Samson 2335 Service manual

Translation of original instructions
EB 2552-2 EN
Type2335 Excess Pressure Valve with Pilot Valve
Self-operated Regulators
Edition July 2021

Definition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip
EB 2552-2 EN
Note on these mounting and operating instructions
These mounting and operating instructions assist you in mounting and operating the device
safely. The instructions are binding for handling SAMSON devices. The images shown in
these instructions are for illustration purposes only. The actual product may vary.
ÎFor the safe and proper use of these instructions, read them carefully and keep them for
later reference.
ÎIf you have any questions about these instructions, contact SAMSON‘s After-sales Service
([e-mail]).
Documents relating to the device, such as the mounting and operating
instructions, are available on our website at www.samsongroup.com >
Service & Support > Downloads > Documentation.

Contents
EB 2552-2 EN
1 General safety instructions.............................................................................4
2 Process medium and scope of application.......................................................5
2.1 Transportation and storage.............................................................................5
3 Design and principle of operation ..................................................................6
4 Installation....................................................................................................9
4.1 Notes on installation ......................................................................................9
4.2 Strainers .....................................................................................................10
4.3 Shut-off valve...............................................................................................10
4.4 Pressure gauge ............................................................................................10
5 Operation...................................................................................................12
5.1 Start-up.......................................................................................................12
5.2 Pressure test.................................................................................................12
5.3 Steam applications.......................................................................................13
5.4 Adjusting the set point..................................................................................13
5.5 Decommissioning.........................................................................................13
6 Maintenance ...............................................................................................14
7 Nameplate..................................................................................................18
8 Technical data .............................................................................................19
9 Dimensions .................................................................................................21
10 After-sales service .......................................................................................23

4 EB 2552-2 EN
General safety instructions
1 General safety instructions
− The device must be mounted, started up or serviced by fully trained and
qualiedpersonnelonly;theacceptedindustrycodesandpracticesareto
be observed. Make sure employees or third parties are not exposed to any
danger.
− All safety instructions and warnings given in these mounting and operating
instructions, particularly those concerning installation, start-up, and mainte-
nance, must be strictly observed.
− According to these mounting and operating instructions, trained personnel
refers to individuals who are able to judge the work they are assigned to
and recognize possible dangers due to their specialized training, their
knowledge and experience as well as their knowledge of the applicable
standards.
− The devices comply with the requirements of the European Pressure
Equipment Directive 2014/68/EU. Devices with a CE marking have an EU
declaration of conformity, which includes information about the applied
conformity assessment procedure. This EU declaration of conformity can be
provided on request.
− To ensure appropriate use, only use the regulator in applications where the
operatingpressureandtemperaturesdonotexceedthespecicationsused
for sizing the regulator at the ordering stage.
− The manufacturer does not assume any responsibility for damage caused by
external forces or any other external factors.
− Any hazards that could be caused in the valve by the process medium, op-
erating pressure or by moving parts are to be prevented by taking appropri-
ate precautions.
− Proper transport, storage, installation, operation and maintenance are as-
sumed.
!

EB 2552-2 EN 5
Process medium and scope of application
2 Process medium and scope of
application
Pressure regulators for set points from 2 to
28bar·ValvesizesDN65to400·Pressure
ratingPN16to40·Suitableforliquids,
gasesandvaporsupto350°C
The differential pressure across the regulator
is used as auxiliary energy to operate the
valve. To open the regulator, this pressure
must be at least as high as the minimum dif-
ferentialpressure∆pminspeciedinTable1.
The attached pilot valve (acting as an excess
pressure valve) determines the function of the
regulator.
Risk of uncontrolled excess pressure in the
plant.
Risk of bursting
If necessary, a suitable overpressure
protection must be installed on site in the
plant section.
WARNING
!
2.1 Transportation and storage
The device must be carefully handled, trans-
ported and stored. Protect the regulator
againstadverseinuences,suchasdirt,
moisture or temperature outside the ambient
temperature range.
Do not remove the protective caps from the
valve ports until immediately before install-
ing the valve into the pipeline.
When regulators are too heavy to be lifted
by hand, fasten the lifting equipment to a
suitable place on the valve body.
Do not attach lifting slings or lifting equip-
ment to mounting parts, such as control
line, pilot valve etc.
The valve can fall or mounting parts may be
damaged.
Securely fasten slings or lifting equipment to
the valve body and secure against slipping.
WARNING
!

