Samson EB 8139 EN Service manual

Translation of original instructions
EB 8139 EN
Edition March 2021
Type3353 Angle Seat Valve

Denition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip
EB 8139 EN
Note on these mounting and operating instructions
These mounting and operating instructions assist you in mounting and operating the device
safely. The instructions are binding for handling SAMSON devices. The images shown in
these instructions are for illustration purposes only. The actual product may vary.
ÎFor the safe and proper use of these instructions, read them carefully and keep them for
later reference.
ÎIf you have any questions about these instructions, contact SAMSON‘s After-sales Service
([e-mail]).
Documents relating to the device, such as the mounting and operating
instructions, are available on our website at www.samsongroup.com >
Service & Support > Downloads > Documentation.

Contents
EB 8139 EN
1 Safety instructions and measures ................................................................1-1
1.1 Notes on possible severe personal injury ......................................................1-3
1.2 Notes on possible personal injury ................................................................1-4
1.3 Notes on possible property damage.............................................................1-5
2 Markings on the device ..............................................................................2-1
2.1 Valve nameplate .........................................................................................2-1
3 Design and principle of operation ...............................................................3-1
3.1 Fail-safe position.........................................................................................3-1
3.2 Additionalttings........................................................................................3-1
3.3 Technical data ............................................................................................3-3
3.3.1 Dimensions and weights ..............................................................................3-4
3.3.2 Permissible differential pressures ..................................................................3-5
4 Shipment and on-site transport ...................................................................4-1
4.1 Accepting the delivered goods .....................................................................4-1
4.2 Removing the packaging from the valve........................................................4-1
4.3 Transporting and lifting the valve..................................................................4-1
4.4 Storing the valve.........................................................................................4-1
5 Installation.................................................................................................5-1
5.1 Installation conditions..................................................................................5-1
5.2 Preparation for installation...........................................................................5-1
5.3 Installing the valve into the pipeline ..............................................................5-2
5.4 Connecting the signal pressure.....................................................................5-2
5.5 Testing the installed valve.............................................................................5-3
5.5.1 Leak test.....................................................................................................5-4
5.5.2 Fail-safe action ...........................................................................................5-4
5.5.3 Pressure test................................................................................................5-4
6 Start-up .....................................................................................................6-1
7 Operation..................................................................................................7-1
8 Malfunctions ..............................................................................................8-1
8.1 Troubleshooting ..........................................................................................8-1
8.2 Emergency action .......................................................................................8-2
9 Servicing....................................................................................................9-1
9.1 Periodic testing ...........................................................................................9-2
9.2 Preparing the valve for service work.............................................................9-2
9.3 Replacing the gaskets ..................................................................................9-2
9.4 Replacing the packing.................................................................................9-4

Contents
EB 8139 EN
9.5 Tightening torques.......................................................................................9-7
9.6 Ordering spare parts and operating supplies ................................................9-7
10 Decommissioning .....................................................................................10-1
11 Removal ..................................................................................................11-1
11.1 Removing the valve from the pipeline..........................................................11-1
12 Repairs ....................................................................................................12-1
12.1 Returning devices to SAMSON ..................................................................12-1
13 Disposal...................................................................................................13-1
14 Certicates...............................................................................................14-1
15 Annex......................................................................................................15-1
15.1 Spare parts ..............................................................................................15-1
15.2 After-sales service.....................................................................................15-3

EB 8139 EN 1-1
Safety instructions and measures
1 Safety instructions and measures
Intended use
TheType3353AngleSeatValveisdesignedforon/offserviceinprocessengineeringand
plants with industrial requirements. The valve is suitable for liquids, vapors and gases at tem-
peraturesfrom–10to+180°CandapressureratingofPN40.Theangleseatvalveiscom-
bined with a pneumatic piston actuator.
Thecontrolvalveisdesignedtooperateunderexactlydenedconditions(e.g.operating
pressure, process medium, temperature). Therefore, operators must ensure that the control
valveisonlyusedinoperatingconditionsthatmeetthespecicationsusedforsizingthe
valve at the ordering stage. In case operators intend to use the control valve in other applica-
tionsorconditionsthanspecied,contactSAMSON.
SAMSON does not assume any liability for damage resulting from the failure to use the de-
vice for its intended purpose or for damage caused by external forces or any other external
factors.
ÎRefertothetechnicaldataandnameplateforlimitsandeldsofapplicationaswellas
possible uses.
Reasonably foreseeable misuse
The control valve is not suitable for the following applications:
− Useoutsidethelimitsdenedduringsizingandbythetechnicaldata
− Useoutsidethelimitsdenedbythevalveaccessoriesconnectedtothevalve
Furthermore, the following activities do not comply with the intended use:
− Use of non-original spare parts
− Performing service and repair work not described
Qualications of operating personnel
The control valve must be mounted, started up, serviced and repaired by fully trained and
qualiedpersonnelonly;theacceptedindustrycodesandpracticesmustbeobserved.Ac-
cording to these mounting and operating instructions, trained personnel refers to individuals
whoareabletojudgetheworktheyareassignedtoandrecognizepossiblehazardsdueto
theirspecializedtraining,theirknowledgeandexperienceaswellastheirknowledgeofthe
applicable standards.
Weldingoperationsmustonlybeperformedbypersonnelwhohasthenecessaryqualica-
tion to perform the applied welding procedure and handle the materials used.

