Rowenta COMPACT GARMENT STEAMER User manual

www.rowentausa.com
1103901405 - 03/07
COMPACT GARMENT STEAMER

ab
8
10
1
4
2
3
5
6
7
9
15
1413
12
16
**
*
**Depending on
Model: Accessories
are specific to certain
models or available as
an optional accessory.
*
11

When using your appliance, basic precautions should always be followed,
including the following:
Read all instructions before use.
• Use appliance for its intended use only.
• This appliance is not designed to be used by people (including children)
with a physical, sensory or mental impairment, or people without knowledge
or experience, unless they are supervised or given prior instructions
concerning the use of the appliance by someone responsible for their safety.
• Children must be supervised to ensure that they do not play with the
appliance.
• Do not leave appliance unattended while plugged in or while it is still hot.
• Do not operate any appliance with a damaged cord, plug or steam hose or
after the appliance malfunctions, or is dropped or damaged in any manner. •
• To reduce the risk of electric shock, do not disassemble or attempt to repair
the appliance. Return appliance to nearest authorized service center for
examination, repair or adjustment.
• To reduce the risk of contact with hot water emitting from steam vents, check
appliance before each use by holding it away from body and operating.
• Steam only in an up and down vertical motion. Never use steam head in a
horizontal position or tilt into a backward position, this may result in water
discharge.
• To reduce the risk of electric shock, do not immerse the appliance in water
or other liquids.
• Appliance should always be turned off before plugging or unplugging.
Never yank the cord to disconnect from outlet, instead grasp plug and pull to
disconnect.
• Do not allow cord to touch hot surfaces. Let appliance cool completely
before putting away.
• Loop cord loosely under the appliance when storing.
• Do not let power cord contact sharp edges or hot surfaces.
• Do not try to fasten the hose adapter during operation. Scalding may occur
if the hose adapter is removed while using the appliance.
• Always disconnect appliance from electrical outlet when filling with water,
emptying or when not in use.
• Do not attempt to hang up the unit using the hose.
• The use of foreign accessory attachments that are not supplied by Rowenta
is not recommended and may result in fire, electric shock or personal injury.
• Burns could occur from touching hot parts, hot water or steam. Use care
when you empty a steam appliance. There may be hot water in the reservoir.
• Do not direct steam at people, animals or steam clothes while they are being
worn.
• Your Rowenta appliance is intended for household use only.
• This is a floor appliance and should never be carried while in use.
SPECIAL INSTRUCTIONS
• This is a 1300, 1400 or 1500 watt appliance. To avoid a circuit overload, do
not operate a high wattage appliance on the same circuit.
• If an extension cord is absolutely necessary, the marked electrical rating
should be at least as great as the electrical rating of the appliance. Cords rated
for less amperage may overheat. Care should be taken to arrange the cord so
that it cannot be pulled or tripped over.
• Do not cut or attempt to extend the steaming hose.
IMPORTANT SAFETY INSTRUCTIONS

Before use
Please read the instructions for use and Important Safeguards
carefully.
• Remove any packaging from the appliance.
• DO NOT PLUG IN OR TURN ON UNTIL ASSEMBLY IS
COMPLETE. • Insert the steam hose into the hole on the
top of the unit while sliding out the eject
knob.
• Completely unwind the power cord.
Filling with water
• Your steamer has been designed to operate using untreated tap water.
If your water is very hard (check with your local water
authority) mix tap water with store-bought bottled or
spring water in the following proportions :
-50% untreated tap water,
-50% distilled or demineralized water.
-or just use bottled spring water.
• Fill with maximum 33 ounces of water, taking care that the water does
not overflow or pass the fill line on the side of the tank.
DESCRIPTION
1. Steam head
2. Eject button
3. Steam hose connector
4. Steam hose
5. Carry handle
6. Max water level
7. Steam hose wrapping
8. Steam head storage slide
9.aFilling inlet
9.bEmptying outlet
10.On / Off switch
11.Electric cord storage
(under base)
12.Upholstery brush*
13.Fabric brush*
14.Crease attachment*
15.Lint pad*
16.Door hook*
*depending on model: this is either equipment specific to certain models or
available as an optional accessory. Accessories that are not listed in this manual
or manufactured by other companies are not recommended for use with the Pro
Compact steamer.
Never overfill your steamer. Never fill it with hot water.
4

