SC32442B54
USER’S MANUAL
Revision 1.0

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-1
1 PRODUCT OVERVIEW
INTRODUCTION
This user’s manual describes SAMSUNG's SC32442B 16/32-bit RISC microprocessor. SAMSUNG’s SC32442B
is designed to provide hand-held devices and general applications with low-power, and high-performance micro-
controller solution in small die size. To reduce total system cost, the SC32442B includes the following
components.
The SC32442B is developed with ARM920T core, 0.13um CMOS standard cells and a memory complier. Its low-
power, simple, elegant and fully static design is particularly suitable for cost- and power-sensitive applications. It
adopts a new bus architecture known as Advanced Micro controller Bus Architecture (AMBA).
The SC32442B offers outstanding features with its CPU core, a 16/32-bit ARM920T RISC processor designed by
Advanced RISC Machines, Ltd. The ARM920T implements MMU, AMBA BUS, and Harvard cache architecture
with separate 16KB instruction and 16KB data caches, each with an 8-word line length.
By providing a complete set of common system peripherals, the SC32442B minimizes overall system costs and
eliminates the need to configure additional components. The integrated on-chip functions that are described in
this document include:
•Around [email protected] arm and 1.2V internal, [email protected]V arm and 1.2V internal, 1.8Vmemory, 3.3V
external I/O microprocessor with 16KB I-Cache/16KB D-Cache/MMU
•External memory controller (SDRAM Control and Chip Select logic)
•LCD controller (up to 4K color STN and 256K color TFT) with LCD-dedicated DMA
•4-ch DMA controllers with external request pins
•3-ch UARTs (IrDA1.0, 64-Byte Tx FIFO, and 64-Byte Rx FIFO)
•2-ch SPls
•IIC bus interface (multi-master support)
•IIS Audio CODEC interface
•SD Host interface version 1.0 & MMC Protocol version 2.11 compatible
•2-ch USB Host controller / 1-ch USB Device controller (ver 1.1)
•4-ch PWM timers / 1-ch Internal timer / Watch Dog Timer
•8-ch 10-bit ADC and Touch screen interface
•RTC with calendar function
•Camera interface (Max. 4096 x 4096 pixels input support. 2048 x 2048 pixel input support for scaling)
•130 General Purpose I/O ports / 24-ch external interrupt source
•Power control: Normal, Slow, Idle, stop and Sleep mode
•On-chip clock generator with PLL

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-2
FEATURES
Architecture
•Integrated system for hand-held devices and
general embedded applications.
•16/32-Bit RISC architecture and powerful
instruction set with ARM920T CPU core.
•Enhanced ARM architecture MMU to support
WinCE, EPOC 32 and Linux.
•Instruction cache, data cache, write buffer and
Physical address TAG RAM to reduce the effect
of main memory bandwidth and latency on
performance.
•ARM920T CPU core supports the ARM debug
architecture.
•Internal Advanced Microcontroller Bus
Architecture (AMBA) (AMBA2.0, AHB/APB).
System Manager
•Little/Big Endian support.
•Support Fast bus mode and Asynchronous bus
mode.
•Address space: 128M bytes for each bank (total
1G bytes).
•Supports programmable 8/16/32-bit data bus
width for each bank.
•Fixed bank start address from bank 0 to bank 6.
•Programmable bank start address and bank size
for bank 7.
•Eight memory banks:
– Six memory banks for ROM, SRAM, – Two
memory banks for ROM/SRAM/
Synchronous DRAM.
•Complete Programmable access cycles for all
memory banks.
•Supports external wait signals to expand the bus
cycle.
•Supports self-refresh mode in SDRAM for power-
down.
•Supports various types of ROM for booting
(NOR/NAND Flash, EEPROM, and others).
NAND Flash Boot Loader
•Supports booting from NAND flash memory.
•4KB internal buffer for booting.
•Supports storage memory for NAND flash
memory after booting.
•Supports Advanced NAND flash
Cache Memory
•64-way set-associative cache with I-Cache
(16KB) and D-Cache (16KB).
•8words length per line with one valid bit and two
dirty bits per line.
•Pseudo random or round robin replacement
algorithm.
•Write-through or write-back cache operation to
update the main memory.
•The write buffer can hold 16 words of data and
four addresses.
Clock & Power Manager
•On-chip MPLL and UPLL:
UPLL generates the clock to operate USB
Host/Device.
MPLL generates the clock to operate MCU at
maximum [email protected] arm and 1.2V interna
[email protected] arm and 1.2V internal,
•Clock can be fed selectively to each function
block by software.
•Power mode: Normal, Slow, Idle, Deep-stop and
Sleep mode
Normal mode: Normal operating mode
Slow mode: Low frequency clock without PLL
Idle mode: The clock for only CPU is stopped.
Stop mode: All clocks are stopped.
Deep-Stop mode: Arm power off internal clocks
are stopped.
Sleep mode: The Core power including all
peripherals is shut down.
•Woken up by EINT[15:0] or RTC alarm interrupt
from Sleep mode
Stacked Memory
• 512Mbit mSDR x32, VDD=1.8V
• 2Gbit Nand Flash x8, VDD=1.8V

