SATO CX400 User manual

PN: 9001124A
CX400
DESKTOP PRINTER
PARTS LIST

Warning: This equipment complies with the requirements in Part 15 of FCC rules for a Class A
computing device. Operation of this equipment in a residential area may cause unacceptable
interference to radio and television reception requiring the operator to take whatever steps nec-
essary to correct the interference.
All rights reserved. This document, nor any part of it, may be reproduced or issued to third parties
in any form without the express permission of SATO America, Inc. The material in this document
is provided for general information only and is subject to change without notice. SATO America,
Inc. does not assume responsibility for any errors or omissions.
06 Nov 03
SATO GROUP OF COMPANIES
BARCODE SATO
INTERNATIONAL PTE LTD
438A Alexandra Road #05-01/ 02,
Alexandra Technopark,
Singapore 119967
Tel: [phone]
Fax: [phone]
Website: www.barcodesato.com
Email: [email protected]
SATO AMERICA INC.
10350 Nations Ford Road Suite A,
Charlotte, NC 28273
Tel: [phone]
Fax: [phone]
Website: www.satoamerica.com
Email: [email protected]
SATO UK LTD
Valley Road, Harwich, Essex England
Co12 4RR, United Kingdom
Tel: [phone]
Fax: [phone]
Website: www.satouk.com
Email: [e-mail]
SATO EUROPE NV
Leuvensesteenweg 369, 1932 Sint- Stevens-Woluwe, Brussels, Belgium
Tel: [phone]
Fax: [phone]
Website: www.sato-europe.com
Email: [email protected]
SATO DEUTSCHLAND GMBH
Schaberweg 28, 61348
Bad Homburg, Germany
Tel: [phone]
Fax: [phone]
Website: www.sato-europe.com
Email: [email protected]
SATO POLSKA SP Z O.O.
Ul Okolna 2, 50-422 Wroclaw
Tel: [phone]
Fax: [phone]
Website: www.sato-europe.com
Email: [email protected]
SATO SHANGHAI CO, LTD
11 Floor, D, Pudong South Road 1111,
Pudong New Area, Shanghai,
China 200120
Tel: [phone]
Fax: [phone]
Website: www.barcodesato.com
Email: [email protected]
BAR CODE SATO ELECTRONICS (S) PTE LTD
438A Alexandra Road #05-01/02,
Alexandra Technopark, Singapore 119967
Tel: [phone]
Fax: [phone]
Website: www.barcodesato.com
www.satosingapore.com
Email: [e-mail]
SATO BAR CODE & LABELLING
SDN BHD
Suite B-08-11&12, Block B Plaza Mont' Kiara, No.2, Jalan Kiara Mont'
Kiara,
50480 Kuala Lumpur, Malaysia
Tel: [phone]
Fax: [phone]
Website: www.barcodesato.com
Email: [email protected]
BARCODE SATO (THAILAND) CO., LTD
370/8 Supattra Building, 5th Floor, Rama9 Road, Bangkapi, Huay Kwang
Bangkok 10320, Thailand
Tel: [phone]
Fax: [phone]
Website: www.barcodesato.com
Email: [e-mail]

SATO CX400 Parts List PN 9001124A Page 1
Printer Assembly, PL1
0
C54
15 C
14
13
C
12
11
D
43
7
47
49
48
Y
50
97
53
Y
42
44
34
2
G
Y
Z
910
8
D
7
6
1
G
G
G
42
50
G

Page 2 PN 9001124A SATO CX400 Parts List
Chassis Assembly, PL2
Base and Options Assemblies, PL3
M
68
69
70
67
B
62
61
32
28
79
B
H
36
38
B
37 K
35
34
J33
98
29
E
63
62 64
65
F
B66
55
56
57
58
50
59 42
X
21
31
30
F
B
22
G
27 26
24
25
L
23
B
20
19
16
G
17
18
X
46
45
51
X
46 60
59
59
59
58
60
50 42
26
X
X
B
X
X
31
77
B
83 Optional 40
41
I
E
39
75 Optional 80
B

SATO CX400 Parts List PN 9001124A Page 3
Housing Assembly, PL4
A
H
A
F
H
B
90
88
88
89
87
86
85
95
96
94
93
91
A
65
65
88
84

Page 4 PN 9001124A SATO CX400 Parts List
Item Part Number Part Description Qty
1 14SC00150 THUMBWHEEL 1
2 14SC00151 CLAMP, L2 2
3 14SC00152 WASHER 2
4 14SC00153 CLAMP SPRING 2
6 14SC00155 PRINT ASSEMBLY BRACKET 1
7 14SC00156 PRINT ASSEMBLY BUTTON 2
8 14SC00157 SHAFT, RIB2 2
9 14SC00158 WASHER, RIB 2
10 14SC00159 BUSH, RIB2 2
11 14SC00160 CHASSIS LOCK, LEFT 1
12 14SC00161 PRINT HEAD COVER 1
13 14SC00162 PRINT HEAD BRACKET 1
14 YCX405706 RIBBON SENSOR 1
15 YCX405701 THERMAL PRINT HEAD 1
16 14SC00163 CHASSIS SHAFT 1
17 14SC00164 ARM SPRING 1
18 14SC00165 RIB, ARM 1
19 14SC00166 PAPER GUIDE, LEFT 1
21 14SC00167 FILM GUIDE 1
20 YC3005762 LED 1
22 14SC00168 PAPER GUIDE, RIGHT 1
23 14SC00169 CONNECTOR BRACKET 1
24 14SC00170 SPACER, SUPPORT 2
25 YCX405703 EXTERNAL CONNECTOR BOARD 1
26 14SC00172 ROLLER BUSHING 3
27 YCX405708 PLATEN ROLLER, METAL/RUBBER 1
28 14SC00173 PEELER BAR 1
29 14SC00174 CABLE CLAMP 1
30 YC3005760 CHASSIS 1
31 14SC00175 PEELER SHAFT 2
32 14SC00176 GUIDE, LEFT 1
33 YCX405705 PAPER SENSOR 1
34 14SC00177 GUIDE, TOP BRACKET 1
35 14SC00178 GUIDE RACK, LEFT 1
36 14SC00179 GUIDE RACK, RIGHT 1
37 14SC00180 GEAR, MO. 5x27T 1
38 14SC00181 GUIDE, BOTTOM 1
39 YC3005757 BASE 1
40 14SC00182 RUBBER BOOT 4
42 14SC00184 GEAR, MO. 5x28T 4
43 14SC00185 SHAFT, RIB3 1

