DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
www.cooperlighting.com
SPECIFICATION FEATURES
10.75”
14.13”
17.13”
7.50”
Ceiling
Cut-Out
4.50”dia.
0.5” - 1.0”
A...Housing
Housing and plaster frame: 18 gauge CRS
with flat black powder coated internal
finish. Adjustable plaster frame can
accommodate up to 1” ceiling thickness.
B ...System Protection:
Thermal protection provided.
C ...Electrical
Integral j-box and electronic metal halide
ballast. 120V/277V input. Junction box
is U.L. listed for through branch wiring.
Includes five 1/2 trade size knockouts
D...Lamp
MR16 metal halide lamp 20 or 39 watts.
GX10 TAL lamp socket included. Internal
rotation ring with locking adjustment.
Provides 360º rotation of trim and secures
original trim position after relamping.
E ...Mounting
Hanger Bars and Butterfly Brackets
included for residential and commercial
applications respectively.
Ceiling Cut-Out: 4.50” dia.
ACCURUS
ACT952ICMH
Insulated Ceiling
Metal Halide
AirTite Housing
for 5” Round Trim
FOR METAL HALIDE MR16
20W or 39W
ORDERING INFORMATION
Housing
ACT952ICMH =
Accurus Insulated Ceiling
Housing for Round Trim
w/Integral Metal Halide Ballast
Voltage
120 =120 volts primary
277 =277 volts primary
Insulated ceiling AirTite housing for Accurus round trim fixtures. Includes
electronic metal halide ballast for use with 20W or 39W MR16 Metal Halide
lamp.
For insulated ceiling applications. Rated for direct contact with insulation
material.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Lamp Wattage
20 =20 watts
39 =39 watts
ACT952ICMH
rev 122007