5
Use
• Plug in your steamer. Place your steamer on the floor
with the steam vents pointing away from the door.
• The steam head should be hung on the door hook while
unit is heating up.
• Press on the On / Off switch, the power indicator light
will illuminate once steamer is turned on.
• Wait for the steam to come out. It will take
approximately 21/2 minutes.
• Remove the steamer head and place
your garment onto the hanger head.
• Grasp the steam head handle with the steam vents
pointing away from you. Start steaming by touching
material lightly with steaming head and moving in an
up/down vertical motion. Begin at the top of the garment
and move in a downward direction. Steam with hose in an upright
position, this allows any condensation to flow back into the steamer.
• During operation, the steamer hose may make a gurgling noise. This is
a normal result of condensation. If it begins to gurgle, extend hose up
and out to move excess moisture back into the base.
Tips: Always check fabric labels for recommendations. Test fabric
for color fastness in an unobtrusive part of the garment (inner
seam). Do not touch silk or velvet with steam head. Some articles
can be steamed better from the underside.
If steaming in a low position near floor, straighten hose up and out
frequently to clear condensation. If hose becomes clogged, it will
make a gurgling noise or the amount of steam will be reduced.
You may also experience dripping if the hose becomes clogged.
Heavier fabrics may require repeated steaming. Exercise caution at
all times.
Important: Heat concentrates the elements contained in water during
evaporation. The types of water listed hereafter may contain organic
waste, mineral or chemical elements that can cause spitting, brown
staining, or premature wear of the appliance: water from clothes
dryers, scented or softened water, water from refrigerators, batteries,
air conditioners, rain water, boiled, filtered or bottled water. Also use
distilled or demineralized water only as advised above.

Accessories (depending on model)
Before using any of the accessories on upholstery or garments, be sure to
consult the manufacturer’s labels regarding their recommendations for
garment care. We also recommend testing on an unobtrusive area.
Upholstery brush*
The upholstery brush is used to aid steam penetration into
difficult or heavy fabrics for faster results.
• Attach the upholstery brush to the steam head by lining up
the bottom of the brush with the bottom of the steam head.
Gently push the top of the brush into place on the steam
head until it clicks into place.
• Gently brush the area to be steamed with the grain or nap
of the fabric.
• Remove the upholstery brush once unit is unplugged and completely
cool. Remove it by pressing on the tab on top of brush while pulling it
forward.
Fabric brush*
The fabric brush opens weave of the fabrics for better steam penetration.
• Attach the fabric brush to the steam head by lining up the bottom of the
brush with the bottom of the steam head. Gently push the top of the
brush into place on the steam head until it clicks into place.
• Gently brush the area to be steamed with the grain or nap of the fabric.
•Remove the fabric brush once unit is unplugged and completely cool by
pressing on the release tab on top of brush while pulling it forward.
Reminder: When using accessories steam only in an up and down
vertical motion. Never use the steam head in a horizontal position
and never steam with your steam head upside down.
Be sure unit is unplugged and completely cool before attaching
accessories.
*depending on model: this is either equipment specific to certain models or available as
an optional accessory.
Warning: Never steam clothes while they are being worn. Hose
and steam head will become hot during use.This is normal. Use
caution and avoid prolonged contact.
6
Be sure unit is unplugged and completely cool before attaching
accessories.
Never touch the steam head until it cools completely.

Crease attachment*
The crease attachment is used to make pant creases easily or to remove
stubborn wrinkles.
• Fasten the crease attachment to the steamer by sliding onto the steam
head so it fits over the raised channels.
• Gently push into place.
• Push on the handle to open the crease attachment.
• Put your fabric in the space between the crease attachment and the
head of the steam brush.
• Release the handle.
• Move the crease attachment in a downwards motion starting from the
top.
• Once unit is unplugged and completely cool, remove the crease
attachment by sliding it off of the steam brush.
Lint pad*
The lint pad removes hair, lint and animal fur for a professional finish.
• To use the lint pad, slowly brush the clothing with the grain or nap of
the fabric.
• The pad can be cleaned by brushing in the opposite direction. We
recommend cleaning on an old cloth that can be discarded.
Be sure unit is unplugged and completely cool before attaching
accessories.
*depending on model: this is either equipment specific to certain models or
available as an optional accessory.
The lint pad is a separate accessory and cannot be attached to the
steam head. You can use the lint pad independently from the steamer.
7

After use
• After using the steamer, switch the power off (power
indicator light will go out) and unplug the appliance. Wind
the power cord on its storage place under the appliance.
• Remove the steam hose.
• Empty the water container from the opening
shown in diagram 9b.
• Place the steam connector back into place. Wrap the hose
around the steamer and insert the steam head onto its
housing. The head slides over the raised channels for secure
storage.
• You can carry your steamer by its handle for easy
portability and storage.
Cleaning
Clean the main unit with a damp cloth. To maintain maximum
performance, your steamer must be descaled occasionally. The descaling
intervals will depend on the water quality and the frequency of use. The
unit should be descaled at least once a year or every 100 hours of use.
For descaling proceed as follows:
1. Unplug the unit and fill it with 1/3 white vinegar and 2/3 water.
2. Let the appliance run for 3 minutes and do not steam any clothing with
this mixture.
3. Switch the appliance off. Unplug it and allow to cool down for at least
30 minutes.
4. Empty the water over the sink. Rinse the appliance with fresh water.
5. Fill the unit with fresh water and repeat steps 2-4.
Be careful there may be hot water remaining in the
steam hose after use. Always remove the steam hose
before emptying your appliance.
For cord winding or transport, never turn your appliance upside down.
Empty all water from the unit before storing it.
8