6 EB 2552-2 EN
Design and principle of operation
3 Design and principle of oper-
ation
See Fig.1 and Fig.2.
Themediumowsthroughtheglobevalve
(1) in the direction indicated by the arrow.
Thepositionoftheplugdeterminestheow
rate across the area released between plug
(3) and seat (2). The travel position of the pi-
lot valve (5) determines the pressure condi-
tions across the valve.
The forces created by the upstream pressure
p1acting on the plug surface and by the
control pressure pSacting on the balancing
bellows (4) or balancing diaphragm (11)
and the force of set point spring (3.1) are
compared.
IntheType2335ExcessPressureValve,the
rising upstream pressure p1causes the main
valve to open. Together with the pilot valve,
theVenturinozzle(8)(thexedrestriction
(6) and needle valve (9) in the version for
steam) create the control pressure pS.
When the pilot valve is closed, the valve is
fully balanced. The control pressure pSbe-
tweenthepilotvalveandVenturinozzleact-
ing on the outside of the balancing bellows
(4) or balancing diaphragm (11) and the
upstream pressure p1balance each other out
(pS= p1). The set point spring below the plug
closes the valve.
When the pilot valve opens, the control pres-
sure pSfalls, causing the differential pressure
at the balancing bellows or balancing dia-
phragm to increase. The force acting on the
plug surface opposes the force of the springs
and the valve opens.
To ensure proper functioning, the minimum
differentialpressure∆pmin must be available
asspecieddependingontheeldofappli-
cation.
The regulator version for steam is only avail-
able with valves balanced by a bellows. This
version has a compensation chamber (10)
alreadyttedinthecontrolline.Theneedle
valve (9) is open and lead-sealed.
Beforestart-up,llthecompensationcham-
berwithwateratthetoplleropening.
Table1: Minimum differential pressure ∆pmin
Valve size DN65 DN80 DN100 DN125 DN150 DN200 DN250 DN300 DN400
Minimum differential
pressure∆pmin
Valvebalancedby
a bellows for steam
applications 0.2bar(640cm²actuator)
0.4bar(320cm²actuator)
1.9bar 2.0bar 1.4bar 1.4bar – –
Valvebalancedby
a bellows for air/
water
1.0bar 1.0bar 0.7bar 0.7bar – –
Valvebalancedby
a diaphragm –0.8bar 0.8bar 0.4bar 0.4bar 0.5bar 0.3bar

EB 2552-2 EN 7
Design and principle of operation
Type2335ExcessPressureValve·Type2422Valvebalanced by a bellows·DN125 to 250
1
2
3
3.1
4
5
7
10
p1p2
8
9
5.1
Type 2422 as main valve balanced by a bellows
Bottom section
with bellows
Pilot valve
pS
Versionsuitableforvapors
7
8
5.1
1
2
3
4
5
Pilot valve
Bottom section
with bellows
pS
Versionsuitableforliquidsandgases
1 Globe valve (main valve)
2 Seat
3 Plug with plug stem
3.1 Set point spring
4 Balancing bellows
5 Pilot valve
5.1 Control line for pilot valve
6Venturinozzle(forgasesand
liquids)
7 Strainer
8 Fixed restriction (version for steam)
9 Needle valve (version for steam)
10 Compensation chamber (only for steam or
mediumtemperaturesabove150°C)
pSControl pressure
p1Upstream pressure
p2Downstream pressure
Fig.1: Functional diagram of valve balanced by a bellows

