Safe Fleet Prime Design FBM-1026-BLK User manual

PRIME DESIGN, A SAFE FLEET BRAND
Address: 580 Opperman Drive, Eagan, MN 55123 ▪ Toll Free: 1.8.PRIME.RACK
Fax: [phone] ▪ Email: inf[email protected] ▪ Website: www.primedesign.net

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪ TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
2
Channels (4X)
Connect Plate (12X)
Foam Pad (12X)
Rubber Washer (12X)
End Caps (8X)
M8 Locknut (12X)
M8 Bolt (12X)
Brackets (4X)
FBM-1026-BLK ASSEMBLY INSTRUCTIONS–PACKAGING CONTENTS
CONTENTS OVERVIEW
1—Flex Channel Mounting System ...................... (Qty 1)
With hardware and Mounting Brackets

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪ TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
3
FBM-1026-BLK ASSEMBLY INSTRUCTIONS–FLEX CHANNEL MOUNTING
Rear
Front
Left
Right
See your Cap Manufacturer’s
OEM for mounting locations
1.50” 16.75” 19.75”
FBM MOUNTING
CHANNELS AND MOUNTING BRACKETS
Slide Channel Connectors
into Channels as shown.
1Install Channels into roof channel grooves. Install Channels into roof Channel grooves.
3
4
2
Install fasteners into factory
roof mounting hole locations
then torque nuts to 80 in-lbs.
Determine the best location to drill for the Channel Mounting Brackets using the guidelines below.
* RECOMMENDED: After installing the Mounting Brackets in Step 1, apply Silicone Sealant (not provided in this kit)
to bolt heads to seal against water intrusion.

Prime Design Limited Warranty. Seller’s sole and exclusive warranty (and Buyer’s sole and exclusive remedy and Seller’s entire liability for any breach thereof) with respect to the Goods is set forth in the Limited Warranty document available at primedesign.net/warranty-liability
(the “Prime Design Limited Warranty”).
▪ TM & © 2021 PRIME DESIGN. PROTECTED BY ONE OR MORE OF THE FOLLOWING PATENT NO.’s 6427889, 6764268, 6971563, 8991889, 9415726, 9506292, 9481313, 9776476, 9796340, 10470565, 10486608, 10501022 AND OTHER PATENTS PENDING
4
FBM-1026-BLK ASSEMBLY INSTRUCTIONS–FLEX CHANNEL MOUNTING
Even
Rear Left Rear Right
Even
Right Rear
Distance varies according
to crossbar configuration
Left Rear
MOUNTING
6.2
6.1
Loosen nuts on all
Mounting Brackets.
NOTE: Mounts should be adjusted to attach to
Heavy Duty Crossbars only.
4.3
Position Rack until evenly spaced between rear Channel Mountings.
Channel Mountings
align to Crossbars.
6.1
6.4
Torque all to
90 in-lbs.
USAM-FBM1026BLK-US01 Rev-A 0519
Shown with AluRack Pickup
for illustrative purposes only.
Loosen bolts.
5Do not torque at this time. Proceed to Step 7 to mount your
specic AluRack/Side Rail Conguration.
