RSA Lighting C-700 User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
A...Housing
Low voltage recessed fixture housing for
insulated ceiling. Includes integral low
voltage magnetic transformer. 14 ga. steel
junction box.
B ...Electrical
Socket is pre-wired to the j-box 18AWG
SF-1 leads. Primary lead is 120V or 277V.
Transformer is rated 180˚ Class H. State of
Washington AirTite approved.
C ...Mounting
Provided with two (2) adjustable 16 ga.
steel hanger bars which can be extended
to 25.25”.
D...System Protection
Transformers have thermal protection
and operate at 11.5 volts nominal.
Ceiling Cut-Out: 3.75” dia.
MICROGEM
HOUSING
C700
Insulated Ceiling
AirTite Housing w/
Integral Low
Voltage Magnetic
Transformer
FOR 12V LAMP 50W max.
ORDERING INFORMATION
Insulated ceiling AirTite (I.C.) Microgem recessed low voltage housing
with integral magnetic transformer 50W max. 120V
For use in insulated ceiling (I.C.) applications. Housing may be covered
on all sides with insulation material.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev. 102406
Housing
C700 =
Microgem insulated ceiling
AirTitr recessed housing.
C700
3.75" dia.
19.125"
17.125"
14.188"
9.88"10.75"
7.5"
14" min.
25.25" max.
A
D
C
B