8 EB 2552-2 EN
Design and principle of operation
Type2335ExcessPressureValve·Type2422Valve,balanced by a diaphragm·DN125to400
6
7
1233.1 11
p1p
2
5.1
5
Diaphragm section
Type2422 as main valve, balanced by a diaphragm
pS
Pilot valve
1Valvebody(mainvalve)
2 Seat
3 Plug with plug stem
3.1 Set point spring
5 Pilot valve
5.1 Control line for pilot valve
6Venturinozzle
7 Strainer
11 Balancing diaphragm
pSControl pressure
p1Upstream pressure
p2Downstream pressure
Fig.2: Functional diagram of valve balanced by a diaphragm

EB 2552-2 EN 9
Installation
4 Installation
See Fig.3.
Select the installation location making sure
that the regulator is installed at a distance of
at least six times the valve size (DN) away
frompipettingsorinstrumentsthatcause
owturbulence(e.g.pipebends,manifolds,
pressure measuring points or other valves).
Theycanchangetheowconditionswhich
may lead to an instable control process es-
pecially in applications with gases, air or
steam.
Contact SAMSON to obtain the
TV-SK17041documentationwhichcontains
more details on installation requirements.
4.1 Notes on installation
Install the ready-assembled regulator in hori-
zontal pipelines.
− Flush and clean the pipeline thoroughly
before installing the regulator.
Otherwise, impurities in the pipeline may
impair the proper functioning of the
valve, above all the tight shut-off.
− Thedirectionofowmustmatchthedi-
rection indicated by the arrow on the
body.
− Install the regulator free of stress. If nec-
essary, support the pipeline near to the
connectinganges.Donotattachsup-
ports directly to the valve or actuator.
− Install a strainer upstream of the regula-
tor.
− Protect the regulator from icing up when
controlling media that can freeze. If nec-
essary, depressurize and drain the regu-
lator and remove it from the pipeline
while the plant is shut down.
The side on which the operating elements
(hook-up of the pilot valve) are located var-
ies depending on whether a valve balanced
by a bellows or a diaphragm is used.
Mounting orientation
Observetheowdirection.
Valve balanced by a bellows
− Bellows including housing
suspended downward.
Valve balanced by a diaphragm
− Balancing diaphragm (diaphragm sec-
tion) pointing upward
Insulation ·Toinsulatecoldsystems,we
recommendrstllingtheplantandcarefully
rinsingit(seesection5.1).Theregulator
must not be insulated until the set point is
adjusted.
− Start up the plant and adjust the set
point. Shut down the plant again and let
it heat up until the condensation water
has dried off.
− Afterwards, insulate the regulator and
pipes conveying the process medium us-
ing insulation material with a water va-
por barrier. If the pilot valve has a
spring, it must must be protected by a
sleeve to allow it to move. The
spring-loaded actuator stem must not
touch the insulation.
Note


10 EB 2552-2 EN
Installation
Thermal insulation
Do not insulate the pilot valve as well in ap-
plications with medium temperatures above
80°C.
Pipeline routing
The inlet and outlet lengths vary depending
on several variables and process conditions
and are intended as recommendations. Con-
tactSAMSONifthelengthsaresignicantly
shorter than the recommended lengths.
To ensure that the regulator functions proper-
ly, proceed as follows:
ÎObserve the inlet and outlet lengths (see
Table2).ContactSAMSONiftheregula-
tor conditions or state of the medium
process deviate.
ÎInstall the regulator free of stress and
with the least amount of vibrations as
possible.
ÎFor media with a tendency to conden-
sate, install the pipeline with a slight
downward slope on both sides so that
the condensate can drain properly. If the
pipeline upstream and downstream of
the regulator run vertically upwards, an
automatic drainage is required.
ÎInstalltheregulatorallowingsufcient
space to remove the actuator and valve
or to perform service work on them.
Pressure testing of the plant·Thepressure
must not exceed the maximum permissible
pressure of the regulator and plant on testing
Note
the pressure of the plant when the regulator
is already installed. An excessive test pres-
sure can damage the balancing bellows or
diaphragm. If necessary, remove the regula-
tor from the pipeline or isolate the regulator
in the pipeline and install a bypass.
4.2 Strainers
Installastrainer(e.g.SAMSONType1/
Type2)upstreamoftheexcesspressure
valve.
− Thedirectionofowmustcorrespondto
the arrow on the body.
− Do not use the strainer to permanently
ltertheprocessmedium.
− Thelterelementmustbeinstalledto
hang downwards or sideways for appli-
cations with steam.
Remember to leave enough space to remove
the lter element.
4.3 Shut-off valve
Install a hand-operated shut-off valve both
upstream of the strainer and downstream of
the regulator. This allows the plant to be shut
down for cleaning and maintenance, and
when the plant is not used for longer periods
of time.
4.4 Pressure gauge
Install a pressure gauge both upstream and
downstream of the regulator to monitor the
pressures prevailing in the plant.
Tip

