Samson 3730 Series Service manual

Series 3730
Type 3730-4 Electropneumatic Positioner
with PROFIBUS-PA communication
Mounting and
Operating Instructions
EB 8384-4 EN (1300-1613)
Firmware version 1.52
Edition February 2015
Fig. 1 · Type 3730-4
EB + CD

2EB 8384-4 EN
DANGER!
indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING!
indicates a hazardous situation which, if not
avoided, could result in death or serious inju-
ry.
NOTICE
indicates a property damage message.
Note: Supplementary explanations,
information and tips
Definitions of the signal words used in these instructions

Contents Page
1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . 6
2 Article code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Design and principle of operation. . . . . . . . . . . . . . . . . . . . 8
3.1 Additional equipment . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.2 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.2.1 Configuration using TROVIS-VIEW software . . . . . . . . . . . . . . 10
3.3 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Attachment to the control valve – Mounting parts and accessories . . . 14
4.1 Direct attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.1 Type 3277-5 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.1.2 Type 3277 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.2 Attachment according to IEC 60534-6 (NAMUR) . . . . . . . . . . . . 20
4.3 Attachment according to VDI/VDE 3847 . . . . . . . . . . . . . . . . 22
4.4 Attachment to Type 3510 Micro-flow Valve. . . . . . . . . . . . . . . 28
4.5 Attachment to rotary actuators . . . . . . . . . . . . . . . . . . . . . 30
4.5.1 Heavy-duty version . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.6 Reversing amplifier for double-acting actuators . . . . . . . . . . . . . 34
4.6.1 Reversing amplifier (1079-1118 or 1079-1119) . . . . . . . . . . . . 34
4.7 Attaching an external position sensor. . . . . . . . . . . . . . . . . . 36
4.7.1 Mounting the position sensor with direct attachment. . . . . . . . . . . 36
4.7.2 Mounting the position sensor with attachment according to IEC 60534-6 38
4.7.3 Mounting the position sensor to Type 3510 Micro-flow Valve . . . . . . 39
4.7.4 Mounting the position sensor to rotary actuators . . . . . . . . . . . . 40
4.8 Attaching positioners with stainless steel housings. . . . . . . . . . . . 41
4.9 Air purging function for single-acting actuators . . . . . . . . . . . . . 41
4.10 Mounting parts and accessories . . . . . . . . . . . . . . . . . . . . 42
5 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1 Pneumatic connections . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.1 Signal pressure gauges . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.2 Supply pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.1.3 Signal pressure (output) . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2 Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . 48
5.2.1 Establishing communication . . . . . . . . . . . . . . . . . . . . . . 51
6 Operator controls and readings . . . . . . . . . . . . . . . . . . . . 53
7 Start-up – Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 56
7.1 Defining the valve closed position . . . . . . . . . . . . . . . . . . . 56
7.2 Setting the volume restriction Q . . . . . . . . . . . . . . . . . . . . 57
EB 8384-4 EN 3
Contents

7.3 Adapting the display. . . . . . . . . . . . . . . . . . . . . . . . . . 57
7.4 Limiting the signal pressure. . . . . . . . . . . . . . . . . . . . . . . 58
7.5 Checking the operating range of the positioner . . . . . . . . . . . . . 58
7.6 Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7.6.1 MAX – Initialization based on maximum range . . . . . . . . . . . . . 61
7.6.2 NOM – Initialization based on nominal range . . . . . . . . . . . . . 62
7.6.3 MAN – Initialization based on a manually selected range . . . . . . . . 63
7.6.4 SUb substitute calibration . . . . . . . . . . . . . . . . . . . . . . . 65
7.7 Zero calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.8 Reset to default values . . . . . . . . . . . . . . . . . . . . . . . . . 68
7.9 Start-up via local interface (SSP) . . . . . . . . . . . . . . . . . . . . 69
7.10 Setting the bus address . . . . . . . . . . . . . . . . . . . . . . . . 69
8 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
8.1 Enabling and selecting parameters . . . . . . . . . . . . . . . . . . 70
8.2 Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
8.2.1 Automatic and manual modes . . . . . . . . . . . . . . . . . . . . . 71
8.2.2 SAFE – Fail-safe position. . . . . . . . . . . . . . . . . . . . . . . . 72
8.3 Malfunction/maintenance alarm . . . . . . . . . . . . . . . . . . . . 73
8.3.1 Confirming error messages . . . . . . . . . . . . . . . . . . . . . . 74
9 Adjusting the limit switch . . . . . . . . . . . . . . . . . . . . . . . 75
9.1 Retrofitting an inductive limit switch. . . . . . . . . . . . . . . . . . . 76
10 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11 Servicing explosion-protected devices . . . . . . . . . . . . . . . . . 78
12 Firmware update (serial interface) . . . . . . . . . . . . . . . . . . . 78
13 Maintenance, calibration and work on equipment . . . . . . . . . . . 79
14 Code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
15 Dimensions in mm. . . . . . . . . . . . . . . . . . . . . . . . . . . 96
15.1 Fixing levels according to VDI/VDE 3845 (September 2010) . . . . . . 99
16 Valve characteristic selection . . . . . . . . . . . . . . . . . . . . . 100
Test certificates. . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
4EB 8384-4 EN
Contents