1-2 EB 8139 EN
Safety instructions and measures
Personal protective equipment
Werecommendcheckingthehazardsposedbytheprocessmediumbeingused(e.g.
uGESTIS(CLP)hazardoussubstancesdatabase).Dependingontheprocessmediumand/
or the activity, the protective equipment required includes:
− Protective clothing, gloves, eye protection and respiratory protection in applications with
hot,coldand/orcorrosivemedia
− Wear hearing protection when working near the valve
ÎCheck with the plant operator for details on further protective equipment.
Revisions and other modications
Revisions,conversionsorothermodicationsoftheproductarenotauthorizedbySAMSON.
Theyareperformedattheuser'sownriskandmayleadtosafetyhazards,forexample.Fur-
thermore, the product may no longer meet the requirements for its intended use.
Warning against residual hazards
To avoid personal injury or property damage, plant operators and operating personnel must
preventhazardsthatcouldbecausedinthecontrolvalvebytheprocessmedium,theoperat-
ing pressure, the signal pressure or by moving parts by taking appropriate precautions. Plant
operatorsandoperatingpersonnelmustobserveallhazardstatements,warningandcaution
notes in these mounting and operating instructions.
Responsibilities of the operator
Operators are responsible for proper use and compliance with the safety regulations. Opera-
tors are obliged to provide these mounting and operating instructions as well as the refer-
enced documents to the operating personnel and to instruct them in proper operation. Fur-
thermore, operators must ensure that operating personnel or third parties are not exposed to
any danger.
Operatorsareadditionallyresponsibleforensuringthatthelimitsfortheproductdenedin
the technical data are observed. This also applies to the start-up and shutdown procedures.
Start-up and shutdown procedures fall within the scope of the operator's duties and, as such,
are not part of these mounting and operating instructions. SAMSON is unable to make any
statements about these procedures since the operative details (e.g. differential pressures and
temperatures) vary in each individual case and are only known to the operator.

EB 8139 EN 1-3
Safety instructions and measures
Responsibilities of operating personnel
Operating personnel must read and understand these mounting and operating instructions as
wellasthereferenceddocumentsandobservethespeciedhazardstatements,warnings
and caution notes. Furthermore, operating personnel must be familiar with the applicable
health, safety and accident prevention regulations and comply with them.
Referenced standards, directives and regulations
The devices comply with the requirements of the European Pressure Equipment Directive
2014/68/EU.DeviceswithaCEmarkinghaveanEUdeclarationofconformity,whichin-
cludes information about the applied conformity assessment procedure. This EU declaration
of conformity is included in the annex of this document.
Referenced documentation
The mounting and operating instructions of the mounted valve accessories (e.g. uEB8357
forType4740LimitSwitch)applyinadditiontothesemountingandoperatinginstructions.
1.1 Notes on possible severe personal injury
DANGER
!
Risk of bursting in pressure equipment.
Valves and pipelines are pressure equipment. Impermissible pressure or improper
opening can lead to valve components bursting.
ÎObserve the maximum permissible pressure for valve and plant.
ÎBeforestartinganyworkonthecontrolvalve,depressurizeallplantsectionsaffect-
ed as well as the valve.
ÎDrain the process medium from all the plant sections concerned as well as the
valve.

