M10 e Series Printers
www.satoamerica.com
Wide-Web Industrial Printers
The M10 e’s are designed to handle media widths of 11.8" and print widths of 10.5"
in direct thermal or thermal transfer modes. A sophisticated system of sensors and
media guides assures proper media registration and simplifies paper loading.
Thermal Transfer Wrinkle-Free Operation
M10 e printers utilize a revolutionary anti-wrinkle ribbon mechanism, which assures
trouble-free operation in most thermal transfer operations, increases printer
reliability, performance, ease of use, and greatly reduces down time and user
intervention especially in mission critical applications.
Print Technology Replacement and Connectivity
The M10 e finally brings benefits of thermal printing technology to markets and
applications historically dependent on inferior print technologies such as impact,
ink-jet, and laser. Thermal technology offers an array of benefits making the M10
e
an ideal candidate for applications involving print technology replacement. A large
selection of user configurable Plug-In Interface Modules (incl.10/100 Ethernet, and
wireless 802.11g Wi-Fi) simplifies connectivity.
THE WIDE-WEB THERMAL SOLUTIONS
The M10 e wide web thermal
industrial printers are ideal for a
range of applications, including:
Chemical Labeling
Automotive Labeling
Paper/Pulp Labeling
ODETTE Labeling
Shipping & Receiving
Multiple-Up Labels
Performs best with
M•E•D•I•A

Printing Method
Print Resolution
Print Speed
Media Width
Max. Print Width
Max. Print Length
Media Length
Max. Ribbon Size
Dimensions
Weight
SATO America, Inc.
10350-A Nations Ford Road, Charlotte, NC 28273
Phone: [phone] Fax: [phone]
E-mail: [email protected]
www.satoamerica.com
Unwinder Plug-In Interface
Modules
© 2007 SATO America, Inc. All rights reserved. Specifications subject to change without notice. Rev. 10/07
SPECIFICATIONS
Stacker
Software
M10 e
Thermal Transfer/Direct Thermal or Direct Thermal Only
305 dpi (12 dots/mm)
5 ips (127 mm/s)
5.16" (131 mm) - 11.8" (300 mm)
10.5" (266 mm)
16.5" (420 mm)
1.7" (43 mm) - 16.6" (422 mm)
10.7" (273 mm) W x 984' (300 m) L - Face-In
Max. 11" (279 mm) ribbon core
18.7" W x 12.3" D x 12.6" H
(475 mm W x 313 mm D x 319 mm H)
50.7 lbs (23 kg)
T HE S TANDARD F OR
R ELIABLE B ARCODE P RINTING
Memory:
16 MB Standard RAM
6 MB Flash (4 MB available to download
forms and fonts)
1 MB or 256k PCMCIA - Optional
Processor:
32-BIT RISC
Media:
Fan-fold (standard) or roll-fed (with optional
unwinder), die-cut or continuous direct
thermal (thermal transfer) labels, synthetics,
and tag stock with or without black mark, gap,
or notch.
Max. Thickness 0.008" (0.20 mm)
Max. Roll Diameter: 8.6" (220 mm)
with optional unwinder
Wind: Face-In
Sensing:
Adjustable transmissive sensor for gap.
Reflective sensor for black mark. Automatic,
programmable setting of top of form. Label
present sensor - optional with label dispenser.
Ribbon-out / low Sensor, Head Up, Paper
Out, Cutter Open Automatic media loading
and top of form synchronization
Plug-In Interface Modules:
• Serial - RS232 (up to 57.6k bps)
• Parallel - IEEE1284 (ECP)
• Ethernet - 10/100BaseT
• Wireless 802.11g
• Twinax/Coax Adapter
• RS422/485
• USB Adapter
Barcode Symbologies:
EElleemmeennttaarryy::
UPC-A, UPC-E, EAN-8, EAN-
13, Code 39, Code 93, Code 128,
Codabar, MSI, Bookland, Industrial 2/5,
Interleaved 2/5, Matrix 2/5, Postnet,
UCC/EAN 128, RSS, Composite
22--DDiimmeennssiioonnaall::
PDF417, Micro PDF417,
Truncated PDF417, Maxicode, Data Matrix,
QR Code
Fonts:
Bitmap - 12 proportional, mono-spaced and
outline fonts (Code table 858). Scalable
Internal CG Triumvirate®& CG Times®fonts.
Optional Downloaded TrueType®fonts,
scalable from 8 to 72 points.
Barcode & Font Formatting:
360° rotation of barcodes and text,
character expansion horizontally and
vertically, sequential numbering, form
overlay for high-speed editing of complex
formats.
Graphic Support:
Printing & storage of .PCX, .BMP format,
SATO Hex/binary
Page Mode, Line Print Mode, and Reverse
Software:
Windows®Drivers (Windows®95, 98, ME,
NT4.0, 2000, XP)
“Label Gallery Free” - Label Software
Printer Utilities
Electrical Requirements:
115V/220V (± 10%), 50/60 Hz (± 1%)
Agency Certifications: CE, UL, CSA, TÜV
Environmental Requirements:
Operating: 41° to 104°F (5° to 40°C)
15-85% RH, non-condensing
Storage: 23° to 140°F (-5° to 60°C)
Max. 90% RH, non-condensing
EDS: 8kV
Optional Features:
Memory Expansion, Label Cutter, Real Time
Clock, Media Unwind, Media Stacker,
Interface Plug-In Modules, Label Gallery
Software
