Ruckus Wireless ZoneFlex 7762-S User manual

Ruckus Wireless™ZoneFlex™
Access Point
Release 9.1 User Guide
For the following ZoneFlex AP models:
■ZoneFlex 2942 802.11g Access Point
■ZoneFlex 2741 802.11g Outdoor Access Point
■ZoneFlex 7942 802.11n Access Point
■ZoneFlex 7962 Dual Band 802.11n Access Point
■ZoneFlex 7762 Dual Band 802.11n Outdoor Access Point
■ZoneFlex 7762-S Dual Band 802.11n Outdoor Sector Access Point
■ZoneFlex 7341 2.4GHz 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7343 2.4GHz 802.11n Smart Wi-Fi Access Point
■ZoneFlex 7363 Dual Band 802.11n Smart Wi-Fi Access Point
Part Number 800-70306-001 Rev B
Published June 2011
www.ruckuswireless.com

i
About This Guide
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . i
Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
Documentation Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ii
1 Introducing the ZoneFlex Access Point
Overview of the ZoneFlex Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Getting to Know the Access Point Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
ZoneFlex 2942/7942 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ZoneFlex 7962 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
ZoneFlex 7341 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ZoneFlex 7343 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ZoneFlex 7363 Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
ZoneFlex 2741 Outdoor Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
ZoneFlex 7762/7762-S Outdoor Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2 Installing the Access Point
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Prepare the Required Hardware and Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Perform a Site Survey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Determine the Optimal Mounting Location and Orientation . . . . . . . . . . . . . . . 29
Step 1: Preconfigure the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Configuring for Management by ZoneDirector . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring for Standalone Operation or for Management by FlexMaster . . . . 35
Step 2: Verify Access Point Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Connect the Access Point to the Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Check the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Associate a Wireless Client with the Access Point . . . . . . . . . . . . . . . . . . . . . . . . 45
Check the TR069 Status (FlexMaster Management Only) . . . . . . . . . . . . . . . . . . 45
Contents

ii
Disconnect the Access Point from the Network . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Step 3: Deploy the Access Point. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
1. Choose a Location for the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
2. Connect the Access Point to a Power Source and the Network . . . . . . . . . . . 46
Troubleshooting Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
3 Navigating the Web Interface
Logging Into the ZoneFlex Web Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Navigating the Web Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
If You Are Using a Dual Band ZoneFlex Access Point. . . . . . . . . . . . . . . . . . . . . . . . .51
4 Configuring the Access Point
Configuring the Device Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Enabling the PoE OUT Port for ZoneFlex 7762/7762-S Outdoor APs . . . . . . . . . 54
Configuring the Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Default IP Addressing Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Obtaining and Assigning an IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Configuring the L2TP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Configuring Common Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Reviewing the Advanced > Common Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Setting Threshold Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Configuring WLAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Using WEP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Using WPA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Customizing 802.1X Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Rate Limiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Controlling Access to the Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Changing the Access Controls for a WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Removing MAC Addresses from the List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Access Control Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Configuring VLAN Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Navigating the VLAN Page . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5 Managing the Access Point
Viewing Current Device Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

iii
Viewing Current Internet Connection Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
Renewing or Releasing DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Viewing Current Wireless Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Viewing Associated Wireless Clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Changing the Administrative Login Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Enabling Other Management Access Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
Viewing FlexMaster Management Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Pointing the AP to FlexMaster . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Working with Event Logs and Syslog Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
Enabling Logging and Sending Event Logs to a Syslog Server . . . . . . . . . . . . . . 92
Sending a Copy of the Log File to Ruckus Wireless Support . . . . . . . . . . . . . . . . 93
Saving a Copy of the Current Log to Your Computer . . . . . . . . . . . . . . . . . . . . . 93
Upgrading the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94
Upgrading Manually via FTP or TFTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Upgrading Manually via the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Upgrading Manually via Local File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Scheduling Automatic Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Rebooting the Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Resetting the Access Point to Factory Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Running Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Where to Find More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99
Index

