RUKO F11 GIM2 User manual

14+
for age
CONTACT US FOR MORE TECH SUPPORT
[phone] Mon-Fri 7:00AM - 7:00PM (PST)
User Manual

[phone] Mon-Fri 7:00AM - 7:00PM (PST)
CONTACT US FOR MORE TECH SUPPORT
[phone] rukobrandsto[email protected]

Copyright ©2023 Ruko All Rights Reserved.
Contents
1
1 Using This Manual
2 Package Contents
3 Preface
1.1 Legend
1.2 Read Before the First Flight
1.3 Video Tutorials
1.4 Download the App
6.1 Controller Features
6.2 Controlling the Drone
6.3 Optimal Transmission Zone
6.4 Emergency Stop
6.5 Charging the Controller
4
4
4
4
4
5
6
10
14
4 Warning
5 Fly Safety
16
6 Remote Controller
16
18
21
22
23
7.1 Preparing the Aircraft
7.2 Drone Diagram
7.3 Assemble the Propeller
7.4 Intelligent Flight Battery
7.5 Gimbal and Camera
24
7 Drone
24
25
25
26
26

Copyright ©2023 Ruko All Rights Reserved.
2
298 Drone Status Indicators
9 Product Functions Profile
9.1 Return to Home
9.2 Waypoint Flight
9.3 Point of Interest
9.4 GPS Follow Me
9.5 Image Recognition Follow Me
9.6 Hand Gesture
30
30
32
33
34
35
35
10 Connect the APP
10.1 Download the APP
10.2 Connect the APP with Drone
36
36
36
11 APP Functions
11.1 Control
11.2 APP Icons Introduction
39
39
40
12 APP Setting
12.1 Setting
42
42
13 Image Storage
13.1 APP One Key Share Function
13.2 How to Download the Pictures and Videos
45
45
47
14 Flight
14.1 Take Off/ Landing Procedures
14.2 Quick Start
49
49
50

Copyright ©2023 Ruko All Rights Reserved. 3
15 Specifications
15.1 Drone
15.2 Gimbal Stabilization
15.3 Camera
15.4 5G Transmission
15.5 APP/ Live View
15.6 Remote Controller
15.7 Intelligent Flight Battery
15.8 Charging Cable: Type-c
53
53
53
54
54
55
55
56
56
16 Common Problems 57
17 Accessories Support 62

Read the following documents before using Ruko drone.
User Manual
Flight Start & Safety Disclaimer
It is recommended to watch all the guide videos on our website and
read the disclaimer and safety guidelines before using for the
first time.
Scan the QR code to watch the guide videos, which
demonstrate how to use Ruko drone.
Copyright ©2023 Ruko All Rights Reserved.
4
F11GIM2 User Manual
1.1 Legend
1.2 Read Before the First Flight
Recommend Warning Hints & Tips Reference
1 Using This Manual
1.3 Video Tutorials
①
②
Scan the QR code downlaod "RUKO DRONE" app.
1.4 Download the App
The IOS version of RUKO DRONE is
compatible with IOS v9.0 and later.
QR code of "RUKO DRONE" for Apple IOS system.
The operation system version of RUKO DRONE
is compatible with Android v5.0 and later.
QR code of "RUKO DRONE" for Android system.
The following terms are used throughout the product literature to
indicate various levels of potential harm when operating
this product :

Copyright ©2023 Ruko All Rights Reserved. 5
F11GIM2 User Manual
2 Package Contents
Drone Remote Controller Drone Battery
User Manual Allen Wrench Screw
Gimbal Cover Spare Propeller USB Charging Cable
RC Cable (USB-C connector)
RC Cable (Micro USB connector)
RC Cable (Lightning connector)

Copyright ©2023 Ruko All Rights Reserved.
6
F11GIM2 User Manual
Important
Safety Precautions
3 Preface
Thank you for purchasing the Ruko-Series GPS aircraft. Please
read all instructions and warnings carefully before operating.
Please also keep this instruction manual for future reference
and maintenance.
This product shoud be operated by the people who are over 14
years old. It is a precision device that combined machinery,
electronics with air mechanics and high frequency transmission
into a single unit. It requires correct assembly and debugging to
avoid any accident. The user should operate and control this
product in a safe manner. In case of incorrect operation, it may
cause serious injury or damage property. It can also be lost due to
incorrect operation.
This product is suitable for experienced UAV pilots no less than
14 years of age.
In the event of a problem during using, operating, or maintaining,
please contact the local sales agent, retailer or keep in touch with
the responsible staff of our company.
This R/C aircraft can be dangerous when in use, please make sure
you keep it far away from any persons or spectators when flying.
In-correct installation, poor conditions, or users not familiar with
operation may cause damage to the aircraft or injure people or
may cause an unexpected accident. Please pay close attention to
flying safety and learn to recognize more dangerous conditions
which may cause an accident due to your own negligence.