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-3
FEATURES (Continued)
Interrupt Controller
•59 Interrupt sources
(One Watch dog timer, 5 timers, 9 UARTs, 24
external interrupts, 4 DMA, 2 RTC, 2 ADC, 1 IIC,
2 SPI, 1 SDI, 2 USB, 1 LCD, 1 Battery Fault, 1
NAND and 2 Camera)
•Level/Edge mode on external interrupt source
•Programmable polarity of edge and level
•Supports Fast Interrupt request (FIQ) for very
urgent interrupt request
Timer with Pulse Width Modulation (PWM)
•4-ch 16-bit Timer with PWM / 1-ch 16-bit internal
timer with DMA-based or interrupt-based
operation
•Programmable duty cycle, frequency, and polarity
•Dead-zone generation
•Supports external clock sources
RTC (Real Time Clock)
•Full clock feature: msec, second, minute, hour,
date, day, month, and year
•32.768 KHz operation
•Alarm interrupt
•Time tick interrupt
• RTC Low Battery Check
General Purpose Input/Output Ports
•24 external interrupt ports
•130 Multiplexed input/output ports
DMA Controller
•4-ch DMA controller
•Supports memory to memory, IO to memory,
memory to IO, and IO to IO transfers
•Burst transfer mode to enhance the transfer rate
LCD Controller STN LCD Displays Feature
•Supports 3 types of STN LCD panels: 4-bit dual
scan, 4-bit single scan, 8-bit single scan display
type
•Supports monochrome mode, 4 gray levels, 16
gray levels, 256 colors and 4096 colors for STN
LCD
•Supports multiple screen size
– Typical actual screen size: 640x480, 320x240,
160x160, and others.
– Maximum frame buffer size is 4 Mbytes.
– Maximum virtual screen size in 256 color mode:
4096x1024, 2048x2048, 1024x4096 and others
TFT(Thin Film Transistor) Color Displays Feature
•Supports 1, 2, 4 or 8 bpp (bit-per-pixel) palette
color displays for color TFT
•Supports 16, 24 bpp non-palette true-color
displays for color TFT
•Supports maximum 16M color TFT at 24 bpp
mode
•LPC3600 Timing controller embedded for
LTS350Q1-PD1/2(SAMSUNG 3.5” Portrait /
256K-color/ Reflective a-Si TFT LCD)
•LCC3600 Timing controller embedded for
LTS350Q1-PE1/2(SAMSUNG 3.5” Portrait /
256K-color/ Transflective a-Si TFT LCD)
•Supports multiple screen size
– Typical actual screen size: 640x480, 320x240,
160x160, and others.
– Maximum frame buffer size is 4Mbytes.
– Maximum virtual screen size in 64K color mode :
2048x1024, and others
UART
•3-channel UART with DMA-based or interrupt-
based operation
•Supports 5-bit, 6-bit, 7-bit, or 8-bit serial data
transmit/receive (Tx/Rx)
•Supports external clocks for the UART operation
(UEXTCLK)
•Programmable baud rate
•Supports IrDA 1.0
•Loopback mode for testing
•Each channel has internal 64-byte Tx FIFO and
64-byte Rx FIFO.

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-4
FEATURES (Continued)
A/D Converter & Touch Screen Interface
•8-ch multiplexed ADC
•Max. 500KSPS and 10-bit Resolution
•Internal FET for direct Touch screen interface
Watchdog Timer
•16-bit Watchdog Timer
•Interrupt request or system reset at time-out
IIC-Bus Interface
•1-ch Multi-Master IIC-Bus
•Serial, 8-bit oriented and bi-directional data
transfers can be made at up to 100 Kbit/s in
Standard mode or up to 400 Kbit/s in Fast mode.
IIS-Bus Interface
•1-ch IIS-bus for audio interface with DMA-based
operation
•Serial, 8-/16-bit per channel data transfers
•128 Bytes (64-Byte + 64-Byte) FIFO for Tx/Rx
•Supports IIS format and MSB-justified data
format
USB Host
•2-port USB Host
•Complies with OHCI Rev. 1.0
•Compatible with USB Specification version 1.1
USB Device
•1-port USB Device
•5 Endpoints for USB Device
•Compatible with USB Specification version 1.1
SD Host Interface
•Normal, Interrupt and DMA data transfer
mode(byte, halfword, word transfer)
•DMA burst4 access support(only word transfer)
•Compatible with SD Memory Card Protocol
version 1.0
•Compatible with SDIO Card Protocol version 1.0
•64 Bytes FIFO for Tx/Rx
•Compatible with Multimedia Card Protocol
version 2.11
SPI Interface
•Compatible with 2-ch Serial Peripheral Interface
Protocol version 2.11
•2x8 bits Shift register for Tx/Rx
•DMA-based or interrupt-based operation
Camera Interface
•ITU-R BT 601/656 8-bit mode support
•DZI (Digital Zoom In) capability
•Programmable polarity of video sync signals
•Max. 4096 x 4096 pixels input support ( 2048 x
2048 pixel input support for scaling)
•Image mirror and rotation (X-axis mirror, Y-axis
mirror, and 180° rotation)
•Camera output format (RGB 16/24-bit and YCbCr
4:2:0/4:2:2 format)
Operating Voltage Range
•Core : 1.7V for 533MHz, 1.4V for 400MHz
•Internal : 1.2V for 400MHz and 1.2V for 300MHz
•Memory:1.8V for 100MHz or 133MHz
•I/O : 3.3V / 2.5V
Operating Frequency
•Fclk Up to 500MHz, 400MHz
•Hclk Up to 133MHz
•Pclk Up to 66MHz or 50MHz
Package
•332-FBGA

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-5
BLOCK DIAGRAM
ARM920T
ARM9TDMI
Processor core
(Internal Embedded ICE)
DD[31:0]
WriteBack
PA Tag
RAM
Data
MMU
C13
DVA[31:0]DVA[31:0]
Instruction
CACHE
(16KB)
Instruction
MMU External
Coproc
Interface
C13
ID[31:0]
IPA[31:0]
IVA[31:0]
CP15
Write
Buffer
AMBA
Bus
I/F
JTAG
Data
CACHE
(16KB)
WBPA[31:0]
DPA[31:0]
Bridge & DMA (4Ch)
Clock Generator
(MPLL)
A
H
B
B
U
S
Memory CONT.
SRAM/NOR/SDRAM
BUS CONT.
Arbitor/Decode
Power
Management
Interrupt CONT.
USB Host CONT.
ExtMaster
LCD
DMA
LCD
CONT.
A
P
B
B
U
S
I2C
GPIO
I2S
RTC
SPI
ADC
SDI/MMC
USB Device
Watchdog
Timer
BUS CONT.
Arbitor/Decode Timer/PWM
0 ~ 3, 4(Internal)
SPI 0, 1
UART 0, 1, 2
NAND Ctrl.
NAND Flash Boot
Loader
Camera
Interface
Stacked
Nand Flash Stacked
mSDR
Figure 1-1. SC32442B Block Diagram

