sauter EQJW146F002 User manual

EQJW146F002
Firmwareversion 2.4x
Heating and District Heating Controller
with graphics display
P100019103
Manual

2 EQJW146F002 EN

EQJW146F002 EN 3
Old > New Firmware revisions
2.3x>2.4x Connected sensor inputs not relevant for closed-loop control are displayed on the 'Spe-
cial values' screen in the controller's operating level (see section3.8)
New functions and parameters for buer tank systems (see section6.5)
− CO1>F22: SLP depending on return ow temperature
− CO5>F25: AA1 reverse
− CO5>F31: AE1 zero shift
− PA1 > P16: Minimum set point to charge buer tank
− PA1 > P17: Stop charging of the buer tank
− PA1 > P18: Charging temperature boost
− PA1 > P19: Lag time of charging pump
New dierential temperature control function (CO1>F23) in systems Anl1.0 and
16.0 (see section6.13)
Restrictions when a mini module (order no. 1400-7436) is used (see section10.3)

Note on these mounting and operating instructions
These mounting and operating instructions assist you in mounting and operating the de-
vice safely. The instructions are binding for handling SAUTER devices.
ÎFor the safe and proper use of these instructions, read them carefully and keep them
for later reference.
Definition of signal words
Hazardous situations which, if not avoided,
will result in death or serious injury
Hazardous situations which, if not avoided,
could result in death or serious injury
Property damage message or malfunction
Additional information
Recommended action
DANGER
!
WARNING
!
NOTICE
!
Note
Tip
4 EQJW146F002 EN

Contents
EQJW146F002 EN 5
1 Safety instructions..............................................................................................................................8
1.1 Disposal..................................................................................................................................................8
2 Operation ..............................................................................................................................................9
2.1 Operating controls.............................................................................................................................9
2.1.1 Rotary pushbutton.............................................................................................................................9
2.1.2 Rotary switch........................................................................................................................................9
2.2 Reading information ...................................................................................................................... 10
2.2.1 Adapting the Trend-Viewer.......................................................................................................... 14
2.3 Selecting operating modes ......................................................................................................... 16
2.4 Setting the time and date ............................................................................................................ 17
2.5 Setting the times-of-use ............................................................................................................... 19
2.6 Setting special times-of-use ........................................................................................................ 21
2.6.1 Party timer.......................................................................................................................................... 21
2.6.2 Public holidays.................................................................................................................................. 22
2.6.3 Vacations ............................................................................................................................................ 24
2.7 Entering day and night set points............................................................................................. 26
3 Start-up ............................................................................................................................................... 28
3.1 Setting the system code number.............................................................................................. 29
3.2 Activating and deactivating functions .................................................................................... 30
3.3 Changing parameters.................................................................................................................... 32
3.4 Calibrating sensors.......................................................................................................................... 33
3.5 Altering the display contrast....................................................................................................... 35
3.6 Changing the display language................................................................................................. 35
3.7 Loading default setting................................................................................................................. 35
3.8 Special values.................................................................................................................................... 36
4 Manual mode.................................................................................................................................... 37
5 Systems ............................................................................................................................................... 38
6 Functions of the heating circuit ................................................................................................. 77
6.1 Outdoor-temperature-controlled control.............................................................................. 77
6.1.1 Gradient characteristic .................................................................................................................. 78
6.1.2 Four-point characteristic............................................................................................................... 80
6.2 Fixed set point control................................................................................................................... 81