Revisions of the positioner firmware compared to the previous version – Control R
Control R 1.43 R 1.44
Internal revisions
R 1.45
Internal revisions
R 1.46
Internal revisions
R 1.52
Diagnosis All EXPERTplus diagnostic functions are available without having
to activate them in the positioner (see EB 8389 EN on
EXPERTplus Valve Diagnostics).
Codes 48 extended The following subitems have been added to Code 48:
h0: Activation/deactivation reference test
h1: Reference test completed (YES/No)
h3: Automatic reset of diagnosis after this time
h4: Remaining time until diagnosis time
See section 14.
Revisions to the communication firmware are listed in the Configuration Manual
KH 8384-4 EN. The Configuration Manual is included on the enclosed CD-ROM and on the
SAMSON website.
EB 8384-4 EN 5
Revisions of the positioner firmware
Note:
The functions of EXPERTplus valve diagnostics are described in the Mounting and Operating
Instructions EB 8389 EN.

1 Important safety instructions
For your own safety, follow these instructions concerning the mounting, start-up and opera-
tion of the positioner:
4The positioner is to be mounted, started up or operated only by trained and
experienced personnel familiar with the product.
According to these Mounting and Operating Instructions, trained personnel refers to
individuals who are able to judge the work they are assigned to and recognize
possible dangers due to their specialized training, their knowledge and experience as
well as their knowledge of the applicable standards.
4Explosion-protected versions of this positioner may only be operated by personnel
who have undergone special training or instructions or who are authorized to work
on explosion-protected devices in hazardous areas. Refer to section 11.
4Any hazards that could be caused by the process medium, the operating pressure, the
signal pressure or by moving parts of the control valve are to be prevented by means
of the appropriate measures.
4If inadmissible motions or forces are produced in the actuator as a result of the supply
pressure, the supply pressure must be restricted by means of a Withoutsupply
pressure reducing station.
To avoid damage to any equipment, the following also applies:
4Do not operate the positioner with the back of the positioner/vent opening facing
upwards.
The vent opening must not be sealed when the positioner is installed on site.
4Proper shipping and appropriate storage are assumed.
4Do not ground electric welding equipment near to the positioner.
Note: The device with a CE marking fulfills the requirements of the Directives 94/9/EC
(ATEX) and 2004/108/EC.
The Declaration of Conformity is included on the enclosed CD-ROM.
6EB 8384-4 EN
Important safety instructions
Vent opening

