Safe Fleet RVS systems RVS-M641 User manual

Reverse With Condence ™ 1
G-Series Rear View Frameless
Mirror Monitor with 4.3" Mirrorlink Display
RVS-M641
Instruction Manual

RVS Systems
2
Introduction.............................. 03
SafetyInformation.............................. 04-06
Before Beginning Installation . . . . . . . . . . . . . . . . . . . . . . 07
InstallationGuide............................. . 08-09
MonitorIntroduction............................ 10-11
Adjustable Grid Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installation + Wire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13-15
Remote Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MenuIntroduction................... . . . . . . . . 17
Mirrorlink................. . . . . . . . . . . . 18-19
Monitor Specications . . . . . . . . . . . . . . . . . . . . . . . . . 20
ChannelSwitch................. . . . . . . . . . . 21
Warranty.......................... . . . . . 22
Disclaimer.......................... . . . . . 23
TABLE OF CONTENTS

Reverse With Condence ™ 3
NOTE! Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.
Congratulations on purchasing a RearView Backup
Camera System!
With this manual you will be able to properly install and
operate the unit.
The Backup Camera System is intended to be installed as a
supplement aid to your standard rear view mirror that already exists
in your vehicle. The Backup Camera System should not be used as a
substitute for the standard rear view mirror or for any other mirror
that exists in your vehicle.
In some jurisdictions, it is unlawful for a person to drive a
motor vehicle equipped with aTV viewer or screen located forward of
the back of the driver’s seat or in any location that is visible, directly
or indirectly, to the driver while operating the vehicle.
INTRODUCTION

RVS Systems
4
Please read the entire manual and follow the instructions and
warnings carefully. Failure to do so can cause serious damage and/or
injury, including loss of life. Be sure to obey all applicable local
trac and motor vehicle regulations as it pertains to this product.
Improper installation will void manufacturer’s warranty.
• The Rear View Camera System is
designed to help the driver safe-
ly detect people and/or objects
helping to avoid damage or injury.
However, you the driver, must use it
properly. Use of this system is not a
substitute for safe, proper or legal
driving.
• Never back up while looking at the
monitor alone. You should always
check behind and around the vehi-
cle when backing up, in the same
way as you would if the vehicle did
not have the Rear View Camera
System.Ifyoubackupwhilelooking
only at the monitor, you may cause
damage or injury. Always back up
slowly.
•The Rear View Camera System is
not intended for use during exten-
sive back-up maneuvers or backing
into cross trac or pedestrian walk-
ways.
•Please, always remember, the area
displayed by the Rear View Camera
Systemis limited.It doesnot display
the entire panorama that is behind
you.
USAGE:
SAFETY INFORMATION

Reverse With Condence ™ 5
•Electric shock or product
malfunction may occur if this
product is installed
incorrectly.
• Use this product within
the voltage range specied. Failure
to do so can cause
electronic shock or product
malfunction.
• Take special care when
cleaning the monitor.
•Make sure to rmly ax the prod-
uct before use.
• If smoke or a burning smell
is detected, disconnect the
system immediately.
•Where the power cable may touch
a metal case, cover the cable with
friction tape. A short circuit
or disconnected wire may cause a
re.
• While installing the Rear View
System be careful with the wire
positioning in order to avoid wire
damage.
• The Rear View System should only
be used when the vehicle is in
reverse.
• Do not watch movies or
operate the monitor while driving;
as it may cause an
accident.
• Do not install the monitor
where it may obstruct drivers
view or obstruct an air bag
device.
• Dropping the unit may cause
possible mechanical failure.
INSTALLATION:
SAFETY INFORMATION

RVS Systems
6
IN NO EVENT SHALL SELLER OR MANUFACTURER BE
LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
SAFETY INFORMATION
If you have questions about this product, contact:
RVS Systems
1797 Atlantic Avenue
Brooklyn, NY 11233
Tel: [phone]

Reverse With Condence ™ 7
Before drilling please check that no cable or wiring is on the other side
of the wall. Please clamp all wires securely to reduce the possibility
of them being damaged while vehicle is in use. Keep all cables away
from hot/moving parts and electrical noisy components.
We recommend doing a benchmark test before installation
to insure that all components are working properly.
Step 1: Choose the monitor and camera locations.
Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm)
hole should be drilled for passing camera cable through vehicles
walls. Install split grommets where applicable.
Step 3: Once all cables and wiring have been properly routed, perform
a system function test by temporarily connecting the system.
BEFORE YOU BEGIN

