays
Figure 7 Pogo connection displays use base receptacles 0100-040, 0100-041, & 0100-042
P/N 7004-015, 7" Display: Pogo, non-locking,
center
P/N 7004-037, 7" Display: Pogo, locking,
center

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 10 of 31
3.4. CVBS Micro-D Connection Displays
Figure 8 Micro-D connection displays use base receptacles 0100-002, 0100-004, & 0100-005
P/N 7004-013, 7" Display: Micro-D, non-locking, center
P/N 7004-060, 7" Display: Micro-D,
non-locking, left
P/N 7004-061, 7" Display: Micro-D,
non-locking, right

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 11 of 31
3.5. SDI Pogo Connection Displays
Figure 9 SDI Pogo-style connection displays use base receptacles 0100-344 & 0100-342
P/N 7004-315, 7" Display: non-locking, center
P/N 7004-337, 7" Display: locking, center
P/N 7004-362, 7" Display: non-locking,
left
P/N 7004-363, 7" Display: non-locking, right

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 12 of 31
3.6. Base Installations
Consult the Outline and Installation drawing to assist with the installation process. Pay close
attention to the dimensions and fastener depths required when considering installation
requirements.
The 7004 displays are compatible with the base designs, as shown below. Bases mount on
either a vertical or a horizontal surface, typically with a minimum of four screws (two per flange).
For base pinout information, refer to the display drawings on the Rosen Aviation website.
3.6.1. CVBS Pogo Base Receptacles
Figure 10 CVBS Pogo-style base receptacles
3.6.2. SDI Pogo Base Receptacles
Figure 11 SDI Pogo-style base receptacle
P/N 0100-041
Base Receptacle: Pogo, DB9 harness,
universal mount
P/N 0100-042
Base Receptacle: Pogo, DB9
harness, horizontal mount
SDI Pogo-style
connection
P/N 0100-344
Base Receptacle:
BNC/DB9 Harness,
SDI, RS-232, with
source select
Note: Base Receptacle
P/N 0100-342 is also
compatible with the 7004
series, but it does not
have source select.
CVBS Pogo-style
connection
P/N 0100-040
Base Receptacle: Pogo
BNC/Molex harness, universal
mount

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 13 of 31
3.6.3. CVBS Micro-D Base Receptacles
Figure 12 CVBS Micro-D-style base receptacle
3.7. Electrical Requirements
Nominal voltage 28VDC / 0.30A
Inrush Current 20A for 250 microseconds
Op Voltage/Current Range 18VDC/0.45A –32VDC/0.27A
Max Power Consumption: 8.6 W
3.8. Pinout Connections
There are several ways to connect a personal display to an aircraft’s entertainment system. Use
the pinout descriptions on the monitor’s Outline and Installation drawing to assist in completing
the wiring connections.
Note: This display is for entertainment purposes only; connect to a non-critical power bus.
3.8.1. RS-232 Control
The SDI displays can be controlled via a cabin management system using RS-232, if an
RS-232 connection is present on the configuration. The display connects to 28VDC
aircraft power and receives video through a video distribution amplifier or directly from
video sources.
For a copy of the RS-232 External Controller Message Formats (P/N 9002934), please
contact Rosen Aviation Technical Support at 541.342.3802.
P/N 0100-002
Base Receptacle: Micro-D, DB9
harness, universal mount
P/N 0100-004
Base Receptacle: Micro-D,
DB9 harness, horizontal
mount
Micro-D-style
connection
P/N 0100-005
Base Receptacle:
Micro-D BNC/Molex harness,
universal mount

