Ross Master Control MC1-PANEL-16 User manual

MC1-PANEL-16 Installation and Cabling
8800DR-002-03
Printed in Canada.
© 2018Ross Video Limited. Ross®, openGear®, and any related marks are trademarks or registered trademarks of Ross Video Limited. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING. All rights reserved. No part of this publication
may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, mechanical, photocopying, recording or otherwise, without the prior written permission of Ross Video. While every precaution has been taken in the preparation of this document, Ross Video
assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein.
CAUTION
Default Values
Ethernet Method
PSU Alarm Enable
Edit Permission
DHCP
Selected
Unlocked
Before you set up and operate your MC1-PANEL-16, refer to the “Important
Regulatory and Safety Notices to Service Personnel” document that was
included with your unit. It is also recommended to refer to the MC1-PANEL-16
User Guide which is available for download from our website.
Ethernet DIP Switches
Specifications
SDI Input Formats
480i 59.94Hz
576i 50Hz
720p 59.94Hz
720p 50Hz
1080i 59.94Hz
1080i 50Hz
Panel Power Consumption
MC1-PANEL-16 <30W
Input Voltage
Power Rating 100-120V~
220-240V~
47-63Hz
Temperature
Operating:
Storage:
0 - 40°C (32 - 104°F)
-20 - 85°C (-4 - 185°F)
Power Connections
PMC LINK
1
2
ETHERNET
1
2SD
MODE
PS 1 PS 2
DIP
Switches
PMC LINK
1
2
ETHERNET
1
2SD
MODE
PS 1 PS 2
DIP Switch 1 and 2 Positions for IP Address Setup
DIP Switch 1
UP
UP
DOWN
DOWN
DIP Switch 2
UP
DOWN
UP
DOWN
Description
Custom User Setup via DashBoard
Automatic Setup using DHCP
IP Address is 192.168.2.10
Subnet Mask is 255.255.255.0
IP Address is 10.1.2.10
Subnet Mask is 255.255.255.0
DIP Switch 1 and DIP Switch 2 are used in conjunction with the
DashBoard menus to set the IP Address of the MC1-PANEL-16.
Please leave DIP Switch 3 and 4in their default (UP) positions.
You will require a standard network CAT-5 cable to connect
the MC1-PANEL-16 to your facility network. Ensure to use
only the Ethernet 1 port.
Refer to the MC1-PANEL-16 User Manual for more information.
Note: The MC1-PANEL-16 powers on automatically when the
power supply is plugged in.
The MC1-PANEL-16 comes standard with one power supply. For
redundancy, and in applications where the equipment is used in a
critical signal path, we recommend that two power supplies be
used with the MC1-PANEL-16.
Note: If you are not installing the redundant power supply, the
message “PSU 2” is reported on the panel display. To disable this
message, navigate to the Alarm Enables tab in DashBoard and
de-select the PSU2 Voltage Out of Range check box.
PMC LINK
1
2
ETHERNET
1
2SD
MODE
PS 1 PS 2
Power
Ethernet Cabling
Ethernet
Note: The Ethernet 2 port is not implemented.
Note: Refer to the MC1-PANEL-16 User Manual for details
on verifying and troubleshooting your ethernet connection.
Note: Ross Video strongly recommends installing your
Master Control System on a network that is segregated from
your facility LAN.

openGear MC1-MK Cabling
Having a problem? Call our free, 24-hour technical support hotline to speak with a live
product specialist located right here in our facility.
Tel: (+1) 613 • 652 • 4886
Email: [email protected]
Input and Reference Cabling Output and Ethernet Cabling
ETHERNET SERIAL
PS1
100-240V~47-63Hz 450W
CAUTION: RISK OF SHOCK
DO NOT OPEN
!
REF 1
LOOP
REF 2
LOOP
PS2
ETHERNET
100-240V~47-63Hz 450W
CAUTION
RISK OF SHOCK
DO NOT OPEN !
Output 4
Output 3
Output 1 Output 2
MC1-MK
MUX-8258
ETHERNET SERIAL
From Router Key Video Out
From Router Program Out
From Router Preview Out
From Router Key Alpha Out
PS1
100-240V~47-63Hz 450W
CAUTION: RISK OF SHOCK
DO NOT OPEN
!
REF 1
LOOP
REF 2
LOOP
PS2
ETHERNET
100-240V~47-63Hz 450W
CAUTION
RISK OF SHOCK
DO NOT OPEN !
MC1-MK
MUX-8258
To Reference Source
Note: This illustrates cabling for one MC1-MK card and one MUX-8258 card in an OG3-FR
series frame. Your setup requirements may differ than what is presented here. The MUX-8258 is
optional.
Specifications
Video Output Specifications
Impedance
Return Loss
Signal Level
DC Offset
Rise and Fall Time
Overshoot
75ohms
SDI OUT 1: 15dB to 1.5GHz
SDI OUT 2-4: >15dB to 1.5GHz
800mV +/- 10%
0+/-50mV
SD: 900ps typical
HD: 150ps typical
75ohm
SDI Output Formats
480i 59.94Hz
720p 59.94Hz
1080i 59.94Hz
576i 50Hz
720p 50Hz
1080i 50Hz
Maximum Power Consumption
OG3-FR Frame
MC1-MK
Sum of both PSU not
to exceed 375W
22W
Default Values
Ethernet Method
Reference Input
Output 1
Output 2
Output 3
Output 4
Remote Control
Serial
Ethernet
Embedded Audio
Edit Permission
DHCP
Frame 1
Program
Program
Preview
Clean Feed 1
Disabled
Disabled
All groups enabled
Unlocked
Temperature
Operating:
Storage:
0 - 40°C (32 - 104°F)
-20 - 85°C (-4 - 185°F)
Video Input Specifications
Impedance
Return Loss
Equalization
(using Belden 1694A cable)
75ohms
SDI IN 1: 15dB to 1.5GHz
SDI IN 2-4: >15dB to 1.5GHz
SD: 120m
HD: 100m
To Ethernet Network To Ethernet Network
CAUTION
Before you set up and operate your MC1-MK card, refer to the “Important
Regulatory and Safety Notices to Service Personnel” document that was
included with your card. It is also recommended to refer to the MC1-MK
Installation Manual which is available for download from our website.