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-6
PIN ASSIGNMENTS
TOP VIEW
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
T
U
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
V
W
Y
AA
AB
AC
AD
AE
AF
18 19 20 21 22 23 24 25 26
14mm(H)x14mm(V)x1.6mm(T)
Figure 1-2. SC32442B Pin Assignments (332-FBGA)

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-7
Table 1-1. 332-Pin FBGA Pin Assignments – Pin Number Order (Sheet 1 of 4)
Pin
Number Pin Name Pin
Number Pin Name Pin
Number Pin Name
A2 ADDR10 B11 ADDR1 E13 VDDI
A3 ADDR13 B12 ADDR12 E14 VSSCOM
A4 NGCS5/GPA16
B13 ADDR15 E15 ADDR16/GPA1
A5 NBE1 B14 ADDR23/GPA8 E16 VDDI
A6 NSRAS B15 ADDR18/GPA3 E17 VDDMOP
A7 NSCAS B16 ADDR21/GPA6 E18 ADDR25/GPA10
A8 ADDR2 B17 ADDR26/GPA11 E19 VSSMOP
A9 ADDR7 B18 DATA3 E20 TCK
A10 ADDR9 B19 DATA1 E21 TMS
A11 VSSMOP B20 DATA8 E22 XTOPLL
A12 ADDR11 B21 VDDI E25 DATA21
A13 ADDR14 B22 VSSOP1 E26 DATA18
A14 ADDR24/GPA9 B23 DATA11 F1 NBE0
A15 DATA2 B24 VDDMOP F2 NGCS7
A16 DATA4 B25 DATA14 F5 VDDI
A17 DATA0 B26 DATA13 F6 NGCS0
A18 DATA5 C1 ADDR5 F7 VDDIARM
A19 DATA6 C2 NWAIT F8 VDDIARM
A20 VDDMOP C25 DATA19 F9 CAMVSYNC/GPJ9
A21 DATA7 C26 DATA15 F10 VSSMOP
A22 DATA9 D1 ADDR3 F11 CAMCLKOUT/GPJ11
A23 DATA10 D2 NGCS4/GPA15 F12 ADDR20/GPA5
A24 DATA16 D25 VSSMOP F13 ADDR19/GPA4
A25 DATA12 D26 DATA17 F14 ADDR17/GPA2
B1 ADDR6 E1 NBE2 F15 ADDR22/GPA7
B2 ADDR8 E2 VSSMOP F16 CAMDATA0/GPJ0
B3 SCKE E5 VSSMOP F17 TXD1/GPH4
B4 NGCS6 E6 NGCS3/GPA14 F18 CAMRESET/GPJ12
B5 NGCS2/GPA13
E7 NGCS1/GPA12 F19 TOUT1/GPB1
B6 NBE3 E8 VDDMOP F20 PWREN
B7 VDDI E9 VDDI F21 VDDALIVE
B8 VSSCOM E10 SCLK1 F22 TDI
B9 ADDR4 E11 ADDR0/GPA0 F25 VDDI
B10 NOE E12 VDDMOP F26 DATA20

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-8
Table 1-1. 332-Pin FBGA Pin Assignments – Pin Number Order (Sheet 2 of 4)
Pin
Number Pin Name Pin
Number Pin Name Pin
Number Pin Name
G1 SCLK0 L5 TOUT0/GPB0 P14 VSSCOM
G2 VDDMOP L6 CAMDATA6/GPJ6 P15 VSSCOM
G5 NFCE/GPA22 L21 TXD2/NRTS1/GPH6 P21 VDDOP1
G6 CAMDATA5/GPJ5
L22 TXD0/GPH2 P22 VSSA_UPLL
G21 VSSMOP L25 XTIPLL P25 RXD1/GPH5
G22 EXTCLK L26 DATA25 P26 DATA30
G25 VSSMOP M1 /CE R1 VSSCOM
G26 DATA22 M2 CAMDATA4/GPJ4 R2 NXDACK0/GPB9
H1 ALE/GPA18 M5 VSSCOM R5 LEND/GPC0
H2 CLE/GPA17 M6 NXBACK/GPB5 R6 LCDVF1/GPC6
H5 CAMHREF/GPJ10
M13 VSSCOM R13 VSSCOM
H6 VSSOP2 M14 VSSCOM R14 VSSCOM
H21 VDDMOP M21 RXD2/NCTS1/GPH7 R21 SDDAT1/GPE8
H22 NRESET M22 TDO R22 EINT4/GPF4
H25 VSSCOM M25 BATT_FLT R25 RXD0/GPH3
H26 DATA26 M26 DATA29 R26 NRTS0/GPH1
J1 NFWE/GPA19
N1 NWE T1 VSS_NF
J2 VSSCOM N2 TOUT3/GPB3 T2 VM/GPC4
J5 CAMPCLK/GPJ8
N5 VDDOP2 T5 VDDIARM
J6 CAMDATA3/GPJ3
N6 NXDACK1/GPB7 T6 NXDREQ0/GPB10
J21 NCTS0/GPH0 N12 VSSCOM T21 VDDA_UPLL
J22 TOUT2/GPB2 N13 VSSCOM T22 EINT0/GPF0
J25 DATA24 N14 VSSCOM T25 EINT7/GPF7
J26 DATA23 N15 VSSCOM T26 EINT3/GPF3
K1 NFRE/GPA20 N21 EINT2/GPF2 U1 /WP
K2 CAMDATA1/GPJ1
N22 UCLK/GPH8 U2 /CS
K5 VDDALIVE N25 NTRST U5 VDDIARM
K6 CAMDATA2/GPJ2
N26 DATA28 U6 VFRAME/GPC3
K21 EINT6/GPF6 P1 VCC_NF U21 IICSDA/GPE15
K22 VSSCOM P2 TCLK0/GPB4 U22 VSSOP
K25 DATA31 P5 NXBREQ/GPB6 U25 EINT5/GPF5
K26 DATA27 P6 NXDREQ1/GPB8 U26 EINT1/GPF1
L1 FRNB P12 VSSCOM V1 LCDVF0/GPC5
L2 CAMDATA7/GPJ7
P13 VSSCOM V2 VD2/GPC10