Positioner Type 3730-4 x x x 0 x 0 x x 1 x 0 0 x 0 x x
With LCD and autotune, PROFIBUS-PA
Explosion protection
ohne 0
ATEX: II 2G Exia IIC T6; II 2D Ex tb IIIC T80°C IP66 1
CSA: Exia IIC T6; Class I, II, Div.1, Groups A, B, C, D, E, F, G; Ex nA II T6;
Ex nL IIC T6; Class I, Div.2, Groups A, B, C, D; Class II, Div.1, Groups E, F, G
FM: Class I, Zone 0 AExia IIC; Class I, II, III, Div.1, Groups A, B, C, D, E, F, G;
Class I, Div.2, Groups A, B, C, D; Class II, Div.2, Groups F, G
3
ATEX: II 3G Ex nA II T6; II 3G Exic IIC T6; II 3D Ex tc IIIC T80°C IP66 8
Additional equipment
Inductive limit switch Without
SJ2-SN (NC contact)
SJ2-S1N (NO contact)
0
1
2
0
Solenoid valve Without
With, 24 V DC
0
4
External position sensor Without
With 0
0
1 0 0
Binary input Without
Floating contact 0
0
1
Diagnostics
EXPERTplus 4
Housing material
Aluminum (standard) 0
Stainless steel 1.4581 0 1
Special applications
Without 0
Positioner compatible with paint 1
Vent connection with ¼-18 NPT thread, back of housing sealed 0 0 0 0 2
Attachment according to VDI/VDE 3847 including interface 6
Attachment according to VDI/VDE 3847 prepared for interface 7
Special version
Without 0 0 0
NEPSI: Exia IIC T6 1 0 0 9
NEPSI: Ex nA II T6; Ex nL IIC T6 8 0 1 0
IECEx: Exia IIC T6 1 0 1 2
GOST: 1Ex ia IIC T6; Ex tb IIIC T80°C Db X, IP66 1 0 1 4
GOST: 2Ex nA ic IIC T6/T5/T4 Gc X; Ex tc IIIC T80°C Db X, IP66 8 0 2 0
2 Article code
EB 8384-4 EN 7
Article code

3 Design and principle of
operation
The electropneumatic positioner is attached
to pneumatic control valves. It is used to as-
sign the valve stem position (controlled vari-
able x) to the control signal (set point w).
The input signal received from a control sys-
tem is compared to the travel or rotational
angle of the control valve, and a pneumatic
signal pressure (output variable y) is pro-
duced.
The positioner consists of a travel sensor sys-
tem proportional to resistance, an analog
i/p converter with a downstream booster
and the electronics unit with microcontroller.
When a set point deviation occurs, the actu-
ator is pressurized or vented. If required, the
changes in the signal pressure can be
slowed down by a connectable Q restriction.
The signal pressure supplied to the actuator
can be limited by software or on site to 1.4,
2.4 or 3.7 bar.
A constant air stream to the atmosphere is
created by the flow regulator (9) with a
fixed set point. The air stream is used to
purge the inside of the case as well as to op-
timize the air capacity booster. The i/p
module (6) is supplied with a constant up-
stream pressure by the pressure regulator
(8) to make it independent of the supply air
pressure.
8EB 8384-4 EN
Design and principle of operation
Fig. 2 · Functional diagram
w
x
Q
%
S
mm
GG
PD
Serial
Interface 16
15 BE2
BE1
11
2
4
13
20
17 18
19
24V DC
5
3
12
6
7
8
10
1
14
9
x
y
1 Control valve
2 Travel sensor
3 PD controller
4 A/D converter
5 Microcontroller
6 i/p converter
7 Air capacity booster
8 Pressure regulator
9 Flow regulator
10 Volume restriction
11* Inductive limit switch
12* Solenoid valve
13 IEC 61158-2
interface module
14 Binary input, passive
15* Binary input, active
16 Display
17* Solenoid valve control
18* Galvanic isolation
19 D/A converter
20 Communication interface
* Optional

The positioner communicates and is pow-
ered using IEC 61158-2 transmission tech-
nology conforming to the PROFIBUS-PA
specification.
As a standard feature, the positioner comes
with a binary input for DC voltage signals to
signalize process information over the
PROFIBUS-PA.
The extended EXPERTplus diagnostics are in-
tegrated into the positioner. They provide in-
formation on the positioner and generates
diagnostic and status messages, which allow
faults to be pinpointed quickly.
The positioner is suitable for the following
types of attachment using the corresponding
accessories:
4Direct attachment to SAMSON
Type 3277 Actuator: section 4.1
4Attachment to actuators according to
IEC 60534-6 (NAMUR): section 4.2
4Attachment to rotary actuators according
to VDI/VDE 3847: section 4.3
4Attachment to Type 3510 Micro-flow
Valve: section 4.4
4Attachment to rotary actuators according
to VDI/VDE 3845: section 4.5
3.1 Additional equipment
Solenoid valve
If the operating voltage for the solenoid
valve (12) fails, the supply pressure for the
booster is vented to the atmosphere. As a
result, the actuator is vented and the valve
moves to the fail-safe position.
NOTICE
In manual mode (MAN), the manual set
point is also reset to 0 %. A different manual
set point must be entered again (Code 1).
Inductive limit switch
The rotary shaft of the positioner carries an
adjustable tag which actuates the installed
proximity switch.
External position sensor
In this version, only the sensor is mounted to
the control valve. The positioner is located
separately from the valve.
The connection of x and y signals to the
valve is established by cable and piping for
air (only without inductive limit switch).
Binary contact
All positioners are fitted with a binary input
for DC voltage signals over which process
information can be issued over the
PROFIBUS-PA network.
Another optional binary input is an active
input powered by the positioner to connect a
floating contact. Its switching condition can
also be issued over the PROFIBUS-PA net-
work.
EB 8384-4 EN 9
Design and principle of operation