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 14 of 31
4. INITIAL POWER UP
Make sure to turn off the power before connecting the harnesses.
1. Ensure low impedance ground connections on the base.
2. Ensure that 28VDC power supply is OFF.
3. Connect the power supply and video source to the appropriate harnesses.
4. Plug in the display/arm assembly.
5. Supply power and wait for a video signal on the screen. The default power setting is
Auto On.
When cycling power, leave unit off for 20 seconds before restoring
power.
5. DISPLAY TOUCH CONTROLS
The 7004 displays have touch-sense buttons on the front panel to control all operating functions;
however, the 7004-3xx models can be controlled from the Rockwell Collins Venue system. Use
the plus (+) and minus (–) buttons to navigate through the options.
Figure 13 Touch controls and functions
5.1. Source Select
Source Select is available depending on the base and video distribution installations on the
aircraft. To change between video sources, press Source Select, either on the front panel or the
remote control.
Power LED
Menu opens the OSD and
accepts option values
Backward
left/down
Power
Forward
right/up
Source Select
switches input
sources

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 15 of 31
6. OSD MENU OPTIONS
The OSD contains screen settings and options in menus and informational readouts that display
over the image, as shown below. Press Menu on the front panel to open the Main Menu, as
shown in Figure 15 on page 15.
Press +and –to navigate within the menu pages, options, and values columns. Select the Back
option to switch menu pages. The yellow highlighted area shows the currently selected option.
Press Menu and +to move right across the menu page options and values.
Press Menu and –to move left across the menu page options and values.
Figure 14 OSD menu pages
The available menu options will vary depending on which source signal is active.
Press Menu to choose a setting or an option.
Select the Back option to switch menu pages.
Select Exit and then press Menu to close the OSD and save the settings.
Note: The on-screen display will timeout and automatically close after no screen activity for a
preset amount of time, which is adjustable on the Technician MenuOSD Timeout option. See
Section 7.3, OSD Timeout, on page 24.
6.1. Exit
Use Exit to close the OSD. When you press Menu, the OSD opens to this screen, as shown
below. Press Menu again to close the OSD from this screen.
Press +and –to access the other menu pages in the OSD.
From other settings within the OSD, select Back and Exit to close the OSD.
Figure 15 Opening screen for the Main Menu
Press +to access
the menu page
options
Press +to access
the menu option
values
Press –to
access menu
pages. The
selected menu
page is
highlighted.

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 16 of 31
6.2. User Menu
The User Menu contains frequently used control settings. Press Menu to open the Main Menu,
and press –and Menu to access the User Page options.
Press +or –to select a User option, and then press Menu to change its value.
Figure 16 User menu options
6.2.1. Backlight
Use this setting to adjust the intensity of the LCD backlight.
From the User page, press +and –to select Backlight, and then press Menu to open
the control bar shown below.
Press +and –to change the value on the control bar accordingly.
Press Menu to set the backlight brightness and close the control bar.
Figure 17 Backlight option
6.2.2. Aspect Ratio
Use Aspect Ratio to adjust the picture expansion to match the encoding of the source
image most closely.
Select UserAspect Ratio and then press Menu. To switch the display between aspect
ratio modes (described below), press the + and –buttons. Watch for proportional
changes in the background picture and choose the optimal mode for the source. Press
Menu to set the mode and select BackExit to close the OSD.
Full Screen: (Default) Displays standard 4:3 source video in 16:9 aspect ratio by
expanding the image horizontally. Circles will appear as ovals in the central and outer
portions of the screen. If the source image is letterboxed, there will be black bars at the
top and bottom of the image. A 16:9 widescreen source will fill the screen with minimal
distortion.
Select Back to
return to the menu
pages

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 17 of 31
Pillar Box: A standard 4:3 source image will appear with vertical black bars on the left
and right side of the image. If the image source is letterboxed, then there will also be
horizontal bars at the top and bottom of the image as well.
Letter Box Expanded: Expands the source video in the vertical and horizontal
dimensions to fill the display screen. Letterbox-format DVDs will have small or no bars
showing in this mode, while 4:3 aspect video sources will expand beyond the screen
boundaries and appear cropped.
6.2.3. Scheme
There are two default color settings or schemes: Natural and Vivid. If the screen colors
are not what you expect, select Scheme and press + and –to toggle between the
settings. The background picture’s colors change as you toggle between the settings.
Vivid uses a higher color saturation level above the Natural level.
Try both schemes to determine which one you like best before adjusting the other picture
quality settings.
Select UserScheme and then press Menu to access the settings.
Select the setting and press Menu to accept the changes, and then select BackExit to
close the OSD.
6.3. Image Adjust Menu
Use the Image Adjust menu options, as shown below, to control the color and picture quality.
Highlight Image Adjust and press Menu to access the Image Adjust menu options.
Press + or –to select an Image Adjust option, and then press Menu to change its value.
Figure 18 Image Adjust menu options
6.3.1. Scheme
Scheme is also available from the Main MenuUser page. For information about how
this option works, see Section 6.2.3,Scheme, on page 17. Changing the Scheme also
affects changes that you make to the User menu settings and is source specific.
Picture-
quality
controls

