SATO “Fl A g TA g SO l u T i O n S T m ”
The UHF Label for all Product Requirements
Tw O SATO “Fl A g TA g SO l u T i O n S ™” A v A i l A b l e
The “FlagTagSolution™” allows customers to benefit from industry-leading RFID read and write performance by
using low cost labels embedded with UPM Rafsec inlays, to encode, verify, and print the UPM Rafsec “FlagTag™”
in SATO RFID printers.
SATO UNIQUE Solution:
One Tag for All
The “FlagTagSolution™” can be used on
pallets, cases, metal drums, liquids, or aluminum
cans without compromising read performance.
SATO and UPM Rafsec developed a unique
(patent pending) UHF label, “FlagTag™” with
the ability to perform in virtually any UHF RFID
application.
Different Types of Tags
Every company that will use UHF technology,
needs to look for a tag that takes into account
the different requirements and limitations of
the goods and packaging.
Different Content &
Packaging Materials
Radio waves can be subject to interference.
Metal, liquid products, consistency of goods
or the packaging material may influence the
performance of an UHF Tag. Sometimes this
can lead to a shorter read distance or to the
changing of frequency, so no reading of the
tag is possible.
2 perforations
For manual “slap & ship” applications using the SATO CL408eUHF
Printer, a “FlagTag™” label with two perforations allows for easy
folding, creating the “flag” to be applied onto pallets and cases.
3 perforations
SATO’s print & apply “FlagTag™” solution is designed for use
with the M8485Se-RFID print engine and SATO’s patent pending
“FlagTag™” application head. This fully automatic solution uses the
“FlagTag™” with three perforations, which allows automatic folding
of the “FlagTag™” in the print & apply or slap & ship process. Print
and apply systems utilizing SATO’s unique “FlagTag™” label and
application head are available from authorized SATO OEM print
engine integrators.
www.satoamerica.com www.satoworldwide.com
TC
1003
6719
765
1003
2246
32795 - 3
TC 1003
3- 1
46
97
On e TA g F O r Al l Ap p l i c A T i O n S

SATO “Fl A g TA g ™” Ap p l i c A T O r He A d
Dual Applicator
Single Applicator
Pallet-Labeling with SATO Printer and “FlagTag™”
The “FlagTagSolution™” is designed to be used with the SATO CL4eand GL4eSeries on-demand, RFID-enabled printer, as well as SATO’s
RFID S-Type print engine for automated print and apply solutions.
Automatic Print & Apply
Solutions Examples
rFid Oem en g i n e S CLeRFID pr i n T e r S GL4eRFID pr i n T e r S
Print Method Direct Thermal / Thermal Transfer Direct Thermal / Thermal Transfer Direct Thermal / Thermal Transfer
Resolution 203 dpi 203 dpi / 305 dpi 203 dpi / 305 dpi
Standard Memory Std: 16 MB RAM / 2 MB Flash
Opt: 1 MB PCMCIA / 6 MB Flash
Std: 16 MB RAM / 2 MB Flash
Opt: 1 MB PCMCIA / 6 MB Flash
Std: 32 MB DRAM / 8 MB Flash
Opt: 32 MB Flash
Max. Print Width 5" (128 mm) 4.1" (104 mm) 4.09" (104 mm)
Max. Print Length 49.2" (1249 mm) 49.2" (1249 mm) / 32.8" (833 mm) 98.98" (2514 mm)
Min. Media Width 1" (25 mm) w/o RFID inlay; Varies with
RFID inlay 0.87" (22 mm) 0.87" (22 mm)
Max. Media Width 5.27" (134 mm) 5.1" (131 mm) 5.04" (128 mm)
Max Print Speed 12"/sec (300 mm/sec) 6"/sec (150 mm/sec) 10"/sec (254 mm/sec)
Interface
RS232C, IEEE1284 (ECP), Wireless
Ethernet (802.11g), LAN (10/100BaseT),
Twinax/Coax, RS422/485, USB Adapter
RS232C, IEEE1284 (ECP), Wireless
Ethernet (802.11g), LAN (10/100BaseT),
Twinax/Coax, RS422/485, USB Adapter
Std: IEEE1284 (ECP), RS232C, USB (2.0)
Opt: Wireless Ethernet (802.11g), LAN
(10/100BaseT)
Protocols UHF UHF & HF (multi protocol) UHF
SATO’s patent pending “FlagTag™” applicator tamp pad is specifically designed for
automatic print & apply applications. This patent pending tamp pad assembles and
applies a RFID “FlagTag™” after it is encoded, verified & printed on a SATO RFID
S-Type print engine. The “FlagTagSolution™” integrated in RFID label applicators
provides free air-like RF performance for RFID case and pallet labeling.
SATO America, Inc.
10350-A Nations Ford Road, Charlotte, NC 28273
Phone: [phone] Fax: [phone]
E-mail: [email protected]
www.satoamerica.com
© 2007 SATO America, Inc. All rights reserved. Specifications subject to change without notice. Rev. 07/07b
SATO Patent Pending “FlagTag™” Applicator Head
SATO “Fl A g TA g SO l u T i O n S ™” AS EA S y AS 1 • 2 • 3
Application of “FlagTag™” labels is easy as 1 • 2 • 3.
Just remove the part of the label with the RFID antenna,
fold over at the perforated line and the label is ready to
apply!
