1
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
SPECIFIC SAFETY RULES
QHold power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring. Fasteners contacting
a "live" wire may make exposed metal parts of the
power tool "live" and could give the operator an
electric shock.
SAFETY RULES FOR LASER GUIDE
The laser guide radiation used in saw is Class 2M with
maximum <5mW and 650nm wavelengths. These lasers
do not normally present an optical hazard, although
staring at the beam may cause flash blindness.
WARNING:
DO NOT stare directly at the laser beam. A
hazard may exist if you deliberately stare into the
beam, please observe all safety rules as follows;
QThe laser shall be used and maintained in accordance
with the manufacturer’s instructions.
QNever aim the beam at any person or an object other
than the work piece.
QThe laser beam shall not be deliberately aimed at
personnel and shall be prevented from being directed
towards the eye of a person for longer than 0.25s.
QAlways ensure the laser beam is aimed at a sturdy
work piece without reflective surfaces. i.e. wood or
rough coated surfaces are acceptable. Bright shiny
reflective sheet steel or the like is not suitable for
laser use as the reflective surface could direct the
beam back at the operator.
QDo not change the laser guide assembly with a
different type. Repair must only be carried out by the
laser manufacturer or an authorised agent.
QSave these instructions. Refer to them frequently
and use them to instruct others who may use this
tool. If you loan someone this tool, loan them these
instructions also.
LASER RADIATION
DO NOT STARE INTO THE BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 2M LASER PRODUCT
CAUTION:
Use of controls or adjustments or performance
of procedures other than those specified herein
may result in hazardous radiation exposure.
SPECIFICATIONS
Motor 18V
Switch Variable Speed
No Load Speed 0-2,100 min-1
Cutting Angle 0º to 45º(Right)
Maximum Cutting
Thickness(Wood ) 40 mm
Blade Stroke 19 mm
Shank capacity 6.35 mm
Orbital Motion 4 Settings
Laser Guide Class 2M,5mW max, 650nm
MODEL BATTERY PACK
(not included) CHARGER
(not included)
CJS-180L
BPP-1815
BPP-1815M
BPP-1817
BPP-1817M
BPL-1820
BPL-1815
BCL-1800
BCS618
BCL1418
BPP-1815
BPP-1815M
BPP-1817
BPP-1817M
BC-1815S
BC-1800
DESCRIPTIONS
1. Lock-off button
2. Switch trigger
3. Blade storage
4. Orbital adjustment knob
5. T-shank saw blade
6. Toolless blade clamp
7. Hex key
8. Hex key storage area
9. Laser guide switch
10. Laser guide
11. Battery pack( not included)
12. Latches
13. Depress latches torelease Battery pack
14. Blade clamp lock
15. Base pivot screw
16. Edge guide screw
17. Base
18. Scale
19. Moves the laser beam in a rotational direction
20. Moves the laser beam laterally left to right
961075062-03(CJS-180L)_EU.indd Sec1:1
961075062-03(CJS-180L)_EU.indd Sec1:1
1/5/10 1:37:41 PM
1/5/10 1:37:41 PM

2
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
OPERATION
WARNING:
Do not allow familiarity with tools to make you
careless. Remember that a careless fraction of a
second issufficient to inflict serious injury.
WARNING:
Always wear safety goggles or safety glasses
with side shields when operating tools. Failure
to do so could result in objects being thrown into
your eyes, resulting inpossible serious injury.
WARNING:
Do not use any attachments or accessories
not recommended by the manufacturer of this
tool. The use of attachments or accessories not
recommended can result in serious personal
injury.
APPLICATIONS
You may use this tool for the purposes listed below:
QCutting wood surfaces
QCutting thin sheet metal
QCutting plastics and laminates
TO INSERT BATTERY PACK(NOT INCLUDED)
Fig.2
QLock the switch trigger by releasing it all the way.
QPlace the battery pack on the tool.
QMake sure the latches on each side of the battery
pack snap into place and the battery pack is secured
on the tool before beginning operation.
CAUTION:
When placing battery pack in the tool, be sure
raised rib on battery pack aligns with the grooves
in the saw and latches into place properly.
Improper installation of the battery pack can
cause damage to internal -components.
TO REMOVE BATTERY PACK(NOT INCLUDED)
Fig.2
QLock the switch trigger by releasing it all the way.
QDepress the latches on the side of battery pack.
QRemove the battery pack from the tool.
BATTERY PROTECTION FEATURES
Ryobi 18 V lithium-ion batteries are designed with
features that protect the lithium-ion cells and maximize
battery life. Under some operating conditions, these
built-in features may cause the battery and the tool it is
powering to act differently from nickel-cadmium batteries.