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-9
Table 1-1. 332-Pin FBGA Pin Assignments – Pin Number Order (Sheet 3 of 4)
Pin
Number Pin Name Pin
Number Pin Name Pin
Number Pin Name
V5 VLINE/GPC2 AA15 SPIMISO0/GPE11 AC25 AIN3
V6 VD4/GPC12 AA16 SPICLK0/GPE13 AC26 VCC_NF
V21 EINT15/SPICLK1/GPG7
AA17 DN1/PDN0 AD1 VSS_SDRAM
V22 AIN6 AA18 EINT13/SPIMISO1/GPG5 AD2 VDDIARM
V25 MPLLCAP AA19 EINT18/GPG10/NCTS1 AD25 AIN2
V26 XTIRTC AA20 VDDI AD26 VSS_SDRAM
W1 VSSOP3 AA21 VSSOP AE1 VD13/GPD5
W2 VSSCOM AA22 OM2 AE2 VSS_SDRAM
W5 VD10/GPD2 AA25 AIN5 AE3 VD18/GPD10/SPICLK1
W6 VD6/GPC14 AA26 VSS_NF AE4 VD17/GPD9/SPIMOSI1
W21 EINT20/nSPICS0/GPG12
AB1 VD12/GPD4 AE5 I2SLRCK/GPE0
W22 XTORTC AB2 VSSCOM AE6 VD15/GPD7/NSS0
W25 UPLLCAP AB5 VD9/GPD1/SPCLK1 AE7 VD22/NSS1/GPD14
W26 VCC_NF AB6 VD14/GPD6/NSS1 AE8 VD19/GPD11
Y1 VD5/GPC13 AB7 VD16/GPD8/SPIMOSI1 AE9 VD23/NSS0/GPD15
Y2 VD7/GPC15 AB8 VDDIARM AE10 SDDAT0/GPE7
Y5 VD3/GPC11 AB9 VDDIARM AE11 I2SSDO/GPE4
Y6 VCLK/GPC1 AB10 SDCLK/GPE5 AE12 SDDAT2/GPE9
Y21 NCON0 AB11 SDDAT3/GPE10 AE13 VDDIARM
Y22 VDDA_ADC AB12 IICSCL/GPE14 AE14 CLKOUT1/GPH10
Y25 VDDA_MPLL AB13 SPIMOSI0/GPE12 AE15 EINT9/GPG1
Y26 VDD_RTC AB14 EINT12/LCD_PWREN/GPG4 AE16 EINT14/SPIMOSI1/GPG6
AA1 VD11/GPD3 AB15 EINT10/NSS0/GPG2 AE17 DP1/PDP0
AA2 VD8/GPD0/nSPICS1
AB16 VDDOP AE18 NRSTOUT/GPA21
AA5 VDDIARM_1 AB17 DP0 AE19 OM3
AA6 VD0/GPC8 AB18 DN0 AE20 AIN0
AA7 VSSOP3 AB19 EINT22/YMON/GPG14 AE21 VREF
AA8 LCDVF2/GPC7 AB20 EINT16/GPG8 AE22 AIN1
AA9 VD1/GPC9 AB21 EINT17/GPG9/NRTS1 AE23 OM0
AA10 I2SSCLK/GPE1 AB22 OM1 AE24 EINT21/NXPON/GPG13
AA11 I2SSDI/GPE3
AB25 AIN7 AE25 VDD_SDRAM
AA12 SDCMD/GPE6 AB26 VSSA_MPLL AE26 AIN4
AA13 CLKOUT0/nSPICS0/GPH9
AC1 VDDOP3 AF2 VDD_SDRAM
AA14 EINT8/GPG0 AC2 VDD_SDRAM AF3 VDDQ_SDRAM

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-10
Table 1-1. 332-Pin FBGA Pin Assignments – Pin Number Order (Sheet 4 of 4)
Pin
Number Pin Name Pin
Number Pin Name
AF4 VD20/GPD12 A1 NC
AF5 VD21/GPD13 A26 NC
AF6 VSSQ_SDRAM AF1 NC
AF7 VDDQ_SDRAM AF26 NC
AF8 CDCLK/GPE2
AF9 VSSQ_SDRAM
AF10 VDDQ_SDRAM
AF11 VSS_SDRAM
AF12 VSSQ_SDRAM
AF13 VDD_SDRAM
AF14 EINT11/NSS1/GPG3
AF15 VDDQ_SDRAM
AF16 EINT19/TCLK1/GPG11
AF17 VSSQ_SDRAM
AF18 EINT23/NYPON/GPG15
AF19 VDDQ_SDRAM
AF20 VSSA_ADC
AF21 VSSQ_SDRAM
AF22 VSSQ_SDRAM
AF23 VDDQ_SDRAM
AF24 VDD_SDRAM
AF25 VSS_SDRAM