iv

i
About This Guide
About This Guide
This guide describes how to install, configure, and manage the Ruckus Wireless™
ZoneFlex™Access Point. This guide is written for those responsible for installing and
managing network equipment. Consequently, it assumes that the reader has basic
working knowledge of local area networking, wireless networking, and wireless
devices.
NOTE: If release notes are shipped with your product and the information there
differs from the information in this guide, follow the instructions in the release notes.
Most user guides and release notes are available in Adobe Acrobat Reader Portable
Document Format (PDF) or HTML on the Ruckus Wireless Support Web site at:
http://support.ruckuswireless.com/
Document Conventions
Tabl e 1 and Tab le 2 list the text and notice conventions that are used throughout this
guide.
Tabl e 1. Text C onve n tions
Convention Description Example
monospace Represents information as it
appears on screen
[Device name]>
monospace bold Representsinformation that
you enter
[Device name]> set
ipaddr 10.0.0.12
default font bold Keyboard keys, software
buttons, and field names
On the Start menu, click All
Programs.
italics
Screen or page names Click Advanced Settings.
The Advanced Settings page
appears.

ii
About This Guide
Related Documentation
In addition to this User Guide, each ZoneFlex Access Point documentation set
includes the following:
■Quick Setup Guide/Getting Started Guide: Provides essential installation and
configuration information to help you get the AP up and running within minutes.
■Online Help: Provides instructions for performing tasks using the Access Point’s
Web interface. The online help is accessible from within the Web interface.
■Release Notes: Provide information about the current software release, including
new features, enhancements, and known issues.
NOTE: If you will be managing your ZoneFlex access points using ZoneDirector, refer
to the ZoneDirector User Guide (available from the Ruckus Wireless website).
Documentation Feedback
Ruckus Wireless is interested in improving its documentation and welcomes your
comments and suggestions. You can email your comments to Ruckus Wireless at:
[email protected]
When contacting us, please include the following information:
■Document title
■Document part number (on the cover page)
■Page number (if appropriate)
For example:
■Ruckus Wireless ZoneFlex Access Point Release 9.1 User Guide
■Part number: 800-70306-001
■Page 88
Table 2. Notice Conventions
Icon Notice Type Description
Information Information that describes
important features or
instructions
Caution Information that alerts you to
potential loss of data or
potential damage to an
application, system, or device
Warning Information that alerts you to
potential personal injury

1
1
Introducing the ZoneFlex Access
Point
Overview of the ZoneFlex Access Point
Congratulations on your purchase of the Ruckus Wireless ZoneFlex Access Point!
ZoneFlex Access Points are the industry’s first centrally-managed Wi-Fi access points
that are capable of extending wireless signals two to four times farther than a
conventional access point.
Your ZoneFlex Access Point uses BeamFlex™, a patent-pending antenna technology
from Ruckus Wireless that allows wireless signals to navigate around interference,
extend wireless signal range, and increase speeds and capacity for wireless networks.
The BeamFlex™ antenna system consists of an array of up to fourteen high-gain
directional antenna elements that allow ZoneFlex Access Points to find quality signal
paths in a changing environment, and sustain the baseline performance required for
supporting data, audio and video applications.
Your ZoneFlex Access Point can be deployed in standalone mode or as part of the
ZoneFlex Smart WLAN system, in which it can be managed by either FlexMaster or
ZoneDirector WLAN controller.
NOTE: For more information on the ZoneFlex system (including FlexMaster and
ZoneDirector), BeamFlex, and other Ruckus Wireless technologies,
visit www.ruckuswireless.com.
In This Chapter
Overview of the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Unpacking the ZoneFlex Access Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Getting to Know the Access Point Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