During some applications, the battery electronics may
signal the battery to shut down, and cause the tool to
stop running. To reset the battery and tool, release the
trigger and resume normal operation.
NOTE: To prevent further shut down of the battery, avoid
forcing the tool.
If releasing the trigger does not reset the battery and
tool, the battery pack is depleted. If depleted, the battery
pack will begin charging when placed on the lithium-ion
charger.
BLADE STORAGE(Fig.3)
The blade storage compartment is located on the back
of the saw. It is convenient for storing extra blades and
storing blades when not in use.
QTo open: Push the door down with your thumb or
finger. Place blades in blade storage compartment.
QTo close: Push the door up with your thumb or finger.
WARNING:
Battery tools are always in operating condition.
Therefore, switch should always be locked when
not in use or carrying at your side.
LASER GUIDE(Fig.4)
Depress the laser guide switch to generate a red laser
beam on the work surface in front of the saw. Use the
laser to guide the saw along the line of cut.
LOCK-OFF BUTTON(Fig.4)
The lock-off button is located on the handle above the
switch trigger. You must depress the lock-off button in
order to pull the switch trigger. The lock resets each time
the trigger is released.
NOTE: You can depress the lock-off button from either
the left or right side.
SWITCH TRIGGER(Fig.4)
To turn the saw ON, depress and hold lock-off button,
then depress the switch trigger. To turn it OFF, release
the switch trigger.
961075062-03(CJS-180L)_EU.indd Sec1:2
961075062-03(CJS-180L)_EU.indd Sec1:2
1/5/10 1:37:42 PM
1/5/10 1:37:42 PM

3
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
OPERATION
WARNING:
This tool is designed to work with T-shank
blades. Use with non-T-shank blades may result
in blades coming loose from tool, resulting in
personal injury or property damage.
BLADE SELECTION
To obtain the best performance from the saw, it is
important to select a specific blade for the particular
application and type of material you wish to cut. By doing
this you will get a smoother, faster cut and prolong blade
life.
NOTE: This tool is designed to work with T-shank blades.
Other types of saw blades are not guaranteed to work
properly and may come loose from the tool.
INSTALLING BLADES(Fig.5)
QRemove battery pack.
QLift blade clamp lock located on front of saw.
QInsert saw blade between blade clamp and saw bar.
QClose blade clamp lock.
QReplace battery pack.
GENERAL CUTTING(Fig.6)
Rest the front of the saw base on the workpiece and align
cutting edge of the blade with the line on your workpiece.
Start the saw and move it forward on the work surface.
Apply downward pressure to keep the saw steady and
only enough forward pressure to keep the blade cutting.
Do not force the saw. Forcing the saw may overheat the
motor and break saw blades. Broken saw blades must
be replaced with new saw blades.
ORBITAL MOTION(Fig.6)
The blade of the saw cuts in orbital motion. This feature
is adjustable and provides faster, more efficient cutting.
With orbital motion, the blade cuts through your work
in the upstroke but does not drag across your work in
the downstroke. The higher settings should be used
when fast cutting in soft material is desired. The lower
settings should be used when cutting materials with
more resistance.
STRAIGHT CUTTING(Fig.6)
A straight cut can be made by clamping a piece of wood
or straightedge to the workpiece and guiding the edge of
the saw against it. Make the cut from one direction only;
don’t cut halfway and complete the cut from the opposite
end.
SPLINTER-FREE CUTTING(Fig.7)
The base of the jig saw has a narrow slot to permit
splinter-free cutting. It is especially useful when cutting
plywood. This feature should only be used when making
straight cuts or circle cuts. It is not for bevel cutting or
plunge cutting.
NOTE: The non-orbital setting also helps reduce
splintering when cutting plywood.
positioning the base in the splinter-free cutting position
QRemove battery pack
QUsing the 3 mm. hex key provided, loosen base pivot
screws and slide base forward.
QAlways set the cutting angle at 0° for splinter-free
cutting. To set cutting angle at 0°, align the 0° mark
on the scale with the edge of the motor housing.
NOTE: When setting angle at 0° for splinter-free cutting,
the positive stop notches on the rear of the base are not
used.
QTighten base pivot screws securely.
QRemove hex key and return it to the storage area.
QReplace battery pack.
OPTIONAL EDGE GUIDE(Fig.8)
An optional edge guide is available for use with the saw.
It can be used for making crosscuts and rip cuts.
QRemove battery pack.
QInsert the arm through the two slots in the base of the
saw as shown.
QAdjust edge guide to the desired width and lock in
place with the edge guide screw.
QReplace battery pack.