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-11
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 1 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
E11 ADDR0/GPA0 ADDR0 Hi-z/– O(L)/– O(L) t12s
B11 ADDR1 ADDR1 Hi-z O(L) O(L) t12s
A8 ADDR2 ADDR2 Hi-z O(L) O(L) t12s
D1 ADDR3 ADDR3 Hi-z O(L) O(L) t12s
B9 ADDR4 ADDR4 Hi-z O(L) O(L) t12s
C1 ADDR5 ADDR5 Hi-z O(L) O(L) t12s
B1 ADDR6 ADDR6 Hi-z O(L) O(L) t12s
A9 ADDR7 ADDR7 Hi-z O(L) O(L) t12s
B2 ADDR8 ADDR8 Hi-z O(L) O(L) t12s
A10 ADDR9 ADDR9 Hi-z O(L) O(L) t12s
A2 ADDR10 ADDR10 Hi-z O(L) O(L) t12s
A12 ADDR11 ADDR11 Hi-z O(L) O(L) t12s
B12 ADDR12 ADDR12 Hi-z O(L) O(L) t12s
A3 ADDR13 ADDR13 Hi-z O(L) O(L) t12s
A13 ADDR14 ADDR14 Hi-z O(L) O(L) t12s
B13 ADDR15 ADDR15 Hi-z O(L) O(L) t12s
E15 ADDR16/GPA1 ADDR16 Hi-z/– O(L)/– O(L) t12s
F14 ADDR17/GPA2 ADDR17 Hi-z/– O(L)/– O(L) t12s
B15 ADDR18/GPA3 ADDR18 Hi-z/– O(L)/– O(L) t12s
F13 ADDR19/GPA4 ADDR19 Hi-z/– O(L)/– O(L) t12s
F12 ADDR20/GPA5 ADDR20 Hi-z/– O(L)/– O(L) t12s
B16 ADDR21/GPA6 ADDR21 Hi-z/– O(L)/– O(L) t12s
F15 ADDR22/GPA7 ADDR22 Hi-z/– O(L)/– O(L) t12s
B14 ADDR23/GPA8 ADDR23 Hi-z/– O(L)/– O(L) t12s
A14 ADDR24/GPA9 ADDR24 Hi-z/– O(L)/– O(L) t12s
E18 ADDR25/GPA10 ADDR25 Hi-z/– O(L)/– O(L) t12s
B17 ADDR26/GPA11 ADDR26 Hi-z/– O(L)/– O(L) t12s
AE20 AIN0 AIN0 – – AI r10
AE22 AIN1 AIN1 – – AI r10
AD25 AIN2 AIN2 – – AI r10
AC25 AIN3 AIN3 – – AI r10
AE26 YM/AIN4 AIN4 –/– –/– AI r10
AA25 YP/AIN5 YP –/– –/– AI r10
V22 XM/AIN6 AIN6 –/– –/– AI r10

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-12
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 2 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
AB25 XP/AIN7 XP –/– –/– AI r10
F16 CAMDATA0/GPJ0 GPJ0 –/– Hi-z/– I t8
K2 CAMDATA1/GPJ1 GPJ1 –/– Hi-z/– I t8
K6 CAMDATA2/GPJ2 GPJ2 –/– Hi-z/– I t8
J6 CAMDATA3/GPJ3 GPJ3 –/– Hi-z/– I t8
M2 CAMDATA4/GPJ4 GPJ4 –/– Hi-z/– I t8
G6 CAMDATA5/GPJ5 GPJ5 –/– Hi-z/– I t8
L6 CAMDATA6/GPJ6 GPJ6 –/– Hi-z/– I t8
L2 CAMDATA7/GPJ7 GPJ7 –/– Hi-z/– I t8
J5 CAMPCLK/GPJ8 GPJ8 –/– Hi-z/– I t8
F9 CAMVSYNC/GPJ9 GPJ9 –/– Hi-z/– I t8
H5 CAMHREF/GPJ10 GPJ10 –/– Hi-z/– I t8
F11 CAMCLKOUT/GPJ11 GPJ11 –/– O(L)/– I t8
F18 CAMRESET/GPJ12 GPJ12 –/– O(L)/– I t8
A17 DATA0 DATA0 Hi-z Hi-z,O(L) I b12s
B19 DATA1 DATA1 Hi-z Hi-z,O(L) I b12s
A15 DATA2 DATA2 Hi-z Hi-z,O(L) I b12s
B18 DATA3 DATA3 Hi-z Hi-z,O(L) I b12s
A16 DATA4 DATA4 Hi-z Hi-z,O(L) I b12s
A18 DATA5 DATA5 Hi-z Hi-z,O(L) I b12s
A19 DATA6 DATA6 Hi-z Hi-z,O(L) I b12s
A21 DATA7 DATA7 Hi-z Hi-z,O(L) I b12s
B20 DATA8 DATA8 Hi-z Hi-z,O(L) I b12s
A22 DATA9 DATA9 Hi-z Hi-z,O(L) I b12s
A23 DATA10 DATA10 Hi-z Hi-z,O(L) I b12s
B23 DATA11 DATA11 Hi-z Hi-z,O(L) I b12s
A25 DATA12 DATA12 Hi-z Hi-z,O(L) I b12s
B26 DATA13 DATA13 Hi-z Hi-z,O(L) I b12s
B25 DATA14 DATA14 Hi-z Hi-z,O(L) I b12s
C26 DATA15 DATA15 Hi-z Hi-z,O(L) I b12s
A24 DATA16 DATA16 Hi-z Hi-z,O(L) I b12s
D26 DATA17 DATA17 Hi-z Hi-z,O(L) I b12s
E26 DATA18 DATA18 Hi-z Hi-z,O(L) I b12s