2
Introducing the ZoneFlex Access Point
Unpacking the ZoneFlex Access Point
Unpacking the ZoneFlex Access Point
1. Open the Access Point package, and then carefully remove the contents.
2. Return all packing materials to the shipping box, and put the box away in a dry
location.
3. Verify that all items listed in Package Contents below are included in the package.
Check each item for damage. If any item is damaged or missing, notify your
authorized Ruckus Wireless sales representative.
Package Contents
A complete Access Point package contains all of the items listed below:
■ZoneFlex Access Point
■Software License Agreement/Product Warranty Statement
■A Quick Setup Guide for ZoneFlex indoor APs or an Installation Guide/Getting
Started Guide for ZoneFlex outdoor APs
■A mounting kit with model-specific mounting hardware (varies by model)
Getting to Know the Access Point Features
This section identifies the physical features of each ZoneFlex Access Point model that
is discussed in this guide. Before you begin the installation process, Ruckus Wireless
recommends that you become familiar with these features.
■ZoneFlex 2942/7942 Access Point
■ZoneFlex 7962 Access Point
■ZoneFlex 7341 Access Point
■ZoneFlex 7343 Access Point
■ZoneFlex 7363 Access Point
■ZoneFlex 2741 Outdoor Access Point
■ZoneFlex 7762/7762-S Outdoor Access Point
NOTE: For more information on the physical features of ZoneFlex 2741 and ZoneFlex
7762 outdoor APs, refer to their respective Getting Started Guides or Installation
Guides.

3
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 2942/7942 Access Point
The side panel of ZoneFlex 2942/7942 features four LED indicators that can be used
to assess both device and network status. The rear view displays the connector panel,
which includes the LAN ports and the optional external antenna connection. Refer to
the following illustrations and tables to learn more.
Side Panel Features
The ZoneFlex 2942/7942 chassis includes a Kensington lock (on the side of the unit
opposite the OPT and DIR LEDs) and a lockable “sliding door” (shown in Figure 1)
that hides and protects the rear connector I/O panel and status LEDs. As your AP may
be placed in a public location, the lock and door mechanisms can help prevent
tampering or theft.
Figure 1. ZoneFlex 2942/7942 side panel features
Tabl e 3 lists the various LED states on ZoneFlex 2942/7942 and describes what each
LED state means. It also describes how to use the HARD RESET button and other
elements on the side panel.
Table 3. ZoneFlex 2942/7942 side panel elements
Number LED/Button Name Description
1 OPT LED Not used in this model
6
5
1
23
4
7
8

4
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
2 DIR LED • Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
•Green: The Access Point is being managed by
ZoneDirector.
• Slow flashing green (one flash every two seconds):
The Access Point is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The Access Point is being managed by
ZoneDirector and is currently receiving
configuration settings (provisioning) or a firmware
update.
3 AIR LED • Off: The WLAN service is down.
•Green: The AP is functioning as a Root AP (RAP)
or Mesh AP (MAP), and the uplink signal is good.
•Slow flashing green (one flash every two seconds):
Mesh networking is enabled, but the AP is still
searching for a mesh uplink.
•Fast flashing green (two flashes every second):
The Access Point is functioning as a Mesh AP and
the wireless signal to its uplink AP is fair.
4 WLAN LED •Off: The WLAN service is down.
•Amber: The WLAN is up, but no clients are
associated and no downlink MAPs are connected.
•Green: The WLAN is up and at least one client is
associated. No downlink MAPs are connected.
•Slow flashing green (one flash every two seconds):
The WLAN is up and at least one downlink MAP
is connected. No clients are associated.
•Fast flashing green (two flashes every second):
The WLAN is up, at least one downlink MAP is
connected, and at least one client is associated.
5 HARD RESET
Button
Pushing and quickly releasing this button reboots
the AP. Pushing and holding it for six seconds resets
the AP to factory defaults.
6 Sliding Door Protects the ports, buttons, and connector on rear
panel
Table 3. ZoneFlex 2942/7942 side panel elements
Number LED/Button Name Description