EB 2552-2 EN 11
Installation
123456
Type2335 Excess Pressure Valve
1 Shut-off valve
2 Upstream pressure gauge
3 Strainer
4Type2422asthemainvalve
5 Downstream pressure gauge
6 Shut-off valve
Fig.3: Installation example for Type2335 Excess Pressure Valve
Table2: Inlet and outlet lengths
DN
min.
a x DN
min.
b x DN
a Inlet length
b Outlet length
State of process
medium Valve conditions Inlet length a Outlet length b
Gas Ma≤0.3 2 4
Vapors1) Ma≤0.3 2 4
Liquid Freeofcavitation/w<3
m
/
s
2 4
Cavitationproducingnoise/w≤3
m
/
s
2 4
1) No saturated steam

12 EB 2552-2 EN
Operation
5 Operation
See Fig.1 and Fig.2.
5.1 Start-up
Do not start up the regulator until all parts
have been mounted (e.g. valve and control
line). Open control line with needle valve
and check to ensure it is connected correctly.
Rinsing the plant ·Afterllingtheplant,rst
completely open the consumer and adjust the
regulatorstoachievethemaximumow
rate.Rinseoutthepipelineatfullowrate
for several minutes. Check the installed
strainer (e.g. by measuring the pressure
drop). Clean the strainer, if necessary.
− Slowlylltheplant.Makesurethatthe
pressure rises simultaneously upstream
and downstream of the regulator to
avoid damaging the balancing bellows/
diaphragm.
− Open all the valves on the consumer
side. Slowly open the shut-off valves
startingontheowpipesideinsmall
steps waiting a few minutes in between.
5.2 Pressure test
The plant operator is responsible for
performing the pressure test. SAMSON's
After-sales Service can support you to plan
and perform a pressure test for your plant.
Risk of valve damage due to a sudden
pressure increase and resulting high ow
velocities.
−Slowly open the shut-off valves.
− The main valve is closed by the internal
set point spring (3.1).
During the pressure test, make sure the fol-
lowing conditions are met:
ÎDo not allow the pressure to exceed the
1.5 times the pressure rating of the valve
body.
ÎUnscrew the control lines from the main
valve for the upstream pressure p1 and
downstream pressure p2 and seal the
openings at the main valve with screw
plugsG¼(DN15to100)orG
3
/
8
(DN125to250).
ÎMake sure that the pressure rises simulta-
neously upstream and downstream of the
regulator to avoid damaging the balanc-
ing bellows or diaphragm.
Note
NOTICE
!

