RSA Lighting MINI ACCURUS ACM510MH User manual

DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
7.25”
12.00”
13.00”
8.18”
4.63”
4.63”
0.5” - 1.0”
Ceiling
Cut-Out
3.63”sq.
A...Housing
Housing and plaster frame: 18 gauge CRS
with flat black powder coated internal
finish. Adjustable plaster frame can
accommodate up to 1” ceiling thickness.
B ...System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
Vent holes in housing provide cooler
operation.
C ...Electrical
Integral j-box and metal halide ballast.
120V input. Junction box is U.L. listed for
through branch wiring. Includes five 1/2
trade size knockouts.
D...Lamp
CMH MR16 20W or ES16 BriteSpot 39W
(not included). GX10 twist-lock lamp socket.
E ...Mounting
Hanger Bars and Butterfly Brackets
included for residential and commercial
applications respectively.
Ceiling Cut-Out: 3.63” sq.
MINI
ACCURUS
ACM510MH
New Construction
Housing
for Square Trim
FOR CMH MR16 20W
or ES16 BriteSpot 39W
ORDERING INFORMATION
Housing
ACM510MH =
Mini Accurus
New Construction Housing
for Square Trim
w/ Integral Ballast
New construction housing for Mini Accurus small aperture square trims
(ACM5101, ACM5102, ACM5103, ACM5104).
For new construction applications. Insulation must be kept 3” from all
sides and at least 1” above the housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
ACM510MH
Voltage
120 =120 volts primary
277 =277 volts primary*
* Consult factory for 277V ballast availability.
Metal Halide Ballast
20 =CMH MR16 20W
39 =ES16 BriteSpot 39W
rev. 091806
