PRIME DESIGN, A SAFE FLEET BRAND
Address: 580 Opperman Drive, Eagan, MN 55123 ▪ Toll Free: 1.8.PRIME.RACK
Fax: 651-552-1799 ▪ Email: inf[email protected] ▪ Website: www.primedesign.net
Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
2
1
M8 HEX HEAD BOLT (x2)
35MM/45MM (see note below)
SEALING WASHER (x2)
M8 CARRIAGE BOLT (x1)
M8 CARRIAGE BOLT (x1)
GUTTERLESS FOOT (x1)
FOAM PAD (x1)
RUBBER WASHER (x2)
5/16” FENDER WASHER (x2)
M8 LOCKNUT (x2)
M8 NUT CAP (x2)
5/16” INTERNAL
LOCK WASHER (x1)
5/16” FLAT WASHER (x1)
M8 LOCKNUT (x1)
GUTTERLESS POST RIGHT (x1)
GUTTERLESS POST LEFT (x1)
FBM-1019 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
1—Mounting Brackets .......................................... (Qty 4)
FBM-1019
Mounting Brackets shown in position on a
generic cap for illustrative purposes only.
Mounting Brackets must be located in Cap
manufacturer’s designated locations.
HKT-8165 Topper Mount Hardware Kit
contains both 35MM and 45 MM M8
Hex Head Bolts to accommodate varying
thicknesses in topper models.
Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
3
FBM-1019 ASSEMBLY INSTRUCTIONS–CROSSBAR MOUNTINGS
Rear
Front
Left
Right
Rear
Front
Rear
Front
FrontRear
Bolt
Sealing Washer
Mounting Bracket
Foam Pad
Rubber Washer
Fender Washer
Locknut
Nut Cap
FBM-1019
MOUNTING BRACKETS 1Set mountings into pre-drilled holes as shown.
3
Torque nuts to 90 in-lbs
2
Torque nuts to 90 in-lbs
Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
4
Even
Rear Left Rear Right
Even
MOUNTING
4.2
4.4
4.1
Loosen nuts on all
Mounting Brackets
4.3
Position Rack until evenly spaced
between rear Channel Mountings
Channel Mountings
align to Crossbars
4.1
4.5
Torque to 90 in-lbs
FBM-1019 ASSEMBLY INSTRUCTIONS–ALURACK MOUNTING
USAM-FBM1019-US01 Rev-A 0720
Shown with AluRack Pickup
for illustrative purposes only
NOTE: Rack should be adjusted to attach the
Mounts to Heavy Duty Crossbars only.