5
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Rear Panel Features
Figure 2 shows the rear panel of ZoneFlex 2942/7942. For a description of each rear
panel part, refer to Table 4.
Figure 2. ZoneFlex 2942/7942 rear panel features
WARNING: For units with Power over Ethernet (PoE). These products and all inter-
connected equipment must be installed indoors within the same building, including
the associated LAN connections, as defined by Environment A of the IEEE 802.3af
Standard.
7 Kensington Lock The Kensington lock feature, located on the
opposite side of the unit from the pictured LEDs, is
designed to prevent the sliding door from opening,
thus locking the unit. The Kensington lock works with
a Kensington MicroSaver lock.
8 Power LED (front) • Off: Off
•Red: Boot up in process
•Green: On
Table 3. ZoneFlex 2942/7942 side panel elements
Number LED/Button Name Description
12 3 45
6

6
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
CAUTION: The external antenna connectors are for indoor use only. Do not connect
them to outdoor antennas.
Table 4. ZoneFlex 2942/7942 rear panel elements
Number Item Name Description
1 Power Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via 10/100 PoE port.
2 Lock Hasp The lock hasp works with a cable or Ruckus mounts.
The recommended lock type isMasterlock 120 series
(D, T, Q, KAD types).
3 External RP-SMA
Connector
• ZoneFlex 2942: One external antenna connector
• ZoneFlex 7942: None
4 LAN Ports • ZoneFlex 2942: Two RJ-45 ports, supporting 10/
100 PoE (Power over Ethernet) and 10/100Mbps
connections.
• ZoneFlex 7942: Two RJ-45 ports, supporting 10/
100/1000 PoE (Power over Ethernet) and 10/100/
1000Mbps connections.
Each Ethernet port has two LEDs, which indicate the
type of device that is connected to the port.
5 OPTIONAL Button Not active in this model at this time.
6 SOFT RESET
Button
Used to reset the AP. This is a normal reset and does
not reset the AP back to factory defaults.
Table 5. Behavior of Ethernet port LEDs on ZoneFlex 2942/7942
LEDs Description
Off Not connected
Steady flashing Amber + Green Connected to 10Mbps device
Steady flashing Amber Connected to 100Mbps device
Steady flashing Green Connected to 1000Mbps device
Intermittent flashing Amber +
Green
Connected to 10Mbps device, and passing traffic
Intermittent flashing Amber Connected to 100Mbps device, passing traffic
Intermittent flashing Green Connected to 1000Mbps device, passing traffic

7
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7962 Access Point
The physical features of ZoneFlex 7962 are very similar to ZoneFlex 2942/7942. It uses
the same dome-type chassis with the sliding door and Kensington lock on the side
panel. There are slight differences, however, in the side panel and rear panel elements.
Refer to the illustrations below for more information.
Side Panel Features
Figure 3 illustrates the side panel features of ZoneFlex 7962. For a description of each
rear panel part, refer to Table 6.
Figure 3. ZoneFlex 7962 side panel
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description
1 OPT LED Not used in this model
1
23
4
5
6
7
8

8
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
2 DIR LED • Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
•Green: The Access Point is being managed by
ZoneDirector.
• Slow flashing green (one flash every two seconds):
The Access Point is being managed by
ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The Access Point is being managed by
ZoneDirector and is currently receiving
configuration settings (provisioning) or a firmware
update.
3 2.4G LED (WLAN) • Off: The WLAN service is down.
•Amber: The WLAN service is up, at least one
wireless client is associated (standalone), or at
least one downlink MAP is connected (RAP), or
uplink RAP is connected (MAP), but signal quality
is poor (RSSI < 15).
•Green: The WLAN service is up, at least one client
is associated (standalone), or at least one
downlink MAP is connected (RAP), or uplink RAP
is connected (MAP), and signal quality is good
(RSSI >= 15).
•Flashing green: The WLAN service is up, no clients
are associated (standalone), no downlink MAPs
are connected (RAP), or no uplink RAP is
connected (MAP).
4 5G LED (WLAN) •Off: The WLAN service is down.
•Green: The WLAN service is up and at least one
wireless client is associated.
•Fast flashing green (two flashes every second):
The WLAN service is up and no wireless clients are
associated.
•Slow flashing green: zMesh AP searching for an
uplink, or searching for ZoneDirector.
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description

