Roto Piccolo Manual

Roto Frank Treppen GmbH | Gutenbergstraße 21 | 86356 Neusäß | Deutschland | Telefon +49 (0) 821 / 46051-0 | Telefax +49 (0) 821 / 46051 –61
[e-mail] | www.roto-treppen.de
F885-91162 / 22.04.2016 / RS 1
FIXING INSTRUCTIONS
STANDARD CONCERTINA INTO AN EXISTING OPENING
Hatchbox not included
M180-20306
Instruction leaflet for installation kit stairway Piccolo parts for assembly in flat bag 155x240
The maximum weight on the stair must not exeed 150 kgs.
Pos.
Quantity
Name
Measurments/DIN
Item Number
1
8x
Chipboard screws
ø6x25
E801-10262
2
4x
Chipboard screws
ø5x20
E801-10253
3
2x
Mounting bracket
F111-50459
1
1
3
3
2
2

Roto Frank Treppen GmbH | Gutenbergstraße 21 | 86356 Neusäß | Deutschland | Telefon +49 (0) 821 / 46051-0 | Telefax +49 (0) 821 / 46051 –61
[e-mail] | www.roto-treppen.de
F885-91162 / 22.04.2016 / RS 2
6
2
3
4
5
5
10
10
11
11
7
8
9
1
9
11
Installation sketch of concertina stair Piccolo with spring hardware kit
M180-20306
Instruction leaflet for installation kit stairway Piccolo parts for assembly in flat bag 155x240
Maximum load bearing for the complete stairway ≤ 150 kg
Position
Pieces
Description
Dimension/DIN
Article number
1
1
Concertina stair
F104-21839
2
8x
Chipboard screws
ø6x25
E801-10262
3
4x
Chipboard screws
ø5x20
E801-10253
4
2x
Mounting bracket
F111-50459
5
4x
Screw
M6x30 / DIN 605
E801-10045
Parts
Pos. 5 until
Pos. 11 in kit
M180-20305
6
4x
Nut
M6 / DIN 934
E803-10367
7
1x
Lever arm left side
F104-21839
8
1x
Lever arm right side
F104-21839
9
2x
Spring
M105-20919
10
2x
Mounting for spring steel
F108-50338
11
14x
Screw for chipboard
Ø6x25
E801-10262
11
„B“ = length of hatchbox
dimension „ A“
finished
dimension outside
cm
finished
dimension inside
cm
cm
69 - 100
65 - 96
47
100 –140
96 - 136
67

Roto Frank Treppen GmbH | Gutenbergstraße 21 | 86356 Neusäß | Deutschland | Telefon +49 (0) 821 / 46051-0 | Telefax +49 (0) 821 / 46051 –61
[e-mail] | www.roto-treppen.de
F885-91162 / 22.04.2016 / RS 3
Operating instruction Piccolo concertina
Opening the stair:
1. Open cover if existing.
2. Hook in operating pole centrally to the lower connection of the stair and lift the stair off the plastic hooks
placed either at the backboard or the cover.
3. Using the operating pole lead the stair slowly down to the floor and remove operating pole ( Attention:
use operating pole with both hands to prevent the stair from sliding off the operating pole )
4. Lay operating pole aside and keep it ready for closing.
Closing the stair:
1. Hook in operating pole centrally to the lower connection of the stair and push the stair slowly up and lift
it into the plastic hooks either at the backboard or the cover. ( Attention: take care that the stair rests
safely in both plastic hooks )
2. Place operating pole for further use.
Maintenance:
1. Please check regularily if all the bolts, nuts and security parts are tight.
2. Please grease or oil all movable parts regularily.
Safety device:
Do not use a retractable stair without 3-sided guardrail.
Fmax ≤ 150 Kg