1-4 EB 8139 EN
Safety instructions and measures
1.2 Notes on possible personal injury
WARNING
!
Risk of burn injuries due to hot or cold components and pipelines.
Depending on the process medium, valve components and pipelines may get very hot
or cold and cause burn injuries.
ÎAllow components and pipelines to cool down or warm up to the ambient tempera-
ture.
ÎWear protective clothing and safety gloves.
Risk of personal injury due to exhaust air being vented.
While the valve is operating, air is vented from the actuator, for example, during
closed-loop operation or when the valve opens or closes.
ÎInstall the control valve in such a way that vent openings are not located at eye level
and the actuator does not vent at eye level in the work position.
ÎUse suitable silencers and vent plugs.
ÎWear eye and hearing protection when working near the control valve.
Risk of personal injury due to residual process medium in the valve.
Whileworkingonthevalve,residualmediumcanowoutofthevalveand,depending
on its properties, cause personal injury, e.g. (chemical) burns.
ÎIf possible, drain the process medium from all the plant sections affected and the
valve.
ÎWear protective clothing, safety gloves, respiratory protection and eye protection.
Exposure to hazardous substances poses a serious risk to health.
Certainlubricantsandcleaningagentsareclassiedashazardoussubstances.These
substances have a special label and a material safety data sheet (MSDS) issued by the
manufacturer.
ÎMakesurethatanMSDSisavailableforanyhazardoussubstanceused.Ifneces-
sary, contact the manufacturer to obtain an MSDS.
ÎInformyourselfaboutthehazardoussubstancesandtheircorrecthandling.

EB 8139 EN 1-5
Safety instructions and measures
WARNING
!
Risk of personal injury through incorrect operation, use or installation as a result of
information on the valve being illegible.
Over time, markings, labels and nameplates on the valve may become covered with dirt
orbecomeillegibleinsomeotherway.Asaresult,hazardsmaygounnoticedandthe
necessary instructions not followed. There is a risk of personal injury.
ÎKeep all relevant markings and inscriptions on the device in a constantly legible
state.
ÎImmediately renew damaged, missing or incorrect nameplates or labels.
1.3 Notes on possible property damage
NOTICE
!
Risk of valve damage due to contamination (e.g. solid particles) in the pipeline.
The plant operator is responsible for cleaning the pipelines in the plant.
ÎFlush the pipelines before start-up.
Risk of valve damage due to unsuitable medium properties.
Thevalveisdesignedforaprocessmediumwithdenedproperties.
ÎOnlyusetheprocessmediumspeciedforsizingthevalve.
Risk of leakage and valve damage due to excessively high or low tightening
torques.
Observethespeciedtorqueswhentighteningcontrolvalvecomponents.Excessive
tightening torques lead to parts wearing out more quickly. Parts that are too loose may
cause leakage.
ÎObservethespeciedtighteningtorques.
Risk of valve damage due to the use of unsuitable lubricants.
The lubricants to be used depend on the valve material. Unsuitable lubricants may cor-
rode and damage surfaces.
ÎOnly use lubricants approved by SAMSON.

1-6 EB 8139 EN
Safety instructions and measures
NOTICE
!
Risk of the process medium being contaminated through the use of unsuitable lubri-
cants and/or contaminated tools and components.
ÎIf necessary, keep the valve and the tools used free from solvents and grease.
ÎMake sure that only suitable lubricants are used.

EB 8139 EN 2-1
Markings on the device
2 Markings on the device
2.1 Valve nameplate
1 Actuator area and number of
actuator springs (Ior II)
2 Required signal pressure in bar
3Valvesize(DNandNPS)
4 Max. perm. differential pressure in
bar
5CongurationID
6 Max. perm. medium temperature
7 Year of manufacture
3
3 3
3
4 4
4 4
2
2
5
6 7
1
1
Made in Europe
SAMSON 3353
Stelldruck
Supply
(bar)
Antrieb
Act. size
Max. Diff.druck/pressure ∆p in bar
Fig.2-1: Nameplate
The nameplate is stuck on the pneumatic actuator.

