SATO CG208 DT/TT User manual

CG Series
www.satoamerica.com
• 203 or 305 dpi Print Resolution
• 4MB Flash Memory
• Thermal Transfer and
Direct Thermal
• Anti-Microbial Casing (CG2 only)
• Multiple Codepage Support
• Competitive Emulation Options
• Easy Maintenance
Streamlined Features
• Healthcare
• Retail
• Transportation & Logistics
• Manufacturing
• Ofce Administration
• Education & Libraries
• Hospitality
• Travel & Leisure
Industry Verticals
• Specimen Labeling
• Wristband Printing
• Shelf Labeling
• Product Labeling
• Ofce Mailings
• File Folder Labeling
• Layaway Marking
• Price Markdowns
Performance, Convenience & Versatility
Anti-Microbial Casing
(CG2 only)
Top Cover Safety Latch EASY Print Head
Replacement
Drop - Load - Go
Media Bin

General Specications
CG Series
SATO America, Inc.
10350-A Nations Ford Road, Charlotte, NC 28273
Phone: [phone] Fax: [phone]
E-mail: [email protected]
©2011 SATO America, Inc. All rights Reserved. Rev D • Specications subject
to change without notice • Any unauthorized reproduction of the contents
of this content, in part or whole, is strictly prohibited • SATO is a registered
trademark of SATO Corporation and its subsidiaries in Japan, the U.S. and
other countries. All other trademarks are the property of their respective owners
MODEL CG208 CG212 CG408 CG412
PRINTING SPECIFICATION
Print Method Direct Thermal/Thermal Transfer (TT) or Direct Thermal only (DT)
Print Resolution 203dpi (8 dots/mm) 305dpi (12 dots/mm) 203dpi (8 dots/mm) 305dpi (12 dots/mm)
Print Speed Max. 4 ips (100mm/sec)
Max. Print
Area
Width 2.2" (56 mm) 2.2" (56 mm) 4.1" (104mm)
Length 23.6" (600 mm) 15.75" (400 mm) 11.8" (300 mm)
Memory Flash ROM: 4MB, RAM: 8MB
MEDIA SPECIFICATION
Sensor Type I-Mark Sensor (Reflection type), Label Gap Sensor (Transmissive type)
Media Type Roll and Fanfold (Face-in, Face-out)
Media Size Width 0.47" to 2.36" (12 to 60 mm) 0.87" to 4.21" (22 to 107 mm)
Length Continuous: 0.23" to 23.62"
(6 to 600 mm)
Tear-Off: 0.47" to 23.62"
(12 to 600 mm)
Continuous: 0.23" to 15.75"
(6 to 400 mm)
Tear-Off: 0.47" to 15.75"
(12 to 400 mm)
Continuous: 0.27" to 11.8" (7 to 300 mm)
Tear-Off: 0.87" to 11.8" (22 to 300mm)
Thickness 0.0024" to 0.0075" (0.06 to 0.19 mm)
Roll Specs Max O.D.: 5.12" (130 mm) - I.D.: 1.57" (40 mm), Fan fold paper: Max height 3.94" (100 mm)
Ribbon (TT only) Width: 2.32" (59 mm), Max outer diameter: 1.50" (38 mm),
Paper core: 0.5" (12.7 mm), Face-Out
Width: 4.33" (110 mm), Max outer diameter: 1.50" (38 mm),
Paper core: 0.5" (12.7 mm), Face-Out
FONT / SYMBOLOGIES
Internal Fonts XU, XS, XM, XB, XL, OCR-A (15x22, 22x33 ), OCR-B (20x24, 30x36), CG Times, CG Triumvirate
Barcode Sym-
bologies
Linear UPC-A/UPC-E, JAN/EAN, CODE39, CODE93, CODE128, GS1-128(UCC/EAN128), CODABAR(NW-7), ITF,
Industrial 2of5, Matrix 2of5, BOOKLAND, MSI, POSTNET, GS1 DataBar(RSS) barcode
2-D QR code, MicroQR, PDF417, MicroPDF, MAXI code, GS1 DataMatrix (ECC200)
Composite
Symbols
EAN-13 Composite, EAN-8 Composite, UPC-A Composite, UPC-E Composite, GS1 DataBar Composite,
GS1 DataBar Truncated Composite, GS1 DataBar Stacked Composite, GS1 DataBar Stacked Omni-Directional
Composite, GS1 DataBar Limited Composite, GS1 DataBar Expanded Composite,
GS1 DataBar Expanded Stacked Composite, GS1-128 Composite
INTERFACE CHARACTERISTICS
Interface Options USB + RS232C model, USB + LAN model
Optional: External Wireless LAN Optional: IEEE1284 + USB
Command SBPL (Ver 4.2) SATO Barcode Printer Language
OPERATING CHARACTERISTICS
Power Requirements AC Adaptor Input voltage: AC100V-240V±10%, Frequency:
50/60Hz, Output voltage: DC19V±5%, 3A
AC Adaptor Input voltage: AC100V-240V±10%, Frequency:
50/60Hz, Output voltage: DC19V±5%, 3.68A
Environment Operating 0 ~ 35ºC / 30 ~ 80% RH (without condensing)
Storage -10 ~ 60ºC / 15 ~ 85% RH (without condensing)
Regulatory Approvals FCC15B Class B, CE (EN55022, EN55024), GB9254-1998, GB17625.1(2003, CISPR22, CISPR24, KN22, KN24,
RoHs compliant, Electrical Power Saving (International Energy Star Program, at usage of AC Adaptor)
Dimensions 5.04" (128 mm) W x 9.25" (235 mm) D x 6.81" (173 mm) H 7.04" (179 mm) W x 9.37" (238 mm) D x 6.81" (173 mm) H
Weight TT: 3.5 Ibs (1.6kg), DT: 3.3 Ibs (1.5kg) TT: 4.2 Ibs (1.9kg), DT: 3.75 Ibs (1.7kg)
OTHER
Optional Accessories Cutter, Dispenser, SATO Label Gallery™
RFID HF Kit, Wireless LAN (802.11 b/g auto switching) Real Time Clock, Linerless Kit
Other Features Anti-Microbial Finishing - Resin of the enclosure/control
panel include an antibacterial substance.