3.2 Communication
The positioner is completely controlled over
the digital signal transmission implemented
complying with PROFIBUS-PA Profile B as
per DIN EN 50170 and DIN 19245 Part 4.
Data are transmitted as bit-synchronous cur-
rent modulation at a rate of 31.25 kbit/s
over twisted-pair cables conforming to
IEC 61158-2.
Usually, the positioner settings are made on
a computer which is connected to one or
more positioners linked over a segment cou-
pler to the PROFIBUS segment of the com-
puter..
The Configuration Manual KH 8384-4 EN
contains a description on how to configure
and operate the positioner over
PROFIBUS-PA.
3.2.1 Configuration using
TROVIS-VIEW software
The positioner can be configured using
TROVIS-VIEW Configuration and Operator
Interface software.
The positioner is equipped with an addi-
tional digital SERIAL INTERFACE to connect
the RS-232 or USB port of the computer to
the positioner over an adapter cable.
The TROVIS-VIEW software enables the user
to easily set parameters in the positioner
and view process parameters online.
Note: The TROVIS-VIEW software is a com-
mon operator interface for various smart
SAMSON devices. The software together
with a device-specific module allow the con-
figuration and parameterization of the de-
vice.
The device-specific module for Type 3730-4
can be downloaded free of charge from the
SAMSON website (Services > Software >
TROVIS-VIEW).
Additional information on TROVIS-VIEW
(e.g. system requirements) can found on the
SAMSON website and in the Data Sheet
T 6661 EN.
10 EB 8384-4 EN
Design and principle of operation

3.3 Technical data
EB 8384-4 EN 11
Design and principle of operation
Type 3730-4 Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Rated travel,
adjustable
Direct attachment to Type 3277 Actuator: 3.6 to 30 mm
Attachment acc. to IEC 60534-6-1: 3.6 to 300 mm
Attachment acc. to VDI/VDE 3847: 3.6 to 300 mm
Attachment to rotary actuators (VDI/VDE 3845): 24° to 100° opening angle
Travel range,
adjustable
Adjustable within the initialized travel/angle of rotation;
travel can be restricted to 15at the maximum
Bus connection Fieldbus interface acc. to IEC 61158-2 bus-powered
Field device acc. to FISCO (Fieldbus Intrinsically Safe Concept)
Communication
Fieldbus
Data transmission as in PROFIBUS-PA specification, acc. to IEC 61158 and
IEC 61784
Certified DTM acc. to FDT Specification 1.2 for integration of the device into suitable
FDT framework applications · Other integrations, e.g. EDD in SIMATIC PDM
Local Over SAMSON SSP interface and serial interface adapter
Software requirements SAMSON TROVIS-VIEW with database module 3730-4
Permissible operating
voltage
9 to 32 V DC, power supply over bus line
The limits in the test certificate additionally apply for explosion-protected devices
Max. operating current 15 mA
Add. current in case of fault 0 mA
Supply air
Supply pressure from 1.4 to 7 bar (20 to 105 psi)
Air quality acc. to ISO 8573-1 Edition 2001: Max. particle size and density: Class 4
Oil content: Class 3; Moisture and water: Class 3; Pressure dew point: At least 10 K
beneath the lowest ambient temperature to be expected
Signal pressure (output) 0 bar up to supply pressure,
limitable to 1.4/2.4/3.7 bar ±0.2 bar via software
Characteristic
Linear/equal percentage/reverse equal percentage · User-defined (over operating
software and communication) · Butterfly valve linear/equal percentage · Rotary plug
valve linear/equal percentage · Segmented ball valve linear/equal percentage
Deviation from terminal-based conformity ≤1 %
Hysteresis ≤0.3 %
Sensitivity ≤0.1 %
Direction of action Reversible
Air consumption Independent from supply pressure approx. 110 ln/h
Air output capacity
Actuator filled with air
Actuator vented
At ∆p = 6 bar: 8.5 mn
3/h, at ∆p = 1.4 bar: 3.0 mn 3/h KVmax (20 °C) = 0.09
at ∆p = 6 bar: 14.0 mn
3/h, at ∆p = 1.4 bar: 4.5 mn 3/h KVmax (20 °C) = 0.15