Copyright ©2023 Ruko All Rights Reserved. 7
F11GIM2 User Manual
Keep it far away from any structures or crowds.
This R/C aircraft may vary slightly in speed or sensitivity while
flying and can cause potential danger. Therefore, please keep it far
away from crowds, buildings, trees, structures, high-voltage wire,
etc. Please also avoid flying in adverse weather conditions such as
rain, electrical storms, and high winds to ensure safety of the user,
any spectators, and surrounding property.
Keep it away from any moist environment.
The inside of the aircraft is composed of many precision electronic
and mechanical parts. Therefore, please try to avoid any moisture or
water content from entering the main body of the aircraft as it may
cause a breakdown of the mechanical and electronic parts and thus
cause an accident.
Only operate with included parts for intended use.
Please use the original parts made by Ruko-Series for any
re-equipping or maintenance to ensure flying safety. Please operate
and use only under the scope of the product function permitted.
Using un-approved parts will void warranty.
DO NOT use for any illegal purpose or use beyond the scope of
which your local laws and regulations have stipulated.
Avoid controlling it independently.
New users may have certain difficulties during the early stages of
learning to operate this aircraft. Please try to avoid operating the
aircraft alone. When available, always operate this aircraft under
the guidance of a more experienced user.
Do not operate under the influence of drugs or alcohol.
Please operate this R/C aircraft according to your own state and
flying skill. Any fatigue, bad mental state, or incorrect operation
may increase the probability of accidental risk.

Copyright ©2023 Ruko All Rights Reserved.
8
F11GIM2 User Manual
Please keep a safe range from aircraft when using top speed.
When the operator is flying in a high speed, please keep the aircraft
far from any surrounding persons or objects so as not to cause
danger or damage.
Store it in a cool, dry place.
The R/C aircraft is composed of material such as metal, fiber, plastic,
electronics, etc. Therefore, please keep it away from any heat source
and avoid prolonged exposure to direct sunlight. Excessive heat
exposure can cause distortion and damage.

Copyright ©2023 Ruko All Rights Reserved. 9
F11GIM2 User Manual
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment may generate and radiate
radio-frequency energy when in use. Please install and use it
according to the instructions or it may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful interfer-ence to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Please note that changes or modifications not expressly
approved by the party responsible for compliance could void
the use's authority to operate the equipment.

Copyright ©2023 Ruko All Rights Reserved.
10
F11GIM2 User Manual
4 Warning
There is some important information in this package and instruction,
please keep it for future reference.
You have the responsibility to make sure that this model of aircraft
won't cause injury to others' body or cause any damage to property.
Please operate strictly as shown on the instruction manual when
debugging or assembling this aircraft. During the process of flying
or landing, please pay more attention to keep 1-2 meters between
the user and the aircraft to avoid colliding to the head or face or
body, which may cause injury.
Our company and distributors won't be responsible for any incorrect
operation, which may cause loss or damage or injury to the body.
Children ages 14 and up should use this product under the guidance
of an adult. This product is FORBIDDEN to be used by children
under 14 years old.
Please correctly assemble and use this product as shown on the
instruction manual or packing instruction. Some parts should be
assembled by an adult.
Small parts are included with this product. Please place it beyond
the reach of the children to avoid a CHOKING HAZARD or parts
being mistakenly swallowed.
Playing on the road or near high traffic areas is strictly FORBIDDEN
so as not to cause an accident.
Please dispose of the packing material timely so as not to cause
injury to children.
Please DO NOT disassemble or re-equip the aircraft as it may cause
a breakdown of the aircraft during flying.

Copyright ©2023 Ruko All Rights Reserved. 11
F11GIM2 User Manual
Batteries in the battery compartment of the charger should be
inserted into the designated power source which has the same
logo as the product.
Built-in rechargeable 3.7V lithium polymer battery included in
the transmitter.
Only the original charging cable make from our factory can be
used.
Charging cable is not a toy.
When charging the battery, please conduct it under the
surveillance of an adult. Please also keep it far away from any
combustible object when charging. Please keep this aircraft
within eyesight when charging.
Please DO NOT make it short-circuited or squeeze the battery
so as not to cause an explosion.
DO NOT mix the Li-ion battery with a different type of battery.
Intelligent lithium battery is loaded in the Quad-rotor. Both
built-in or external can be used for charging.
Please DO NOT make the battery short-circuited or decompose
the battery. DO NOT throw the battery into the fire; DO NOT
place the batteries near the high temperature or heated area
(such as near the fire or near the electric heating device).