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-13
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 3 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
C25 DATA19 DATA19 Hi-z Hi-z,O(L) I b12s
F26 DATA20 DATA20 Hi-z Hi-z,O(L) I b12s
E25 DATA21 DATA21 Hi-z Hi-z,O(L) I b12s
G26 DATA22 DATA22 Hi-z Hi-z,O(L) I b12s
J26 DATA23 DATA23 Hi-z Hi-z,O(L) I b12s
J25 DATA24 DATA24 Hi-z Hi-z,O(L) I b12s
L26 DATA25 DATA25 Hi-z Hi-z,O(L) I b12s
H26 DATA26 DATA26 Hi-z Hi-z,O(L) I b12s
K26 DATA27 DATA27 Hi-z Hi-z,O(L) I b12s
N26 DATA28 DATA28 Hi-z Hi-z,O(L) I b12s
M26 DATA29 DATA29 Hi-z Hi-z,O(L) I b12s
P26 DATA30 DATA30 Hi-z Hi-z,O(L) I b12s
K25 DATA31 DATA31 Hi-z Hi-z,O(L) I b12s
AB18 DN0 DN0 – – AI us
AB17 DP0 DP0 – – AI us
AA17 DN1/PDN0 DN1 –/– – AI us
AE17 DP1/PDP0 DP1 –/– – AI us
T22 EINT0/GPF0 GPF0 –/– Hi-z/– I t8
U26 EINT1/GPF1 GPF1 –/– Hi-z/– I t8
N21 EINT2/GPF2 GPF2 –/– Hi-z/– I t8
T26 EINT3/GPF3 GPF3 –/– Hi-z/– I t8
R22 EINT4/GPF4 GPF4 –/– Hi-z/– I t8
U25 EINT5/GPF5 GPF5 –/– Hi-z/– I t8
K21 EINT6/GPF6 GPF6 –/– Hi-z/– I t8
T25 EINT7/GPF7 GPF7 –/– Hi-z/– I t8
AA14 EINT8/GPG0 GPG0 –/– Hi-z/– I t8
AE15 EINT9/GPG1 GPG1 –/– Hi-z/– I t8
AB15 EINT10/nSS0/GPG2 GPG2 –/–/– Hi-z/Hi-z/– I t8
AF14 EINT11/nSS1/GPG3 GPG3 –/–/– Hi-z/Hi-z/– I t8
AB14 EINT12/LCD_PWREN/GPG4 GPG4 –/–/– Hi-z/O(L)/– I t8
AA18 EINT13/SPIMISO1/GPG5 GPG5 –/–/– Hi-z/Hi-z/– I t8
AE16 EINT14/SPIMOSI1/GPG6 GPG6 –/–/– Hi-z/Hi-z/– I t8
V21 EINT15/SPICLK1/GPG7 GPG7 –/–/– Hi-z/Hi-z/– I t8

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-14
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 4 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
AB20 EINT16/GPG8 GPG8 –/– Hi-z/– I t8
AB21 EINT17/nRTS1/GPG9 GPG9 –/–/– Hi-z/O(H)/– I t8
AA19 EINT18/nCTS1/GPG10 GPG10 –/–/– Hi-z/Hi-z/– I t8
AF16 EINT19/TCLK1/GPG11 GPG11 –/–/– Hi-z/Hi-z/– I t12
W21 EINT20/nSPICS0/GPG12 GPG12 –/– Hi-z/– I t12
AE24 EINT21/GPG13 GPG13 –/– Hi-z/– I t12
AB19 EINT22/GPG14 GPG14 –/– Hi-z/– I t12
AF18 EINT23/GPG15 GPG15 –/– Hi-z/– I t12
G22 EXTCLK EXTCLK – – AI is
W25 UPLLCAP UPLLCAP – – AI r50
V25 MPLLCAP MPLLCAP – – AI r50
M25 nBATT_FLT nBATT_FLT – – I is
F1 nBE0 nBE0 Hi-z Hi-z,O(H) O(H) t12s
A5 nBE1 nBE1 Hi-z Hi-z,O(H) O(H) t12s
E1 nBE2 nBE2 Hi-z Hi-z,O(H) O(H) t12s
B6 nBE3 nBE3 Hi-z Hi-z,O(H) O(H) t12s
Y21 NCON NCON – – I is
L1 FRnB FRnB – Hi-z,O(L) I d2s
J1 nFWE/GPA19 nFWE O(H)/– Hi-z,O(H)/– O(H) t12s
K1 nFRE/GPA20 nFRE O(H)/– Hi-z,O(H)/– O(H) t12s
G5 nFCE/GPA22 nFCE O(H)/– Hi-z,O(H)/– O(H) t12s
H2 CLE/GPA17 CLE O(L)/– Hi-z,O(L)/– O(L) t12s
H1 ALE/GPA18 ALE O(L)/– Hi-z,O(L)/– O(L) t12s
AE18 nRSTOUT/GPA21 nRSTOUT –/– O(L)/– O(L) b8
B10 nOE nOE Hi-z Hi-z,O(H) O(H) t12s
H22 nRESET nRESET – – I is
F6 nGCS0 nGCS0 Hi-z Hi-z,O(H) O(H) t12s
E7 nGCS1/GPA12 nGCS1 Hi-z/– Hi-z,O(H)/– O(H) t12s
B5 nGCS2/GPA13 nGCS2 Hi-z/– Hi-z,O(H)/– O(H) t12s
E6 nGCS3/GPA14 nGCS3 Hi-z/– Hi-z,O(H)/– O(H) t12s
D2 nGCS4/GPA15 nGCS4 Hi-z/– Hi-z,O(H)/– O(H) t12s
A4 nGCS5/GPA16 nGCS5 Hi-z/– Hi-z,O(H)/– O(H) t12s
B4 nGCS6 nGCS6 Hi-z Hi-z,O(H) O(H) t12s

