60” Channels (2X)
Mountings (6X)
Top Connector (2X) Bottom Connector (2X)
M8 Bolt (4X)
End Caps (4X) Screws (8X) Brackets (4X)
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
1—FBM-0020 ........................................................ (Qty 1)
Channels with hardware
CONTENTS OVERVIEW
2—Rear Crossbar Assembly.................................. (Qty 1)
3—Front Crossbar Assembly................................. (Qty 1)

PRIME DESIGN, A SAFE FLEET BRAND
▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
3
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
6—Front Drive Shaft .............................................. (Qty 1)
B Version, 35.75”
7—Z Post ................................................................ (Qty 1)
Adjustable, 7.25”
8—L Post................................................................. (Qty 1)
US3, Square Cap, 11.25”
9—Ladder Stop Assembly ..................................... (Qty 2)
1.75”
5—Connecting Bar................................................. (Qty 1)
48.00”
4—Drive Shaft........................................................ (Qty 1)
Rear, Right Hand, 34.00”
10—HRR Removeable Handle Assembly ............. (Qty 1)
11—HKT-8163-Rotation Hardware Kit ................. (Qty 1)
(Not called out in Overview)
" Flat Washer (10X)
Anti-Seize (1X)
Lubricant (1X)
Clevis Pin (1X)
Cotter Pin (1X)
M8 x 50MM (4X) ⅜" x 2.25" (2X)
1.00" Sealing
Stickers (16X)
M8 Lock Nut (5X) ⅜" Lock Nut (2X) ⅜" Flat Washer (4X)
M8 x 25MM (1X)

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪
Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
4
Rear
Front
Rear
Front
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–FBM MOUNTINGS
FBM-0020
MOUNTING BRACKETS
Loosen nuts
Slide the upper and lower
Channel Connectors into
Channels and align holes
Slide all Mounting Bodies
onto Base Puller Assembly 2
Position Base Pullers and
Nut onto Roof Mounting Boss 1
3.2
3.1
Torque to
80 in-lbs
4.1
4.2
Slide Channels onto
Mounting Brackets
INSTALLER NOTE: Mounting Brackets
must be disassembled for installation
onto the vehicle’s roof.

PRIME DESIGN, A SAFE FLEET BRAND
▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
5
Left Rear
47.00”
4”
55.50”
Right Rear
47.00”
4”
55.50”
Left Rear
Flush to end
Flush to end
96.00”
Right Rear
96.00”
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–FBM MOUNTINGS
5
Torque screws to 90 in-lbs
6Set to distances then torque Mounting Bracket nuts to 80 in-lbs
7
Loosen Bolts
8Set to distances shown, but do not tighten at this time

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪
Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
6
1
1
3
2
4
5
7
9
6.25”
6.25”
6.25”
6.25”
Rear
Front
Front
Rear
6
8
RIGHT ROTATION ASSEMBLY
CROSSBARS CROSSBAR ADJUSTMENT
Torque to
90 in-lbs 1.2
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–RIGHT SIDE ROTATION
1.1

PRIME DESIGN, A SAFE FLEET BRAND
▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
7
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–RIGHT SIDE ROTATION
REAR DRIVE SHAFT
CONNECTING BAR
CYLINDER HARDWARE
FRONT DRIVE SHAFT
2.1
2.2
2.3
Torque to
90 in-lbs
3.1
3.2
4.1
5.1
5.3
4.2
5.2

PRIME DESIGN, A SAFE FLEET BRAND ▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪
Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
8
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–RIGHT SIDE ROTATION
CONNECTING BAR FASTENERS
L POSTS
SEE QUICK START GUIDE FOR ADJUSTMENTS
DRIVE SHAFT SEALING
Z POSTS
SEE QUICK START GUIDE FOR ADJUSTMENTS
6
7.1
7.2
Torque to 90 in-lbs
8.2
Torque to 90 in-lbs
8.1
9.1
9.2
Apply Silicone Sealant
to Connecting Bar ends
9.1

PRIME DESIGN, A SAFE FLEET BRAND
▪Address: 1689 Oakdale Avenue #102, West St Paul, Minnesota 55118 ▪Phone: [phone] ▪Toll Free: 1.8.PRIME.RACK ▪Fax: [phone] ▪Email: in[email protected] ▪Website: www.primedesign.net
TM & © 2018 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6764268, 6971563, 2364879, 8857689, 8511525, 8991889, 2271515, 2364897, 9506292, 9481313, 9481314, 9796340, 6202807, 6427889, 9415726 AND OTHER PATENTS PENDING
9
10
10
11
VBR-E-PM21 ASSEMBLY INSTRUCTIONS–LEFT SIDE BASE
LEFT SIDE BASE
LADDER STOPS CYLINDER ADJUSTMENT
Adjust the Cylinder Flow
Control Screw to allow
approximately 3 seconds
time for the ladder to glide
down when operating the
loaded Ladder Rack.
11
10.1
10.2