RVS Systems
8
INSTALLATION GUIDE
Replacement Monitor
The mirror monitor replaces the existing car mirror. Carefully remove
the mirror o the“pin”. Slide the replacement mirror on to the pin and
secure it with the screw provided (already in the screw hole).Dier-
ent cars have dierent brackets. Depending on your vehicle make and
manufacturer. There are many methods to remove the original rear-
view mirror, however, please don’t force the mirror o the bracket.
The manufacturer will not be responsible for damage caused to your
car by incorrect mirror installation. Figure 1.1
Camera & Cable
Be sure to position the cable properly. The aviation camera cable uses
aircraft grade connectors which means the camera cable can be ex-
posed to all weather elements. Do not run the cable over sharp edges,
do not kink the cable and keep away from HOT and rotating parts.
Fasten all cables and secure all excess cable. Connect camera to the
camera extension cable which runs inside the vehicle. Figure 1.2

Reverse With Condence ™ 9
INSTALLATION GUIDE
Wiring
After connecting the camera to the“camera cable” the camera should
be plugged into AV2 input. Connect the RED 12V power wire to a an
ignition power source and the BLACK 12V ground wire to a chassis
ground.The GREEN wire is the REVERSE trigger wire. Connect this wire
to the vehicle’s backup light circuit to activate the rear-view image
whenever the vehicle shifts into reverse. To connect additional camer-
as, connect to the corresponding input. Figure 2.1, Figure 2.2
Precautions for use of Mirror Monitor
I. The Mirror Monitor is made of glass. Do not subject it to a
mechanical shock by dropping it from a high place, etc.
II. Do not apply excessive force to the monitor surface or the
adjoining areas since this may cause the color tone to vary.
III. Clean with a soft dry cloth and/or Windex only.
IV. Do not attempt to disassemble the mirror monitor.
Safety
• Before drilling, be sure no cable or wire is on the other side.
• Feed as much cable as possible into vehicle & clamp securely.
This reduces the possibility of cable being hooked or snagged.

RVS Systems
10
MONITOR INTRODUCTION

Reverse With Condence ™ 11
MONITOR INTRODUCTION
14.3" Ultra Bright Screen
2Mirrorlink Mode Switch
3Toggle Display Mode (Mirrorlink, Camera Displays)
4Toggle Volume Up
5Toggle Volume Down
6Mounting Bracket
7Connection Input
8Speaker
9Black to GND
10 Red to Ignition +12V
11 Reverse Trigger
12 Left Audio
13 Right Audio
14 Camera Input #1
15 Camera Input #2

RVS Systems
12
ADJUSTABLE GRID LINES
Generally, to help drivers estimate the distance from obstacles, there are
three lines for reference- red, yellow, and green. Those three lines are dis-
played on the monitor when car is reversing.The green line is 10 feet from
the back of the car and the yellow line is 6.5 feet away.The distant red line
is 3.3 from the backside of car while the closed red line is 1.3 feet from the
car. Both reference lines on the left and right should leave 0.65 feet from
the car.
Grid Lines
9.9 feet
6.6 feet
3.3 feet
9.9 feet
6.6 feet
3.3 feet 1.3 feet
The accuracy of the grid-lines can vary based on how you angle your cam-
era. Therefore to compensate for inaccurancies, you can adjust the grid
lines to your camera angle.
Accuracy

Reverse With Condence ™ 13
INSTALLATION AND WIRE
FIGURE 1.1
FIGURE 1.2

RVS Systems
14
INSTALLATION AND WIRE
FIGURE 2.1
1. RED- Power (+)
2. YELLOW- Video
3. GREEN- Mirror / Normal Imaging
4. WHITE- Audio
5. BLACK- Ground (-)

Reverse With Condence ™ 15
INSTALLATION AND WIRE
FIGURE 2.2

RVS Systems
16
REMOTE INTRODUCTION
Remote Introduction
Up Clockwise
Down
Right
Left
Adjust grid line
Counterclockwise
Press the button to toggle L/R gridlines
Remote control Rotate gride line
Remote Introduction

Reverse With Condence ™ 17
MENU INTRODUCTION
Menu Introduction
Short press the Menu to toggle between Picture and System. Once in
these settings, press Sel/Rec to switch among items. Use Up and Down
to adjust settings.
Menu Introduction

RVS Systems
18
MIRRORLINK
Mirrorlink
MirrorLink enables you to view your mobile phone on your mirror mon-
itor through WiFi and standard programs like DLNA, Miracast and Air
Play. Navigate your trip, select and listen to music, or play games on
your mirror monitor, all with your cell phone! Your backup camera will
also automatically display on your monitor when you reverse.
Connection
1) Use the M button to toggle between Android/iOS

Reverse With Condence ™ 19
MIRRORLINK

RVS Systems
20
MONITOR SPECIFICATIONS
Monitor Information
Screen Size 4.3"
Dot Resolution 480 x 3 (RGB) x 272
Display Format TFT-LCD
Working Voltage 12V
Video System PAL/Auto/NTSC
Video Input 2 Channel
Working Temperature -20°C ~ +65°C
Brightness 1100 cd/m2
Operating Temperature -20°C ~ +75°C
Video System Auto NTSC/PAL
Overall Dimensions 3.15" (H) x 10.55" (L) x 1" (D)