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-15
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 5 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
F2 nGCS7 nGCS7 Hi-z Hi-z,O(H) O(H)
t12s
A7 nSCAS nSCAS Hi-z Hi-z,O(H) O(H) t12s
A6 nSRAS nSRAS Hi-z Hi-z,O(H) O(H) t12s
N25 nTRST nTRST I – I is
C2 nWAIT nWAIT – Hi-z,O(L) I d2s
N1 nWE nWE Hi-z Hi-z,O(H) O(H) t12s
L5 TOUT0/GPB0 GPB0 –/– O(L)/– I t8
F19 TOUT1/GPB1 GPB1 –/– O(L)/– I t8
J22 TOUT2/GPB2 GPB2 –/– O(L)/– I t8
N2 TOUT3/GPB3 GPB3 –/– O(L)/– I t8
P2 TCLK0/GPB4 GPB4 –/– –/– I t8
M6 nXBACK/GPB5 GPB5 –/– O(H)/– I t8
P5 nXBREQ/GPB6 GPB6 –/– –/– I t8
N6 nXDACK1/GPB7 GPB7 –/– O(H)/– I t8
P6 nXDREQ1/GPB8 GPB8 –/– –/– I t8
R2 nXDACK0/GPB9 GPB9 –/– O(H)/– I t8
T6 nXDREQ0/GPB10 GPB10 –/– –/– I t8
AE23 OM0 OM0 – – I is
AB22 OM1 OM1 – – I is
AA22 OM2 OM2 – – I is
AE19 OM3 OM3 – – I is
F20 PWREN PWREN O(H) O(L) O(H) b8
J21 nCTS0/GPH0 GPH0 –/– –/– I t8
R26 nRTS0/GPH1 GPH1 –/– O(H)/– I t8
L22 TXD0/GPH2 GPH2 –/– O(H)/– I t8
R25 RXD0/GPH3 GPH3 –/– –/– I t8
F17 TXD1/GPH4 GPH4 –/– O(H)/– I t8
P25 RXD1/GPH5 GPH5 –/– –/– I t8
L21 TXD2/nRTS1/GPH6 GPH6 –/–/– O(H)/O(H)/– I t8
M21 RXD2/nCTS1/GPH7 GPH7 –/–/– Hi-z/Hi-z/– I t8
N22 UEXTCLK/GPH8 GPH8 –/– Hi-z/– I t8
AA13 CLKOUT0/nSPICS0/GPH9 GPH9 –/– O(L)/– I t12
AE14 CLKOUT1/GPH10 GPH10 –/– O(L)/– I t12

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-16
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 6 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
B3 SCKE SCKE Hi-z O(L) O(H) t12s
G1 SCLK0 SCLK0 Hi-z O(L) O(SCLK) t12s
E10 SCLK1 SCLK1 Hi-z O(L) O(SCLK) t12s
AE5 I2SLRCK GPE0 –/– Hi-z/– I t8
AA10 I2SSCLK GPE1 –/– Hi-z/– I t8
AF8 CDCLK GPE2 –/– Hi-z/– I t8
AA11 I2SSDI GPE3 –/–/– Hi-z/Hi-z/– I t8
AE11 I2SSDO GPE4 –/–/– O(L)/Hi-z/– I t8
AB10 SDCLK/GPE5 GPE5 –/– O(L)/– I t8
AA12 SDCMD/GPE6 GPE6 –/– Hi-z/– I t8
AE10 SDDAT0/GPE7 GPE7 –/– Hi-z/– I t8
R21 SDDAT1/GPE8 GPE8 –/– Hi-z/– I t8
AE12 SDDAT2/GPE9 GPE9 –/– Hi-z/– I t8
AB11 SDDAT3/GPE10 GPE10 –/– Hi-z/– I t8
AA15 SPIMISO0/GPE11 GPE11 –/– Hi-z/– I t8
AB13 SPIMOSI0/GPE12 GPE12 –/– Hi-z/– I t8
AA16 SPICLK0/GPE13 GPE13 –/– Hi-z/– I t8
AB12 IICSCL/GPE14 GPE14 –/– Hi-z/– I d8
U21 IICSDA/GPE15 GPE15 –/– Hi-z/– I d8
E20 TCK TCK I – I is
F22 TDI TDI I – I is
M22 TDO TDO O O O ot
E21 TMS TMS I – I is
R5 LEND/GPC0 GPC0 –/– O(L)/– I t8
Y6 VCLK/GPC1 GPC1 –/– O(L)/– I t8
V5 VLINE/GPC2 GPC2 –/– O(L)/– I t8
U6 VFRAME/GPC3 GPC3 –/– O(L)/– I t8
T2 VM/GPC4 GPC4 –/– O(L)/– I t8
V1 LCD_LPCOE/GPC5 GPC5 –/– O(L)/– I t8
R6 LCD_LPCREV/GPC6 GPC6 –/– O(L)/– I t8
AA8 LCD_LPCREVB/GPC7 GPC7 –/– O(L)/– I t8
AA6 VD0/GPC8 GPC8 –/– O(L)/– I t8
AA9 VD1/GPC9 GPC9 –/– O(L)/– I t8