Copyright ©2023 Ruko All Rights Reserved.
12
F11GIM2 User Manual
The aircraft should be kept far away from any other electric
compliance or equipment as far as possible or kept far away
from the place where having the magnetic object nearby as
they may cause interference with each other.
Please keep the safe distance from the high-speed rotating
rotor so as not to cause twisted or danger of being wounded
or being cut.
Engine will heat up. Please DO NOT touch it to avoid being
burned or injured.
Please DO NOT close this product to your ear as it may cause
injury to your hearing.
Type-C 5V wall charger recommended for charging the drone.
DO NOT use any charger stronger than 5V.
To comply with the command of the magnetic environment
requirement formulated by the Aviation Radio Bureau and the
related authority, during the regulated period in certain areas,
please stop using the transmitter of this model when such
regulation command is issued.
Keep your UAS within sight.
Never fly over groups of people.
Never fly over stadiums or sports events.
Understand airspace restrictions and requirements.

Copyright ©2023 Ruko All Rights Reserved. 13
F11GIM2 User Manual
The product should only be used by adults and children
14 years and older. Adult supervision is required for
children under 14 years of age.

Copyright ©2023 Ruko All Rights Reserved.
14
F11GIM2 User Manual
①
②
③
Make sure the antenna of the remote control is oriented towards
the drone.
Make sure fly in the open area without any interference
and obstacle.
Do not fly against the wind, the video transmission distance is 3KM.
5 Fly Safety
Image transmission area requirements:
Fly in Open
Areas
Strong GPS
Signal
Maintain
Line of Sight
Maximum flight
altitude height is
about 120 meters
Avoid flying over or near obstacles, crowds, high voltage power
lines, trees, airport or bodies of water.
DO NOT fly near strong electromagnetic sources such as power
lines and base stations as it may affect the onboard compass.

Copyright ©2023 Ruko All Rights Reserved. 15
F11GIM2 User Manual
7m/s
No Fly Zone
Stay away from the rotating
propellers and motors.
DO NOT use the drone in adverse weather conditions such as
rain, snow, fog and wind speeds exceeding 7 m/s or 16 mph.
It's important to understand basic flight guidelines,for the
safety of both you and those around you. Don't forget to read
the Safety Guidelines before flight.

Copyright ©2023 Ruko All Rights Reserved.
16
F11GIM2 User Manual
6.1 Controller Features
6 Remote Controller
1.Left Joystick
The left joystick is the throttle stick
which controls the aircraft up/down,
left rotation/right rotation.
2.Right Joystick
The right joystick is the directional
stick which controls the aircraft
forward/backward, fly left sideways/
fly right sideways.
3.Emergency Stop
Press once and then long press for
3 seconds to trigger an emergency
stop, the aircraft will lose power and
drop in place. (DO NOT use unless it
is an emergency.)
4.Power Button
Press once to check the current
battery level. Press once and then
long press to turn on the remote
controller.
5.Speed Mode Switch/ Indoor Mode
Press once to switch between
Camera mode, Normal mode, and
Sport mode. The default is normal
mode.
Long press for 3 seconds to turn off
GPS mode and switch to indoor
mode. (GPS mode is on by default,
please do not turn it off when flying
outdoors to avoid losing the aircraft.)
6.Return to Home (RTH) Button
Return to Home (RTH) Button
Press the button to initiate RTH. The
aircraft returns to the last recorded
Home Point (Due to GPS signal
issues, the landing position may
deviate slightly from the Home
Point, within a radius of about 3
meters). Press again to cancel RTH.
7.Shutter
Press once to take a photo.
1
2
3
4
5
7
8
6
12
9
10
11
13
15
14
SOTP
SPEED

Copyright ©2023 Ruko All Rights Reserved. 17
F11GIM2 User Manual
8.Record
Press once to record a video.
9.Mobile Device Holder
Used to securely mount the mobile
device to the remote controller.
10.USB-C Port
For charging the remote controller.
11.Joysticks Storage Slot
For storing the control joysticks.
12.Antenna
Signal reception area
13.Camera Zoom
Controls the camera zoom in and out.
14.Gimbal Dial
Controls the tilt of the camera.
15.Remote Controller Cable
Connect to a mobile device for video
linking via the remote controller cable.
Select the cable according to the
mobile device.
The F11GIM2 has three speed mode: Camera mode 4.5m/s, Normal
mode 6.5m/s, and Sport mode 10m/s. The default speed is Normal
mode, higher speed will consume battery faster.
Distance
Status Display
Long-distance Version
Remote Control Battery
GPS signal strength
Remote Control
Signal Strength
Speed Aircraft Battery
Photo/Video
Height D-speed V-speed

Power off the remote control.
Keep pressing the , then press once
and long press the (press once
indicating the power level, long press the
remote control beeps three times and
power on, LED screen indicates
"RHAND MODE".)
Copyright ©2023 Ruko All Rights Reserved.
18
F11GIM2 User Manual
Remote Controller Stick Mode-Mode 1 (Default Mode)
6.2 Controlling the Drone
Throttle Joystick
Left Joystick Right Joystick
Direction Joystick
Switch Remote Controller Stick Mode--Mode 2
Left Joystick Right Joystick
Throttle Joystick
Direction Joystick
STOP
SPEED