12 EB 8384-4 EN
Design and principle of operation
Type 3730-4 Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Permissible ambient
temperature
–20 to +80 °C for all versions
–45 to +80 °C with metal cable gland
–25 to +80 °C with inductive limit switch (SJ2-S1N) and metal cable gland
The limits in test certificate additionally apply for explosion-protected devices.
Influ-
ences
Temperature ≤0.15 %/10 K
Supply air None
Vibration ≤0.25 % up to 2000 Hz and 4 g acc. to IEC 770
Electromagnetic
compatibility
Complying with requirements of EN 61000-6-2, EN 61000-6-3, EN 61326-1 and
NAMUR Recommendation NE 21
Explo-
sion
pro-
tection
ATEX Type 3730-41
Type 3730-48
II 2G Exia IIC T6; II 2D Ex tb IIIC T80°C IP66*
II 3G Ex nA II T6; II 3G Exic IIC T6; II 3D Ex tc IIIC T80°C IP66*
CSA Type 3730-43
Exia IIC T6; Class I, II, Div.1, Groups A, B, C, D, E, F, G;
Ex nA II T6; Ex nL IIC T6; Class I, Div.2, Groups A, B, C, D;
Class II, Div.1, Groups E, F, G
FM Type 3730-43 Class I, Zone 0 AEx ia IIC; Class I, II, III, Div.1, Groups A, B, C, D, E, F, G;
Class I, Div.2, Groups A, B, C, D; Class II, Div.2, Groups F, G
GOST Type 3730-41
Type 3730-38
1Ex ia IIC T6; Ex tb IIIC T80°C Db X, IP66
2Ex nA ic IIC T6/T5/T4 Gc X; Ex tc IIIC T80°C Db X, IP66
IECEx Type 3730-41 Ex ia IIC T6
NEPSI Type 3730-41
Type 3730-48
Ex ia IIC T6
Ex nA II T6; Ex nL IIC T6
CCoE Ex ia IIC T6
INMETRO On request
Electrical connection One M20 x 1.5 cable gland, for 6 to 12 mm clamping range · Second additional
threaded M20 x 1.5 hole · Screw terminals for 0.2 to 2.5 mm² wire cross-section
Degree of protection IP 66/NEMA 4X
Use in safety-instrumented sys-
tems (SIL)
Emergency venting at 0 mA set
point and on using the optional
solenoid valve
Observing the requirements of IEC 61508, the systematic capability of the pilot
valve for emergency venting as a component in safety-instrumented systems is
given.
Use is possible on observing the requirements of IEC 61511 and the required
hardware fault tolerance in safety-instrumented systems up to SIL 2 (single de-
vice/HFT = 0) and SIL 3 (redundant configuration/HFT = 1).
Binary input 1
Input 0 to 30 V DC reverse polarity protection, static destruction limit 40 V,
current consumption 3.5 mA at 24 V, galvanically isolated
Signal Signal “1” at Ue > 5 V · Signal “0” at Ue < 3 V

EB 8384-4 EN 13
Design and principle of operation
Materials
Housing Die-cast aluminum EN AC-AlSi12(Fe) (EN AC-44300) acc. to DIN EN 1706;
chromated and powder paint coated · Special version: stainless steel 1.4581
External parts Stainless steel 1.4571 and 1.4301
Cable gland Black polyamide, M20x1.5
Weight Approx. 1 kg
Options for Type 3730-4
Binary input 2 for floating contact
Switching input R < 100 Ω, contact loadability 100 mA, static destruction limit 20 V / 5.8 mA,
galvanically isolated
Solenoid valve Approval acc. to IEC 61508/SIL
Input
24 V DC, reverse polarity protection, static destruction limit 40 V
Current consumption I = U 5.7 V
3840
−
Ω(corresponding to 4.8 mA at 24 V/114 mW)
Signal "0" no pick-up ≤12 V
Signal "1" safe pick-up >19 V (emergency venting at 0 V)
Service life >5 x 106switching cycles
KVcoefficient 0.15
Inductive limit switch For connection to switching amplifier acc. to EN 60947-5-6
SJ2-SN proximity switch NAMUR NC contact
SJ2-S1N proximity switch NAMUR NO contact
External position sensor
Travel Same as positioner
Cable 10 m with M12x1 connector, designed for continuous flexing, flame retardant acc. to
VDE 0472, resistant to oils, lubricants, coolants as well as other corrosive media
Perm. ambient temperature –60 to +105 °C
Vibration immunity Up to 10 g in the range between 10 and 2000 Hz
Degree of protection IP 67