Contents
6 EQJW146F002 EN
6.3 Underoor heating/drying of jointless oors ....................................................................... 82
6.4 Outdoor temperature for rated operation (day).................................................................. 83
6.5 Buer tanks stems Anl 16.x.......................................................................................................... 84
6.6 Summer mode.................................................................................................................................. 85
6.7 Delayed outdoor temperature adaptation ............................................................................ 86
6.8 Remote Control Unit ...................................................................................................................... 87
6.9 Optimization ..................................................................................................................................... 87
6.10 Flash adaptation .............................................................................................................................. 88
6.10.1 Flash adaptation without outdoor sensor (based on room temperature) ................. 89
6.11 Adaptation......................................................................................................................................... 90
6.12 Cooling control................................................................................................................................. 91
6.13 Dierential temperature control................................................................................................ 93
7 Functions of the DHW circuit ...................................................................................................... 94
7.1 DHW heating in the storage tank system............................................................................... 94
7.1.1 DHW circuit additionally controlled by a globe valve........................................................ 96
7.2 DHW heating in the storage tank charging system............................................................ 97
7.2.1 Cold charging protection ............................................................................................................. 99
7.3 DHW heating in instantaneous heating system.................................................................100
7.4 Domestic hot water heating with solar system..................................................................101
7.5 Intermediate heating...................................................................................................................101
7.6 Parallel pump operation .............................................................................................................102
7.7 Circulation pump during storage tank charging..............................................................102
7.8 Priority position..............................................................................................................................102
7.8.1 Reverse control...............................................................................................................................103
7.8.2 Set-back operation........................................................................................................................103
7.9 Forced charging of DHW storage tank...................................................................................104
7.10 Thermal disinfection of DHW storage tank..........................................................................104
8 System-wide functions................................................................................................................106
8.1 Automatic summer/standard time switchover ..................................................................106
8.2 Frost protection..............................................................................................................................106
8.3 Forced pump operation..............................................................................................................107
8.4 Return ow temperature limitation........................................................................................107

Contents
EQJW146F002 EN 7
8.5 Condensate accumulation control..........................................................................................109
8.6 Three-step control.........................................................................................................................109
8.7 On/o control .................................................................................................................................110
8.8 Continuous control in control circuit RK1.............................................................................110
8.9 Releasing a control circuit/controller with binary input .................................................111
8.10 Speed control of the charging pump.....................................................................................111
8.11 External demand processing.....................................................................................................112
8.12 Capacity limitation in RK1 ..........................................................................................................113
8.13 Creep feed rate limitation with a binary input ...................................................................115
8.14 Requesting a demand by issuing a 0 to 10V signal..........................................................115
8.15 Connecting potentiometers for valve position input ......................................................115
8.16 Locking manual level...................................................................................................................116
8.17 Locking the rotary switch...........................................................................................................116
8.18 Feeder pump operation..............................................................................................................116
8.19 External demand for heat due to insucient heat supply.............................................116
8.20 Entering customized key number...........................................................................................117
9 Operational faults..........................................................................................................................118
9.1 Error list.............................................................................................................................................118
9.2 Sensor failure ..................................................................................................................................118
9.3 Temperature monitoring............................................................................................................119
9.4 Error status register.......................................................................................................................119
10 Communication .............................................................................................................................121
10.1 Memory module............................................................................................................................121
11 Installation .......................................................................................................................................124
12 Electrical connection....................................................................................................................126
13 Appendix..........................................................................................................................................132
13.1 Function block lists .......................................................................................................................136
13.2 Parameter lists ................................................................................................................................148
13.3 Resistance values...........................................................................................................................154
13.4 Technical data.................................................................................................................................155
13.5 Customer setting...........................................................................................................................156

8 EQJW146F002 EN
Safety instructions
1 Safety instructions
For your own safety, follow these instructions concerning the mounting, start up and opera-
tion of the controller:
− The device is to be mounted, started up or operated only by trained and experienced
personnel familiar with the product.
− For electrical installation, you are required to observe the relevant electrotechnical regu-
lations of the country of use as well as the regulations of the local power suppliers. Make
sure all electrical connections are installed by trained and experienced personnel! Before
performing any such work on the controller, disconnect it from the power supply.
− The device is designed for use in low voltage installations. For wiring and maintenance,
you are required to observe the relevant regulations concerning device safety and elec-
tromagnetic compatibility.
To avoid damage to any equipment, the following also applies:
− Proper shipping and storage are assumed.
− Before start-up, wait until the controller has reached the ambient temperature.
1.1 Disposal
Waste electrical and electronic equipment may still contain valuable substances. They may
also, however, contain harmful substances which were necessary for them to function. For
this reason, do not dispose of this kind of equipment together with your household waste. Se-
lect a suitable disposal method. Instead, dispose of your waste equipment by handing it over
to a designated collection point for the recycling of waste electrical and electronic equipment.