9
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
5 HARD RESET
Button
Pushing and quickly releasing this internal button
reboots the AP. Pushing and holding it for six
seconds resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings will erase all settings that you configured
previously.
6 Sliding Door Protects the ports, buttons, and connector on the
rear panel
7 Kensington Lock The Kensington lock feature, located on the
opposite side of the unit from the pictured LEDs, is
designed to prevent the sliding door from opening,
thus locking the unit. The Kensington lock works with
a Kensington MicroSaver lock.
8 Power LED (front) • Off: Off.
•Amber: Boot up in process.
•Green: On.
Table 6. ZoneFlex 7962 side panel elements
Number LED/Button Name Description

10
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Rear Panel Features
Figure 4 shows the rear panel of ZoneFlex 7962. For a description of each rear panel
part, refer to Tab le 7.
Figure 4. ZoneFlex 7962 rear panel features
Table 7. ZoneFlex 7962 rear panel elements
Number Item Name Description
1 Power Connect the power adapter to this socket. (Input
110-240V AC, Output 12V 1.0A DC). Power can also
be supplied via the 10/100/1000 PoE port.
2 Lock Hasp The lock hasp works with a cable or Ruckus Wireless
mounts. The recommended lock type is Masterlock
120 series (D, T, Q, KAD types).
3 LAN Ports Two RJ-45 ports, one for a 10/100/1000 PoE (Power
over Ethernet) connection and another for a 10/100/
1000Mbps connection.
Each Ethernet port has two LEDs, which indicate the
type of device that is connected to the port.
• Flashing green + amber: 10Mbps Layer 2 device
• Flashing amber: 100Mbps Layer 2 device
• Flashing green: 1000Mbps Layer 2 device
12 3 4
5

11
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex 7341 Access Point
ZoneFlex 7341 features five LEDs on its front panel, and buttons and connectors on
its rear panel.
Front Panel
Figure 5 shows the front panel of ZoneFlex 7341. For a description of each front panel
part, refer to Tab le 8.
Figure 5. ZoneFlex 7341 front panel
4 OPTIONAL Button Not active in this model at this time.
5 SOFT RESET
Button
Use to reset AP. This is a normal reset and does not
set AP back to factory defaults.
Table 8. ZoneFlex 7341 front panel elements
LED Description
PWR LED • Off: Off.
•Red: Boot up in process.
•Green: On.
OPT LED Not used in this model
Table 7. ZoneFlex 7962 rear panel elements
Number Item Name Description
P

12
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
DIR LED • Off: The Access Point is not being managed by
ZoneDirector (standalone mode).
•Green: The Access Point is being managed by
ZoneDirector.
•Slow flashing green (one flash every two
seconds): The Access Point is being managed
by ZoneDirector, but is currently unable to
communicate with ZoneDirector.
•Fast flashing green (two flashes every second):
The Access Point is being managed by
ZoneDirector and is currently receiving
configuration settings (provisioning) or a
firmware update.
WLAN LED • Off: The WLAN service is down.
•Amber: The WLAN service is up and no clients
are associated (standalone), or no wireless
clients and no downlink MAPs are connected
(RAP).
•Green: The WLAN service is up and at least one
wireless client is associated. If Mesh is enabled,
no downlink MAPs are connected.
•Fast flashing green: The WLAN service is up, at
least one client is associated, and at least one
Mesh downlink is connected.
•Slow flashing green: At least one Mesh
downlink is connected, and no clients are
associated.
AIR LED • Off: The WLAN service is down.
•Green: The AP is functioning as a RAP or MAP
and the uplink signal is good.
•Slow flashing green (one flash every two
seconds): Mesh networking is enabled, but the
AP is still searching for a mesh uplink.
•Fast flashing green (two flashes every second):
The AP is functioning as a MAP and the wireless
signal to its uplink AP is fair.
Table 8. ZoneFlex 7341 front panel elements
LED Description