SCROLL CUTTING(Fig.9)
Scroll cuts can be made with the jig saw by guiding the
direction of the cut with applied pressure on the handle
as shown.
WARNING:
Excessive side pressure to the blade could result
in broken blades or damage to the material being
cut.
961075062-03(CJS-180L)_EU.indd Sec1:3
961075062-03(CJS-180L)_EU.indd Sec1:3
1/5/10 1:37:42 PM
1/5/10 1:37:42 PM

4
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
OPERATION
ANGLE CUTTING (Bevel Cutting) (Fig.10-
Fig.11)
Bevel cutting angles may be adjusted from 0° to 45° right
or left. Angles for cuts from 0° to 45° in 15° increments
are marked on a scale on both the left and right side
of the base. Notches on the rear of the base provide
positive stops at each of the above mentioned 15°
increments. A protractor is recommended when accurate
cuts are required.
QRemove battery pack.
QUsing the 3 mm. hex key provided, loosen the base
pivot screws until the base can be moved.
QSlide base backward until base pivot screws can
move freely in slots in base.
QAlign the mark, on the base, of the desired angle with
the edge of the motor housing.
QOnce the desired angle is reached, slide base forward
until tab on motor housing aligns with the appropriate
notch on rear of base.
NOTE: When making a set-up for accurate cuts with
a protractor, or for angles other than the preset 15°
increments, the positive stop notches on the rear of the
base are not used.
QTighten the base pivot screws securely.
QReturn hex key to storage compartment.
QReplace battery pack.
NOTE: The wide slot in the base must be used when
making bevel cuts, scroll cuts, plunge cuts, and when
cutting metal.
PLUNGE CUTTING(Fig.12)
WARNING:
To avoid loss of control, broken blades, or
damage to the material being cut, always use
extreme caution when making plunge cuts. We
do not recommend plunge cutting on materials
other than wood.
QMark the line of cut clearly on the workpiece.
QSet the cutting angle at 0°.
QTilt the saw forward so that it rests on the front edge
of the base and blade will not come in contact with
the workpiece when the saw is turned on.
QMake sure the blade is inside the area to be cut.
QUsing high speed, start the saw and slowly lower the
blade into the workpiece until the blade cuts through
the wood.
QContinue lowering the blade into the workpiece until
the base rests flat on the work surface, then move the
saw forward to complete the opening.
WARNING:
Use of controls or adjustments or performance
of procedures other than those specified herein
could result in hazardous radiation exposure.
ADJUSTING THE LASER(Fig.13)
The laser can be realigned by adjusting the two screws
located in the front of the saw. The top screw moves the
laser beam laterally from left to right. The bottom screw
moves the laser beam in a rotational direction.
NOTE: Draw a pencil line on scrap workpiece parallel to
the long edge of the base as a straight line guide to aid in
the adjusting process.
QRemove the blade from the saw.
QTurn laser on.
QRest base of saw on scrap workpiece.
QAdjust screws as necessary.
QSince blade thicknesses vary, always make a trial cut
in scrap workpiece to ensure an accurate cut.
QCheck for proper alignment.
QRepeat as necessary until laser is aligned.
MAINTENANCE
WARNING:
When servicing, use only identical replacement
parts. Use of any other parts may create a
hazard or cause product damage.
WARNING:
Always wear safety goggles or safety glasses
with side shields during power tool operation or
when blowing dust. If operation is dusty, also
wear a dust mask.
WARNING:
To avoid serious personal injury, always remove
thebattery pack from the tool when cleaning or
performing any maintenance.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, oil, grease, etc.
961075062-03(CJS-180L)_EU.indd Sec1:4
961075062-03(CJS-180L)_EU.indd Sec1:4
1/5/10 1:37:43 PM
1/5/10 1:37:43 PM

5
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
MAINTENANCE
WARNING:
Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, etc.,
come in contact with plastic parts. Chemicals can
damage, weaken ordestroy plastic which may
result in serious personal injury.
Only the parts shown on the parts list are intended to
be repaired or replaced by the customer. All other parts
should be replaced at an Authorized Service Center.
ENVIRONMENTAL PROTECTION
Recycle raw materials instead of disposing as
waste.The machine, accessories and
packaging should be sorted for environmental-
friendly recycling.
SYMBOL
Safety Alert
V Volts
min-1 Revolutions or reciprocations per minute
Direct current
CE Conformity
Please read the instructions carefully before
starting the machine.
Recycle unwanted
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
961075062-03(CJS-180L)_EU.indd Sec1:5
961075062-03(CJS-180L)_EU.indd Sec1:5
1/5/10 1:37:43 PM
1/5/10 1:37:43 PM