2-2 EB 8139 EN

EB 8139 EN 3-1
Design and principle of operation
3 Design and principle of oper-
ation
The pneumatic control valve consists of an
angle seat valve with a soft-seated plug and
a pneumatic piston actuator. Depending on
the version, the actuator can be equipped
with a mechanical manual override or an
electric limit switch.
Themediumowsthroughthevalveinthe
direction indicated by the arrow. The signal
pressure applied to the piston actuator deter-
mines the position of the plug and thus the
cross-sectionalareaofowbetweentheseat
and plug.
Theplug/actuatorstem(14)issealedbya
self-adjusting PTFE V-ring packing (22) at
the valve and by a radial shaft seal (25) at
the actuator.
3.1 Fail-safe position
The fail-safe position of the valve upon sup-
ply air (signal pressure) failure is determined
by how the piston and actuator spring are
arranged in the pneumatic actuator.
Fail-close
The actuator spring closes the valve upon air
supply failure. The valve opens when the sig-
nal pressure increases.
Fail-open
The actuator spring opens the valve upon air
supply failure. The valve closes when the sig-
nal pressure increases.
3.2 Additional ttings
Strainers
We recommend installing a SAMSON
strainer upstream of the valve. It prevents sol-
id particles in the process medium from
damaging the valve.
Additional actuator spring (changing the
spring force)
Fail-close(FA/NC/TS)valveswiththevalve
sizesDN40and50(NPS1½and2)and
with60cm²actuatorscanbettedwithone
or two actuator springs (marked on the
nameplate with Ior II). See the 'Markings on
the device' section).
Byaddingaspringorremovingtheinternal
spring, the permissible differential pressure
and associated signal pressure can be
changed.
Actua-
tor Version Spring force
Quantity
of
springs
Signal
pressure
60cm² FA/NC/TS 1440N 13.8bar
2160N 25.4bar

3-2 EB 8139 EN
Design and principle of operation
20
3
25
66
20
3
S
55
66
25
22
14
1
55
S
22
14
1
Fail-close
FA/NC/TS
Fail-open
FE/NO/TR
1Body
3 Piston
14 Plug(withplug/actuatorstem)
20 Spring
22 V-ring packing
25 Radial shaft seal
55 Vent plug
66 Filter
S Signal pressure connection
Fig.3-1: Type3353 Angle Seat Valve

EB 8139 EN 3-3
Design and principle of operation
3.3 Technical data
The nameplate provides information on the control valve version (see the 'Markings on the
device' section). More information is available in Data Sheet uT8139.
Table 3-1: Technical data
Valve size DN15 to 50 · NPS½ to 2
Material 1.4408
Type of connection Welding ends · Threaded ends
Pressure rating PN 40
Seat-plug seal Soft seal
Characteristic On/off
Conformity ·
Actuator 30cm²(Ø=63mm)or60cm²(Ø=90mm)
Permissible signal pressure Minimumaccordingtosection3.3.2·Maximum8bar
Signal pressure connection G¼
Temperature range
Permissible medium temperature –10to+180°C
Permissible ambient temperature –10to+60°C
Permissible ow velocity
Max. velocity at the valve outlet Liquids:3m/s·Gases:0.3Mach

3-4 EB 8139 EN
Design and principle of operation
3.3.1 Dimensions and weights
Valve size DN (NPS) 15 (½) 20 (¾) 25 (1) 32 (1¼) 40 (1½) 50 (2)
Face-to-face dimension L mm 65 75 90 110 120 150
End-to-end length L1 mm 170 175 197 205 210 226
Height including actuator H mm 193 194 211 212 224 226
Bodyconnection G G½ G¾ G G1¼ G1½ G2
Thread length t mm 15 16 19 22 22 26
Valve weight kg 0.28 0.33 0.64 0.8 1.3 1.9
Version with welding ends
Valve size DN (NPS) 15 (½) 20 (¾) 25 (1) 32 (1¼) 40 (1½) 50 (2)
Face-to-face dimension L mm 100 120 150 160 180 190
End-to-end length L1 mm 187 197 227 218 230 241
Height including actuator H mm 197 199 214 223 230 229
Ød1connection mm 18.1 23.7 29.7 38.4 44.3 55.1
Wall thickness s mm 1.6 2 2.6
Valve weight kg 0.28 0.33 0.64 0.8 1.3 1.9
Pneumatic piston actuator
Version Actuator
area/Ø 30cm²/Ø63 60cm²/Ø90 (one spring)
60cm²/Ø90
(two springs)
HousingØD mm 100 127
Signal pressure connection G¼
Weight kg 1.35 2.2 2.75
ØD
L1
S
H
H
Ød1ISO 4200
L
L1
L
ØD
ØG ISO 228-1
t
Version with welding
ends
Version with female
thread