EQJW146F002 EN 9
Operation
2 Operation
The controller is ready for use with the default temperatures and operating schedules. On
start-up, the current time and date need to be set at the controller (see section2.4).
2.1 Operating controls
The operating controls are located in the front panel of the controller.
2.1.1 Rotary pushbutton
*
Rotary pushbutton
Turn [q]:
Select readings, parameters and function blocks
Press [Û]:
Conrm adjusted selection or settings
2.1.2 Rotary switch
The rotary switch is used to set the operating mode and the relevant parameters for each
control circuit.
Operating level
Operating modes
Manual level
Day set point (rated room temperature)
Night set point (reduced room temperature)
Times-of-use for heating/DHW
Special time-of-use
Time/date
Settings

10 EQJW146F002 EN
Operation
2.2 Reading information
The display indicates the date, time and actual temperature when the rotary switch is posi-
tioned at (operating level).
Outdoor-temperature-compensated control · Current temperature = Outdoor temperature
Deactivation depending on
outdoor temperature active
A vacation period is active
Fixed set point control · Current temperature = Flow temperature

EQJW146F002 EN 11
Operation
Further information can be obtained by turning the rotary pushbutton:
qOperating state
The following applies for heating circuits HC1 and HC2:
Heating
circuit
Current
operating
mode Valve
opens
closes
Current positioning
value
Circulation pump
(heating) ON/OFF
The following applies for DHW heating:
Current
operating
mode
Pump ON/OFF
Storage tank charging pump
Circulation pump (DHW)
Solar circuit pump
For further details, see section2.3.
qSelected system code number
For further details, see section3.1.
¼Important measured values of the entire system, e.g. out-
door temperature, ow temperature and return ow tem-
perature, are displayed.

12 EQJW146F002 EN
Operation
qTimes-of-use (depending on system code number)
– Heating circuit HC1
– Heating circuit HC2
– DHW heating
The day mode times is highlighted in black on the time
chart.
Night mode and deactivation times are highlighted in
gray on the time chart.
For further details, see section2.5.
qSpecial values
Measured values from additional sensor inputs (not rele-
vant for closed-loop control) or from the 0 to 10V input
are displayed.
qAlarm list
The last four alarm entries are listed.
¼Open the alarm list and select further alarm entries (q).
Further information on an alarm (including time and
date when it occurred) runs across the display.

EQJW146F002 EN 13
Operation
qEvent list
The last four event entries are listed.
¼Open the event list and select further event entries (q).
Further information on an event (including time and date
when it occurred) runs across the display.
qTrend-Viewer
The standard graph shows the data measured at the out-
door sensor AF1 and ow sensor VF1 plotted over time.
For further details, see section2.2.1.
Details on the controller version (device identication, serial number, software and hardware
versions) are displayed in the extended operating level.
Turn the rotary switch to (settings).
qEnter code number 1999.
¼Conrm key number.
Turn the rotary switch to (operating level).
qSelect 'Information'.
Note

14 EQJW146F002 EN
Operation
The additional "meter" page is displayed with
connection status and further meter data for meters 1 to
3 in the "extended operating level" mode when the
meter bus is activated (see section10.2.1). In addition,
the respective measuring and limit values are displayed
after conrming the plant scheme when the ow rate
and/or capacity limitation is active.
− The additional information is hidden when the key number
1999 is entered again.
− The key number 1999 cannot be used to change the con-
troller conguration and parameterization. A separate key
number exists for conguration and parameterization (see
section3).
2.2.1 Adapting the Trend-Viewer
The standard graph shows the data measured at the outdoor sensor AF1 and ow sensor
VF1 plotted over time.
¼Open the Trend-Viewer.
Adding measuring data
qSelect – – – – on the display.
¼Activate editing mode for sensor selection.
qSelect sensor.
Note

EQJW146F002 EN 15
Operation
¼Conrm selected sensor.
Deleting measured data:
qSelect the sensor whose measured data are no longer to
be displayed.
¼Activate editing mode for sensor.
qSelect – – – – on the display.
¼Conrm deletion.
Shifting the time line:
qSelect 'Scroll'.
¼Activate editing mode for scroll function.
qShift the time line.
¼Conrm time display.