EB 2552-2 EN 13
Operation
The pressure gauge located on the upstream
pressure side allows the adjusted set point to
be monitored.
First set the maximum set point by turning
the set point adjuster clockwise (P).
Wait until the excess pressure valve starts to
regulate before adjusting the set point by
slowly turning the adjuster counterclockwise
(Q).
Incorrectly adjusted set point or set point
cannot be adjusted.
Malfunction
Start by turning the set point adjuster by one
turn at a time and wait until the upstream
pressure reaches the set point. As soon as
the excess pressure valve starts to work, you
can adjust the set point by making larger
changes. Wait several minutes until the pres-
sure conditions have stabilized and check
the set point. Correct the set point, if neces-
sary.
After start-up and set point adjustment,
avoid fast changes in pressure.
5.5 Decommissioning
Depressurize the plant. Close the shut-off
valvesstartingfromtheowpipe(high-pres-
sure line).
NOTICE
!
5.3 Steam applications
Observe the following points for applications
with steam:
− Before start-up, all pipes conveying the
process medium must be completely
drained and dry (to prevent steam ham-
mering).
− Beforestart-up,llthecompensation
chamber (10) with water (also at the pi-
lot valve, if necessary).
− Slowly start up the plant and allow time
for the pipes and valves to heat up.
− Air and condensate must be allowed to
escape from the plant.
Install steam trap or air vent for
steam-operated systems at a suitable lo-
cation.
5.4 Adjusting the set point
Adjust the required set point while the plant
(consumer) is open by turning the set point
adjuster at the pilot valve (5).
When the adjusted upstream pressure (set
point) is reached, the pilot valve opens,
causing the main valve to open as well.
Turn clockwise (P):
– To increase the pressure set point
Turn counterclockwise (Q):
– To reduce the pressure set point

14 EB 2552-2 EN
Maintenance
6 Maintenance
The regulator does not require any mainte-
nance. Nevertheless, it is subject to natural
wear, particularly at the seat, plug and oper-
ating diaphragm.
Depending on the operating conditions,
check the regulator at regular intervals to
avoid possible malfunctions.
Be aware of the risks on performing work
on pressurized or hot plant sections.
Hot process medium can escape uncon-
trolled on dismantling the regulator. Risk of
scalding.
Allow the regulator to cool down before de-
pressurizing and draining it and remove it
from the pipeline.
Details on faults and how to remedy them
canbefoundinTable3onpage15.
The listed examples of malfunctions are
caused by mechanical faults in the main
valve or pilot valve as well as incorrect regu-
lator sizing.
In the simplest case, the functioning can be
restored following the recommended action.
To repair the pilot valve, read the operating
instructions for the corresponding regulator
(pilot valve). As in many cases, special tools
are required, we advise you to contact
SAMSON'safter-salesservicetondout
how to proceed to repair the regulator or
replaceacomponent(seesection10on
page23).
WARNING
!
Exceptional operating and installation condi-
tions can lead to changed situations that
may affect the control response and lead to
malfunctions. In such cases, check the instal-
lation conditions, process medium, tempera-
ture and pressure conditions. A thorough
analysis may often require the on-site assis-
tance of SAMSON's After-sales Service.
The table is not intended to be exhaustive as
there are diverse reasons for malfunctions.

EB 2552-2 EN 15
Maintenance
Table3: Troubleshooting
Malfunction Possible reasons Recommended action Note
Malfunction only occurs when the consumer is closed or during low load:
Upstream
pressure does not
reach the
adjusted pressure
set point
Pilotvalve·Leakage
between seat and plug
Remove valve from the pipe-
line and clean seat and plug.
Renew plug, if necessary. If
this is not possible, return reg-
ulator for repair.
Install a shut-off valve instead
of the pilot valve. If the main
valve closes when the shut-off
valve is closed, the pilot valve
has caused the malfunction.
Mainvalve·Leakage
between seat and plug
Remove valve from the pipe-
line and clean seat and plug.
Renew plug, if necessary. If
this is not possible, return reg-
ulator for repair.
Balancing bellows/
diaphragm of the main
valve defective
Replace bellows/diaphragm.
Install a shut-off valve instead
of the pilot valve. If the main
valve does not open when the
shut-off valve is opened, the
main valve has caused the mal-
function. Particularly in steam
applications, steam hammering
can damage the bellows. There-
fore, make sure that no water
or condensate is present in the
pipeline before start-up.
Malfunction occurs when the consumer is open or at maximum load:
Upstream
pressure is much
higher than the
adjusted pressure
set point
The pilot valve does not
function.
Balancing bellows/dia-
phragm defective. Medium
leaks from the actuator.
Replace the defective compo-
nent.
Install a shut-off valve instead
of the pilot valve and open it. If
the main valve opens when the
shut-off valve is open, the pilot
valve has caused the malfunc-
tion.
The pilot valve is blocked.
Clean the pilot valve. Apply
grease to plug stem guides, if
necessary. Replace defective
parts.
Main valve seized up Clean main valve.
Install a shut-off valve instead
of the pilot valve and open it. If
the main valve does not open
when the shut-off valve is
opened, the main valve has
caused the malfunction.
In steam applications: plant
started up too quickly.
Fill condensation chambers
with water. Slowly start up the
plant.