4 Attachment to the control
valve – Mounting parts and
accessories
WARNING!
Mount the positioner, keeping the following
sequence:
1. Remove protective film from pneumatic
connections.
2. Mount the positioner on the control
valve
3. Connect the supply air
4. Connect the electrical power
5. Perform the start-up settings
The positioner is suitable for the following
types of attachment:
4Direct attachment to SAMSON
Type 3277 Actuator
4Attachment to actuators according to
IEC 60534-6 (NAMUR)
4Attachment according to VDI/VDE 3847
4Attachment to Type 3510 Micro-flow
Valve
4Attachment to rotary actuators
NOTICE
Attach the positioner to the control valve,
observing the following instructions to avoid
damaging the positioner.
–Use only the mounting parts/accessories
listed in the Tables 1 to 7 (pages 42 to
46) to mount the positioner. Observe the
type of attachment.
–Observe the assignment between lever
and pin position (see travel tables on
page 15).
Lever and pin position
The positioner is adapted to the actuator
and to the rated travel by the lever on the
back of the positioner and the pin inserted
into the lever.
The travel tables on page 15 show the maxi-
mum adjustment range at the positioner. The
travel that can be implemented at the valve
is additionally restricted by the selected
fail-safe position and the required compres-
sion of the actuator springs.
The positioner is standard equipped with the
lever M(pin position 35).
Note: If the standard mounted lever M (pin
position 35) is replaced, the newly mounted
lever must be moved once all the way as far
as it will go in both directions to adapt it to
the internal measuring lever.
14 EB 8384-4 EN
Attachment to the control valve – Mounting parts and accessories
Fig. 3 · Lever M with pin position 35

EB 8384-4 EN 15
Attachment to the control valve – Mounting parts and accessories
Travel tables
Note: The lever Mis included in the scope of delivery.
Levers S,L,XL for attachment according to IEC 60534-6 (NAMUR) are available as acces-
sories (see Table 3 on page 44).
Direct attachment to Type 3277-5 and Type 3277 Actuators
Actuator size Rated travel Adjustment range at positioner 1) Required
lever
Assigned
pin position
[cm²] [mm] Min. Travel Max.
120 7.5 5.0 to 25.0 M 25
120/240/175/350 15 7.0 to 35.0 M 35
355/700/750 30 10.0 to 50.0 M 50
Attachment according to IEC 60534-6 (NAMUR)
SAMSON valves/Type 3271 Actuator Adjustment range at positioner 1)
Other valves/actuators Required
lever
Assigned
pin position
Actuator size Rated travel
[cm²] [mm] min. Travel max.
60 and 120 with
Type 3510 Valve 7.5 3.6 to 18.0 S 17
120 7.5 5.0 to 25.0 M 25
120/240/175/350 15 7.0 to 35.0 M 35
700/750 7.5
355/700/750 15 and 30 10.0 to 50.0 M 50
1000/1400/2800 30 14.0 to 70.0 L 70
1000/1400/2800 60 20.0 to 100.0 L 100
1400/2800 120 40.0 to 200.0 XL 200
Attachment to rotary actuators according to VDI/VDE 3845
Rotary actuators Required
lever
Assigned
pin position
Min. Opening angle Max.
24 to 100° M 90°
1) The min./max. adjustment range is based on the NOM (nominal range) initialization mode