16 EQJW146F002 EN
Operation
Zooming in/out
qSelect 'Zoom'.
¼Open zoom function.
qZoom in or out.
¼Conrm display.
Closing the Trend-Viewer
qSelect 'Back'.
¼Close the Trend-Viewer
2.3 Selecting operating modes
Day mode (rated operation): regardless of the programmed times-of-use and summer mode,
the set points relevant for rated operation are used by the controller. Icon:
Night mode (reduced operation): regardless of the programmed times-of-use, the set points
relevant for reduced operation are used by the controller. Icon:
Control operation deactivated: regardless of the programmed times-of-use, control opera-
tion of the heating circuits and DHW heating remains deactivated. The frost protection is ac-
tivated, if need be. Icon:
Icons when the frost protection is activated: HC , DHW
Automatic mode: during the programmed times-of-use, the controller works in day mode.
Outside these times-of-use, the controller is in night mode, unless control operation is deacti-
vated depending on the outdoor temperature. The controller switches automatically between
both operating modes. Icon within the times-of-use: , icon outside the times-of-use:
Manual mode: valves and pumps can be controlled manually. For further details, see sec-
tion4.

EQJW146F002 EN 17
Operation
Turn the rotary switch to (operating modes). The oper-
ating states of all system control circuits are displayed:
− Heating circuit HC1
− Heating circuit HC2
− DHW heating
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
qSelect the control circuit.
¼Activate editing mode for the control circuit. The operat-
ing mode is shown inverted on the display.
qSelect the operating mode:
Automatic mode
Day mode
Night mode
System deactivated
¼Conrm the operating mode.
2.4 Setting the time and date
The current time and date need to be set immediately after start-up and after a power failure
lasting more than 24 hours. This is the case when the time blinks on the display.

18 EQJW146F002 EN
Operation
Turn the rotary switch to (time/date). The current time is
selected (gray background).
¼Activate editing mode for the time. The time reading is
inverted.
qChange the time.
¼Conrm the time setting.
qSelect 'Date' (dd.mm) [q].
¼Activate editing mode for the date. The date reading is
inverted.
qChange date (day.month).
¼Conrm the date setting.
qSelect 'Year'.

EQJW146F002 EN 19
Operation
¼Activate editing mode for the year. The year reading is
inverted.
qChange the year.
¼Conrm the year setting.
Deactivate or activate the automatic summer/standard time
switchover as required. See section8.1:
qSelect 'Auto summertime'.
¼Activate the editing mode for automatic summer/stan-
dard time switchover. The current setting is shown invert-
ed on the display:
ON = Summer/standard time switchover active
OFF = Summer/standard time switchover not active
qDeactivate or activate the automatic summer/standard
time switchover.
¼Conrm deactivation/activation.
Turn the rotary switch back to (operating level).
The correct time is guaranteed after a power failure of 24 hours. Normally, the correct time
is still retained at least 48 hours after a power failure.
2.5 Setting the times-of-use
Three times-of-use can be set for each day of the week.
Parameters WE Value range
HC1, HC2 DHW, CP
Start rst time-of-use 06:00 00:00 00:00 to 24:00 h; in steps of 15 minutes
Stop rst time-of-use 22:00 24:00 00:00 to 24:00 h; in steps of 15 minutes
Start second time-of-use --:-- --:-- 00:00 to 24:00 h; in steps of 15 minutes
Stop second time-of-use --:-- --:-- 00:00 to 24:00 h; in steps of 15 minutes
Note

20 EQJW146F002 EN
Operation
Start third time-of-use --:-- --:-- 00:00 to 24:00 h; in steps of 15 minutes
Stop third time-of-use --:-- --:-- 00:00 to 24:00 h; in steps of 15 minutes
Turn the rotary switch to (times-of-use). The rst control
circuit is displayed together with its programmed times-of-
use.
qProgram the times-of-use of another control circuit, if re-
quired:
– Heating circuit HC2
– DHW heating
– Circulation pump (DHW) CP
ÎOnly those control circuits are available for selection
which can be controlled by the selected system.
¼Activate editing mode for the control circuit. The times-
of-use for Monday are displayed.
qSelect period/day for which the times-of-use are to be
valid. The times-of-use can be programmed for individu-
al days or for a block of days, e.g. Monday to Friday,
Saturday and Sunday or Monday to Sunday. The select-
ed days are shown inverted on the display.
¼Activate editing mode for the period/day.
The start time of the rst time-of-use period can now be
edited (inverted reading).
qChange start time.(in steps of 15 minutes)
¼Conrm the start time.The stop time of the rst time-of-
use period can now be edited.
qEnd stop time.(in steps of 15 minutes)