16 EB 2552-2 EN
Maintenance
Troubleshooting (continued)
Malfunction Possible reasons Recommended action Note
The pressure
does not reach
the set point.
Strainer in the line in which
the pilot valve is installed is
clogged up.
Clean the strainer.
The required minimum dif-
ferential pressure to operate
the regulator is not avail-
able.
Raise upstream pressure or
reduce downstream pressure.
Set point range of the pilot
valve is too low. Convert or replace pilot valve.
Main valve seized up Clean main valve. Install a shut-off valve instead of
the pilot valve and open it. If the
main valve does not open when
the shut-off valve is opened, the
main valve has caused the mal-
function.
The pilot valve is blocked.
Clean the pilot valve. Clean
internal control line used to
tap the upstream pressure.
Needle valve (steam) in-
stalledbetweenxedrestric-
tion and main valve is
blocked or closed.
Clean the needle valve. Check
setting (open).
Main valve is sized to be too
small(KVS/CV)
Resize the valve. Replace
main valve.
Regulator's
reaction is
sluggish
Strainer in the line in which
the pilot valve is installed is
clogged up.
Clean the strainer.
Inside the pilot valve is
clogged up, impairing the
owthroughthevalve.
Clean the inside of the pilot
valve.
Needle valve (steam) in-
stalledbetweenxedrestric-
tion and main valve is
blocked.
Clean the needle valve. Check
setting (open).
Thexedrestrictionis
clogged up. Cleanxedrestriction.
ControllineorVenturi
nozzle blocked Clean parts. Improve steam conditioning, if necessary.

EB 2552-2 EN 17
Maintenance
Troubleshooting (continued)
Malfunction Possible reasons Recommended action Note
Control loop
hunts
KVS/CVof pilot valve too
large (after valve has been
replaced).
Install pilot valve with suit-
ableKVS/CVcoefcient.
Theowconditionsinthe
plant at the location where
the regulator is installed are
not suitable for the regulator.
Pipe reducers, instruments
and diversions can change
theowconditionswhich
may lead to an instable
control process especially in
applications with gases, air
or steam. Refer to the
SAMSON document
TV-SK17041forminimum
distances.
If this is the case, send a sketch of
the plant to SAMSON for a thor-
ough analysis.
KVS/CVof main valve too
large
Resize the valve. Replace
main valve or reduced the
owrate(smallerKVS/CV
coefcient).
Periodic excitation to vibrate
originating from the plant Contact SAMSON.
Possibly change the natural fre-
quency, e.g. over the needle
valve (9) when there is resonance
in the plant.

18 EB 2552-2 EN
Nameplate
7 Nameplate
Nameplate of main valve
SAMSON
DN
bar
Made in Germany
˚C
T
bar
∆p
PN
Kvs
No
No
∆p
Made in Germany
Size
SAMSON psi
Npsi T˚F Cv Cl
12
910 11
8
5
4
1
3
2
9
810 11 12
5
4
1
3
2
DIN version
ANSI version
DIN valve
1Valvetype
2 Model number index
3 Material number
4 Order number or date
5KVScoefcient
8Valvesize
9 Pressure rating
10 Perm. differential pressure in bar
11 Perm.temperaturein°C
12 Body material
ANSI valve
5Valvesize
8 Perm. differential pressure in psi
9Perm.temperaturein°F
10 Body material
11 CVcoefcient(KVS x 1.17)
12 Class (pressure rating)
Fig.4: Nameplate of Type2335 Excess Pressure Valve