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-17
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 7 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
V2 VD2/GPC10 GPC10 –/– O(L)/– I t8
Y5 VD3/GPC11 GPC11 –/– O(L)/– I t8
V6 VD4/GPC12 GPC12 –/– O(L)/– I t8
Y1 VD5/GPC13 GPC13 –/– O(L)/– I t8
W6 VD6/GPC14 GPC14 –/– O(L)/– I t8
Y2 VD7/GPC15 GPC15 –/– O(L)/– I t8
AA2 VD8/GPD0/nSPICS1 GPD0 –/– O(L)/– I t8
AB5 VD9/GPD1/SPICLK1 GPD1 –/– O(L)/– I t8
W5 VD10/GPD2 GPD2 –/– O(L)/– I t8
AA1 VD11/GPD3 GPD3 –/– O(L)/– I t8
AB1 VD12/GPD4 GPD4 –/– O(L)/– I t8
AE1 VD13/ GPD5 GPD5 –/–/– O(L)/O/– I t8
AB6 VD14/GPD6 GPD6 –/–/– O(L)/O/– I t8
AE6 VD15/GPD7 GPD7 –/–/– O(L)/O/– I t8
AB7 VD16/SPIMISO1/GPD8 GPD8 –/–/– O(L)/Hi-z/– I t8
AE4 VD17/SPIMOSI1/GPD9 GPD9 –/–/– O(L)/Hi-z/– I t8
AE3 VD18/SPICLK1/GPD10 GPD10 –/–/– O(L)/Hi-z/– I t8
AE8 VD19//GPD11 GPD11 –/–/– O(L)/Hi-z/– I t8
AF4 VD20/ GPD12 GPD12 –/–/– O(L)/Hi-z/– I t8
AF5 VD21/ GPD13 GPD13 –/–/– O(L)/Hi-z/– I t8
AE7 VD22/nSS1/GPD14 GPD14 –/–/– O(L)/Hi-z/– I t8
AE9 VD23/nSS0/GPD15 GPD15 –/–/– O(L)/Hi-z/– I t8
AE21 Vref Vref – – AI ia
L25 XTIpll XTIpll – – AI m26
V26 Xtirtc Xtirtc – – AI nc
E22 XTOpll XTOpll – – AO m26
W22 Xtortc Xtortc – – AO nc
Y26 VDD_RTC VDD_RTC P P P drtc
Y22 VDDA_ADC VDDA_ADC P P P d33th
Y25 VDDA_MPLL VDDA_MPLL P P P d12t
T21 VDDA_UPLL VDDA_UPLL P P P d12t
K5 VDDalive VDDalive P P P d12i
F21 VDDalive VDDalive P P P d12i

PRODUCT OVERVIEW SC32442B RISC MICROPROCESSOR
1-18
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 8 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
AA20 VDDi VDDi P P P d12c
F5 VDDi VDDi P P P d12c
F25 VDDi VDDi P P P d12c
B21 VDDi VDDi P P P d12c
E16 VDDi VDDi P P P d12c
E13 VDDi VDDi P P P d12c
E9 VDDi VDDi P P P d12c
B7 VDDi VDDi P P P d12c
F7 VDDiarm VDDiarm P P P d12c
F8 VDDiarm VDDiarm P P P d12c
T5 VDDiarm VDDiarm P P P d12c
U5 VDDiarm VDDiarm P P P d12c
AD2 VDDiarm VDDiarm P P P d12c
AB8 VDDiarm VDDiarm P P P d12c
AB9 VDDiarm VDDiarm P P P d12c
AE13 VDDiarm VDDiarm P P P d12c
AA5 VDDiarm VDDiarm P P P d12c
G2 VDDMOP VDDMOP P P P d18o
H21 VDDMOP VDDMOP P P P d18o
B24 VDDMOP VDDMOP P P P d18o
A20 VDDMOP VDDMOP P P P d18o
E17 VDDMOP VDDMOP P P P d18o
E12 VDDMOP VDDMOP P P P d18o
E8 VDDMOP VDDMOP P P P d18o
AB16 VDDOP VDDOP P P P d18o
P21 VDDOP1 VDDOP1 P P P d18o
N5 VDDOP2 VDDOP2 P P P d33o
AC1 VDDOP3 VDDOP3 P P P d33o
AC2 VDD_SDRAM VDD_SDRAM P P P
AE25 VDD_SDRAM VDD_SDRAM P P P
AF2 VDD_SDRAM VDD_SDRAM P P P
AF13 VDD_SDRAM VDD_SDRAM P P P
AF24 VDD_SDRAM VDD_SDRAM P P P

SC32442B RISC MICROPROCESSOR PRODUCT OVERVIEW
1-19
Table 1-2. SC32442B 332-Pin FBGA Pin Assignments (Sheet 9 of 10)
Pin
Number Pin Name Default Function I/O State @BUS REQ I/O State @Sleep I/O State @nRESET I/O Type
AF3 VDDQ_SDRAM VDDQ_SDRAM
P P P
AF7 VDDQ_SDRAM VDDQ_SDRAM
P P P
AF10 VDDQ_SDRAM VDDQ_SDRAM
P P P
AF15 VDDQ_SDRAM VDDQ_SDRAM
P P P
AF19 VDDQ_SDRAM VDDQ_SDRAM
P P P
AF23 VDDQ_SDRAM VDDQ_SDRAM
P P P
AC26 VCC_NF VCC_NF P P P
P1 VCC_NF VCC_NF P P P
W26 VCC_NF VCC_NF P P P
AF20 VSSA_ADC VSSA_ADC P P P Sth
AB26 VSSA_MPLL VSSA_MPLL P P P st
P22 VSSA_UPLL VSSA_UPLL P P P st
J2 VSSCOM VSSCOM
P P P si
M5 VSSCOM VSSCOM
P P P si
R1 VSSCOM VSSCOM
P P P si
W2 VSSCOM VSSCOM
P P P si
AB2 VSSCOM VSSCOM
P P P si
M14 VSSCOM VSSCOM
P P P si
K22 VSSCOM VSSCOM
P P P si
H25 VSSCOM VSSCOM
P P P si
M13 VSSCOM VSSCOM
P P P si
N12 VSSCOM VSSCOM
P P P si
N13 VSSCOM VSSCOM
P P P si
N14 VSSCOM VSSCOM
P P P si
N15 VSSCOM VSSCOM
P P P si
P12 VSSCOM VSSCOM
P P P si
P13 VSSCOM VSSCOM
P P P si
P14 VSSCOM VSSCOM
P P P si
P15 VSSCOM VSSCOM
P P P si
R13 VSSCOM VSSCOM
P P P si
R14 VSSCOM VSSCOM
P P P si
E14 VSSCOM VSSCOM
P P P si
B8 VSSCOM VSSCOM
P P P si