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 18 of 31
6.3.2. Picture-quality Controls
The Brightness, Contrast, Saturation, Hue, and Sharpness menu options use control bars
to fine-tune different aspects of the picture quality. To adjust these options, press Menu
and –to select Image Adjust. Choose a menu option, and then press Menu to open a
control bar and adjust the value, similar to Figure 19, shown below.
Press + or –to increase or decrease the control’s value.
Press Menu to set the menu option and close the control bar.
Select BackExit to close the OSD.
Figure 19 Sample picture-quality control bar
6.3.3. Reset Scheme
Restores the values of the current scheme to their default settings, and it affects only the
current source. Use Reset Scheme to revert to the default screen colors if the other
Image Adjust options did not correct the screen quality.
Select Image AdjustReset Scheme and then press Menu.
Select BackExit to close the OSD.
For information about the different Scheme modes, see Section 6.2.3 on page 17.
6.3.4. Image Adjust Advanced (Submenu)
Use the Image Adjust Advanced submenu options, as shown below, to fine-tune the
primary screen colors and to restore the monitor’s factory screen settings. Press Menu
and + or –to select Image AdjustAdvanced, and then press Menu.
To close the menu, select the Back option, or select BackExit to close the OSD.
Figure 20 Advanced submenu options

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 19 of 31
6.3.4.1. Color Temperature
Use the Color Temperature options to change the warmth of the picture in all sources.
When you select Color Temperature, the screen changes, and a toggle appears to
switch between User and 6500K, as shown below.
Figure 21 Color Temperature options
Press –and Menu to open the Color Temperature Page.
Press –to access the User setting and then press Menu and –to access the
individual colors.
6.3.4.1.1. Color Levels: Red, Green, Blue
Setting the Color Temperature to User will make the Red, Blue, and Green options
active. Each color adjusts the low-level registers of its respective color value in the
picture.
Select the Image AdjustAdvancedColor Temperature and press Menu. Set
Color Temperature to User, and then press Menu.
Press –to choose a color level, and then press Menu to open a control bar to
adjust the value, similar to Figure 22 shown below.
Red: Press –to show more cyan-colored tones, and press +to intensify the
red tones.
Green: Press –to show more magenta tones, and press +to intensify the
green tones.
Blue: Press –to show more yellow tones, and press +to intensify the blue
tones.
Press Menu to set the color and close the control bar.
Select BackExit to close the OSD.
Figure 22 Sample color-level control bar

Rosen Aviation 7” Widescreen Display
Document Number: 106211
Revision: B
Date: 04/17/14
Template: 4.4.1.6FM2; Revision A; 12/06/12
Page 20 of 31
6.3.4.2. Restore Defaults
This option restores the default screen settings from the user menus for all video
sources. It does not erase Technician Menu settings or change the internal time and
date. A Defaults Restored message appears in the lower corner of the menu after the
restore is complete.
Figure 23 Restore Defaults option
6.4. Info
Use the Information page to review operating status, view details about the display, and access
the Technician Menu.
To open the Info page, press Menu and then –to navigate to Info.
Notes:
Press Menu and +to highlight the Back option—required to access the Technician
Menu.
The firmware (FW) fields vary by model and are subject to change.
Figure 24 Info page
Status
message
Use Info to verify video
source and resolution
settings.
Back option
active