EB 2552-2 EN 19
Technical data
8 Technical data
Table4: Technical data · All pressures in bar (gauge)
Type2422 Valve·Balanced by a bellows·Suitable for liquids, gases or vapors
Valve size DN65 DN80 DN100 DN125 DN150 DN200 DN250
Pressure rating PN16 to 40
Conformity ·
StandardKVScoefcients
KVScoefcient 501) 801) 1251) 200 360 520 620
KVSI(withowdividerST1) 381) 601) 951) 150 270 400 500
KVSIII(withowdividerST3) 251) 401) 601) 100 180 260 310
xFZ value 0.4 0.35 0.3
Minimum
differential
pressureΔpmin
For vapors 0.2bar(640cm²actuator)1)
0.4bar(320cm²actuator)1)
1.9bar/
3.0bar2)
2.0bar/
3.0bar2)
1.4bar/
3.0bar2)
For gases and liquids 1.0bar/
3.0bar2)
0.7bar/
3.0bar2)
Max.permissibledifferentialpressure∆pmax 20bar 16bar 16bar/
35bar2)
12bar/
35bar2)
10bar/
25bar2)
ReducedKVScoefcient
KVScoefcient 321) 801) 1251) 360
KVSI(withowdividerST1) – 601) 951) 270
KVSIII(withowdividerST3) – 401) 601) 180
xFZ value 0.4 0.35 0.3
Min. differential
pressureΔpmin
For vapors 0.4bar(640cm²actuator)1)
0.8bar(320cm²actuator)1)
–1.9bar 2.0bar
For gases and liquids 0.2bar1) 1.0bar
Max.permissibledifferentialpressure∆pmax 20bar 16bar 12bar
LeakageclassaccordingtoIEC60534-4 I≤0.05%ofKVScoefcient(metalseal)
IV≤0.01%ofKVScoefcient(softseal)
Max. permissible temperature (depending
on the pilot valve)
Type2406:60°C4)·Type44-6B: 150°C/200°C3)
Type44-7:150°C·Type41-73:150°C/350°C3)
Set point ranges in bar, continuously adjust-
able at the pilot valve
Type2406:2to5,4,5to10·Type44-6B: 2 to 6, 4 to 10, 8 to 20
Type44-7: 2 to 4.4, 2,4 to 6.6, 6 to 11
Type41-73: 2 to 5, 4.5 to 10, 8 to 16, 10 to 22, 20 to 28
1) VersionwithType2420DiaphragmActuator,640cm²
2) Reinforced version with bellows
3) Versionforsteam
4) Specialversionupto150°C

20 EB 2552-2 EN
Technical data
Type2422 Valve·Balanced by a diaphragm·Suitableforliquidsandgases
Valve size DN125 DN150 DN200 DN250 DN300 DN4004)
Pressure rating PN16to40
Conformity ·
KVScoefcient 250 380 6501) 8001) 1250 2000
xFZ value 0.35 0.31) 0.2
MinimumdifferentialpressureΔpmin 0.8bar 0.4bar1) 0.5bar 0.3bar
Max. permissible differential pressure
∆pmax
12bar 10bar1) 6bar
Leakage class according to
IEC60534-4 ≤0.01%ofKVScoefcient
Max. permissible temperature2)4)
Depends on the pilot valve
Type2406:60°C3)
Type44-6B: 150°C
Type44-7:150°C
Type41-73:150°C
Set point ranges in bar, continuously
adjustable at the pilot valve
Type2406: 2 to 5, 4.5 to 10
Type44-6B: 2 to 6, 4 to 10, 8 to 20
Type44-7: 2 to 4.4, 2.4 to 6.6, 6 to 11
Type41-73: 2 to 5, 4.5 to 10, 8 to 16, 10 to 22, 20 to 28
1) VersionwithreducedKVScoefcientpossible.SametechnicaldataasDN150.
2) Steam pressure regulator as special version on request
3) Specialversionupto150°C
4) Max.50°CwithDN400