4.1 Direct attachment
4.1.1 Type 3277-5 Actuator
Refer to Table 1 on page 42 for the required
mounting parts as well as the accessories.
Note the travel table on page 15.
Actuator with 120 cm²
Depending on the type of positioner attach-
ment, the signal pressure is routed either left
or right of the yoke through a bore to the
actuator diaphragm. Depending on the
fail-safe action of the actuator "Actuator
stem extends" or "Actuator stem retracts"
(valve closes or opens upon supply air
failure), the switchover plate (9) must first be
attached to the actuator yoke. Align the
switchover plate with the corresponding
symbol for left or right attachment according
to the marking (view looking onto the
switchover plate).
1. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
onto the positioner, making sure both
seal rings (6.1) are seated properly.
2. Remove screw plug (4) on the back of
the positioner and close the signal pres-
sure output "Output 38" on the connect-
ing plate (6) or on the pressure gauge
bracket (7) with the stopper (5) included
in the accessories.
3. Place follower clamp (3) on the actuator
stem, align and screw tight so that the
mounting screw is located in the groove
of the actuator stem.
4. Mount cover plate (10) with narrow side
of the cut-out opening (Fig. 4, left) point-
ing towards the signal pressure connec-
tion. Make sure that the bonded gasket
(14) points towards the actuator yoke.
5. 15 mm travel: Keep the follower pin (2)
at lever M(1) on the back of the
positioner in the pin position 35 (deliv-
ered state).
7.5 mm travel: Remove the follower pin
(2) from the pin position 35, reposition it
in the bore for pin position 25 and
screw tight.
6. Insert formed seal (15) into the groove of
the positioner housing and the seal ring
(10.1) on the back of the housing.
7. Place positioner on the cover plate (10)
in such a manner that the follower pin
(2) rests on the top of the follower clamp
(3). Adjust the lever (1) correspondingly
and open the positioner cover to hold
the positioner shaft in position at the cap
or the switch (Fig. 23).
The lever (1) must rest on the follower
clamp with spring force.
Mount the positioner on the cover plate
(10) using the two fixing screws.
Note for all types of attachment except for
direct attachment to Type 3277-5: The sig-
nal pressure output at the back must be
sealed using the screw plug (4, order no.
0180-1254) and the associated O-ring (or-
der no. 0520-0412).
8. Mount cover (11) on the other side.
Make sure that the vent plug points
downwards when the control valve is in-
stalled to allow any condensed water
that collects to drain off.
16 EB 8384-4 EN
Attachment to the control valve – Mounting parts and accessories

EB 8384-4 EN 17
Attachment to the control valve – Mounting parts and accessories
9 11
Supply 9 Output 38
5
6
4
7
6
10
10.1
3
2
1
15
6.1
1.1
1.2
14
8
Fig. 4 · Direct attachment - Signal pressure connection for Type 3277-5 Actuator with 120 cm²
Switchover plate (9) 1 Lever
1.1 Nut
1.2 Disk spring
2 Follower pin
3 Follower clamp
4 Screw plug
5 Stopper
6 Connecting plate
6.1 Seal rings
7 Pressure gauge bracket
8 Press. gauge mounting kit
9 Switchover plate
for actuator
10 Cover plate
10.1 Seal ring
11 Cover
14 Gasket
15 Formed seal
Symbols
Actuator stem
extends
Attachment left Attachment right
Actuator stem
retracts
Signal pressure
input for right
attachment
Signal pressure
input for left
attachment Marking
Note:
Always use the connecting plate (6)
included in the accessories to connect
supply and output.
Never screw threaded parts directly
into the housing.
Lever M
Cut-out of
cover plate (10)

4.1.2 Type 3277 Actuator
Refer to Table 2 on page 43 or the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 15.
Actuators with 175 to 750 cm²
Mount the positioner on the yoke as shown
in Fig. 5. The signal pressure is routed to the
actuator over the connection block (12), for
actuators with fail-safe action "Actuator
stem extends" internally through a bore in
the valve yoke and for "Actuator stem re-
tracts" through external piping.
1. Place follower clamp (3) on the actuator
stem, align and screw tight so that the
mounting screw is located in the groove
of the actuator stem.
2. Mount cover plate (10) with narrow side
of the cut-out opening (Fig. 5, on the left)
pointing towards the signal pressure
connection. Make sure that the bonded
gasket (14) points towards the actuator
yoke.
3. For actuators with 355, 700 and
750 cm², remove the follower pin (2) at
lever M(1) on the back of the positioner
from pin position 35, reposition it in the
bore for pin position 50 and screw tight.
For actuators 175 to 350 cm² with
15 mm travel, the follower pin (2) re-
mains in pin position 35.
4. Insert formed seal (15) in the groove of
the positioner casing.
5. Place positioner on the cover plate in
such a manner that the follower pin (2)
rests on the top of the follower clamp
(3). Adjust the lever (1) correspondingly
and open the positioner cover to hold
the positioner shaft in position at the cap
or the switch (Fig. 23). The lever (1) must
rest on the follower clamp with spring
force. Mount the positioner on the cover
plate (10) using the two fixing screws.
6. Make sure that the tip of the gasket (16)
projecting from the side of the connec-
tion block (12) is positioned above the
actuator symbol that corresponds with
the actuator with fail-safe action "Actua-
tor stem extends" or "Actuator stem re-
tracts." If necessary, remove the three
fixing screws and the cover. Then reposi-
tion the gasket (16) turned by 180°. The
previous version of the connection block
(Fig. 5, bottom) requires the switch plate
(13) to be turned such that the corre-
sponding actuator symbol points to the
marking.
7. Place the connection block (12) with the
associated seal rings against the
positioner and the actuator yoke. Screw
it tight using the fixing screw (12.1). For
actuators with fail-safe action "Actuator
stem retracts", additionally remove the
stopper (12.2) and fit on the external
signal pressure piping.
8. Mount cover (11) on the other side.
Make sure that the vent plug points
downwards when the control valve is in-
stalled to allow any condensed water
that collects to drain off.
18 EB 8384-4 EN
Attachment to the control valve – Mounting parts and accessories

