DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Housing
Shallow low voltage recessed fixture
housing for insulated ceiling installations.
Includes integral low voltage magnetic
transformer. All aluminum construction.
14 ga. steel junction box.
B ...Electrical
Socket is pre-wired to the j-box 18AWG
SF-1 leads. Primary lead is 120V or 277V.
Transformer is rated 180˚ Class H. State of
Washington AirTite approved.
C ...Mounting
Provided with two (2) adjustable 16 ga.
steel hanger bars which can be extended
to 25.25”.
D...System Protection
Transformers have thermal protection
and operate at 11.5 volts nominal.
Ceiling Cut-Out: 3.75” dia.
MICROGEM
SHALLOW
HOUSING
C900
Insulated Ceiling
AirTite Shallow
Housing w/ Integral
Low Voltage
Transformer
FOR 12V LAMP 50W max.
ORDERING INFORMATION
Shallow insulated ceiling AirTite (I.C.) Microgem recessed low voltage
housing with integral magnetic transformer 50W max. 120V or 277V.
For use in insulated ceiling (I.C.) applications. Housing may be covered
on all sides with insulation material.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev. 102406
Housing
C900 =
Microgem shallow insulated
ceiling low voltage recessed
housing.
3.75"
20.125"
18.125"
15.188"
13.25"14.13"
5.5"
14" min.
25.25" max.
A
D
C
B
C900
Voltage
120 =120 volts primary
277 =277 volts primary
