PBR-255-ARE2 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
CONTENTS OVERVIEW
1—Rear Crossbar Assembly.................................. (Qty 1)
2—Front Crossbar Assembly ................................. (Qty 1)
6—Front Drive Shaft .............................................. (Qty 1)
B Ver, 23.75”
3—Rear Drive Shaft............................................... (Qty 1)
Right Hand, 36”
4—Handle Latch Assembly ................................... (Qty 1)
Right Hand
5—Connecting Bar................................................. (Qty 1)
24”

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
3
M8 Locknut (4X) Flat Washer (4X)
BLC-1065-M8 (4X)
Mounting Foot (1X)
Mounting Post (1X)Mounting Top (1X) Foam Pad (1X)
M8 x 30MM (2X)
M8 Locknut (2X)Seal Washer (2X)
Neoprene Washer (2X)
Fender Washer (2X)
BLT-6846-M8 (1X)
BLT-6864-M8 (2X)
BLT-6850-M8 (1X)
Mounting Foot (1X)
Mounting Post (1X)Mounting Top (1X) Foam Pad (1X)
M8 x 30MM (2X)
M8 Locknut (2X)Seal Washer (2X)
Neoprene Washer (2X)
Fender Washer (2X)
BLT-6846-M8 (1X)
BLT-6864-M8 (2X)
BLT-6850-M8 (1X)
PBR-255-ARE2 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
9—Mounting Bracket Assembly............................ (Qty 2)
Vertical w/Hardware
7—Z Post ................................................................ (Qty 2)
Adjustable, 7.25”
8—L Post ................................................................ (Qty 2)
Square Cap, 9.25” w/Hardware
10—Mounting Bracket Assembly.......................... (Qty 2)
Horizontal w/Hardware

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
4
PBR-255-ARE2 ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
10—Ladder Stop.................................................... (Qty 2)
With Hardware
BLT-6870-M8 (2X)
M8 x 25MM (1X)
Anti-Seize (1X)
Lubricant (1X)
Clevis Pin (1X)Cotter Pin (1X)
M8 x 50MM (4X) ⅜" x 2.25" (2X)
1.00" Sealing
Stickers (16X)
M8 Lock Nut (5X) ⅜" Lock Nut (2X) ⅜" Flat Washer (4X)" Flat Washer (10X)
11—HKT-8163 (Not called out in Overview)........ (Qty 1)

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪
TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
5
PBR-255-ARE2 ASSEMBLY INSTRUCTIONS–MOUNTING BRACKETS
Assemble the Mounting Top to the Mounting Post using bolt
assembly BLT-6846-M8. Do not tighten until Step 11.3
0.2
VERTICAL MOUNTING BRACKET
Assemble the Mounting Foot to the Mounting Post using bolt
assembly BLT-6850-M8. Do not tighten until Step 11.3
0.1
Assemble the remaining Mounting Brackets according to Steps
0.1–0.2 and set aside for assembly Steps 1 & 2.
0.3