2
10 1415
1 2 3 11 11.1
SUPPLY
13
B
C
1.1
1.2
12
12.1
12
12.2
12.11216
16 16
12.2
SUPPLY
Ansicht A
Ansicht B
Ansicht C
SUPPLYG
G 3/8
A
Fig. 5 · Direct attachment – Signal pressure connection for Type 3277 Actuator with 175 to 750 cm²
Actuator stem
retracts extends
View A
View C
View B
Actuator stem retracts
Actuator stem extends
Marking
Connection block (old)
with switch plate (13)
12 Connection block
12.1 Screw
12.2 Stopper or connection for
external piping
13 Switch plate
14 Gasket
15 Formed seal
16 Gasket
Lever M
Cut-out of
cover plate (10)
1 Lever
1.1 Nut
1.2 Disk spring
2 Follower pin
3 Follower clamp
10 Cover plate
11 Cover
11.1 Vent plug
EB 8384-4 EN 19
Attachment to the control valve – Mounting parts and accessories

4.2 Attachment according to
IEC 60534-6 (NAMUR)
Refer to Table 3 on page 44 for the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 15.
The positioner is attached to the control
valve with a NAMUR bracket (10).
1. Screw the two bolts (14) to the bracket
(9.1) of the stem connector (9), place the
follower plate (3) on top and use the
screws (14.1) to tighten.
Actuator size 2800 cm²and 1400 cm²
(120 mm travel):
– For a travel of 60 mm or smaller,
screw the longer follower plate (3.1)
directly to the stem connector (9).
– For a travel exceeding 60 mm,
mount the bracket (16) first and then
the follower plate (3) to the bracket
together with the bolts (14) and
screws (14.1).
2. Mount NAMUR bracket (10) to the con-
trol valve as follows:
–For attachment to the NAMUR rib,
use an M8 screw (11), washer, and
toothed lock washer directly in the
yoke bore.
–For attachment to valves with
rod-type yokes, use two U-bolts (15)
around the yoke. Align the NAMUR
bracket (10) in such a way that the
slot of the follower plate (3) is cen-
trally aligned with the NAMUR
bracket at mid valve travel.
3. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
(8) on the positioner, making sure both
seal rings (6.1) are seated properly.
4. Select required lever size (1) M,Lor XL
and pin position according to the actua-
tor size and valve travels listed in the ta-
ble on page 15.
Should you require a pin position other
than position 35 with the standard in-
stalled lever M, or require a lever size L
or XL, proceed as follows:
5. Screw the follower pin (2) in the as-
signed lever bore (pin position) as listed
in the table. Only use the longer follower
pin (2) included in the mounting kit.
6. Place lever (1) on the positioner shaft
and screw tight using the disk spring
(1.2) and nut (1.1).
Note: If you have mounted a new lever (1),
you must move it once all the way as far as
it will go in both directions.
7. Place positioner on the NAMUR bracket
in such a manner that the follower pin
(2) rests in the slot of the follower plate
(3, 3.1). Adjust the lever (1) correspond-
ingly.
Screw the positioner to the NAMUR
bracket using both its fixing screws.
20 EB 8384-4 EN
Attachment to the control valve – Mounting parts and accessories