EB 8139 EN 3-5
Design and principle of operation
3.3.2 Permissible differential pressures
Thespecicationsforthestandardversionhaveadarkgraybackground.
a) Fail-close (FA/NC) version
Pressure rating DN 15 · 20 25 · 32 40 · 50
NPS ½ · ¾ 1 · 1¼ 1½ · 2
Actuator Signal
pressure ∆pActuator area Thrust
30cm² 720N 5.0bar 20 10 4
60cm²
1440N
(one spring) 3.8bar 40 16 6
2160N
(two springs) 5.4bar – 25 10
b) Fail-open (FE/NO) version
Requiredactuatorsandsignalpressurestoclosethevalveatthespecieddifferentialpres-
sure.Assignedaccordingtovalvesizeandactuatorarea.
Control valve DN15 · DN20
Pressure
rating
DN 15 · 20 ControlvalveDN15(NPS½)·DN20(NPS¾)
NPS ½ · ¾
∆
60 cm²/Ø90 30 cm²/Ø63
0
345678
5
10
15
20
25
30
35
40
p[bar]
[bar]
pzul
Actuator Signal
pressure ∆p
30cm²
Ø=63mm
4bar 6
5bar 16
6bar 26
7bar 36
8bar 40
60cm²
Ø=90mm
3bar 27
4bar 40

3-6 EB 8139 EN
Design and principle of operation
Control valve DN25 · DN32
Pressure
rating
DN 25 · 32 ControlvalveDN25(NPS1)·DN32(NPS1¼)
NPS 1 · 1¼
∆
60 cm²/Ø90
30 cm²/
Ø63
0345678
5
10
15
20
25
30
35
40
p[bar]
[bar]
pzul
Actuator Signal
pressure ∆p
30cm²
Ø=63mm
5bar 6
6bar 10
7bar 14
8bar 18
60cm²
Ø=90mm
3bar 11
4bar 19
7bar 40
Control valve DN40 · DN50
Pressure
rating
DN 40 · 50 ControlvalveDN40(NPS1½)·DN50(NPS2)
NPS 1½ · 2
∆
60 cm²/
Ø90
30 cm²/
Ø63
0345678
5
10
15
20
25
30
35
40
p[bar]
[bar]
pzul
Actuator Signal
pressure ∆p
30cm²
Ø=63mm
5 2
6 4
7 5
8 7
60cm²
Ø=90mm
3 4
4 7
5 11
6 14
7 18
8 21

EB 8139 EN 4-1
Shipment and on-site transport
4 Shipment and on-site trans-
port
The work described in this section is only to
be performed by personnel appropriately
qualiedtocarryoutsuchtasks.
4.1 Accepting the delivered
goods
After receiving the shipment, proceed as fol-
lows:
1. Check the scope of delivery. Check that
thespecicationsonthevalvenameplate
matchthespecicationsinthedelivery
note. See the 'Markings on the device'
section for nameplate details.
2. Check the shipment for transportation
damage. Report any damage to
SAMSON and the forwarding agent
(refer to delivery note).
4.2 Removing the packaging
from the valve
Observe the following sequence:
ÎDo not open or remove the packaging
until immediately before lifting to install
the valve into the pipeline.
ÎDispose and recycle the packaging in ac-
cordance with the local regulations.
4.3 Transporting and lifting the
valve
Due to the low service weight, lifting equip-
ment is not required to lift and transport the
control valve (e.g. to install it into the pipe-
line).
Transport instructions
− Protect the control valve against external
inuences(e.g.impact).
− Do not damage the corrosion protection
(paint, surface coatings). Repair any
damage immediately.
− Protect the control valve against moisture
and dirt.
− Observe the permissible ambient tem-
perature (see 'Technical data' in the 'De-
sign and principle of operation' section).
4.4 Storing the valve
Risk of valve damage due to improper
storage.
ÎObserve the storage instructions.
ÎAvoid long storage times.
ÎContact SAMSON in case of different
storage conditions or longer storage
times.
We recommend regularly checking the con-
trol valve and the prevailing storage condi-
tions during long storage periods.
NOTICE
!
Note

4-2 EB 8139 EN
Shipment and on-site transport
Storage instructions
− Protect the control valve against external
inuences(e.g.impact).
− Secure the valve in the stored position
against slipping or tipping over.
− Do not damage the corrosion protection
(paint, surface coatings). Repair any
damage immediately.
− Protect the control valve against moisture
and dirt. Store it at a relative humidity of
lessthan75%.Indampspaces,prevent
condensation. If necessary, use a drying
agent or heating.
− Make sure that the ambient air is free of
acids or other corrosive media.
− Observe the permissible ambient tem-
perature (see 'Technical data' in the 'De-
sign and principle of operation' section).
− Do not place any objects on the control
valve.