9
Problems Possible
causes Solutions
There is no steam. The steamer is not
turned on.
Check that your appliance is
correctly plugged in and press the
illuminated on/off switch (on the
front of the base).
The water level is too
low. Turn your appliance off and refill it to the max line on the side of the
water tank.
The hose is kinked. Be sure that the hose is fully unra-
veled.
There is no more
water. Unplug your steamer and refill it.
There is little steam. Your steamer has a
build-up of scale
because it has not
been rinsed out
regularly.
Descale the steamer and descall at
least once a year or every 100
hours of use
. If your water is hard,
increase the frequency.
The water level is too
low. Turn your appliance off and refill it.
There is too much
water. Unplug your steamer and empty it partially.
Water runs through
the holes of the
steambrush.
There is condensation
in the hose.
Never use steamer in a horizontal
position. Hold the hose vertically
outstretched and wait for water to
flow back into the steamer.
The steamer takes a
long time to heat.
Your steamer has a
build-up of scale
because it has not
been descaled
regularly.
Rinse out the steamer at least once
a year or every 100 hours of use
. If
your water is hard, increase the
frequency.
There is too much
water. Unplug your steamer and empty it partially.
TROUBLESHOOTING
If after descaling you believe that there is still buildup in the appliance,
repeat this operation. Use a new solution of vinegar and water each
time you repeat steps 1 and 2.

LIMITED WARRANTY
This Rowenta product is warranted for 1 year from date of purchase
against defects in material and workmanship. During this period, any
Rowenta product that, upon inspection by Rowenta, is proved
defective, will be repaired or replaced, at Rowenta´s option, without
charge to the customer. If a replacement product is sent, it will carry
the remaining warranty of the original product. This warranty does
not apply to any defect arising from a buyer’s or user’s misuse of the
product, negligence, failure to follow Rowenta’s instructions, use on
current or voltage other than that stamped on the product, or
alteration or repair not authorized by Rowenta. Repair or disassembly
by anyone other than a Rowenta authorized service center will void
the warranty.
THE WARRANTIES SET FORTH HEREIN ARE EXCLUSIVE AND NO
OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO ANY WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR USE, ARE MADE BY ROWENTA OR
ARE AUTHORIZED TO BE MADE WITH RESPECT TO THE PRODUCT.
Some states do not allow limitations on how long an implied
warranty lasts or do not allow the exclusion of incidental or
consequential damages, so the above limitations may not apply to
you. This warranty gives you specific legal rights, and you may also
have other rights, which vary from state to state.
If you believe your product is defective, bring the product (or send it,
postage prepaid) along with proof of purchase to the nearest
authorized Rowenta Service Center (see below). If you send the
product, please include a letter explaining the nature of the claimed
defect.
In the interest of improving products, Rowenta reserves the
right to change specifications without prior notice.
10

California Electric
1170G Burnett Avenue
Concord, CA 94520
925-827-1011
CORRESPONDENCE CAN BE SENT TO:
ROWENTA
196 Boston Avenue
Medford, MA 02155, U.S.A.
Tel: [phone]
www.rowentausa.com
OFFICE LOCATION ONLY. Letters will be accepted at this address and
packages without a return authorization number will be refused or
forwarded to a service center. To service product see service center
information below.
SERVICE CENTER INFORMATION:
If your appliance needs service, ship the product to your nearest
regional service center. Be sure to put your name on the outside of the
shipping box (no P.O. boxes please), include a brief note describing the
issue, and include a copy of the sales receipt if the product is in
warranty. If in warranty, Rowenta will repair or replace the product at
their discretion. If the product is out of warranty, you will be advised of
the cost of repair before any work begins.
Turnpike Appliance
California Electric
3495A Lawson Blvd.
1170G Burnett Ave.
Oceanside, NY 11572
Concord, CA 94520
516-483-5596
925-827-1011
SERVICE CENTER INFORMATION IS SUBJECT TO CHANGE. Please
visit our website at www.rowentausa.com or call 781-396-0600 for
automated service center information.
Authorized Appliance
1644 West Ogden Ave.
Downers Grove, IL 60515
630-852-1550
11