SATO CX400 Parts List PN 9001124A Page 5
44 14SC00186 CLAMP, LEFT 1
45 14SC00187 GEAR, ONE WAY, LEFT 1
46 14SC00188 WASHER, DIFF. 2
47 14SC00189 SHAFT, RIB1 1
48 14SC00190 CHASSIS LOCK, RIGHT 1
49 14SC00191 LOCK SPRING, RIGHT 1
50 14SC00192 BUSHING, DIFFERENTIAL 4
51 14SC00193 GEAR, MO. 5x54T 1
52 14SC00194 SPRING, THERMAL PRINT HEAD 1
53 14SC00195 HINGE PIN 2
54 14SC00196 LOCK SPRING, RIGHT 1
55 14SC00197 PIN, TOP DIFFERENTIAL 1
56 14SC00198 PIN, LOWER DIFFERENTIAL 1
57 14SC00199 SPRING, DIFFERENTIAL 1
58 14SC00200 SPRING HOLDER 2
59 YC3005761 UNWOVEN FABRIC 4
60 14SC00201 HOLDER, PUSH 2
61 14SC00202 SPRING, DIFFERENTIAL 1
62 14SC00203 GEAR 2
63 14SC00204 GEAR, ONE WAY, RIGHT 1
64 14SC00205 HOLDER, D 1
65 14SC00206 SPRING, RIB2 3
66 14SC00207 PLATEN SWITCH 1
67 14SC00208 GEAR, MO. 5x42T 1
68 14SC00209 GEAR, MO.5 17x44T 1
69 14SC00210 MOTOR BRACKET 1
70 YCX405707 MOTOR 1
75 YCX405200 DISPENSER ASSEMBLY (OPTIONAL) 1
77 14SC00211 COVER HINGE 1
79 14SC00212 HARNESS COVER 1
80 YCX405702 MAIN CIRCUIT BOARD, CX400 1
83 YCX405100 CUTTER ASSEMBLY (OPTIONAL) 1
84 14SC00213 FACE COVER 1
85 14SC00214 SWITCH, 2-POSITION 1
86 YCX405704 PANEL BOARD, CX400 1
87 14SC00215 FEED BUTTON 1
88 14SC00216 TRACK GEAR, PAPER 2
89 14SC00217 GEAR, MO. 5x20T 1
90 14SC00218 PAPER TRACK COVER 1
91 YC3005756 HOUSING COVER w/ WINDOW 1
93 14SC00219 PAPER HOLDER, LEFT 1
94 14SC00220 PAPER HOLDER, RIGHT 1
Item Part Number Part Description Qty

Page 6 PN 9001124A SATO CX400 Parts List
95 14SC00221 PAPER HOLDER LOCK 1
96 YC3005759 HOUSING 1
97 14SC00240 PRINT HEAD GUIDE 1
98 14SC00222 ROLLER BUSHING 2 1
A 14SC00223 SCREW, M13x6, PHILLIPS, BLACK 4
B 14SC00224 SCREW, T3x6, PHILLIPS, BLACK 26
C 14SC00225 SCREW, M3x4, PHILLIPS, BLACK 5
D 14SC00226 SCREW, T3x6, PHILLIPS, WASHERED, ZINC 2
E 14SC00227 SCREW, T3x8, PHILLIPS, BLACK 6
F 14SC00228 SCREW, T3x4, PHILLIPS, ZINC 3
G 14SC00229 SCREW, M2.6x6, PHILLIPS, ZINC 8
H 14SC00230 SCREW, T2.6x6, PHILLIPS, NICKEL 9
I 14SC00231 SCREW, T3x10, PHILLIPS, NICKEL 2
J 14SC00232 SCREW, T1.7x4, PHILLIPS, NICKEL 3
K 14SC00233 SCREW, T1.4x2, PHILLIPS 2
L 14SC00234 SCREW, M3x6, PHILLIPS, BLACK 4
M 14SC00235 SCREW, M3x4, PHILLIPS, NICKEL 2
N 14SC00236 SCREW, M2x2, PHILLIPS, NICKEL 2
O 14SC00241 SCREW, M2x3, PHILLIPS, BLACK 3
X 14SC00237 SNAP RING 7
Y 14SC00238 SNAP RING 7
Z 14SC00239 SNAP RING 2
Item Part Number Part Description Qty
